Manual
applicable for
1. Introduction
Thank you for buying this quality WHD product. Please read this manual carefully, especially the safety
and security information.
Please check that you have the correct manual for your product. To do this, please compare the product
code number shown above with the product code number displayed on your product.
2. Contents Check List
- BTR 55
- 2 pieces, PT screws 3x16
- Silicone tube (length: 250 mm)
- 2 pieces, cardboard distance rings
- Manual
3. Safety & security
Important information
In addition to this guidance please comply with your own country-specific safety & security regulations.
3.1. How to use this guide:
Read these instructions carefully before use and use this product only in accordance with the instructions
listed here.
3.2. Signs & symbols used
This sign warns of the danger of injury and property damage.
This sign warns of injury arising from electricity.
This sign warns of injury and/or explosion.
This symbol refers to additional information.
3.3. Signal words and their meaning
Danger: Potential severe physical damage and acute danger.
Warning: Potential electrical shock physical damage and severe property damage.
Caution: Potential fire hazard, physical damage or property damage as a result thereof.
Attention: Advisory notes only.
Version (Technical and optical modifications reserved)
BTR 55
124-055-03-012-00, 124-055-03-015-00, 124-055-05-012-00, 124-055-06-012-00
Seite 1 von 8
29.03.2022
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WHD BTR 55
Summary of Contents for WHD BTR 55
- Page 1 124-055-03-012-00, 124-055-03-015-00, 124-055-05-012-00, 124-055-06-012-00 1. Introduction Thank you for buying this quality WHD product. Please read this manual carefully, especially the safety and security information. Please check that you have the correct manual for your product. To do this, please compare the product code number shown above with the product code number displayed on your product.
- Page 2 Indoors, flush mounted socket. 6. Improper use The device is not suitable for outdoor operation. The ambient air temperature should not exceed 30 ° C. 7. BTR 55 specifications Supply Voltage 230 V AC, 50 Hz Output 2 x 1.2 watt...
- Page 3 For installation, a recessed box with a 60 mm diameter is required. Two PT screws, 3 x 14 are included. 9.1. Connections When looking at the front of the BTR 55 the connectors are located as follows: Left side connections: LINE OUT L (left)…...
- Page 4 Manual BTR 55 applicable for 124-055-03-012-00, 124-055-03-015-00, 124-055-05-012-00, 124-055-06-012-00 9.2. Connecting power supply Connecting the 230 VAC cable: Plug the cable into the screw-type terminal and fasten it firmly with the screws on the front. Note: To protect the device against electromagnetic interference there is the silicone tube.
- Page 5 Manual BTR 55 applicable for 124-055-03-012-00, 124-055-03-015-00, 124-055-05-012-00, 124-055-06-012-00 9.4. Connecting the speakers Connect the speakers to the screw-type terminals provided. Plug the speaker cable into the screw-type terminal and fasten it firmly with the screws on the front. Note: The speakers must be connected with separate wires.
- Page 6 5. When the connection is established the blue status LED is constantly on. Note: - After the first Pairing with an external device the BTR 55 identifies the mobile device and no future Pairing is necessary. - To reconnect the devices, select them on the smartphone/tablet BTR55.
- Page 7 BTR 55 ON/OFF button about 3-5 sec. Note: If you have lost contact with the BTR 55 longer than 20 minutes (outside the radio range), the connection must be re-established. The pairing is maintained. 10.5. LED Status Signals Blue LED Signal...
- Page 8 BTR 55 applicable for 124-055-03-012-00, 124-055-03-015-00, 124-055-05-012-00, 124-055-06-012-00 11. Disposal WHD are members of the INTERSEROH association. We participate in the dual system as well as other industry-specific solutions. Therefore, plastic, metal and electronic parts can all be recycled. 12. Declaration of Conformity This product supports all CE-marking criteria.
