- Page 1 SUPER FINISH 23 PRO AIRLESS HIGH-PRESSURE SPRAYING UNIT ORIGINALBETRIEBSANLEITUNG - D - Betriebsanleitung - GB - Operating manual - F - Mode d'emploi - E - Manual de instrucciones wagner-group.com...
- Page 2 1. Faulty units may not be used. 2. Secure a Wagner spray gun with the securing lever at the trigger guard. 3. Ensure earthing. 4. Check the permissible operating pressure of the high-pressure hose and spray gun.
-
Page 3: Table Of Contents
Super Finish 23 Pro CONTENTS Contents SAFETY REGULATIONS FOR AIRLESS SPRAYING 37 Ventilate unit (hydraulic system) if the sound of inlet valve is not audible ______________________ 44 Flash point _________________________________ 37 Taking the unit into operation with Explosion protection _________________________ 37 coating material ____________________________ 44 Danger of explosion and fire from sources of ignition during spraying work _________________ 37... -
Page 4: Safety Regulations For Airless Spraying
Super Finish 23 Pro SAFETY REGULATIONS SAFETY REGULATIONS FOR DANGER OF INJURY FROM THE SPRAY JET AIRLESS SPRAYING Attention, danger of injury by injection! Never point the spray gun at yourself, other persons or animals. All local safety regulations in force must be observed. Never use the spray gun without spray jet The following sources are just a sample of those containing safety guard. -
Page 5: Max. Operating Pressure
Lay the high-pressure hose in such a way as to ensure that (bunghole). An explosive gas/air mixture can it cannot be tripped over. arise. The container must be earthed. Only use WAGNER original-high-pressure hoses in order to ensure functionality, safety and durability. 1.17 CLEANING THE UNIT... -
Page 6: Setup On An Uneven Surface
Super Finish 23 Pro SAFETY REGULATIONS/ GENERAL VIEW OF APPLICATION 1.20 SETUP ON AN UNEVEN SURFACE GENERAL VIEW OF APPLICATION The front end must always point downwards in order to avoid APPLICATION sliding away. If possible do not use the unit on an inclined surface since the SF 23 Pro is an electric driven unit for the airless atomization of unit tends to wander through the resulting vibrations. -
Page 7: Filtering
Super Finish 23 Pro GENERAL VIEW OF APPLICATION 2.2.2 FILTERING FUNCTIONING OF THE UNIT Sufficient filtering is required for fault-free operation. To this The following section contains a brief description of the tech- purpose the unit is equipped with a suction filter (Item 1) and nical construction for better understanding of the function: an insertion filter in the spray gun (Item 2). -
Page 8: Explanatory Diagram
Super Finish 23 Pro DESCRIPTION OF UNIT EXPLANATORY DIAGRAM Tip guard with airless tip* Spray gun* High-pressure hose* Connection for high-pressure hose Pressure gauge* Pressure control valve ON / OFF switch Pressure relief valve Spraying Circulation Return hose* 10 Suction hose* 11 Hopper* 12 Outlet valve 13 Oil dipstick... -
Page 9: Adjusting The Handle
Super Finish 23 Pro DESCRIPTION OF UNIT ADJUSTING THE HANDLE TECHNICAL DATA Swing the handle (1) upwards (the sleeves fall downwards and Voltage : 230 -240 V AC, 50 Hz secure the handle in the terminal position). Fuses : 16 A time-lag Unit connecting line : 6 m long, 3 x 1.5 mm²... -
Page 10: Startup
Super Finish 23 Pro STARTUP STARTUP HIGH PRESSURE HOSE AND SPRAY GUN 1. Screw the high pressure hose (9) onto the hose connec- Press the inlet valve inside the coating mate- tion rial inlet (4) downwards before starting the 2. Screw the spray gun (10) onto the high pressure hose operation. -
Page 11: Cleaning Preserving Agent When Starting-Up Of Operation Initially
Super Finish 23 Pro STARTUP CLEANING PRESERVING AGENT WHEN STARTING-UP OF OPERATION INITIALLY Unit with suction tube 1. Immerse the suction system into a container filled with a suitable cleaning agent (recommendation: water). Unit with hopper 2. Fill up hopper with a suitable cleaning agent (recommen- dation: water). -
Page 12: Spraying Technology
Use the lowest possible pressure setting to create the desired spray pattern in order to minimise spray mist. • To achieve perfect surfaces at varnishing works, special accessories are available at Wagner, e.g. FineFinish tips. Your Wagner dealer will advise you. 30 cm 30 cm... -
Page 13: Handling The High-Pressure Hose
Never pull on the high-pressure hose to move the device. Make sure that the high-pressure hose cannot twist. This can In using quick-drying or two-component be avoided by using a Wagner spray gun with a swivel joint coating materials, do not fail to rinse unit and a hose system. -
Page 14: Cleaning The Unit
Super Finish 23 Pro DISPLAYS AT THE UNIT / CLEANING THE UNIT CLEANING THE UNIT A clean state is the best method of ensuring operation with- • Unit with upper hopper out problems. After you have finished spraying, clean the unit. 1. -
Page 15: Cleaning The Unit From The Outside
Super Finish 23 Pro CLEANING THE UNIT CLEANING THE UNIT FROM THE OUTSIDE HIGH-PRESSURE FILTER 1. Set pressure relief valve to (pressure relief, circulation). First unplug the power plug from the outlet. 2. Switch the unit off using the ON/OFF switch (Pos. 0). 3. -
Page 16: Cleaning The Airless Spray Gun
3. Pull the old filter (3) out of the gun head. Clean or replace. high-pressure hose. 4. Slide the new filter, tapered end first, into the gun head. Wagner recommends replacing high-pres- 5. Thread the handle assembly into the gun head. Tighten sure hoses after 6 years. -
Page 17: Repairs At The Unit
Super Finish 23 Pro REPAIRS AT THE UNIT REPAIRS AT THE UNIT Switch the unit off. Before all repair work: Unplug the power plug from the outlet. 10.1 INLET VALVE Disassembly 1. Place the enclosed 30 mm wrench on the housing (1). 2. -
Page 18: Outlet Valve
Super Finish 23 Pro REPAIRS AT THE UNIT 10.2 10.3 OUTLET VALVE PRESSURE CONTROL VALVE 1. Use a 22 mm wrench to screw the outlet valve from the Only have the pressure control valve (1) re- paint section. placed by the customer service. 2. -
Page 19: Replacing The Power Cable
Super Finish 23 Pro REPAIRS AT THE UNIT 10.4 REPLACING THE POWER CABLE This may only be carried out by a skilled elec- trician. No liability is assumed for incorrect installation. Switch the unit off. Before all repair work: Unplug the power plug from the outlet. -
Page 20: Connection Diagram
Super Finish 23 Pro REPAIRS AT THE UNIT 10.7 CONNECTION DIAGRAM... -
Page 21: Remedy In Case Of Faults
Super Finish 23 Pro REPAIRS AT THE UNIT 10.7 REMEDY IN CASE OF FAULTS TYPE OF MALFUNCTION WHAT ELSE? POSSIBLE CAUSE MEASURES FOR ELIMINATING THE MALFUNCTION Unit does not start The device does No voltage applied Check voltage supply not start after it has Unit fuse has triggered Let the motor cool down been plugged in and... -
Page 22: Spare Parts And Accessories
Super Finish 23 Pro SPARE PARTS AND ACCESSORIES SPARE PARTS AND ACCESSORIES 11.1 SUPER FINISH 23 PRO ACCESSORIES Accessories: ITEM DESIGNATION ORDER NO. ITEM DESIGNATION ORDER NO. Spray gun Vector Pro (2-finger) 0538 041 Tip extension Spray gun Vector Pro (4-finger) 0538 040 Length 15 cm 0556 051... - Page 23 Some paints may need to be diluted to achieve the best result possible. The experts at Wagner application technology have therefore tested a wide range of materials for you. Their recommendations can be found in the Wagner Spray Guide at sprayguide.
- Page 24 Super Finish 23 Pro SPARE PARTS AND ACCESSORIES Airless tip table Wagner without tip without tip TradeTip 3 tip G thread (7/8 - 14 UN) F thread (11/16 - 16 UN) Order no. 0289390 Order no. 0289391 up to 270 bar (27 MPa) All of the tips in the table below are supplied together with the appropriate gun fi lter.
- Page 25 Super Finish 23 Pro SPARE PARTS AND ACCESSORIES All of the tips in the table below are supplied together with the appropriate gun fi lter. Application Tip marking Spray Bore Spraying Gun fi lter Order no. angle inch / mm width mm 1) Roof coatings 20°...
- Page 26 Super Finish 23 Pro 2SpeedTip The innovative changeover nozzle from WAGNER combines two nozzle cores into one nozzle. 2 Speed Tip holder Order no. 0271065 Tip table Object size Painting material Lacquer (L) Emulsion (D) Filler (S) Nozzles: 111 / 415 Nozzles: 225 / 629 Order no.
-
Page 27: Spare Parts List Super Finish 23 Pro
Super Finish 23 Pro SPARE PARTS AND ACCESSORIES 11.2 SPARE PARTS SF 23 PRO ITEM ORDER NO. DESIGNATION 9953696 Motor protection switch 2393002 Oval-head tapping screw 4,2 x 45 (2 pcs.) 2393003 Oval-head tapping screw 4,2 x 25 (2 pcs.) 2388381 Oval-head tapping screw 4,2 x 22 2388377... - Page 28 Super Finish 23 Pro SPARE PARTS AND ACCESSORIES Spare parts diagram SF 23 Pro...
-
Page 29: Spare Parts List High-Pressure Filter
Super Finish 23 Pro SPARE PARTS AND ACCESSORIES 11.3 11.4 SPARE PARTS LIST HIGH-PRESSURE FILTER SPARE PARTS LIST HOPPER ITEM ORDER NO. DESIGNATION ITEM ORDER-NO DESIGNATION 0097 121 High-pressure filter HF- 01 compl. 0341 265 Hopper 5l, assy. (pos. 2-6) 0097 301 Filter block 0340 901... -
Page 30: Spare Parts List Trolley
Super Finish 23 Pro SPARE PARTS AND ACCESSORIES 11.5 SPARE PARTS LIST TROLLEY ITEM ORDER NO. DESIGNATION 2369570 Handle 13806 Sleeve 2396299 Half-hollow rivet 2369585 Cleaning cup 2393786 Cleaning cup holder 2369550 Bottom frame, cart 2369578 Foot, damping 9920304 Washer 2391181 Hexagon socket head cap screw 2393118... -
Page 31: Testing Of The Unit
The guarantee certificate is valid as confirmation, as is the Wagner or one of our dealers will take back your used Wagner waste electrical or electronic equipment and will dispose of original purchase document that carries the date of the pur- it for you in an environmentally friendly way. -
Page 32: Ce - Declaration
EN 61000-3-11, EN 61000-6-1, EN 61000-6-3 accessory parts, additional components or spare parts that The EU declaration of conformity is enclosed with the are not original Wagner parts. product. for products to which modifications or additions have been If required, it can be re-ordered using order number carried out. - Page 33 Ногинский р-н, территория Czechia «Ногинск-Технопарк» д.14 Tel. +420 734 792 823 Tel. +7 495 221 6666 Telefax 420 227 077 364 Telefax +7 495 99 55 88 2 info@aplikacebarev.cz 2216666@m-p-l.ru dis@m-p-l.ru www.wagner-group.com Part. No. 2398950 08/2018_RS © Copyright by J.Wagner GmbH...
