1. Introduction
Thank you for buying this quality product. Please read this manual carefully, especially the safety and
security information.
Please check that you have the correct manual for your product. To do this, please compare the product
code number shown above with the product code number displayed on your product.
2. Contents Check List
- AirBridge
- Power Supply
- 3,5mm Stereo Jack
- Cinch Cable
- TOSlink Cable
- Manual
3. Safety & security
Important information
In addition to this guidance please comply with your own country-specific safety & security regulations.
3.1. How to use this guide:
Read these instructions carefully before use and use this product only in accordance with the instructions
listed here.
3.2. Signs & symbols used
This sign warns of the danger of injury and property damage.
This sign warns of injury arising from electricity.
This sign warns of injury and/or explosion.
This symbol refers to additional information.
3.3. Signal words and their meaning
Danger: Potential severe physical damage and acute danger.
Warning: Potential electrical shock physical damage and severe property damage.
Caution: Potential fire hazard, physical damage or property damage as a result thereof.
Attention: Advisory notes only.
Version (Technical and optical modifications reserved)
AirBridge
124-312-00-100-01
Page 1 of 8
24.09.2015
Advertisement
Table of Contents
Related Manuals for WHD AirBridge
Summary of Contents for WHD AirBridge
- Page 1 Please check that you have the correct manual for your product. To do this, please compare the product code number shown above with the product code number displayed on your product. 2. Contents Check List - AirBridge - Power Supply - 3,5mm Stereo Jack...
- Page 2 5. Intended use Indoors, connecting to WLAN IEEE 802.11n. 6. Improper use The device is not suitable for outdoor operation. The ambient air temperature should not exceed 30 ° C. 7. Specifications AirBridge Power Supply 5 VDC Opt. Output Level -17 dBm WLAN IEEE 802.11b/g/n up to 150 Mbps...
- Page 3 AirBridge applicable for 124-312-00-100-01 9. Installation 9.1. General Put the AirBridge in a convenient location and connect the cables according to your deployment scenarios. 9.2. Connections 1 … LED / Status 2 … Mini-USB plug for power supply 3 … Optical TOSLINK (S/PDIF) OUT(digital) 4 …...
- Page 4 Then choose „WHD Air-Bridge“. Your Smartphone, Tablet or PC connects to the AirBridge. 3. Open the WHD Multiroom Audio Player App, which you can download via App Store or Google Play Store for free. Select in the WHD Multiroom Audio Player App the „Assistent“...
- Page 5 Is the AirBridge flashing steady red or blue for too long, probably the access key is entered incorrectly, and therefore may be no network connectivity. The system tries repeatedly using the wrong data log onto the network.
- Page 6 LED blinking constantly red Reset the AirBridge. No working solution fond (Reset) Press the RESET button for > 6 sec. with the end of a paper clip. The AirBridge configuration is now on factory settings. Repeat the process. Music breaks through overbooking WLANs...
- Page 7 AirBridge applicable for 124-312-00-100-01 Can the analog output jack and the digital TOSLINK output of AirBridge be connected in parallel? Yes, that is also parallel and synchronous. Are phone calls transferred to the AirBridge? Our tested smartphones "stream" a call not wireless, but interrupting the stream. This makes sense, because otherwise there would be problems because of the microphone.
- Page 8 17. Product Registration & Warranty Extension Fill out the form below www.whd.de/Produktregistrierung to register your new WHD product and get an extended warranty for an additional year. Note that you can perform only registered Products Software Updates and registration for our Hotline/Support is imperative.
