Page 2 Change of name, address or ownership In the event of a Safety Recall, or for various reasons, Holden may need to contact you as the owner of this vehicle. If you have recently changed your address, or name, or purchased this vehicle second-hand, please help us to help you by taking a few minutes to fill in and mail the forms at the beginning of the Service/warranty booklet.
Page 3 CHAPTERS Dashboard · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·...
Page 4 Please note that all information, illustrations and specifications in this Handbook are based on the latest production information available at the time of printing. Holden reserves the right to make changes at any time without notice and without incurring any obligation.
Page 5: Table Of Contents
Daimler Chrysler AG. in all vehicles, model variants, engine options, 8/uetooth ® word mark and logo are registered optional equipment and Genuine Holden trademarks and are owned by the Bluetooth SIG, Inc. Accessories (and Parts).
Page 6 Chapter 6 - Emergencies Chapter 8 - Specifications Customer assistance -Australia Specifications Customer assistance - New Zealand General specifications Flat tyre Identification labels Changing a flat tyre Chapter 9 Tow and load Spare wheel carrier troubleshooting Loading the vehicle Towing a disabled vehicle Towing Engine overheating Flat battery...
Page 7 ....... . The asterisk signifies equipment options not in all vehicles, model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 8: Dashboard Layout
Chapter 1A 1A-2 DASHBOARD DASHBOARD LAYOUT LAYOUT INDEX (OMEGA/SV6/SS) Page Glovebox ......................3-18 Vents 1A-34 ......................Hazard warning switch ...................
Page 9 1A-3 SV6/SS...
Page 10 Chapter 1A 1A-4 DASHBOARD DASHBOARD LAYOUT cont. LAYOUT INDEX (SS-V) Page Glovebox ......................3-18 Vents 1A-34 ......................Sunlight sensor ....................
Page 11 Chapter 1A 1A-5 DASHBOARD DASHBOARD LAYOUT cont. SS-V...
Page 12: Chapter 1A- Dashboard
Chapter 1A 1A-6 DASHBOARD INSTRUMENTATION GAUGES 0 Temperature gauge temperature gauge indicates engine coolant temperature when the ignition is on. Stop-start driving in heavy traffic, driving at high speed in warm weather, hill climbing towing cause the needle to move toward the H. This is normal and no cause for concern.
Page 13 Chapter 1A 1A-7 DASHBOARD INSTRUMENTATION cont. INFORMATION DISPLAYS The instrument panel information display provides visual information to the driver for a number of vehicle functions such as trip computer, audio, warnings and reminders. Centre display. Display- Ignition on When the ignition is switched on, a vehicle Welcome Welcome system check is performed and the status is...
Page 14: Warning/Reminder Indications
7. Do not run the engine when this warning is illuminated. If the oil level is normal, system checked ai the nearesi Holden Dealer. The Check Oil animation is displayed until the TRIP button or the ENTER switch are pressed.
Page 15 ABS Fault animation does not extinguish or illuminates when driving, it indicates a malfunction with the ABS. Contact your Holden Dealer as soon as possible. Note The vehicle's brake system will still operate conventionally with the anti-lock operation disabled. Refer to Anti-lock brake system chapter 4.
Page 16 Fault belt pretensioner system may not function correctly in an accident. Contact your Holden Dealer immediately. Note The SRS warning lamp 1t illuminates after an accident if the airbag(s) and/or pretensioners have activated.
Page 17 �� OOO,OOOkm that the ESP® system is no longer functioning. Stability Contact your Holden Dealer. Ctrl Off The Stability Ctrl Off animation is displayed until the TRIP button or the ENTER switch are pressed. It then reverts to the original trip computer display.
Page 18 Chapter 1A 1A-12 DASHBOARD WARNING/REMINDER INDICATIONS cont. Low fuel If the Low Fuel animation illuminates when driving, it indicates that the fuel level is low. Odometer The Low Fuel animation is displayed until the TRIP button or the ENTER switch are pressed. OOO,OOOkm il Low Fuel appears at the bottom of the display Fuel...
Page 19 Select Service error If the Contact Dealer animation illuminates when driving, it indicates a fault in the instrument Odometer panel. Contact your Holden Dealer as soon as possible. OOO,OOOkm Contact Contact Dealer animation is displayed Dealer until the TRIP button or the ENTER switch Service are pressed.
Page 20 Engine while driving, reduce the vehicle's speed and load, until the lamp stops flashing, then take the vehicle to a Holden Dealer as soon as possible. The Check Engine animation is displayed until the TRIP button or the ENTER switch are pressed. It then reverts to the original trip computer display.
Page 21 Note This reminder is calculated only by distance. Remember that if driving infrequently, special servicing may be required. Refer to the Service/warranty booklet in the glovebox. The Service message is reset when your Holden Dealer services the vehicle. Cruise control The Cruise On animation illuminates when the cruise control is activated and ready for use.
Page 22 Chapter 1A 1A-16 DASHBOARD WARNING/REMINDER INDICATIONS cont. Battery saver mode on If the Battery Saver Mode On animation illuminates, it indicates that the battery voltage level is low. Battery Saver Mode On Alarm activated If the alarm has been activated, the Alarm Activated animation appears for about one second followed by a animation showing which...
Page 23 If the lamp illuminates and stays on when driving, the system may require servicing. Although the vehicle may still be drivable and not require towing, take the vehicle to a Holden Dealer as soon as possible. If the lamp flashes while driving, reduce the vehicle's speed and load, until the lamp stops flashing, then take the vehicle to a Holden Dealer as soon as possible.
Page 24: Trip Computer
Chapter 1A 1A-18 DASHBOARD TRIP COMPUTER The trip computer is shown on the centre display CONTROLS Press the TRIP button on the left-hand spoke of the steering wheel to scroll between the trip computer displays and to highlight the values. When the values are highlighted, press the ENTER switch (push down on the scroll wheel) to the left of the TRIP button to reset the values.
Page 25 Chapter 1A 1A-19 DASHBOARD TRIP COMPUTER cont. Odometer/tripmeter The odometer records kilometres travelled since the vehicle was Odometer built. The tripmeter shows the kilometres travelled from the start 000,000 km of a particular trip. Trip To reset only the tripmeter to zero, highlight the tripmeter value and press the ENTER switch for more than three seconds.
Page 26 Chapter 1A 1A-20 DASHBOARD TRIP COMPUTER cont. Overs peed Overspeed allows the driver to set a speed that they do not want to exceed. The OverSpeed animation will illuminate in the display ®kml h and a chime will sound to warn that the vehicle's speed is equal or has exceeded the preselected value.
Page 27 Chapter 1A 1A-21 DASHBOARD TRIP COMPUTER cont. (.A. To select a Preset, rotate the ENTER switch up or down to highlight the desired preset. OverS peed Note While the vehicle's speed is 10 km/h or below, each of the presets can be altered and values can be stored for future use. �141¥41- 60km/h ENTER to E dit...
Page 28 Chapter 1A 1A-22 DASHBOARD TRIP COMPUTER cont. Trip computer notes If the wrong buttons are accidentally pressed, causing the display to show anything other than normal, switch the ignition off then on again (only when the vehicle is stationary). Several warning lamps are linked to the instrument panel display window. Refer to Warning/reminder indications previously in this chapter.
Page 29 Chapter 1A 1A-23 DASHBOARD TRIP COMPUTER cont. (.A. To select a Preset, rotate the ENTER switch up or down to highlight the desired preset. O v e r S p ee d Note While the vehicle's speed is 10 km/h or below, each of the presets can be altered and values can be stored for future use.
Page 30: Customisation Menu
Chapter 1A 1A-24 DASHBOARD CUSTOMISATION MENU USING THE CUSTOMISATION MENU Entering the Customisation menu Odometer Scroll to the Customisation menu using the TRIP Customise button and press the ENTER switch. Options OOO,OOOkm Note T he Customisation menu cannot be opened when the vehicle speed is above 10 km/h.
Page 31 Chapter 1A 1A-25 DASHBOARD CUSTOMISATION MENU cont. Security 107.8 FM For information on the following features, refer to chapter 2. � Security Auto unlock Auto unlock Auto lock Choose when you want the doors to unlock automatically. Flash remote lock Beep remote lock Auto unlock is switched off.
Page 32 Chapter 1A 1A-26 DASHBOARD CUSTOMISATION MENU cont. Trip Computer 107.8 FM For information on the following features, refer to Trip computer Trip Computer � previously in this chapter..11 1mi�E·I= I·E•I Inl l Dist to Arrival Underspeed chime Distance to go Choose if you want the underspeed chime to sound.
Page 33: Steering, Horn, Hazard Warning
1A-27 Chapter 1A DASHBOARD TILT/REACH STEERING WARNING Do not attempt to adjust the steering wheel while driving. Move the lock lever under the steering column downwards. Grasp the steering wheel and move it as required. It can be moved up or down, pulled towards pushed...
Page 34: Wipers And Washers
Chapter 1A 1A-28 DASHBOARD WIPERS AND WASHERS OPERATING THE WIPERS AND WASHERS The lever on the left side of the steering column controls the wipers and washers. They operate when the ignition is switched to the ON or ACCESSORIES positions. WARNING Never operate the wipers on dry glass, as this will damage the rubber and scratch the glass.
Page 35: Lights
Chapter 1A 1A-29 DASHBOARD LIGHTS LIGHTS SWITCH =Off Turns the headlamps and park lamps off. AUTO =Automatic head lamps Headlamps and park lamps switch on and off automatically. Select high and low beam using the lever. Note Head lamps and park lamps switch on automatically when wipers are operating.
Page 36: Lights
Chapter 1A 1A-30 DASHBOARD LIGHTS cont. EXTERIOR LAMPS Automatic headlamps When the headlamp switch is in the AUTO position, the headlamps and park lamps automatically switch off and on according to the ambient light. Select high and low beam using the lever. Note The light sensor is centrally mounted on the top of the dashboard.
Page 37 Chapter 1A 1A-31 DASHBOARD LIGHTS cont. Personal identity keys* When the button is pressed on the key, the system identifies the key and sets the headlamp time delay to the last adjustments used for that key. Refer to Personal identity keys in chapter 2. Fog lamps* Fog lamps provide a different illumination of the road to the usual headlamp beam.
Page 38: Cruise Control
Chapter 1A 1A-32 DASHBOARD CRUISE CONTROL OPERATING CRUISE CONTROL The cruise control maintains the vehicle's speed without you having your foot on the accelerator pedal. Note The cruise control will only operate at speeds above km/h engine). The cruise control will only operate at speeds above km/h engine).
Page 39 Chapter 1A 1A-33 DASHBOARD CRUISE CONTROL cont. Pausing the cruise control CRUISE ON Press the brake pedal, press the clutch pedal (if the vehicle is fitted with a manual transmission) or press the ON-OFF/CANCEL switch once. This deactivates the cruise control. The Cruise Inactive animation appears, but cruise control retains the speed in its memory.
Page 40: Ventilation System
Chapter 1A 1A-34 DASHBOARD VENTILATION SYSTEM The vehicle features a flow-through ventilation system for comfort. Under reasonable conditions, it should not be necessary to open the windows at any time. Outside air is drawn into the vehicle through the opening between the bonnet and the windscreen, unless recirculation has been selected.
Page 41: Manual Heater, Air Conditioning
Chapter 1A 1A-35 DASHBOARD MANUAL HEATER, AIR CONDITIONING* CONTROLS VEUD1A_019 Fan speed Recirculation button Temperature control Air conditioning (A/C) button* Mode control Rear window demister Fan speed Turn the outer button ring clockwise to increase the fan speed or anticlockwise to reduce it.
Page 42 Chapter 1A 1A-36 DASHBOARD MANUAL HEATER, AIR CONDITIONING* cont. A/C button* Press the A/C button to switch the air conditioning on and off. The lamp in the button illuminates when the air conditioning is on. Note T he fan must be on before the air conditioning will work. �...
Page 43 Chapter 1A 1A-37 DASHBOARD MANUAL HEATER, AIR CONDI TIONING* cont. Air conditioning For a quick cool down when first entering the vehicle on a hot day: Press the A/C button to switch on the air conditioning. Press the� button to switch on the recirculation. Turn the temperature control to the coldest setting.
Page 44 The system is protected by switches that guard against abnormal loads and loss of refrigerant. The air conditioning compressor may switch off until the fault is rectified. Have the system checked by a Holden Dealer if this occurs. Cigarette smoke If occupants are smoking, it is recommended that the recirculate position not be used.
Page 45 Chapter 1A 1A-39 DASHBOARD CLIMATE CONTROL* T he climate control panel is located in the centre of the dashboard. It is designed to maintain the interior of the vehicle at the desired temperature. T he temperature for the driver's and passenger's side can be adjusted independently. CONTROLS VEUD1A_020 OFF button...
Page 46: Climate Control
Chapter 1A 1A-40 DASHBOARD CLIMATE CONTROL* cont. Temperature controls Turn the temperature controls clockwise (warmer) or anticlockwise (cooler). The temperature can be set between 17 oc and 30 oc (a setting between 22 oc and 24 oc is recommended). The temperature settings for each side are shown in the display. Note If turning the temperature control past 30 oc, the display will show H (hottest).
Page 47 Chapter 1A 1A-41 DASHBOARD CLIMATE CONTROL* cont. Press+ or- on the fan button to increase or decrease the fan speed. The fan speed is shown in the display. Note The climate control sets the fan speed automatically. When adjusting the fan speed, the system will revert to semi-automatic operation.
Page 48 Chapter 1A 1A-42 DASHBOARD CLIMATE CONTROL* cont. AIC button Press the A/C button to switch the air conditioning on and off. AIC appears in the display when the air conditioning is on. A/C OFF appears when it is off. Note �...
Page 49 Chapter 1A 1A-43 DASHBOARD CLIMATE CONTROL* cont. Rear window demist button CiUJ Press the button to turn the rear demister on. Press the button again to turn the rear demister off. CiUJ T he symbol appears in the display. Note To avoid unnecessary electrical consumption, the rear demister switches off automatically.
Page 50 The system is protected by switches that guard against abnormal loads and loss of refrigerant. The air conditioning compressor may switch off until the fault is rectified. Have the system checked by a Holden Dealer if this occurs. Adjusting the temperature...
Page 51 Chapter 1A 1A-45 DASHBOARD CLIMATE CONTROL* cont. Hissing Occasionally a slight hissing sound may be heard for a short time when the air conditioning switches off and pressure in the system equalises. This is normal. Water Water condensation forms when the air conditioning is operating, this condensation is discharged underneath the vehicle.
Page 52 5 to 10 minutes (even in winter) to lubricate the air conditioning system seals. Pollen/dust filter A passenger compartment air filter may be fitted to filter outside air entering the vehicle. The filter removes contaminants such as pollen and dust. This can be fitted at your request by your Holden Dealer.
Page 53 Chapter 1A 1A-47 DASHBOARD BLUETOOTH® CAR KIT The Bluetooth® car kit allows you to answer incoming calls on your mobile phone without looking at or touching your mobile phone. Your Bluetooth® voice capable phone need only be inside the vehicle for it to connect to the Bluetooth® car kit. Bluetooth®...
Page 54 Chapter 1A 1A-48 DASHBOARD BLUETOOTH®* cont. Bluetooth® button The Bluetooth® button� is located on the right-hand spoke of the steering wheel. VEUD1A_021 Note When pressing the � button with the ignition on, a phone symbol appears in the instrument panel centre display for a few seconds.
Page 55: Bluetooth
Chapter 1A 1A-49 DASHBOARD BLUETOOTH®* cont. Pairing your mobile phone The pairing between the Bluetooth® capable mobile phone and the Bluetooth® car kit can be established as follows: Switch on your mobile phone. 2. Switch on the ignition. Perform the following steps on your mobile phone: Enter the Bluetooth®...
Page 56 Chapter 1A 1A-50 DASHBOARD BLUETOOTH®* cont. Making a call by voice dialling To use the voice dial functions of your mobile phone (provided that your mobile phone is capable), entries for dialling phone numbers with voice dialling have to be prerecorded. T hese voice commands can then be called via the Bluetooth®...
Page 57 Chapter 1A 1A-51 DASHBOARD BLUETOOTH®* cont. Private/hands-free WARNING Only activate this function if the vehicle is parked. To switch from hands-free to the mobile phone handset: 1. Press and hold the� button for three seconds. Continue the call on the mobile phone handset. Press the�...
Page 58 Your mobile phone has no last redialled numbers. Make the initial call from the mobile phone handset. This feature is not compatible on your mobile phone and the Bluetooth® car kit. Refer to your Holden Dealer. An echo is present Audio system volume is too loud.
Page 59: Steering Wheel
The asterisk signifies equipment options not . . . in all vehicles, model variants, engine options, Notes on compact discs optional equipment and Genuine Holden (all units) 18-53 Accessories (and Parts)........
Page 60 Chapter 1 B 18-2 AUDIO STEERING WHEEL REMOTE CONTROLS (ALL UNITS) AUDIO Button Select source: FM1 � FM2 �AM � CD� FrontAUX �Rear AUX � FM1 � FM2 �AM� ... Note AUX sources are only selectable when AUX device is plugged in. CD is only selectable when a CD is loaded.
Page 61: Overview (Level 1)
18-3 Chapter 18 AUDIO OVERVIEW (LEVEL 1) OMEGA, SV6 (LEVEL SINGLE CD) VEUD1B_002 SS (LEVEL 6 CD CHANGER) (OPTIONAL OMEGA, SV6) VEUD1B_003...
Page 62 Chapter 1 B 18-4 AUDIO OVERVIEW (LEVEL 1) cont. Radio preset buttons 1-6. Radio Mode: Station seek (down). CD Mode short press: Previous T rack. Automatic Station Memory storage ASM. Radio band button. Radio mode: toggle between FM 1, FM2 and AM band (if ASM is not active). Short press: Recall clock/calendar information display.
Page 63: Important Information
When the electronic link between the vehicle and the radio is interrupted, the display 'Security Lockout Active' will be shown. In this case, please contact your Holden Dealer. Security Indicator Light �...
Page 64: Switching On/Off
Chapter 18 18-6 AUDIO SWITCHING ON/OFF (LEVEL 1) ON/OFF button Switch the radio on and off by pressing the(!) button�. On/Off (Using ignition key) The radio can operate when the ignition key is turned to the Accessories position. When the vehicle's Accessories Control is turned off by turning the ignition key off (and opening the drivers door) the radio (if operating) will be switched off.
Page 65: Audio Settings
Chapter 1 B 18-7 AUDIO AUDIO SETTINGS (LEVEL 1) SOURCE (MODE) SELECTION The radio mode can be selected by any of the following actions: Pressing the(!) button if the previously played source was radio. Pressing the BAND button Pressing the ASM button The CD mode can be selected by any of the following actions: Pressing the button...
Page 66 Chapter 1 B 18-8 AUDIO AUDIO SETTINGS (LEVEL 1) cont. Volume Turning the Volume Control Dial clockwise will increase the volume, turning it anti clockwise will decrease the volume. Independent Tone Memories* This radio is equipped with Independent Tone Memories. Bass and Treble can be set independently for each listening mode such as AM, FM, CD and Telephone.
Page 67 Chapter 18-9 AUDIO AUDIO SETTINGS (LEVEL 1) cont. Balance To shift the sound towards the right or the left: Enter the Option menu by pressing the Volume Control Dial 0 when the radio is switched on. The menu item 'AUDIO' is highlighted. 2.
Page 68: Radio Operation
Chapter 1 B 18-10 AUDIO RADIO OPERATION (LEVEL 1) RADIO DISPLAY Selecting a Radio Band Press the BAND button repeatedly to select one AM and two FM bands (FM1 & FM2). The chosen band will be shown on the display. If the ASM mode is active ('ASM' appears on the display), one AM band and one FM band can be selected.
Page 69 Chapter 18 1 B-11 AUDIO RADIO OPERATION (LEVEL 1) cont. The Local/Distance selection has no effect when the ASM search feature is being used. Access the Option Menu by pressing the Volume Control Dial when the radio source is selected. Highlight the menu item 'SEEK SENS' by turning the Volume Control Dial clockwise.
Page 70 Chapter 1 B 18-12 AUDIO RADIO OPERATION (LEVEL 1) cont. Automatic Station Memory (ASM) This feature allows the storage of an additional 6 AM and 6 FM radio stations. It is of great benefit when travelling long distances, e.g. on holidays, since you can store the strongest radio stations without knowing their frequency.
Page 71 Chapter 1 B 18-13 AUDIO RADIO OPERATION (LEVEL 1) cont. Interference Interference is caused by either natural or man made electrical disturbances. This can affect the amplitude of the reception signal. AM signals are more prone to this type of interference than FM signals. This type of interference has little or no effect on the frequency of the reception signal, thus AM is susceptible to interference from power lines, fluorescent lighting, neon signs, traffic light control circuits, overhead tram wires and electrical storms.
Page 72 18-14 Chapter 18 AUDIO SINGLE OPERATION (LEVEL 1) � The CD drive is built into the radio and COs are loaded through the CD slot on the front face of the radio. Note T he CD drive is designed for standard 12 em COs only. Using incorrect sized COs (e.g.
Page 73: Single Cd Operation
Chapter 1 B 18-15 AUDIO SINGLE OPERATION (LEVEL 1) cont. Fast Forward/Fast Back (Track Cue/Review) Press and hold the ..,...,. button or the ...,..,. . button to rapidly move forwards or backwards within the current track. CD Random When this feature is selected, all tracks on the current CD will be played in random order.
Page 74 Chapter 18 18-16 AUDIO CD CHANGER OPERATION (LEVEL 1) CD Changer Operation (only for Level 1) The CD Changer holds up to six CDs at one time. The Changer is built into the radio «D and CDs are loaded through the single slot on the front face of the radio, after pressing the LOAD button�...
Page 75: Cd Changer Operation
Chapter 18-17 AUDIO CD CHANGER OPERATION (LEVEL 1) cont. Loading a To load a CD into the CD Changer, briefly press the LOAD button�- When the Changer is ready to accept the CD, 'Insert Disc' will be displayed. The Load Indicator Light� will flash green, and the radio will beep twice. Insert the CD with the label surface facing upwards, into the CD slot until the mechanism pulls the CD inside and it begins to play.
Page 76 Chapter 1 B 18-18 AUDIO CD CHANGER OPERATION (LEVEL 1) cont. Playing COs Press the ON button� if the previous mode was CD. � Press the CD button if the vehicle's accessories or ignition is on. � Press the CD button if the vehicle's accessories or ignition is off to turn on the radio in CD source.
Page 77 Chapter 1 B 18-19 AUDIO CD CHANGER OPERATION (LEVEL 1) cont. Choosing Track and Folder using the MP3-Browse Mode When listening to MP3-CDs, you can browse the directories (folders) and tracks of the MP3-CD to find a track more easily. To choose a track in the actual folder: Press the button 3 BROWSE MP3 The files of the currently played folder are shown.
Page 78 Chapter 1 B 18-20 AUDIO CD CHANGER OPERATION (LEVEL 1) cont. CD Random You can choose between different modes for random play: RANDOM TRACK for CD, RANDOM DISC for CD, RANDOM IN DISC for MP3-CDs and RANDOM IN FOLDER for MP3-CDs. Press the preset button RANDM until the desired Random function is activated.
Page 79: Aux Operation
Chapter 1 B 18-21 AUDIO AUX OPERATION (LEVEL 1) AUX operation T his unit is equipped with an AUX input socket� at the front of the Audio Head unit. You can connect any suitable audio source to the AUX input socket e.g. portable MP3 player.
Page 80: Additional Features
Chapter 1B 18-22 AUDIO ADDITIONAL FEATURES (LEVEL 1) Speed Dependent Volume (SDV) The SDV system adjusts the radio volume depending on the vehicle's speed. As the vehicle's speed increases, the volume of the radio also increases to compensate for the driving noise. Note This feature will never completely compensate for the driving noise.
Page 81 Chapter 1B 18-23 AUDIO ADDITIONAL FEATURES (LEVEL 1) cont. To turn distortion limiting on and off: Enter the Options menu by pressing the Volume Control Dial when the radio is switched on. The menu item 'AUDIO' is highlighted. Turn the Volume Control Dial clockwise to highlight 'AUD SETUP'.
Page 83: Overview (Ss-V)
Chapter 1 B 18-25 AUDIO OVERVIEW cont. CONTROLS CD Load button. Long press: To Load all disks. Single press: To Load one disk. Short press: Show time display of active source . Long press: Adjust clock and calendar. Enter Help menu. Automatic Station Memory storage.
Page 84: Important Information
When the electronic link between the vehicle and the radio is interrupted, the display 'Security Lockout Active' will be shown. In this case, please contact your Holden Dealer. Security Indicator Light �...
Page 85 Chapter 1 B 18-27 AUDIO I MPORTANT INFORMATION cont. SETTING THE CLOCK & CALENDAR Note The clock and calendar can be adjusted when the radio is either on or off. Adjust the clock and calendar as follows: Press and hold the TIME button for more than 2 seconds.
Page 86: Switching On/Off
Chapter 18 18-28 AUDIO SWITCHING ON/OFF (SS-VJ ON/OFF Switch the radio off and on by pressing the (!) button On/Off (Using ignition key) The radio can operate when the ignition key is turned to the Accessories position. When the vehicle's Accessories Control is turned off by turning the ignition key off and opening the drivers door, the radio (if operating) will be switched off.
Page 87: Personal Identity Keys
Chapter 1 B 18-29 AUDIO PERSONAL IDENTITY KEYS* (SS-V) Memory 1 and Memory 2 This radio features Personal Identity Memories, which provide two different memories of electronic settings for different ignition keys. For the sound system the following settings are individually memorised by the key system and become unique to the particular key: Radio On or Off.
Page 88: Audio Settings
Chapter 1 B 18-30 AUDIO AUDIO SETTINGS (SS-V) SOURCE (MODE) SELECTION The radio mode can be selected by any of the following actions: Pressing the (!)button if the previously played source was radio. Pressing the BAND button�- The CD mode can be selected by any of the following actions: Pressing the(!) button if the previously played source was CD.
Page 89 Chapter 1 B 18-31 AUDIO AUDIO SETTINGS (SS-VJ cont. Treble Access the Option menu by pressing the Menu Control Dial when the radio is switched on. The menu item 'Audio' is highlighted. Press the Menu Control Dial to access the audio menu. Turn the Menu Control Dial clockwise to highlight 'Treble'.
Page 90 Chapter 1B 18-32 AUDIO AUDIO SETTINGS (SS-VJ cont. EQUALIZER FUNCTION The audio unit is equipped with five pre-programmed equalizer curves. Each of these curves have been factory-programmed to enhance a particular style of music. However it may be used with any type. To turn this function on or off, or to scroll through the five EQ curves, press the button one or more times.
Page 91 Chapter 1 B 18-33 AUDIO AUDIO SETTINGS (SS-V) cont. LOUDNESS CONTOUR CIRCUIT A user selectable loudness contour circuit to enhance the Bass and Treble response at low volume levels can be activated if you feel that the sound system needs more bass and treble at low listening levels.
Page 92: Radio Operation
Chapter 1 B 18-34 AUDIO RADIO OPERATION (SS-VJ Radio Display Frequenc y Time displa y BAND 102.0 DISC1----- Number and position of COs in pla y er VEUD1B 008 Selecting a Radio Band Press the BAND button � repeatedly to select one AM and two FM bands (FM1 & FM2).
Page 93 Chapter 1 B 18-35 AUDIO RADIO OPERATION cont. Note The Local/Distance selector has no effect when the ASM search feature is being used. 1. Access the Option menu by pressing the Menu Control Dial when the radio is switched on. Highlight the menu item 'Seek sens' by turning the Menu Control Dial clockwise.
Page 94 Chapter 1 B 18-36 AUDIO RADIO OPERATION cont. Using Automatic Station Memory BAND� Select the desired radio band with the button. Press the button for at least two seconds until the sound is briefly muted or a beep sounds (if Confirmation Beeps are turned on, refer to Confirmation Beeps further on in this chapter).
Page 95 Chapter 1 B 18-37 AUDIO RADIO OPERATION cont. Peculiarities of FM Mobile Reception A mobile FM receiver cannot be expected to continuously provide the quality of FM reception you may have experienced on your home receiver. Contrary to popular opinion, FM broadcasts are not static free, and although your radio has a built-in electronic interference absorption circuit, some static will occur from time to time, especially in areas without a direct line of sight to the transmitter.
Page 96 Chapter 18 18-38 AUDIO CD CHANGER OPERATION The CD Changer holds up to six COs at one time. The Changer is built into the radio � and COs are loaded through the single slot on the front face of the radio, after pressing the LOAD button (refer to 'Loading a CD' on the next page).
Page 97 Chapter 1 B 18-39 AUDIO CD CHANGER OPERATION (SS-V) cont. MP3 Display Folder number Track number Elapsed time Number and position of COs in player VEUD1B_010 For MP3-CD operation the following modes are available: Normal mode with folder number, track number, and playtime. Folder info mode with folder number, track number, and folder name.
Page 98 Chapter 1 B 18-40 AUDIO CD CHANGER OPERATION (SS-V) cont. Loading a To load a CD into the CD Changer, briefly press the LOAD button When the Changer is ready to accept the CD, 'Insert Disc' will be displayed. The Load Indicator Light� will flash green, and the radio will beep twice (if beeps are turned on).
Page 99 Chapter 1 B 18-41 AUDIO CD CHANGER OPERATION Playing COs Press the button if the previous mode was CD. � Press the CD button if the vehicle's accessories or ignition is on. � Press the CD button if the vehicle's accessories or ignition is off to turn on the radio in CD source.
Page 100: Cd Changer Operation
Chapter 1 B 18-42 AUDIO CD CHANGER OPERATION cont. Choosing track and folder using the MP3-Browse mode When listening to MP3-CDs, you can browse the directories (folders) and tracks of the MP3-CD to find a track more easily. To choose a track in the actual folder: Press the softkey BRWS MODE.
Page 101 COs. If this happens, one of the following error messages may appear on the display: 'Mechanism Error'. 'Error check Disc'. 'No Discs'. 'CD Error'. 'Over Heat Error'. T he player will switch to radio mode after displaying the error message for several seconds. Consult your Holden Dealer if an error message keeps occurring.
Page 102: Aux Operation
Chapter 1 B 18-44 AUDIO AUX OPERATION AUX operation This unit is equipped with an AUX input socket� at the front of the Audio Head unit. You can connect any suitable audio source to the AUX input socket e.g. portable MP3 player.
Page 103 Chapter 18 18-45 AUDIO ADDITIONAL FEATURES (SS-V) Help menu T his unit is equipped with a help menu to help you understand the radio and its functions. Button help You can display help texts for each of the radio buttons. Press the HELP button to enter the help menu.
Page 104 Chapter 1 B 18-46 AUDIO ADDITIONAL con_t_ ADDITIONAL AUDIO SETTINGS Dynamic Distortion Limiter (DOL) Your radio is equipped with a system that limits the amount of amplifier distortion that you can hear. When this feature is turned on it continuously monitors the quality of the signal to the speakers.
Page 105: Additional Features
Chapter 1 B 18-47 AUDIO ADDITIONAL FEATURES (SS-V) cont. Access the Option menu by pressing the Menu Control Dial when the radio is switched on. Highlight the menu item 'Audio setup' by turning the Menu Control Dial clockwise. Press the Menu Control Dial Highlight the menu item 'Beeps' by turning the Menu Control Dial clockwise.
Page 106 Chapter 1 B 18-48 AUDIO ADDITIONAL FEATURES (55-V) cont. DISPLAY SETTINGS You can adjust several settings of the display e.g. brightness and contrast to meet your needs. Brightness setting The brightness is adjustable from -5 to +5. Access the Option menu by pressing the Menu Control Dial when the radio is switched on.
Page 107 Chapter 1 B 18-49 AUDIO ADDITIONAL FEATURES (SS-VJ cont. Contrast setting (DVD player mode only * ) Access the Option menu by pressing the Menu Control Dial when the radio is switched on. Highlight the menu item 'Display' by turning the Menu Control Dial clockwise.
Page 108: Additional Features
Chapter 1B 18-50 AUDIO ADDITIONAL FEATURES (SS-V) cont. Colour Setting Access the Option menu by pressing the Menu Control Dial when the radio is switched on. Highlight the menu item 'Display' by turning the Menu Control Dial clockwise. Press the Menu Control Dial Highlight the menu item 'Colour' by turning the Menu Control Dial clockwise.
Page 109: Telephone (All Units)
Volume, Bass, Treble and Balance can all be adjusted in the Telephone mode without affecting these settings in radio or CD mode. For fitment of your hands free kit, contact your Holden Dealer. IMPORTANT When this feature is used for the first time, the volume may need to be adjusted to the phone as well as to the radio.
Page 110: Antenna Information (All Units)
Chapter 1 B 18-52 AUDIO ANTENNA INFORMATION (ALL UNITS) Fixed mast antenna " · · remove roof antenna, rotate anticlockwise. install roof antenna, rotate it clockwise. WARNING Driving through an automatic vehicle wash with the antenna installed may result in damage to the antenna or the roof panel.
Page 111: Notes On Compact Discs
Chapter 18 18-53 AUDIO NOTES ON COMPACT DISCS (ALL UNITS) Handle the CD by its edge and avoid touching the playing surface. Do not stick paper labels, tape, etc., and do not write on either surface. Do not expose the CD to direct sunlight or a heat source such as a hot air duct for longer periods.
Page 112 Chapter 18 18-54 AUDIO NOTES...
Page 113 ......... The asterisk signifies equipment options not in all vehicles, model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 114: Chapter 2 - Locks
Chapter 2 LOCKS KEYS KEY(MAIN) This key operates all locks and ignition, except for the glovebox. The following buttons appear on the key. Lock: Press the@ button on the key to lock the doors and to arm the alarm system. Unlock: Press the button on the key to unlock the doors and to disarm the...
Page 115 If a transmitter is lost or stolen, a replacement can be purchased through your Holden Dealer. Remember to bring any additional transmitters so they can also be re-coded to match the new transmitter. Once your dealer has coded the new transmitter, the lost transmitter will not unlock your vehicle.
Page 116 Chapter 2 LOCKS KEYS cont. PERSONAL IDENTITY KEYS* This system stores two sets of electronic settings. The settings are stored when a personal identity key is removed from the ignition and are recalled when the @ button is pressed on the key. For instance, one driver may have a preferred radio station. Pressing the @ button on their key automatically customises the radio for that driver.
Page 117 If the vehicle is delivered with only one key, notify your Holden Dealer immediately. Always store spare keys in a safe, dry place. If the key is returned to you with signs of damage, contact your Holden Dealer as soon as possible.
Page 118: Ignition Switch
Note If the vehicle stalls after 5 seconds, return the key to the LOCK position. Slowly rotate the key to the START position. If the security warning lamp flashes, contact your Holden Dealer. Refer to Engine starting in chapter 4.
Page 119: Door Locks
Chapter 2 LOCKS DOOR LOCKS LOCKING Doors are locked when the lock snib is flush with the door handle. If the snib is showing red, the door is unlocked. Refer to Door lock snibs further on in this chapter. Once to lock Note You can select the Auto lock feature which locks...
Page 120 Chapter 2 LOCKS DOOR LOCKS cont. Locking from the inside Press the side of the switch with the til symbol on the centre console to lock all doors. This will not arm the alarm. If locking has not worked Note The horn chirps rapidly five times if any door is open while the button on the key is pressed.
Page 121 The force required to make the key free turn, reduces each time. Do not attempt to demonstrate or test this feature. Always remember to fully insert the key when locking and unlocking the doors. If any problems occur, contact your Holden Dealer. DOOR LOCK SNIBS How the door lock snibs work...
Page 122: Bonnet Lock
Chapter 2 2-10 LOCKS BONNET LOCK OPENING THE BONNET From the driver's side of the vehicle, pull the lever towards you. T his allows the bonnet to release but is prevented from opening by the safety catch. To open the bonnet completely, reach under the bonnet to the passenger's side of the emblem and push up on the front edge of the release catch.
Page 123: Hard Tonneau Cover Lock
Chapter 2 2-11 LOCKS HARD TONNEAU COVER LOCK* WARNING Sitting or standing in the cargo area or on the surface of the hard tonneau cover* while the vehicle is in motion may lead to serious injury or death. Do not carry volatile materials or liquids within the cargo area while the hard tonneau cover* is shut as harmful fumes or gases may accumulate.
Page 124 Chapter 2 2-12 LOCKS HARD TONNEAU COVER LOCK* cont. Manual unlocking Insert the hard tonneau cover key into the lock, turn it towards the driver's side to unlock the cover.
Page 125: Tailgate Latch
Chapter 2 2-13 LOCKS TAILGATE LATCH T he tailgate latch is located on the inside of the tailgate. While facing the front of the vehicle, turn the latch toward the passenger's side, to open. To close, push the tailgate to the upright position until it engages.
Page 126: Security
Chapter 2 2-14 LOCKS SECURITY ALARM Arming and disarming When the button on the key is pressed or when the vehicle is locked using the key in the driver's door lock, the alarm is armed automatically (after a short delay of approximately 30 seconds).
Page 127 Chapter 2 2-15 LOCKS SECURITY cont. The following messages are possible depending upon the model and what has activated the alarm: by Bonnet- if the bonnet has been opened. by Passenger door- if the passenger door has been opened. by Driver's door- if the driver's door has been opened. by Battery disconnect- if the battery has been disconnected.
Page 128 Do not disassemble key. Replacement keys can only be programmed by your Holden Dealer. If the vehicle's key is lost, inform your Holden Dealer immediately so the vehicle can be reprogrammed to no longer recognise the missing key as valid.
Page 129 ........The asterisk signifies equipment options not in all vehicles, model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 130: Chapter 3- Know Your Vehicle
Chapter 3 KNOW YOUR VEHICLE SEATS FRONT SEATS WARNING Do not adjust the driver's seat when the vehicle is moving as the seat could move suddenly causing the driver to lose control. Seat adjustment (seats with a single switch, 4-way) To adjust the height: Move the whole of the switch up to raise the seat.
Page 131 Chapter 3 KNOW YOUR VEHICLE SEATS cont. To tilt the seat forward: Pull the dump latch lever on the side of the seat back. T he seat will tilt forwards. return the seat original position, push the seat back rearward until the latch is locked in position.
Page 132 Chapter 3 KNOW YOUR VEHICLE SEATS cont. Head restraint WARNING This safety feature is not intended as a headrest. It is solely for the reduction of whiplash neck movement in an accident involving your vehicle. The centre of the head restraint should be at eye level, never at neck level.
Page 133: Restraints
Chapter 3 KNOW YOUR VEHICLE RESTRAINTS SEAT BELTS WARNING Seatbelts are designed to bear upon the bony structure of the body, and should be worn low across the front of the pelvis or the pelvis, chest and shoulders, as applicable; wearing the lap section of the belt across the abdominal area must be avoided.
Page 134 Chapter 3 KNOW YOUR VEHICLE RESTRAINTS cont. Lap/sash belts To fasten the seat belt: Pull the metal tongue across your body and clip it into the buckle. When the metal tongue is locked safely into place you will hear a 'click'. Give a gentle pull on the buckle to ensure full engagement.
Page 135: Child Restraints
Chapter 3 KNOW YOUR VEHICLE RESTRAINTS cont. CHILD RESTRAINTS WARNING - EXTREME HAZARD Do not use a rearward facing child restraint on a seat protected by an airbag in front of it. The child could be seriously injured if the airbag inflates, as the child's head would be very close to the inflating airbag.
Page 136 Chapter 3 KNOW YOUR VEHICLE RESTRAINTS cont. Booster seats are for when children outgrow a typical forward-facing child seat but they are still too small for lap/sash seat belts. A booster seat raises the child so that the knees bend comfortably, the lap/sash seat belt is correctly positioned and the child can see out the window.
Page 137 Chapter 3 KNOW YOUR VEHICLE RESTRAINTS cont. Anchorage points Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used for adult seat belts, harnesses, or for attaching other items or equipment to the vehicle. Only child restraints that have clips to attach to the vehicle's anchorage fitting (as shown in the following illustrations) are to be used.
Page 138 Holden child restraint anchor fitting If the child restraint anchor fitting is ever removed ensure that the bolt is securely tightened to 20 ± 5 Nm (Newton metres). Check with your Holden Dealer if unsure. Note If unsure about installing a child restraint anchor fitting, please contact an approved restraint fitting station or your Holden Dealer.
Page 139: Supplemental Restraint System
It is recommended that this work be carried out by a Holden Dealer or approved repairer. The system should also be inspected by a Holden Dealer if the dashboard area or steering wheel is scratched, cracked or damaged.
Page 140 Chapter 3 3-12 KNOW YOUR VEHICLE SUPPLEMENTAL RESTRAINT SYSTEM cont. Airbags and child restraints WARNING - EXTREME HAZARD Do not use a rearward facing child restraint on a seat protected by an airbag in front of it. The child could be seriously injured if the airbag inflates, as the child's head would be very close to the inflating airbag.
Page 141: Seat Belt Pretensioners
If the warning lamp,;· comes on at any other time, or if the warning Airbag Fault is displayed on the instrument panel centre display, have the system checked by your Holden Dealer immediately. Refer to Warning/reminder indications in chapter 1A.
Page 142: Power Windows
Chapter 3 3-14 KNOW YOUR VEHICLE POWER WINDOWS OPERATING THE POWER WINDOWS The power window switches are located between the front seats. The switches are operational when the ignition is switched on or the button on the key is pressed. WARNING Before operating the power windows, check they are free of obstructions and...
Page 143: Mirrors
Chapter 3 3-15 KNOW YOUR VEHICLE MIRRORS EXTERNAL REAR VIEW MIRROR To adjust the external rear view mirrors, switch the ignition on and use the switches in the centre console as follows: Move switch to the right to operate the right hand side mirror. Move switch to the left to operate the left hand side mirror.
Page 144: Internal Mirrors
Chapter 3-16 KNOW YOUR VEHICLE MIRRORS cont. INTERNAL MIRRORS Internal rear view mirror Push the lever on the lower edge of the mirror forwards (away from you) and then adjust the position of the mirror. reduce headlamp glare from following vehicles, pull lever...
Page 145: Interior Lamps
Chapter 3 3-17 KNOW YOUR VEHICLE INTERIOR LAMPS OPERATING THE INTERIOR LAMPS Note The operation of interior lamps is also affected by the battery saver feature. Refer to Battery saver further on in this chapter. Interior (dome) lamp interior lamp located centre-front of the roof.
Page 146 Chapter 3 3-18 KNOW YOUR VEHICLE STORAGE COMPARTMENTS GLOVEBOX T he glovebox is located in the dashboard directly in front of the passenger seat. To open the glovebox, pull the handle towards you. To close, push the lid firmly back into place. A key is provided solely to lock and unlock the glovebox.
Page 147: Storage Compartments
Chapter 3 3-19 KNOW YOUR VEHICLE STORAGE COMPARTMENTS cont. SUNGLASSES HOLDER The sunglasses holder is located in the roof and is designed to accommodate one pair of sunglasses. To open, push in the rear of the lid and release it. To close, swivel the holder back to its original position and press in the rear of the lid to engage the latch.
Page 148 Chapter 3 3-20 KNOW YOUR VEHICLE STORAGE COMPARTMENTS cont. FRONT SEAT-BACK POCKETS A storage pocket is located on the rear of both front seats. VEUD3_076 Net pocket* The net pocket is located at the rear of the cabin, for the storage of lightweight items.
Page 149: Power Socket
Chapter 3 3-21 KNOW YOUR VEHICLE POWER SOCKET The power socket is located inside the centre console. The power socket is operational when the ignition is switched to either ON or ACCESSORIES. Note Any accessory device (e.g. mobile phone, car fridge connected to the power socket must not exceed a current draw of 10 amps.
Page 150: Retained Accessory Power
Chapter 3 3-22 KNOW YOUR VEHICLE RETAINED ACCE SSORY POWER AND BATTERY SAVER RETAINED ACC ESSORY POWER (RAP) The power windows will work when the key is in the ON or ACCESSORIES positions. Once the ignition is switched to LOCK, the RAP allows the power windows to continue to operate for up to 10 minutes.
Page 151: Soft Tonneau Cover
Chapter 3 3-23 KNOW YOUR VEHICLE SOFT TONNEAU COVER* INSTALLING THE TONNEAU COVER Remove the cover, front bar and bows from the tonneau cover bag. VEUD3_080 Installing bows tonneau cover supplied with two bows. Note The front and rear bows are different lengths.
Page 152 Chapter 3 3-24 KNOW YOUR VEHICLE SOFT TONNEAU COVER* cont. Fitting the tonneau cover Place the tonneau cover roughly in position over the tray with the attached bar towards the front of the vehicle. Fit one end of the bar into either the left-hand or right-hand slot as shown.
Page 153 Chapter 3 3-25 KNOW YOUR VEHICLE SOFT TONNEAU COVER* cont. The front edge of the cover has a magnetic strip, ensure it is seated down correctly. VEUD3_084 Lay the tonneau cover over the bows. 10. Starting from the rear, use the finger loops to pull the cover's plastic strip over the slot provided around the top edge of the load area.
Page 154 Chapter 3 3-26 KNOW YOUR VEHICLE SOFT TONNEAU COVER* cont. REMOVING THE TONNEAU COVER Using the finger loops provided, remove the cover by pulling the loops out and up. From underneath the cover, remove the front bar on one side, by pushing it towards the front of the vehicle and tilting down.
Page 155 Chapter 3 3-27 KNOW YOUR VEHICLE SOFT TONNEAU COVER* cont. FITTING THE TONNEAU COVER WITH HIGH LOADS The cover can be adjusted for higher loads. Remove the two bows if required. Attach the front of the cover. Refer to Installing the tonneau cover previously in this chapter.
Page 156: Hard Tonneau Cover
Chapter 3 3-28 KNOW YOUR VEHICLE HARD TONNEAU COVER* WARNING Sitting or standing in the cargo area or on the surface of the hard tonneau cover * while the vehicle is in motion may lead to serious injury or death. Do not carry volatile materials or liquids within the cargo area while the hard tonneau cover * is shut as harmful fumes or gases may accumulate.
Page 157 Chapter 3 3-29 KNOW YOUR VEHICLE HARD TONNEAU COVER* cont. With the aid of an assistant hold the tonneau cover in its open position. Remove the struts from the upper ball pins. Using a small flat-bladed screwdriver, lever retaining clips open approximately 3 mm as shown at While holding the screwdriver and the clip in the open position, remove the...
Page 158 Chapter 3 3-30 KNOW YOUR VEHICLE HARD TONNEAU COVER* cont. VEUD3_097 Raise the tonneau cover at the rear to the point where the hinge tongues can be disconnected from the hinge slots as shown, and remove. Note Take care not to damage the tonneau cover or the vehicle. Ensure there is a enough room above the vehicle.
Page 159: Sports Bar
Chapter 3 3-31 KNOW YOUR VEHICLE SPORTS BAR* Sports bar The sports bar is an appearance item only. It does not provide additional protection in an accident and should not be used as a tie down point for loads. VESD445...
Page 160 Chapter 3 3-32 KNOW YOUR VEHICLE NOTES...
Page 161: Driving
..... . . The asterisk signifies equipment options not in all vehicles, model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 162: Safety
Chapter 4 DRIVING SAFETY BEFORE ENTERING THE VEHICLE Check that windows, mirrors and lamps are clean. Visually check tyre inflation. Note Check the tyre pressures each week. BEFORE DRIVING OFF Ensure that both doors are closed and secured. Position your seat for comfortable driving. Adjust rear view mirrors.
Page 163: Driving Precautions
Chapter 4 DRIVING DRIVING PRECAUTIONS RUNNING-IN There is no need to follow a formal running-in schedule. However, by observing a few simple precautions during the first few hundred kilometres of driving you will greatly assist the vehicle's future performance and economy. Avoid using heavy acceleration for the first 500 km.
Page 164 Chapter 4 DRIVING DRIVING PRECAUTIONS cont. LOADING THE VEHICLE Loading the vehicle changes the mass distribution and therefore the handling when driving. After loading the vehicle, take care to become familiar with the vehicle's driving characteristics. Refer to Loading the vehicle in chapter 9. LOOSE ARTICLES Do not leave loose articles or luggage in the passenger compartment.
Page 165: Park Brake
Chapter 4 DRIVING PARK BRAKE OPERATING THE PARK BRAKE The park brake lever is located between the front seats. Applying the park brake To apply, pull the lever straight up, without pressing the release button. When the ignition is switched on and the park brake is applied, the park brake warning lamp ((D) on the instrument panel illuminates.
Page 166: Engine Starting
Chapter 4 DRIVING ENGINE STARTING Ensure that the park brake is firmly applied and release it only after you have started the engine and are ready to drive off. Manual transmission*: Fully depress the clutch pedal to the floor, shift the gear lever to the Neutral position then crank the engine.
Page 167 Chapter 4 DRIVING TRANSMISSION OPERATION AUTOMATIC TRANSMISSION* Gear selector lever Press the select button on the front of the transmission gear selector lever to move into any position indicated by the arrows.
Page 168: Transmission Operation
Chapter 4 DRIVING TRANSMISSION OPERATION cont. Gear display When the position of the transmission gear selector is changed, an animation is shown on � the instrument panel centre display. The selected gear is magnified and changes according to the selector lever's movement. The gears displayed are P R N D 3 2 1 (vehicles with 4 speed transmission) or P R N D (vehicles with or 6 speed transmission).
Page 169 Chapter 4 DRIVING TRANSMISSION OPERATION cont. 4 speed transmission* selector lever positions Note The engine will not start unless the transmission gear selector is in position P (park) or N (neutral). P (park) In this position, the driven (rear) wheels are locked prevent vehicle from moving.
Page 170 Chapter 4 4-10 DRIVING TRANSMISSION OPERATION cont. Used for general driving. The transmission can shift between all forward gears as required. It is recommended that D be selected with Sport shift mode when towing on the highway at speeds over 80 km/h. Note If on a steep downhill gradient, the transmission may not shift up from 1st to 2nd gear depending on the conditions.
Page 171 Chapter 4 4-11 DRIVING TRANSMISSION OPERATION cont. 5 speed transmission* selector lever positions Note The engine will not start unless the transmission gear selector is in position P (park) or N (neutral). P (park) In this position the driven (rear) wheels are locked to prevent the vehicle from moving.
Page 172 Chapter 4 4-12 DRIVING TRANSMISSION OPERATION cont. D (drive) This is the normal driving position. The transmission automatically selects the appropriate gear according to the current load and driving conditions. After selecting D from PorN, pause for a moment before accelerating, to allow the transmission to engage the forward gear.
Page 173 Chapter 4 4-13 DRIVING TRANSMISSION OPERATION cont. 6 speed transmission* selector lever positions Note The engine will not start unless the transmission gear selector is in position P (park) or N (neutral). P (park) In this position the driven (rear) wheels are locked to prevent the vehicle from moving.
Page 174 Chapter 4 4-14 DRIVING TRANSMISSION OPERATION cont. D (drive) This is the normal driving position. The transmission automatically selects the appropriate gear according to the current load and driving conditions. After selecting D from PorN, pause for a moment before accelerating, to allow the transmission to engage the forward gear.
Page 175 Chapter 4 4-15 DRIVING TRANSMISSION OPERATION cont. 4 SPEED TRANSMISSION Sport shift mode (select the® button) Sport shift mode can be selected where maximum engine power and transmission responsiveness is required. When operated in Sport shift mode, the transmission will delay upshifts and allow earlier downshifts, so that lower gears/higher engine speeds are used for most driving conditions improving vehicle performance and acceleration.
Page 176 Chapter 4 4-16 DRIVING TRANSMISSION OPERATION cont. 5 AND 6 SPEED TRANSMISSION Sport shift mode Sport shift mode can be selected where maximum engine power and transmission responsiveness is required. When operated in Sport shift mode, the transmission will delay upshifts and allow earlier downshifts, so that lower gears/higher engine speeds are used for most driving conditions, improving vehicle performance and acceleration.
Page 177 Chapter 4 4-17 DRIVING TRANSMISSION OPERATION cont. Normal shift mode Normal shift mode is recommended for normal or freeway driving, as it provides optimum fuel economy. When the ignition is switched on, normal shift mode is selected automatically. Normal Normal When normal shift mode is selected (Sport shift Shift Shift...
Page 178 Chapter 4 4-18 DRIVING TRANSMISSION OPERATION cont. Active Select* (AIS) mode cont. When A/S mode is enabled, the Active Select Odometer On animation illuminates in the centre display on • 000,100 km the instrument panel. After 2 seconds it reverts to ••...
Page 179: Manual Transmission
Chapter 4 4-19 DRIVING TRANSMISSION OPERATION cont. MANUAL TRANSMISSION* 6-speed manual - V6 engine Shift patterns T he manual transmissions fitted vehicles with V6 and V8 engines have six forward gears and a reverse gear. T he shift pattern illustrated is also found on the top of the gear shift lever.
Page 180: Active Safety Systems
Note The vehicle's brake system remains operational, but ABS Fault without ABS assistance. Have your Holden Dealer check the system as soon as possible. ABS Fault animation is displayed until the TRIP button on the steering wheel is pressed.
Page 181: Electronic Stability Program (Esp®)
Chapter 4 4-21 DRIVING ACTIVE SAFETY SYSTEMS cont. ELECTRONIC STABILITY PROGRAM (ESP®) Operation The Electronic Stability Program (ESP®) is an advanced feature that works in conjunction with the vehicle's Anti-lock Braking System (ABS) and includes the Traction Control System (TCS). When required, the ESP® improves driving stability in any driving situation.
Page 182 If pressing the � button to switch off the system and the Stability Ctrl Off animation is not shown, or If the animation is shown when you did not switch off the system, a malfunction occurred and the system vvill not vvork. Contact your Holden Dea!cr to have the Stability system checked.
Page 183: Electronic Brake Assist (Eba)
Chapter 4 4-23 DRIVING ACTIVE SAFETY SYSTEMS cont. ELECTRONIC BRAKE ASSIST (EBA) The EBA is incorporated into the ESP® system and detects an emergency braking situation. It recognises how rapidly the brake pedal is applied and automatically provides maximum braking efficiency as long as the brake pedal is depressed. Additionally, the EBA initiates ABS earlier, shortening the stopping distance required.
Page 184 Chapter 4 4-24 DRIVING ON EQUIPMENT SNOW CHAINS Due to lack of clearance, snow chains cannot be fitted to vehicles equipped with the following wheel and tyre configurations: 245/45R18 245/40R19 If these vehicles need to be driven in the snow, the owner should consider changing to the following wheel and tyre configurations: (suitable for V6 vehicles only) 225/60R16...
Page 185: Add On Equipment
FITTING ROO/NUDGE BARS If a roo/nudge bar is to be fitted, it is critical that the Holden approved roo/nudge bar be used. Other types must not be fitted. The Holden roo/nudge bar is available from your Holden Dealer and has been compatibility tested with the vehicle's design, including the Holden airbag system.
Page 186 Chapter 4 4 - 2 6 DRIVING NOTES...
Page 187: Chapter 5 - Fuel
LPG. Holden approved LPG powered vehicles have a specially designed engine that is fitted at the assembly plant. The asterisk signifies equipment options not in all vehicles, model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 188: Fuel
Take the vehicle to your Holden Dealer if you think the vehicle needs inspecting for any of the above reasons.
Page 189 Only clean fuel of good quality should be used. The use of fuel containing more than 10% ethanol may also affect your New Vehicle Warranty to the extent that Holden considers that the fuel affects the specifications and quality of your vehicle.
Page 190 The performance and safety of the vehicle could be seriously jeopardised if converted to LPG. Holden approved LPG powered vehicles have a specially designed engine that is fitted at the assembly plant. For specific details of the approved Holden LPG system please refer to the LPG supplement provided for this option.
Page 191: Emission Control
To ensure continuing compliance with the regulations, you must have the vehicle serviced at the frequency shown in the Maintenance schedule, in the Service/warranty booklet. Your Holden Dealer will maintain the vehicle's emission control system as per the vehicle's service manual.
Page 192: Reducing Fuel Consumption
Chapter 5 FUEL REDUCING FUEL CONSUMPTION ENGINE To keep the engine in peak mechanical condition, have it serviced regularly in accordance with the maintenance schedule. Refer to Maintenance schedule in the Service/warranty booklet. This ensures items such as the spark plugs, air cleaner and engine idle speed are maintained for minimum fuel usage and peak engine performance.
Page 193: In All Vehicles, Model Variants, Engine Options
......The asterisk signifies equipment options not in all vehicles, model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 194 Normally, any problems with the sales, operation, servicing or the validity of original equipment supplied with your vehicle will be handled by your Holden Dealer's Sales and Service Department. We realise however that, with the best intentions, misunderstandings sometimes occur.
Page 195: New Zealand
EMERGENCIES FOR NEW ZEALAND HOLDEN OWNERS The information in this Owner's Handbook applies primarily to Australian Holden vehicles and there may be some differences to the Warranty and Owner Assistance provisions for New Zealand. Applicable details for New Zealand are set out in the Holden Warranty and Owner Assistance Information booklet enclosed in the New Zealand glovebox wallet.
Page 196: Flattyre
Chapter 6 EMERGENCIES FLATTYRE WARNING All passengers must be out of the vehicle when it is being jacked. Do not jack a vehicle with a trailer attached. Remove the trailer first. Only jack the vehicle on hard, level surfaces. Ensure moving parts of the jack are adequately lubricated before use. Use the jack only at the designated lifting points.
Page 197: Changing A Flat Tyre
Chapter 6 EMERGENCIES CHANGING A FLAT TYRE Park on a hard, level surface, in a safe location, and set the park brake firmly. Switch the hazard warning flashers on. Remove the ignition key and place manual transmissions in reverse gear or automatic transmissions in P (park).
Page 198 Chapter 6 EMERGENCIES CHANGING A FLAT TYRE cont. To remove the tool container, undo and remove the retaining nut. Slide the jack package off the bolt and place next to the wheel to be changed. Remove the jack handle, extension bar, wheel wrench and jack from the container.
Page 199 Chapter 6 EMERGENCIES CHANGING A FLAT TYRE cont. Insert the extension bar into the spare wheel lowering slot. Twist the bar back and forth to engage into the carrier. Note lower tailgate while the extension bar is in place. VEUD6 062 10.
Page 200 Place the spare wheel next to the wheel with the flat tyre. Note Spare wheel carrier troubleshooting procedure further on in this chapter was used to lower the spare wheel, the carrier assembly must be inspected and repaired by your Holden Dealer.
Page 201 Chapter 6 EMERGENCIES CHANGING A FLAT TYRE cont. 15. If the wheel trim covers the wheel nuts, remove as follows: If a full wheel cover is fitted, lever it off with the end of the wheel wrench. If a centre cap is fitted that covers the wheel nuts, remove it using the end of the wheel wrench.
Page 202 Chapter 6 6-10 EMERGENCIES CHANGING A FLAT TYRE cont. 20. To use the jack handle, kneel down beside the vehicle to the side of the jack. 21. Grasp the hooked fold out section with one hand as shown. 22. With the other hand turn the handle through 180 degrees until it reaches position 23.
Page 203 Chapter 6 6-11 EMERGENCIES CHANGING A FLAT TYRE cont. WARNING To fully tighten the wheel nuts, the wrench must be fully extended. VEUD6 017 31. Replace any wheel trim or nut cap that was covering the wheel or wheel nuts. Note If a full wheel trim is fitted, the tyre valve must line up with the hole in the wheel trim before refitting.
Page 204 Chapter 6 6-12 EMERGENCIES CHANGING A FLAT TYRE cont. Make sure the wheel is stored securely. Check the security by trying to push and pull then try to turn wheel, as shown. If the wheel moves, use the extension bar and jack handle to tighten the wheel carrier, repeating step to 38.
Page 205 Chapter 6 6-13 EMERGENCIES CHANGING A FLAT TYRE cont. TROLLEY JACK OR VEHICLE HOIST If using a trolley jack or vehicle hoist to raise the vehicle, it is important that the jack be positioned under the centre of the suspension cross member or hoist pad locations, as shown in the illustration.
Page 206: Spare Wheel Carrier Troubleshooting
Chapter 6 6-14 EMERGENCIES SPARE WHEEL CARRIER TROUBLESHOOTING Secondary latch system This vehicle has an underbody-mounted wheel carrier assembly, equipped with a secondary latch system. It is designed to stop the spare wheel from suddenly falling off the vehicle if the cable holding the spare wheel is damaged. WARNING For the secondary latch to work, the tyre must be stored with the valve stem pointing down.
Page 207 12. Wind the extension bar/jack handle clockwise to raise the cable back up if the cable is hanging under the vehicle. WARNING If any of the above spare wheel carrier troubleshooting events occur do not use the spare wheel carrier to hold a wheel until the assembly has been inspected by your Holden Dealer.
Page 208: Towing A Disabled Vehicle
Chapter 6 6-16 EMERGENCIES TOWING A DISABLED VEHICLE WARNING Flat tray towing is the only recommended towing procedure. A slot and rope location is provided to move a bogged or disabled vehicle a short distance or to pull the vehicle onto a flat tray tow truck. Use only wheel lashings to secure the vehicle to the flat tray tow truck.
Page 209 80 km/h for the duration of one hour. When the protection mode is activated, it is advisable to stop the vehicle as soon as it is safe to do so or take the vehicle to the nearest Holden Dealer as soon as possible.
Page 210: Engine Overheating
Chapter 6 6-18 EMERGENCIES ENGINE OVERHEATING cont. LOW COOLANT LEVEL If the level is too low, proceed as follows: WARNING Do not remove the radiator cap if the engine and radiator are still hot. Scalding fluid and steam can be blown out under pressure which could cause serious burns. When the engine has cooled sufficiently, check the coolant reservoir level and radiator level and fill as follows.
Page 211 Refer to Under bonnet checks in chapter 7. If the coolant is low, this may indicate that a problem exists. See your Holden Dealer as soon as possible. VEUD6_019 Note The engine may temporarily operate at high temperatures during demanding...
Page 212: Flat Battery
Please read the following warnings and procedure in full before attempting to jump start the vehicle. If, after reading the following procedure, you are still unsure about 'jump starting', Holden strongly recommends for your safety and that of the vehicle that you seek the assistance of a suitably trained service technician. WARNING Do not push start or tow start either a manual or an automatic vehicle .
Page 213 Chapter 6 6-21 EMERGENCIES FLAT BATTERY cont. Jump starting connection posts The jump start positive and negative posts are located in the engine bay on the • left-hand side of the vehicle. These posts are used instead of a direct connection to a battery. •...
Page 214 Chapter 6 6-22 EMERGENCIES FLAT BATTERY cont. Jump starting procedure Note The battery in both vehicles must have a negative earth and a 12 volt rating. Position the two vehicles so that they are NOT touching. Apply the park brakes. Put automatic transmissions in P (park) and manual transmissions in neutral.
Page 215: Fuse Replacement
Any improper alterations to the electrical system may cause a fire hazard and engine damage. To maintain your own safety and that of the vehicle, have any work involving the electrical system or the replacement of high current fuses or relays carried out by your Holden Dealer.
Page 216 Chapter 6 6-24 EMERGENCIES FUSE REPLACEMENT cont. BATTERY FUSES AND RELAYS The fuse panel is located behind the passenger's seat side battery. Lift up the access flap to locate the fuse panel. Fuse box VEUD6_091...
Page 217 Chapter 6 6-25 EMERGENCIES FUSE REPLACEMENT cont. Battery fuse and relay index Fuses: F1 - REAR SEAT ENTERTAINMENT ....(1 OA) � � C£!:) AMPLIFIER ......(30A) NAVIGATION/ C£D � TELEMATICS/PHONE ..(1 OA) RADIO & INFOTAINMENT .. (15A) INST/DISP/RFA/DLC ..(1 OA) CEIJ F6 - REAR APO* ......
Page 218 Chapter 6 6-26 EMERGENCIES FUSE REPLACEMENT cont. CABIN FUSES AND RELAYS The fuse panel is located in the left hand side kick panel. Use the slot in the fuse panel cover and slide rearwards to reveal the fuse panel. VEUD6_023 VEUD6_024...
Page 219 Chapter 6 6-27 EMERGENCIES FUSE REPLACEMENT cont. Cabin fuse and relay index F16- PHONE/KE Y LKJISRVM/ RAIN SENS ......(10A) Circuit breakers: F17- SUNROOF ......(20A) 81 - WINDOW BATTERY ... (20A) F18- SPARE POWER WINDOWS ... (20A) F19- SPARE POWER SEATS ....
Page 220 Chapter 6 6-28 EMERGENCIES FUSE REPLACEMENT cont. ENGINE COMPARTMENT FUSES AND RELAYS This is the main fuse/relay box. Remove the clip-on cover to gain access. Fuse puller...
Page 221 Chapter 6 6-29 EMERGENCIES FUSE REPLACEMENT cont. Engine compartment fuse and relay index Fuses: FL 1 - SPARE F28- ECM 1 ......... (15A) FL2- REAR DEFOG ....(40A) F29- EVEN COILS/ INJECTORS ......(20A) FL3- ABS MOTOR....... (40A) F30- SPARE FL4- BATT MAIN 3 ......
Page 222: Bulb Replacement
Grease spots on Halogen bulbs will, within a short time, lead to bulb failure. Clean stained bulbs with methylated spirits. BULBS TO BE CHANGED BY A HOLDEN DEALER Fog lamps*. Instrument panel lamps.
Page 223 Chapter 6 6-31 EMERGENCIES BULB REPLACEMENT cont. Unclip the air filter box cover and Headlight move rearward. Disconnect the air Bulbs flow meter connector (V8 only). Location Note When refitting the air filter box cover, ensure that the air filter element and cover are seated correctly.
Page 224 Chapter 6 6-32 EMERGENCIES �ULB REPLACEMENT cont. Front lamp assembly Front turn signal lamp (PY21W amber bulb). Headlamp inboard high beam (H9 bulb, 65W). Headlamp wiring connector. Park lamps (W5W bulb). Headlamp outboard low beam (H7 bulb, 55W). Note Depending on the model variant, the park lamp bulb is in either of the two positions shown.
Page 225 Chapter 6 6-33 EMERGENCIES BULB REPLACEMENT cont. Headlamps- outboard low beam Follow the steps described in section Front lamps previously in this chapter, to gain access to the lamp assembly. Turn outboard dust anti clockwise and remove. Note Take care not to drop the dust cap into the engine compartment.
Page 226 Chapter 6 6-34 EMERGENCIES BULB REPLACEMENT cont. Headlamps- inboard high beam Follow the steps described in section Front lamps previously in this chapter to gain access to the lamp assembly. Turn inboard dust anti clockwise and remove. Note Take care not to drop the dust cap into the engine compartment.
Page 227 Chapter 6 6-35 EMERGENCIES BULB REPLACEMENT cont. Front park lamps * Follow the steps described in section Front lamps previously in this chapter to gain access to the lamp assembly. Remove the outboard low beam dust cover to access the bulb. Note Take care not to drop the dust cap into the engine compartment.
Page 228 Chapter 6 6-36 EMERGENCIES BULB REPLACEMENT cont. Front turn signal Follow the steps described in section Front lamps previously in this chapter to gain access to the lamp assembly. To aid access, remove the outboard dust cap. Note Take care not to drop the dust cap into the engine compartment.
Page 229 Chapter 6 6-37 EMERGENCIES BULB REPLACEMENT cont. REAR LAMPS To gain access to the rear turn signal, stop/tail and reverse bulbs: Remove the 6 scrivets and the access panel Use a flat blade screwdriver to prise outwards under the head of the centre pin of the scrivet.
Page 230 Chapter 6 6-38 EMERGENCIES BULB REPLACEMENT cont. Rear lamp assembly Reverse lamp (P21W bulb). Stop/tail lamp (P21/5W bulb). Turn signal lamp (PY21W amber bulb). Rear lamp wiring connector. Rear turn signal, stop/tail, reverse Follow the steps described in section Rear lamps previously in this chapter to gain access to the lamp assembly.
Page 231 Chapter 6 6-39 EMERGENCIES BULB REPLACEMENT cont. NUMBER PLATE LAMP (WSW BULB) Push the locking tang at the end of the lamp housing towards the lens and pull the lamp assembly downwards. Remove the bulb holder from the lamp housing by rotating the bulb holder anticlockwise.
Page 232 Chapter 6 6-40 EMERGENCIES NOTES...
Page 233 ..... . . The asterisk signifies equipment options not in all vehicles, model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 234: Exterior Checks
Chapter 7 WEEKLY CHECKS EXTERIOR CHECKS MISCELLANEOUS CHECKS As well as taking the vehicle to be serviced, there are a few simple, weekly checks that the owner/operator is recommended to make. These are shown on the following pages. WARNING If the engine temperature is high, the cooling fan may remain on for several minutes after switching off the ignition.
Page 235 Chapter 7 WEEKLY CHECKS EXTERIOR CHECKS cont. TYRES Air pressure Weekly checking of the air pressure in the tyres (including the spare) ensures your safety, as well as reducing fuel consumption and increasing the life of the tyres. For constant long distance or rough road driving, daily checking is recommended.
Page 236 At sustained high speeds, this type of tyre runs at higher temperatures than standard tyres. Only operate them within the limits recommended by the manufacturer. Any doubts about the tyres on the vehicle should be referred to your Holden Dealer.
Page 237 Chapter 7 WEEKLY CHECKS EXTERIOR CHECKS cont. Tyres with a higher speed or load rating are acceptable, provided they are fitted to a suitable rim size. Note New tyres should be fitted in pairs to the front. If replacing only one tyre, it should be paired on the same axle with the least worn of the other three.
Page 238: Under Bonnet Checks
Chapter 7 - 6 WEEKLY CHECKS UNDER BONNET CHECKS UNDER BONNET LAYOUT- V6 ENGINE Page 7-12 Engine coolant reservoir ................. . . 7-14 Brake fluid reservoir .
Page 239 Chapter 7 WEEKLY CHECKS UNDER BONNET CHECKS CONT. UNDER BONNET LAYOUT- VB ENGINE Page Engine coolant reservoir 7-12 ................. . . Brake fluid reservoir 7-14 .
Page 240: Engine Oil
Chapter 7 WEEKLY CHECKS UNDER BONNET CHECKS cont. ENGINE OIL Engine oil level Check the oil level weekly. The level is checked with the dipstick. Refer to Under bonnet layout previously in this chapter for engine oil dipstick location. Checking the engine oil level V6 &...
Page 241 Chapter 7 WEEKLY CHECKS UNDER BONNET CHECKS cont. Engine oil consumption Every internal combustion engine uses a certain amount of oil, especially when running in. The engine is dependent on oil for lubricating critical areas, such as the cylinder walls, pistons, rings and valve stems. These parts are all sub ected to high friction loads and will prematurely wear out without a constant supply of engine oil.
Page 242 If, after taking into account the above factors, you are still concerned that your engine has excessive oil consumption then consult your Holden Dealer. Remember that an 10,000 engine's oil consumption should not be judged until it has run at least...
Page 243: Automatic Transmission Fluid Level
Hot area. The level should never read over the full Hot mark. Note On vehicles fitted with a 5 speed or 6 speed automatic transmission, the fluid will be checked when the vehicle is serviced by your Holden Dealer. Adding transmission fluid Use only Holden specified automatic transmission fluid.
Page 244: Engine Coolant
Chapter 7 7-12 WEEKLY CHECKS UNDER BONNET CHECKS cont. ENGINE COOLANT Engine coolant level Check the coolant level at least once a week. The cap for the coolant reservoir is yellow and has the word DEXCOOL marked on the top. Refer to Under bonnet layout previously in this chapter for coolant...
Page 245 Refer to Specifications in chapter 8 for engine coolant specifications and water-to coolant ratio. Mix a solution of Holden coolant and clean fresh water in a container as per the ratio specified. Note Failure to use the coolant or maintain the specified concentration may result in voiding the New Vehicle Warranty.
Page 246: Brake Fluid
Ensure that the ignition is switched off. Wipe the sides of the cap clean and turn anticlockwise to remove. Top up with heavy duty brake fluid which meets Holden specifications. Refer to Specifications in chapter 8 for the correct specification.
Page 247: Clutch Fluid
Adding clutch fluid Ensure that the ignition is switched off. Wipe the sides of the cap clean and turn anti clockwise to remove. Top up with heavy duty brake fluid which meets Holden specifications. Refer to Specifications in chapter 8. WARNING Use only new fluid.
Page 248: Power Steering Fluid
Top up with power steering fluid which meets Holden specifications. Do not overfill the reservoir. Secure the cap and clean up any spilt fluid. Note lf the power steering fluid requires constant topping up, it could indicate that a fault exists. Contact your Holden Dealer.
Page 249: Washer Fluid
Adding washer fluid For a crystal clear windscreen, the correct amount of Holden washer fluid additive can be added. Refer to Exterior cleaning in chapter 10. Note Do not use ordinary soap or detergent as these not only froth up, but also damage the wiper rubbers.
Page 250: Battery
REPLACEMENT BATTERY The vehicle's battery is located inside the passenger cabin, behind the passenger seat. It is secured behind a small access panel. For battery replacement, refer to your Holden Dealer or authorised repairer. WARNING Do not place heavy objects on the battery cover.
Page 251 ......The asterisk signifies equipment options not in all vehicles, model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 252: Specifications- V6 Engines
120 minutes reserve capacity. WARNING Use only a manufacturer recommended battery with a ventilation system. Use of other batteries may effect the e!ectr!c power management system and allow explosive gases into the vehicle cabin. Refer to your Holden Dealer or authorised repairer.
Page 253: Specifications- V8 Engines
120 minutes reserve capacity. WARNING Use only a manufacturer recommended battery with a ventilation system. Use of other batteries may effect the electric power management system and allow explosive gases into the vehicle cabin. Refer to your Holden Dealer or authorised repairer.
Page 254: General Specifications
Chapter 8 SPECIFICATIONS GENERAL SPECIFICATIONS DIMENSIONS (MM) Omega V-series Length 5055 5040 5040 5040 Width - excl. mirrors 1899 1899 1899 1899 Width - incl. mirrors 2100 2100 2100 2100 Height 1497 1480 1480 1480 3009 Wheelbase 3009 3009 3009 Overhang - front Overhang rear...
Page 255 Chapter 8 SPECIFICATIONS IDENTIFICATION LABELS 0 COOLING SYSTEM/ AIR CONDITIONING LABEL This label shows the warnings for the air conditioning and cooling system as well as information on the air conditioning refrigerant and compressor oil. 0 BODY AND OPTION PLATE This plate shows model identification, Vehicle Identification...
Page 256 = active belts with driver, passenger and side airbags = act1ve belts with driver, passenger, side and curtain airbags Body style code: Luxury level: Omega/SV6/SS, P = SS-V Model series: E World manufacturer identifier: 6 =Asia Pacific, G =Australia, = GM Holden...
Page 257: Identification Labels
Chapter 8 SPECIFICATIONS IDENTIFICATION LABELS cont. ENGINE NUMBERS V6 engine The engine number is located at the rear of the engine on the passenger's side. Note The engine number must be viewed from under the vehicle. V8 engine The engine number is located at the front of the engine on the driver's side.
Page 258 Chapter 8 SPECIFICATIONS NOTES...
Page 259 ......... . . The asterisk signifies equipment options not in all vehicles, model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 260 Chapter 9 T OW AND LOAD LOADING THE VEHICLE MAXIMUM FRONT AND REAR AXLE LOADS Do not exceed the maximum axle loads shown in the diagram, including the weight of any fitted accessories. If unsure, the vehicle should be weighed at a weighbridge. T his ensures the vehicle's axles have sufficient strength to carry the total weight and still retain a considerable capacity safety margin to cope with weight transfer as the vehicle brakes, accelerates, corners and goes over bumps.
Page 261 Chapter 9 TOW AND LOAD LOADING THE VEHICLE cont. NO TES ON LO ADING THE VEHICLE Place heavy objects in the rear load area as far forward as possible against the rear bulkhead. When stacking objects, place the heavier objects at the bottom. Unsecured objects in the rear load area could be thrown forward with great force during heavy braking or in an accident.
Page 262 Chapter TOW AND LOAD LOADING THE VEHICLE cont. SECURING CARGO WARNING Do not operate the vehicle with the tailgate in the open position as cargo may fall from the load area and the number plate will be obscured from view. Do not use the moulded ribs in the rear load area to secure cargo.
Page 263 Holden will not accept liability for defects occurring in towing equipment not marketed by Holden or for defects in the vehicle arising from the use of such equipment or for loss or injury caused by use of such equipment. The use of such equipment may void your New Vehicle Warranty, to the extent that Holden considers the non...
Page 264 Ensure the weight of the packed trailer is not greater than the towing capacity of the Holden approved tow bar package fitted to the vehicle. Towing with Electronic Stability Program (ESP®) When towing with a vehicle fitted with ESP®, you may hear the noise of the ESP®...
Page 265 Chapter 9 TOW AND LOAD TOWING cont. TOWING EQUIPMENT Recommended equipment Tow load Mandatory equipment Holden 1,600 kg rated tow bar. Up to 750 kg Holden trailer wiring harness. Holden 1,600 kg rated tow bar. Load distribution hitch. Between 751 kg Holden trailer wiring harness.
Page 266 Chapter 9 TOW AND LOAD TOWING cont. TOWING PRECAUTIONS When heavily loading the vehicle or when towing, the tyres should be inflated to the maximum recommended pressure. Refer to Tyres in chapter 7 for tyre placard location and information about tyre pressures. Ensure that a load distribution hitch is correctly distributing the tow ball load.
Page 267 ......The asterisk signifies equipment options not in all vehicles, model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 268 Chapter 10 10-2 CLEANING INTERIOR CLEANING WARNING Many cleaning products are toxic, flammable or may damage the interior. When cleaning the interior, avoid volatile cleaners such as acetone, lacquer thinners, enamel reducers, nail polish removers, or cleaners such as laundry soaps, bleaches or reducing agents.
Page 269 Do not bleach or dye seat belts as this may severely weaken them. INTERIOR GLASS Clean interior glass of the vehicle using a good quality glass cleaner, such as Holden Glass Cleaner, and a clean soft cloth. Take care when cleaning inside the rear window so as not to damage the rear window de mister.
Page 270 Chapter 10 10-4 CLEANING EXTERIOR CLEANING CARING FOR PAINT WARNING Do not spill coolant on the vehicle's exterior surfaces as it can damage the paint work. If y ou wash it off immediately. To help preserve that shiny new vehicle finish, pay special attention to correctly treating those conditions that can damage the paint.
Page 271 Do not use a sponge or cloth at this point. Fill a bucket with lukewarm water and add no more than two capfuls of gentle detergent, such as Holden Hi Suds Car Wash. Do not use hot water, strong soap or chemical detergents.
Page 272 Chapter 10 10-6 CLEANING EXTERIOR CLEANING cont. AIR INTAKES The intake area between the bonnet and windscreen can collect leaves which impairs air flow into the vehicle. Also, the air intake area below the front bumper can collect leaves and road grime, which impairs engine cooling. Refer to Exterior checks in chapter 7.
Page 273 However, the use of a good quality Polymer Glaze, such as Holden Quick and Easy Speed Finish, approximately every 3 months will reduce the effects of road bloom by removing natural contaminants which can build up on the paint.
Page 274 Use a good quality glass cleaner, such as Holden Glass Cleaner, and wash each section of glass in turn, making sure that the water, its container and the sponge are quite clean and free from grit.
Page 275 Chapter 10 10-9 CLEANING CLEANING PRODUCTS Part number Size Description Usage Seals in a deep, lustrous glazed finish. Quick and Easy 92145132 Long life protection from oxidation, salt Speed Finish and weather damage. Seals in a deep, lustrous glazed finish. Quick and Easy 92145418 Long life protection from oxidation, salt...
Page 276 Chapter 10 10-10 CLEANING NOTES...
Page 277 INDEX Audio system cont... CD changer 4-20 ..........operation ......
Page 278 INDEX cont. Central locking ......2-2, 2-7 Automatic transmission ..... 4-7 Active select ....1A-13, 4-17 Changing a flat tyre ......6-5 Fluid level........7-11 Troubleshooting (spare wheel carrier) ....6-14 Gear display ......... 4-8 Child restraints ........3-7 Gear selector lever ......
Page 279 INDEX cont. Demister, windscreen Engine with climate control ....1A-42 Overheating ....... 6-17 with manual heater ....1 A-37 Specifications ......8-2, 8-3 Dimensions ........8-4 Starting ........4-6 Dimmer, instrument lighting ... 1 A-29 Temperature warning ....1 A-1 0 Dipping headlamps ......
Page 281 INDEX cont. Oil cont. Lights cont ... Light switch ......1A-29 Consumption ........ 7-9 Night panel mode ..... 1A-29 Dipstick ........7-8 Park lamps ....... 1 A-29 Low pressure warning ....1A-8 Personal identity keys ....1 A-31 Overheating ........6-17 Turn signals ......
Page 282 INDEX cont. Supplemental Restraint System (SRS) 3-11 Safety mode warning 1A-14 ..........
Page 283 INDEX cont. Warning/reminder indications cont .. Rest reminder ......1A-12 Underspeed ....... 1A-21, 1A-23 Safety mode active ....1 A-14 Seat belt pretensioner ....1 A-1 0 Vanity mirrors ........3-16 Seat belt warning lamp .... 1A-17 Vehicle identification number ..8-5, 8-6 Security warning lamp .....

HOLDEN VE UTE 2007 Owner's Handbook Manual

Table of Contents

Audio

Locks

Know Your Vehicle

Driving

Emergencies

Weekly Checks

Specifications

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for HOLDEN VE UTE 2007

Summary of Contents for HOLDEN VE UTE 2007

Table of Contents
