Page 1 EP EPICA EP Epica Owner’s Handbook...
Page 2 Change of name, address or ownership In the event of a Safety Recall, or for various reasons, Holden may need to contact you as the owner of this vehicle. If you have recently changed your address, or name, or purchased this vehicle second-hand, please help us to help you by taking a few minutes to fill in and mail the forms at the beginning of the Service/warranty booklet.
Page 3: Table Of Contents
CHAPTERS Dashboard ........... 1A Audio ............ 1B Locks ............2 Know your vehicle ........3 Driving .............4 Fuel ............5 Emergencies ...........6 Weekly checks ........7 Specifications .........8 Tow and load ...........9 Cleaning ..........10 Index...
Page 4 Please note that all information, illustrations and specifications in this Handbook are based on the latest production information available at the time of printing. Holden reserves the right to make changes at any time without notice and without incurring any obligation.
Page 5 Reducing fuel consumption Steering wheel audio controls Chapter 6 – Emergencies General information Customer assistance – Australia Chapter 2 – Locks For New Zealand Holden owners Changing a flat tyre Keys Door locks Towing a disabled vehicle Security Engine overheating...
Page 6 Chapter 7 – Weekly checks Chapter 9 – Tow and load Exterior checks Loading the vehicle Under bonnet checks Towing Battery Chapter 10 – Cleaning Chapter 8 – Specifications Interior cleaning Specifications 2.5 litre engine Exterior cleaning Specifications 2.0 litre engine Cleaning Products General specifications Index...
Page 7 Lights ......... 1A-18 Cruise control ......1A-20 Ventilation system...... 1A-22 Manual heater, air conditioning ......1A-23 ......1A-27 Climate control The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 8 1A-2 Chapter 1A DASHBOARD DASHBoARD lAyouT lAyouT InDEx CDx Page  Passenger vent ....................1A-22  Centre vents....................1A-22  Clock ......................1A-15 Dashboard storage compartment ..............3-24   Hazard warning switch ...................1A-16  Lever for wipers and washers ................1A-17  Instruments ......................1A-6 ...
Page 9: Dashboard
1A-3 Chapter 1A DASHBOARD DASHBoARD lAyouT cont. V250_1A079...
Page 10 1A-4 Chapter 1A DASHBOARD DASHBoARD lAyouT cont. lAyouT InDEx CDxi Page Passenger vent 1A-22   Centre vents....................1A-22  Clock ......................1A-15  Driver Information Display (DID) ..............1A-12  Sunlight sensor ....................1A-33 Dashboard storage compartment ..............3-24   Hazard warning switch ...................1A-16 ...
Page 11 1A-5 Chapter 1A DASHBOARD DASHBoARD lAyouT cont. CDxi �...
Page 12 1A-6 Chapter 1A DASHBOARD InSTRumEnTATIon InSTRumEnTS Tachometer  The tachometer shows engine speed in thousands of revolutions per minute (RPM). Speedometer  The speedometer shows vehicle speed in kilometres per hour (km/h). Fuel gauge  The fuel gauge shows the level of fuel in the fuel tank when the ignition is on: E = empty, F = full.
Page 13 Stop when safe, switch off the engine and check the engine oil level. Refer to Engine oil level in chapter 7. Do not run the engine when this warning is illuminated. If the oil level is normal, have the system checked at the nearest Holden Dealer.
Page 14 If the v warning lamp illuminates when driving, it indicates that the airbag system or seatbelt pretensioner system may not function correctly in an accident. Contact your Holden Dealer immediately. Note The v warning lamp illuminates after an accident if the airbag(s) and/or pretensioners have activated.
Page 15 If the warning lamp does not extinguish or illuminates when driving, it indicates a malfunction with the TCS. Contact your Holden Dealer immediately. warning lamps illuminate when the traction control has been turned off by pressing the TCS switch.
Page 16 Holden Dealer as soon as possible. If the Z lamp flashes while driving, reduce the vehicle’s speed and load, until the lamp stops flashing, then take the vehicle to a Holden Dealer as soon as possible. Driver’s seatbelt warning lamp The X warning lamp reminds the driver to fasten their seatbelt.
Page 17 1A-11 Chapter 1A DASHBOARD WARnIng/REmInDER InDICATIonS cont. Turn signals The appropriate arrow flashes when the lever on the right side of the steering column is moved up or down with the ignition switched on. Note • Both arrows flash when the hazard warning flasher is switched on.
Page 18 1A-12 Chapter 1A DASHBOARD DRIvER InfoRmATIon DISPlAy (DID) Information display V250_1A055 The Driver Information Display (DID) provides visual information for the trip computer, climate control system and the compass when the ignition switch is in the ON position. TRIP ComPuTER Press the MODE button on the left-hand side of the information display to scroll between the trip computer displays.
Page 19 1A-13 Chapter 1A DASHBOARD DRIvER InfoRmATIon DISPlAy (DID) cont. Driving distance for remaining fuel Driving distance for remaining fuel is an estimate of how far the vehicle will travel on the current amount of fuel. It is based on previous fuel usage and is frequently updated.
Page 20 1A-14 Chapter 1A DASHBOARD DRIvER InfoRmATIon DISPlAy (DID) cont. Compass The compass displays the vehicle’s driving direction (N, NE, E, SE, S, SW, W, NW). Note The direction will be displayed when the ignition is on. Compass calibration The compass needs to be calibrated the first time it is used or when the battery has been disconnected.
Page 21 1A-15 Chapter 1A DASHBOARD CloCk Digital clock When the ignition is in the ACC or ON position, the digital clock displays the time. There are 3 adjusting buttons: H Hour button. To advance 1 hour, press the H button. • •...
Page 22 1A-16 Chapter 1A DASHBOARD STEERIng, HoRn, HAzARD WARnIng TIlT STEERIng WArNINg WArNINg Do not attempt to adjust the steering Do not attempt to adjust the steering wheel while driving. wheel while driving. 1. To adjust the steering wheel, pull the lock lever on the side of the steering column backwards (towards you) and hold.
Page 23 1A-17 Chapter 1A DASHBOARD WIPERS AnD WASHERS oPERATIng THE WIPERS AnD WASHERS The lever on the left side of the steering column controls the wipers and washers. They operate when the ignition is switched to the ON position. WArNINg Never operate the wipers on dry glass, as this will damage the rubber and scratch the glass.
Page 24 1A-18 Chapter 1A DASHBOARD lIgHTS ExTERIoR lIgHTS Light switch Rotate the end of the lever to one of the following positions to turn the headlamps and park lamps on or off. OFF = Off Turns the headlamps and park lamps off. 8 = Park lamps Turns on the park, tail, rear number plate lamps and instrument panel lighting.
Page 25 1A-19 Chapter 1A DASHBOARD lIgHTS cont. > = Fog lamps • To turn the fog lamps on, rotate the collar up with the ignition switched on and the headlamp switch set to 8 or 9 P. The collar will then return to its original position.
Page 26 1A-20 Chapter 1A DASHBOARD CRuISE ConTRol oPERATIng CRuISE ConTRol The cruise control maintains the vehicle’s speed without having your foot on the accelerator pedal. The cruise control buttons are located on the right side of the steering wheel. Note The cruise control will only operate at speeds above 30 km/h.
Page 27 1A-21 Chapter 1A DASHBOARD CRuISE ConTRol cont. Turning the cruise control off Press the ON OFF button. lamp extinguishes. Note Switching off the ignition deactivates cruise control and clears the speed memory. WArNINg • Do not use the cruise control when road or driving conditions require varying speeds.
Page 28 1A-22 Chapter 1A DASHBOARD vEnTIlATIon SySTEm The vehicle features a flow-through ventilation system for comfort. Under reasonable conditions, it should not be necessary to open the windows at any time. Outside air is drawn into the vehicle through the opening between the bonnet and the windscreen, unless recirculation has been selected.
Page 29 1A-23 Chapter 1A DASHBOARD mAnuAl HEATER, AIR ConDITIonIng   Fan speed control Rear window demister   Air conditioning (A/C) button Mode control   Temperature control Recirculation button Fan speed  Turn the control clockwise to increase the fan speed or anticlockwise to reduce it. Turn it anticlockwise to turn the fan off.
Page 30 1A-24 Chapter 1A DASHBOARD mAnuAl HEATER, AIR ConDITIonIng cont. Mode control Select one of the air flow modes  bellow. Face mode directs air to all the dashboard vents. Bi-level mode directs approximately half of the air to the dashboard vents, then directs the remaining air to the front and rear floor outlets.
Page 31 1A-25 Chapter 1A DASHBOARD mAnuAl HEATER, AIR ConDITIonIng cont. Air conditioning For a quick cool down when first entering the vehicle on a hot day: 1. Press the A/C button  to switch on the air conditioning. 2. Press the ...
Page 32 Pollen/dust filter A passenger compartment air filter is fitted to filter outside air entering the vehicle. The filter removes contaminants such as pollen and dust. The pollen/dust filter will be serviced as per the service schedule by your Holden Dealer.
Page 33 1A-27 Chapter 1A DASHBOARD ClImATE ConTRol The climate control panel is located in the centre of the dashboard. It is designed to maintain the interior of the vehicle at the desired temperature.   Air conditioning (A/C) button Rear window demister AUTO button ...
Page 34 1A-28 Chapter 1A DASHBOARD ClImATE ConTRol cont. Temperature control  Turn the temperature control clockwise (warmer) or anticlockwise (cooler). The temperature can be set between 18 °C and 32 °C (a setting between 22 °C and 24 °C is recommended). The temperature setting is shown on the information display.
Page 35 1A-29 Chapter 1A DASHBOARD ClImATE ConTRol cont.  Turn the fan speed control clockwise to increase the fan speed or anticlockwise to decrease the fan speed. The fan speed is shown on the information display. Note • The climate control sets the fan speed automatically.
Page 36 1A-30 Chapter 1A DASHBOARD ClImATE ConTRol cont. A/C button Press the A/C button  to switch the air conditioning on and off. indicator lamp button illuminates and n appears on the information display when conditioning is on. Note • To conserve fuel, the air conditioning V250_1A068 may be switched off in cold weather.
Page 37 1A-31 Chapter 1A DASHBOARD ClImATE ConTRol cont. Windscreen demist button The climate control cannot determine if the windscreen needs demisting. Press the V button  to demist the windscreen and side windows. The system changes the outlets to demist and switches on the air conditioning.
Page 38 1A-32 Chapter 1A DASHBOARD ClImATE ConTRol cont. noTES What the system does In automatic operation the system responds quickly to cooling and heating requirements. It is not necessary to set a cooler or hotter temperature than required to ensure fast cooling or heating.
Page 39 Pollen/dust filter A passenger compartment air filter is fitted to filter outside air entering the vehicle. The filter removes contaminants such as pollen and dust. The pollen/dust filter will be serviced as per the service schedule by your Holden Dealer.
Page 40 1A-34 Chapter 1A DASHBOARD noTES...
Page 41 MP3 player operation ... 1B-11 Steering wheel audio controls ........ 1B-15 General information ..... 1B-18 Glossary of terms ....1B-21 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 42 1B-2 Chapter 1B AUDIO AuDIo SySTEm SInglE CD PlAyER ConTRolS Display and functions: Power/volume and mute Tune and previous/next buttons rotary button Sound mode selection button SCAN/AST button INFO/DISP button Display screen < Auxiliary input socket Seek tuning buttons Preset radio station buttons and Directory button CD/MP3 mode function buttons: CD/MP3 disc slot...
Page 43: Audio
1B-3 Chapter 1B AUDIO AuDIo SySTEm cont. SIx CD CHAngER ConTRolS CDXi Display and functions: Power/volume and mute INFO/DISP button rotary button < Auxiliary input socket SCAN/AST button Preset radio station buttons and Display screen CD/MP3 mode function buttons: Seek tuning buttons •...
Page 44 1B-4 Chapter 1B AUDIO AuDIo SySTEm cont. AuDIo DISPlAy SCREEn V250_1B005 Display screen layout: MP3 play mode indicator (all directories on the disc) MP3/WMA disc play indicator MP3 play mode indicator Radio mode indicator (directory of the disc only) Disc insert indicator Equaliser mode indicator Weak FM signal indicator <...
Page 45 If the Security Card is lost and the PIN Code has not been recorded, the PIN Code can be requested from your GM Holden Dealer. Proof of ownership will be requested before the PIN Code is supplied. There may be a charge for this service.
Page 46 1B-6 Chapter 1B AUDIO AuDIo SySTEm cont. ConTRol BuTTonS Power on When the power is OFF press the power volume and mute rotary button to activate the audio system. The radio, CD or MP3 function will be shown on the display screen. The operating mode will be the same as before the audio system was turned off.
Page 47 1B-7 Chapter 1B AUDIO AuDIo SySTEm cont. Bass control Bass control is used to adjust the bass (low frequency) sound quality. 1. Select the bass control mode using the button SOUND 2. When BAS appears on the information display screen , rotate the power/ volume and mute rotary button...
Page 48 1B-8 Chapter 1B AUDIO AuDIo SySTEm cont. Balance control Balance control adjusts the volume separation between left and right audio speakers. 1. Select the balance control mode using the button SOUND will show BAL right or left depending on the last setting used. The display screen 2.
Page 49 1B-9 Chapter 1B AUDIO AuDIo SySTEm cont. Automatic tuning 1. Use the buttons to search for a receivable station. 2. To search for the next receivable station push and hold for more then one second either seek up or down arrow. Automatic tuning sensitivity When a seek tuning search is initiated, the radio automatically searches for the stronger (local) stations.
Page 50 1B-10 Chapter 1B AUDIO AuDIo SySTEm cont. CD player operation 1. Press the power/volume and mute rotary button or insert a CD to activate the audio system. 2. If no CD is in the CD/MP3 disc slot insert a CD, label side upwards into the CD/MP3 disc insert slot The audio system will automatically begin playing the CD disc from the first track.
Page 51 1B-11 Chapter 1B AUDIO AuDIo SySTEm cont. repeat play 1. To repeatedly listen to the current CD audio track, press the button grouped with the preset radio station and CD/MP3 mode function buttons rPT will appear on the display screen and the current audio track will be played repeatedly until the function is cancelled.
Page 52 1B-12 Chapter 1B AUDIO AuDIo SySTEm cont. Note • This audio system will support the playback of audio files recorded on various formats of recordable media. These include CD-R and CD-RW. • The ability of the audio system to play back the recorded audio files is dependant on a number of factors.
Page 53 1B-13 Chapter 1B AUDIO AuDIo SySTEm cont. repeat play 1. To repeatedly listen to the current MP3 audio file, press the button grouped < with the preset radio station and CD/MP3 mode function buttons rPT will appear on the display screen and the current audio file will be played repeatedly until the function is cancelled.
Page 54 1B-14 Chapter 1B AUDIO AuDIo SySTEm cont. Directory up and down For this function to operate, the MP3 disc must be recorded with multiple audio file directories or albums. 1. To change the directory, press the buttons . The selected directory will appear briefly on the display screen .
Page 55 1B-15 Chapter 1B AUDIO AuDIo SySTEm cont. STEERIng WHEEl AuDIo ConTRolS Power button ON/OFF and mute function 1. To turn the audio system ON using the steering wheel remote control, press the PWr button. 2. Pressing the power button again will enable the mute function or disable the mute function.
Page 56 1B-16 Chapter 1B AUDIO AuDIo SySTEm cont. Cue (fast forward) 1. To search for a point within the current audio track being played, press and hold the SEEK button for more than 0.5 second. The playback will increase speed to 6 times normal playback speed. 2.
Page 57 Do not add a label to the CD, it could get caught in the CD player, If a CD requires a label try using a CD marking pen instead. Note If a disc error occurs repeatedly see your Holden Dealer. LOAD: Press this button to load CDs into the CD player, the player will hold six CDs.
Page 58 AuDIo SySTEm cont. gEnERAl InfoRmATIon Audio system faults In case of faulty operation, consult your Holden Dealer. Antenna The antenna is incorporated in the rear window. The antenna is part of the heated rear window demister pattern. This type of antenna may be adversely affected by dirt on the inside of the window or damage to the antenna pattern.
Page 59 1B-19 Chapter 1B AUDIO AuDIo SySTEm cont. Peculiarities of FM mobile reception A mobile FM receiver can not be expected to continuously provide the quality of FM reception you may have experienced on your home receiver. Contrary to popular opinion, FM broadcasts are not static free, and although your new radio has a built-in electronic interference absorption circuit some static will be evident from time to time especially in areas without a direct line of sight to the transmitter.
Page 60 1B-20 Chapter 1B AUDIO AuDIo SySTEm cont. Care of your CD • Handle the CD by its edge and avoid touching the playing surface. Directly after removal from CD/MP3 slot, place the CD into the CD cover to prevent damage or soiling. •...
Page 61 1B-21 Chapter 1B AUDIO AuDIo SySTEm cont. gloSSARy of TERmS Automatic station search Station search by tuner. The tuner will search until a station is found. Auto store (AST) The best receivable stations in the FM and AM wave bands can automatically be stored.
Page 62 1B-22 Chapter 1B AUDIO noTES...
Page 63 Locks Page Keys..........2-2 Door locks........2-5 Security...........2-8 Boot lock ........2-10 Bonnet lock ........2-11 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 64 Note Even if a key has the same profile it will not start the engine if the electronic code is incorrect. In the event of the original keys being lost, any additional or replacement keys must be purchased from and programmed by your Holden Dealer, using your key code number. Lock/unlock: Press the...
Page 65: Locks
Holden Dealer. Remember to bring any additional transmitters so they can also be re-coded to match the new transmitter. Once your Holden Dealer has coded the new transmitter, the lost transmitter will not unlock your vehicle. Up to 4 keys can be matched to your vehicle at the same time.
Page 66 (anticlockwise) and unlocked (clockwise) by turning the key in the driver’s door lock. • If the vehicle is delivered with only one key, notify your Holden Dealer immediately. • Always store spare keys in a safe, dry place.
Page 67 Chapter 2 LOCKS DooR loCkS loCkIng Doors are locked when the lock snib is flush with the door handle. If the snib is showing red, the door is unlocked. Refer to Door lock snibs further on in this chapter. remote locking When the vehicle is unlocked, close all doors and then press the button on...
Page 68 Chapter 2 LOCKS DooR loCkS cont. unloCkIng Doors are unlocked when the lock snib is showing red. If the snib is flush with the door handle, the door is locked. Refer to Door lock snibs further on in this chapter. remote unlocking When the vehicle is locked, press the button on the key to unlock all doors...
Page 69 Chapter 2 LOCKS DooR loCkS cont. DooR loCk SnIBS To lock any door from the inside, push the door lock snib flush with the door handle. To unlock any door from the inside, pull the door lock snib. Note • The driver’s door lock snib will lock and unlock all doors.
Page 70 Otherwise, after 30 seconds, the alarm will automatically stop and the system will lock the doors and reset the alarm. If the system does not operate as described above, have it checked by your Holden Dealer.
Page 71 • Replacement keys can only be programmed by your Holden Dealer. • If the vehicle’s key is lost, inform your Holden Dealer immediately so the car can be reprogrammed to no longer recognise the lost key as valid. • A maximum of 4 keys can be programmed to suit one vehicle.
Page 72 2-10 Chapter 2 LOCKS BooT loCk unloCkIng THE BooT Use one of the methods shown below to unlock/open the boot. After partially opening the boot lid, gas struts automatically take over to lift and hold the boot lid in the fully open position.
Page 73 2-11 Chapter 2 LOCKS BonnET loCk oPEnIng THE BonnET From the driver’s side of the vehicle, pull the lever towards you. This allows the bonnet to release but is prevented from opening by the safety catch. To open the bonnet completely, reach under the front edge of the bonnet and push the bonnet release lever to the passenger’s side of the vehicle.
Page 74 2-12 Chapter 2 LOCKS noTES...
Page 75 Supplemental restraint system ..3-12 Power windows......3-19 Mirrors ..........3-20 Interior lamps ........3-22 Assist grips ........3-23 Storage compartments ....3-24 Power socket ........3-29 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 76: Know Your Vehicle
Chapter 3 KNOW YOUR VEHICLE SEATS fRonT SEATS WArNINg – SIDE IMPACT AIrBAgS (SIAB) Do not fit unauthorised seat covers as they may impair the deployment of the SIAB. Do not position your body or any object (including pillows) between front seats and doors.
Page 77 Chapter 3 KNOW YOUR VEHICLE SEATS cont. Front head restraint WArNINg • This safety feature is not intended as a headrest. It is solely for the reduction of whiplash neck movement in an accident involving your vehicle. • The centre of the head restraint should be at eye level, never at neck level. To raise the height of the head restraint, lift the head restraint upwards.
Page 78 Chapter 3 KNOW YOUR VEHICLE SEATS cont. REAR SEAT Folding rear seat back The rear seat may be folded forwards in two separate sections (60/40) to gain access to the boot area or for carrying long loads. To fold a section forward, press the corresponding release lock button (located at the top of the rear seat back) all the way down and fold the section forward.
Page 79 Chapter 3 KNOW YOUR VEHICLE SEATS cont. rear head restraints WArNINg • This safety feature is not intended as a headrest. It is solely for the reduction of whiplash neck movement in an accident involving your vehicle. • The centre of the head restraint should be at eye level, never at neck level. To raise the height of the head restraint, push the locking button in and lift the head restraint upwards.
Page 80 Chapter 3 KNOW YOUR VEHICLE RESTRAInTS SEATBElTS WArNINg • Seatbelts are designed to bear upon the bony structure of the body, and should be worn low across the front of the pelvis or the pelvis, chest and shoulders, as applicable; wearing the lap section of the belt across the abdominal area must be avoided.
Page 81 Chapter 3 KNOW YOUR VEHICLE RESTRAInTS cont. Lap/sash belts To fasten the seatbelt: • Pull the metal tongue across your body and clip it into the buckle. • When the metal tongue is locked safely into place you will hear a ‘click’. •...
Page 82 Chapter 3 KNOW YOUR VEHICLE RESTRAInTS cont. CHIlD RESTRAInTS WARNING AVERTISSEMENT ADVERTENCIA WArNINg – EXTrEME HAZArD • Do not use a rearward facing child restraint on a seat protected by an airbag in front of it. The child could be seriously injured if the airbag inflates, as the child’s head would be very close to the inflating airbag.
Page 83 Chapter 3 KNOW YOUR VEHICLE RESTRAInTS cont. Young children Forward facing child seats are for use when the child is able to sit and easily hold his or her head upright. It is also possible to purchase convertible seats which can be used as a rearward facing child restraint or converted to a forward facing child seat.
Page 84 3-10 Chapter 3 KNOW YOUR VEHICLE RESTRAInTS cont. Anchorage points WArNINg • Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used for adult seatbelts, harnesses, or for attaching other items or equipment to the vehicle.
Page 85 3-11 Chapter 3 KNOW YOUR VEHICLE RESTRAInTS cont. To attach top strap of child restraint: 1. Open up the lid of anchor point (A). 2. Pull bracket (B) of the anchor towards the front of the vehicle. 3. Raise the head restraint in the position where the child restraint is to be used.
Page 86 Holden Dealer immediately, as the airbags and seatbelt pretensioners may not function correctly in the event of an accident. The system should also be inspected by a Holden Dealer if the dashboard area or steering wheel is scratched, cracked or damaged, or, if Side Impact Airbags (SIAB) are fitted, the front seats and upholstery are damaged.
Page 87 3-13 Chapter 3 KNOW YOUR VEHICLE SuPPlEmEnTAl RESTRAInT SySTEm cont. Airbags and child restraints WARNING AVERTISSEMENT ADVERTENCIA WArNINg – EXTrEME HAZArD • Do not use a rearward facing child restraint on a seat protected by an airbag in front of it. The child could be seriously injured if the airbag inflates, as the child’s head would be very...
Page 88 3-14 Chapter 3 KNOW YOUR VEHICLE SuPPlEmEnTAl RESTRAInT SySTEm cont. Front airbags The driver’s airbag is stored inside the steering wheel. AIrBAg is stamped on the steering wheel and a label is attached on both sides of the passenger side sun visor. WArNINg •...
Page 89 3-15 Chapter 3 KNOW YOUR VEHICLE SuPPlEmEnTAl RESTRAInT SySTEm cont. Passenger sensing system If the vehicle is equipped with a passenger sensing system for the front passenger seat, the warning lamp illuminates for 6 seconds when the ignition is switched on to check the lamp is working.
Page 90 3-16 Chapter 3 KNOW YOUR VEHICLE SuPPlEmEnTAl RESTRAInT SySTEm cont. Side Impact Airbags (SIAB) Side Impact Airbags (SIAB) for the driver and front passenger are stored in the side of the seat backs closest to the door. If the vehicle is fitted with SIAB, there will be labels on the outer side of both front seats.
Page 91 3-17 Chapter 3 KNOW YOUR VEHICLE SuPPlEmEnTAl RESTRAInT SySTEm cont. Curtain airbags If the vehicle is fitted with curtain airbags there will be labels on the vehicle in the positions shown. Curtain airbags are stored in the roof area, just above the front and rear doors. The curtain airbag only deploys on the side of the vehicle that is struck.
Page 92 This is designed to remind you that the pretension system has been used and therefore needs to be replaced by your Holden Dealer. The seatbelts will remain operational.
Page 93 3-19 Chapter 3 KNOW YOUR VEHICLE PoWER WInDoWS oPERATIng THE PoWER WInDoWS The power window switches are located on the driver’s door, while individual switches are located on all other doors. The switches are operational when the ignition is switched on. •...
Page 94 3-20 Chapter 3 KNOW YOUR VEHICLE mIRRoRS ExTERnAl REAR vIEW mIRRoR To adjust the external rear view mirrors, switch the ignition on and use the switch located on the driver’s side of the instrument panel as follows: • Move the centre toggle switch to the right to operate the right hand side mirror.
Page 95 3-21 Chapter 3 KNOW YOUR VEHICLE mIRRoRS cont. InTERnAl mIRRoRS Internal rear view mirror Push the lever on the lower edge of the mirror forwards (away from you) and then adjust the position of the mirror. To reduce headlamp glare from following vehicles, pull lever...
Page 96 3-22 Chapter 3 KNOW YOUR VEHICLE InTERIoR lAmPS oPERATIng THE InTERIoR lAmPS Interior (dome) lamp The interior dome lamp has 3 settings that can be used: • Slide the switch towards the rear of the vehicle to turn the lamp on. •...
Page 97 3-23 Chapter 3 KNOW YOUR VEHICLE ASSIST gRIPS ASSIST gRIPS loCATIon Assist grips are provided above the passenger doors. The rear assist grips also have coat hooks. V250_3046 WArNINg • Do not hold onto assist grips while seated in the vehicle. •...
Page 98 3-24 Chapter 3 KNOW YOUR VEHICLE SToRAgE ComPARTmEnTS glovEBox The glovebox is located in the dashboard directly in front of the passenger seat. • To open the glovebox, pull the handle towards you. • To close, push the lid firmly back into place.
Page 99 3-25 Chapter 3 KNOW YOUR VEHICLE SToRAgE ComPARTmEnTS cont. DASHBoARD SToRAgE ComPARTmEnT The dashboard storage compartment is located between the centre vents. • To open the lid, push the locking button upwards and release it. • To close, move the lid back to its original position and press in the bottom part to engage the latch.
Page 100 3-26 Chapter 3 KNOW YOUR VEHICLE SToRAgE ComPARTmEnTS cont. CuP HolDERS Cup holders are designed for holding standard size soft drink cans and smaller size bottles. Larger drink bottles or cups should not be forced into the cup holders, or they may become jammed.
Page 101 3-27 Chapter 3 KNOW YOUR VEHICLE SToRAgE ComPARTmEnTS cont. ASHTRAy AnD CIgARETTE lIgHTER Front ashtray • To access the ashtray, push in the top part of the lid and release it, this will expose the ashtray and cigarette lighter. • To empty the ashtray, grasp the receptacle and carefully pull it up.
Page 102 3-28 Chapter 3 KNOW YOUR VEHICLE SToRAgE ComPARTmEnTS cont. REAR SEAT-BACk PoCkETS A storage pocket is located on the rear of both front seats. V250_3055 SHoPPIng Hook A shopping hook is located on the passenger side of the centre console. To access, push in the bottom section to expose the hook.
Page 103 3-29 Chapter 3 KNOW YOUR VEHICLE PoWER SoCkET The power socket is located underneath the front ashtray. The power socket is operational when the ignition is switched to either the ON or ACC position. Note Any accessory device (e.g. mobile phone, car fridge) connected to the power socket must not exceed a current draw of 10 amps.
Page 104 3-30 Chapter 3 KNOW YOUR VEHICLE noTES...
Page 105 Driving precautions ......4-3 Park brake ........4-5 Engine starting........4-6 Transmission operation ....4-7 Active safety systems ....4-11 Add on equipment ......4-14 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 106 Chapter 4 DRIVING SAfETy BEfoRE EnTERIng THE vEHIClE • Check that windows, mirrors and lamps are clean. • Visually check tyre inflation. Note Check the tyre pressures each week. BEfoRE DRIvIng off 1. Ensure that all doors are closed and secured. 2.
Page 107: Driving
Chapter 4 DRIVING DRIvIng PRECAuTIonS RunnIng-In There is no need to follow a formal running-in schedule. However, by observing a few simple precautions during the first few hundred kilometres of driving you will greatly assist the vehicle’s future performance and economy. •...
Page 108 Chapter 4 DRIVING DRIvIng PRECAuTIonS cont. loADIng THE vEHIClE Loading the vehicle changes the mass distribution and therefore the handling when driving. After loading the vehicle, take care to become familiar with the vehicle’s driving characteristics. Refer to Loading the vehicle in chapter 9. looSE ARTIClES Do not leave loose articles or luggage in the passenger compartment.
Page 109 Chapter 4 DRIVING PARk BRAkE oPERATIng THE PARk BRAkE The park brake lever is located between the front seats. Applying the park brake To apply, pull the lever straight up, without pressing the release button. When the ignition is switched on and the park brake is applied, the park brake warning lamp on the instrument panel illuminates.
Page 110 Chapter 4 DRIVING EngInE STARTIng 1. Ensure that the park brake is firmly applied and release it only after you have started the engine and are ready to drive off. 2. Manual transmission : Shift the gear lever to the Neutral position. Automatic transmission : Move the transmission gear selector to position P (park) or N (neutral).
Page 111 Chapter 4 DRIVING TRAnSmISSIon oPERATIon AuTomATIC TRAnSmISSIon gear selector lever Press the select button on the front of the transmission gear selector lever to move to the required position. gear display When the position of the transmission gear selector lever is changed, the selected lever position is displayed and changes according to the selector lever’s movement.
Page 112 Chapter 4 DRIVING TRAnSmISSIon oPERATIon cont. Automatic transmission selector lever positions Note The engine will not start unless the transmission gear selector is in position P (park) or N (neutral). (Park) This stops the front wheels from rotating and should be selected (together with the park brake) when leaving the vehicle.
Page 113 The mode warning lamp will illuminate on the instrument panel. Push the n button again to turn winter • mode off. mode indicator lamp flashes, If the have your vehicle checked by a Holden Dealer immediately.
Page 114 4-10 Chapter 4 DRIVING TRAnSmISSIon oPERATIon cont. mAnuAl TRAnSmISSIon Shift patterns The manual transmission has 5 forward gears and 1 reverse gear. The shift pattern is illustrated on the top of the gear shift lever. Operating notes • When shifting from one gear to another, be sure to depress the clutch V250_4014 pedal fully to avoid damage to the...
Page 115 If the u warning lamp (ABS off) in the instrument panel does not extinguish or illuminates when driving, a malfunction in the system has occurred. The vehicle’s brake system remains operational, but without ABS assistance. Have your Holden Dealer check the system as soon as possible.
Page 116 4-12 Chapter 4 DRIVING ACTIvE SAfETy SySTEmS cont. TRACTIon ConTRol SySTEm (TCS) Operation The Traction Control System (TCS) helps prevent the driving wheels (front) from spinning. As soon as even one driving wheel starts to spin, the TCS activates automatically, reduces the power from the engine and applies the brakes to the spinning wheel.
Page 117 If the warning lamp is shown when you did not switch off the system, a malfunction has occurred and the system will not work. Contact your Holden Dealer to have the system checked. Note The TCS will not function if the vehicle’s brakes are overheated. The warning lamp will illuminate until the brakes have reached normal operating temperature.
Page 118 4-14 Chapter 4 DRIVING ADD on EQuIPmEnT SnoW CHAInS WArNINg Snow chains should be fitted only on the front (drive) wheels. • • Snow chains may only be used at speeds up to 50 km/h. • Snow chains should only be used for short distances if the roads are not snow covered.
Page 119: Fuel
LPG. The performance and safety of the vehicle would be seriously jeopardised if converted to LPG. The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 120 • whenever the exhaust system, underbody or rear of the vehicle is damaged. Take the vehicle to your Holden Dealer if you think the vehicle needs inspecting for any of the above reasons. Do not sit (or leave children or pets) in a parked vehicle for any extended period of time with the engine running.
Page 121 Only clean fuel of good quality should be used. The use of fuel containing more than 10% ethanol may also affect your New Vehicle Warranty to the extent that Holden considers that the fuel affects the specifications and quality of your vehicle.
Page 122 LPg conversion Your vehicle was not designed to be converted to LPG. Holden does not provide LPG conversion kits for these vehicles. Your New Vehicle warranty may be invalidated to the extent that any LPG alterations affect the specifications of your vehicle. Refer to...
Page 123 To ensure continuing compliance with the regulations, you must have the vehicle serviced at the frequency shown in the Maintenance schedule, in the Service/warranty booklet. Your Holden Dealer will maintain the vehicle’s emission control system as per the vehicle’s service manual.
Page 124 Chapter 5 FUEL REDuCIng fuEl ConSumPTIon EngInE To keep the engine in peak mechanical condition, have it serviced regularly in accordance with the maintenance schedule. Refer to Maintenance schedule in the Service/warranty booklet. This ensures items such as the spark plugs, air cleaner and engine idle speed are maintained for minimum fuel usage and peak engine performance.
Page 125 Emergencies Page Customer assistance – Australia..........6-2 For New Zealand Holden owners ...6-3 Changing a flat tyre ......6-4 Towing a disabled vehicle ....6-9 Engine overheating.......6-11 Transmission shift lock control system ......6-14 Flat battery........6-15 Fuse replacement ......6-17 Bulb replacement......6-21 The asterisk signifies equipment options not in all vehicles;...
Page 126 Normally, any problems with the sales, operation, servicing or the validity of original equipment supplied with your vehicle will be handled by your Holden Dealer’s Sales and Service Department. We realise however that, with the best intentions, misunderstandings sometimes occur.
Page 127: Emergencies
EMERGENCIES foR nEW zEAlAnD HolDEn oWnERS The information in this Owner’s Handbook applies primarily to Australian Holden vehicles and there may be some differences to the Warranty and Owner Assistance provisions for New Zealand. Applicable details for New Zealand are set out in the Holden Warranty and Owner Assistance Information booklet enclosed in the New Zealand glovebox wallet.
Page 128 Chapter 6 EMERGENCIES CHAngIng A flAT TyRE WArNINg • All passengers must be out of the vehicle when it is being jacked. • Do not jack a vehicle with a trailer attached. Remove the trailer first. • Only jack the vehicle on hard, level surfaces. •...
Page 129 Chapter 6 EMERGENCIES CHAngIng A flAT TyRE cont. 4. The spare wheel and tool kit are stored in a compartment in the floor of the boot. The jack is also stored in a compartment in the boot, situated to the left hand side. Open the boot and lift the spare wheel cover up by the handle.
Page 130 Chapter 6 EMERGENCIES CHAngIng A flAT TyRE cont. 6. Using the wheel nut wrench, loosen the wheel nuts in an anti-clockwise direction, one half to a full turn, but do not remove the wheel nuts. 7. Remove the jacking location trim gain access to the jacking location.
Page 131 Chapter 6 EMERGENCIES CHAngIng A flAT TyRE cont. 9. Wind the jack up by hand until it engages with the jacking point, ensure that the jack is not tilted and the base is resting squarely on the ground. WArNINg • Failure to position the jack as described above could cause the vehicle to slip off the jack.
Page 132 Chapter 6 EMERGENCIES CHAngIng A flAT TyRE cont. 17. With the wheel on the ground, fully tighten the wheel nuts in the sequence shown. 18. Replace the tools and the flat tyre as shown in step 4 and 5. 19. To avoid movement of the tools and spare wheel, the retaining bolt should be tightened firmly by hand.
Page 133 Chapter 6 EMERGENCIES ToWIng A DISABlED vEHIClE WArNINg • When towing on a flat tray tow truck, use wheel lashings and/or tie down hooks to secure the vehicle to the tray. • Do not attach towing equipment to the bumpers or brackets, suspension or cross members.
Page 134 6-10 Chapter 6 EMERGENCIES ToWIng A DISABlED vEHIClE cont. WArNINg • When towing on a flat tray tow truck, use wheel lashings and/or tie down hooks to secure the vehicle to the tray. • Do not attach towing equipment to the bumpers or brackets, suspension or cross members.
Page 135 6-11 Chapter 6 EMERGENCIES EngInE ovERHEATIng WArNINg Immediate action is required if the engine overheats. This is indicated by one or more of the following: The temperature gauge needle moving over to the H. • • Steam escaping from under the bonnet. •...
Page 136 6-12 Chapter 6 EMERGENCIES EngInE ovERHEATIng cont. If you see or hear steam coming from the engine, stop and switch the engine off. Do not open the bonnet until the engine has cooled down. If the temperature gauge is high with no sign of steam: 1.
Page 137 10 minutes if the temperature gauge does not again show an overheat condition. If overheating occurs again you should have the vehicle attended to, as soon as possible, by your Holden Dealer. The engine may temporarily operate at high temperatures during demanding operating conditions, especially on hot days, including: •...
Page 138 7. Start the engine and shift the transmission into the desired position. 8. Reinstall the cap. 9. Refer to your Holden Dealer as soon as possible. Note If the shift lever is returned to the P (park) position, the above procedure will need •...
Page 139 Please read the following warnings and procedure in full before attempting to jump start the vehicle. If, after reading the following procedure, you are still unsure about ‘jump starting’, Holden strongly recommends for your safety and that of the vehicle that you seek the assistance of a suitably trained service technician. WArNINg Do not push start or tow start either a manual or an automatic vehicle.
Page 140 6-16 Chapter 6 EMERGENCIES flAT BATTERy cont. Jump starting procedure Note The battery in both vehicles must have a negative earth and a 12 volt rating. 1. Position the two vehicles so that they are NOT touching. 2. Apply the park brakes. 3.
Page 141 Any improper alterations to the electrical system may cause a fire hazard and engine damage. To maintain your own safety and that of the vehicle, have any work involving the electrical system or the replacement of high current fuses or relays carried out by your Holden Dealer.
Page 142 6-18 Chapter 6 EMERGENCIES fuSE REPlACEmEnT cont. EngInE ComPARTmEnT fuSES AnD RElAyS This is the main fuse/relay box. Remove the clip-on cover to gain access. Fuse puller...
Page 143 6-19 Chapter 6 EMERGENCIES fuSE REPlACEmEnT cont. EngInE ComPARTmEnT fuSES AnD RElAyS Fuses: ECM ........(15A) F27 - ENG3 ........(20A) F1 - F2 - PWR SEAT ......(30A) F28 - ENG2 ........(15A) LCM ........(30A) F29 - ILLUM LT ......(10A) F3 - F4 - DRIVER’S PWR WIDW ..
Page 144 6-20 Chapter 6 EMERGENCIES fuSE REPlACEmEnT cont. CABIn fuSES AnD RElAyS The fuse panel is located in the right hand side dashboard. Use the slot on the forward edge of the fuse panel cover to pull open. Cabin fuse and relay index Fuses: B/UP LP.......
Page 145 6-21 Chapter 6 EMERGENCIES BulB REPlACEmEnT Note If unsure of the bulb replacement process for any of the lamps, please have the work carried out by a suitably trained service technician. noTES WHEn REPlACIng BulBS Switch the ignition OFF and remove the keys. •...
Page 146 6-22 Chapter 6 EMERGENCIES BulB REPlACEmEnT cont. Headlamps  = Low beam (55W)  = High beam (55W)  = Turn signal (PY21)  = Park lamp (5W wedge) V250_6068 Headlamps, low and high beam (55W) 1. Follow the steps described in section Front lamps previously in this chapter, to gain access to the lamp assembly.
Page 147 6-23 Chapter 6 EMERGENCIES BulB REPlACEmEnT cont. Front park lamps 1. Follow the steps described in section Front lamps previously in this chapter to gain access to the lamp assembly. 2. Remove the inboard high beam dust cover to access the bulb. 3.
Page 148 6-24 Chapter 6 EMERGENCIES BulB REPlACEmEnT cont. REAR lAmPS To gain access to the rear turn signal and stop/tail bulbs: 1. Open the boot. 2. Remove the 2 bolts on the inner side of the lamp. 3. Remove the lamp by pulling directly rearwards of the vehicle.
Page 149 6-25 Chapter 6 EMERGENCIES BulB REPlACEmEnT cont. rear turn signal, stop and tail lamps 1. Follow the steps described in section Rear lamps previously in this chapter to gain access to the lamp assembly. 2. From the rear of the assembly, turn the bulb holder of the bulb that needs replacing anticlockwise to remove it from its housing.
Page 150 6-26 Chapter 6 EMERGENCIES BulB REPlACEmEnT cont. numBER PlATE lAmP (5W BulB) 1. Using a Phillips head screwdriver, remove the 2 screws and the lens housing at the lower edge of the boot lid. 2. Remove the bulb holder from the lamp housing by rotating the bulb holder anticlockwise.
Page 151 3. Refit the new bulb into the lamp. 4. Refit the lens housing. Make sure they are securely locked in place. 5. Check lamp operation. BulBS To BE CHAngED By A HolDEn DEAlER • Front fog lamps • Instrument panel lamps.
Page 152 6-28 Chapter 6 EMERGENCIES noTES...
Page 153 Automatic transmission fluid level ........7-9 Engine coolant ......7-10 fluid ....7-12 Brake/clutch Power steering fluid ....7-13 Washer fluid ......7-14 Battery ..........7-15 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 154 Chapter 7 WEEKLY CHECKS ExTERIoR CHECkS mISCEllAnEouS CHECkS As well as taking the vehicle to be serviced, there are a few simple, weekly checks that the owner/operator is recommended to make. These are shown on the following pages. WArNINg • If the engine temperature is high, the cooling fan may remain on for several minutes after switching off the ignition.
Page 155: Weekly Checks
Chapter 7 WEEKLY CHECKS ExTERIoR CHECkS cont. TyRES Air pressure Weekly checking of the air pressure in the tyres (including the spare) ensures your safety, as well as reducing fuel consumption and increasing the life of the tyres. For constant long distance or rough road driving, daily checking is recommended.
Page 156 At sustained high speeds, this type of tyre runs at higher temperatures than standard tyres. Only operate them within the limits recommended by the manufacturer. Any doubts about the tyres on the vehicle should be referred to your Holden Dealer.
Page 157 Chapter 7 WEEKLY CHECKS ExTERIoR CHECkS cont. Tyres with a higher speed or load rating are acceptable, provided they are fitted to a suitable rim size. Note New tyres should be fitted in pairs to the front. If replacing only one tyre, it should be paired on the same axle with the least worn of the other three.
Page 158 Chapter 7 WEEKLY CHECKS unDER BonnET CHECkS unDER BonnET lAyouT � Page Power steering fluid reservoir ................7-13   Engine coolant reservoir ...................7-10 Engine oil filler cap ....................7-7  fluid reservoir ................7-12  Brake/clutch  Dipstick for engine oil ..................7-7 Windscreen washer fluid reservoir ..............7-14 ...
Page 159 Their use increases costs, may be detrimental to the operation of the vehicle and may void the New Vehicle Warranty, to the extent that Holden considers the non-recommended fluid to have affected the specifications or quality of the vehicle.
Page 160 Chapter 7 WEEKLY CHECKS unDER BonnET CHECkS cont. Engine oil consumption Every internal combustion engine uses a certain amount of oil, especially when running in. The engine is dependent on oil for lubricating critical areas, such as the cylinder walls, pistons, rings and valve stems. These parts are all subjected to high friction loads and will prematurely wear out without a constant supply of engine oil.
Page 161 If, after taking into account the above factors, you are still concerned that your engine has excessive oil consumption then consult your Holden Dealer. Remember that an engine’s oil consumption should not be judged until it has run at least 10,000 km.
Page 162 7-10 Chapter 7 WEEKLY CHECKS unDER BonnET CHECkS cont. EngInE CoolAnT Engine coolant level Check the coolant level at least once a week. The cap for the coolant reservoir is yellow. Refer to Under bonnet layout previously in this chapter for coolant reservoir location. Checking the coolant level WArNINg Do not remove the coolant reservoir...
Page 163 Refer to Specifications in chapter 8 for engine coolant specifications and water-to-coolant ratio. 1. Mix a solution of Holden coolant, refer to Specifications in chapter 8 and clean fresh water in a container as per the ratio specified.
Page 164 1. Ensure that the ignition is switched off. 2. Wipe the sides of the cap clean and turn anticlockwise to remove. 3. Top up with heavy duty brake fluid which meets Holden specifications. Refer to Specifications in chapter 8 for the correct specification.
Page 165 Refer to Specifications in chapter 8 for the correct power steering fluid to use. 1. Ensure the ignition is switched off. 2. Top up with power steering fluid which meets Holden specifications. Do not overfill the reservoir. 3. Secure the cap and clean up any spilt fluid.
Page 166 Adding washer fluid For a crystal clear windscreen, the correct amount of Holden washer fluid additive can be added. Refer to Exterior cleaning in chapter 10. Note Do not use ordinary soap or detergent as these damage the wiper rubbers.
Page 167 Do not remove the caps on the top of the battery. The battery supplied in the car is maintenance free and does not require checking or filling. REPlACEmEnT BATTERy The vehicle’s battery is maintenance-free. For battery replacement, refer to your Holden Dealer or authorised repairer. vEHIClE BATTERy DISConnECTIon The battery is recharged by the alternator when the engine is running.
Page 168 7-16 Chapter 7 WEEKLY CHECKS noTES...
Page 169 Specifications Page Specifications 2.5 litre engine ..8-2 Specifications 2.0 litre engine ..8-3 General specifications ....8-4 Identification labels ......8-5 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 170 50% clean fresh water and 50% Dexcool *Coolant specification anti-freeze coolant, conforming to specification number GM6277M Coolant capacity 8 L approximately Automatic ESSO JWS 3309 or conforming to Holden transmission fluid specification number HN2414 Brake fluid DOT 4 Power steering fluid ®...
Page 171: Specifications
SPECIfICATIonS - 2.0 lITRE EngInE Engine type Inline 6 cylinder DOHC 24 valve Engine capacity 1993 cc Engine power and torque Please refer to holden.com.au Engine SAE 5W-30 or 10W-30 API SL/SM oil specification ILSAC GF-3/GF-4 oil Refill engine 6.4 L approximately (including filter)
Page 172 Chapter 8 SPECIFICATIONS gEnERAl SPECIfICATIonS DImEnSIonS (mm) CDX and CDXi sedan Length 4805 Width - excluding mirrors 1810 Width - including mirrors 2046 Height 1450 Wheel base 2700 Overhang - front Overhang - rear 1136 Front track 1550 rear track 1545 The above figures are based on the design dimensions.
Page 173 Chapter 8 SPECIFICATIONS IDEnTIfICATIon lABElS Compliance label The compliance label is located in the boot under the spare wheel cover on the driver’s side. To view the label open the boot and lift the spare wheel cover up by the handle. V250_8004 Engine number The engine number is stamped onto the...
Page 174 Engine type: L = 2.5L DOHC K = 2.0L DOHC Body style: 69 = 4 door sedan Transmission: A = Automatic F = Manual Model series: L = Epica Manufacturer identifier: K = Asia Pacific, L = Korea, 3 = GM Holden...
Page 175: Tow And Load
Tow and load Page Loading the vehicle......9-2 Towing ..........9-4 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 176 Chapter 9 TOW AND LOAD loADIng THE vEHIClE mAxImum vEHIClE PAyloADS Overloading is a safety hazard and could also shorten the life of the vehicle. The typical recommended carrying capacity of the vehicle is as shown in the table below. Do not exceed the maximum axle loads shown below in the diagram, including the weight of any options or accessories fitted to the vehicle.
Page 177 Chapter 9 TOW AND LOAD loADIng THE vEHIClE cont. noTES on loADIng THE vEHIClE • Place heavy objects in the rear luggage compartment as far forward as possible against the rear seat backrests. When stacking objects, place the heavier objects at the bottom.
Page 178 Holden will not accept liability for defects occurring in towing equipment not marketed by Holden or for defects in the vehicle arising from the use of such equipment or for loss or injury caused by use of such equipment. The use of...
Page 179 TOW AND LOAD ToWIng cont. ToWIng EQuIPmEnT Tow load Mandatory equipment recommended equipment Holden 1200 kg rated tow bar. A load distribution hitch is recommended for loaded trailers Holden trailer wiring harness. Up to weighing more than 700 kg. 700 kg...
Page 180 Ensure the weight of the packed trailer is not greater than the towing capacity of the Holden approved tow bar package fitted to the vehicle.
Page 181 Chapter 9 TOW AND LOAD ToWIng cont. ToWIng PRECAuTIonS • When heavily loading the vehicle or when towing, the tyres should be inflated to the maximum recommended pressure. Refer to Tyres in chapter 7 for tyre placard location and information about tyre pressures. •...
Page 182 Chapter 9 TOW AND LOAD noTES...
Page 183: Cleaning
Cleaning Page Interior cleaning ......10-2 Exterior cleaning ......10-5 Cleaning Products ......10-9 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
Page 184 10-2 Chapter 10 CLEANING InTERIoR ClEAnIng WArNINg Many cleaning products are toxic, flammable or may damage the interior. When cleaning the interior, avoid volatile cleaners such as acetone, lacquer thinners, enamel reducers, nail polish removers, or cleaners such as laundry soaps, bleaches or reducing agents.
Page 185 10-3 Chapter 10 CLEANING InTERIoR ClEAnIng cont. CloTH To clean seats upholstered with cloth, observe the following instructions: • Remove loose dirt and dust with a vacuum cleaner or soft brush. • DO NOT use a whisk broom or a coarse hair brush. •...
Page 186 Do not bleach or dye seatbelts as this may severely weaken them. InTERIoR glASS Clean interior glass of the vehicle using a good quality glass cleaner, such as Holden Glass Cleaner, and a clean soft cloth. Take care when cleaning inside the rear window so as not to damage the rear window demister or antenna.
Page 187 10-5 Chapter 10 CLEANING ExTERIoR ClEAnIng CARIng foR PAInT To help preserve that shiny new vehicle finish, pay special attention to correctly treating those conditions that can damage the paint. • Road bloom: If, over a long period of time, oils, dirt, exhaust and other pollutants are allowed to build up, they may combine to affect the paint finish.
Page 188 Do not use a sponge or cloth at this point. 2. Fill a bucket with lukewarm water and add no more than two capfuls of gentle detergent, such as Holden Hi Suds Car Wash. Do not use hot water, strong soap or chemical detergents.
Page 189 However, the use of a good quality Polymer Glaze, such as Holden Quick and Easy Speed Finish, approximately every 3 months will reduce the effects of road bloom by removing natural contaminants which can build up on the paint.
Page 190 Use a good quality glass cleaner, such as Holden Glass Cleaner, and wash each section of glass in turn, making sure that the water, its container and the sponge are quite clean and free from grit.
Page 191 10-9 Chapter 10 CLEANING ClEAnIng PRoDuCTS Part number Size Description Usage Seals in a deep, lustrous glazed finish. Quick and Easy 92145132 237 ml Long life protection from oxidation, salt Speed Finish and weather damage. Seals in a deep, lustrous glazed finish. Quick and Easy 92145418 437 ml...
Page 192 10-10 Chapter 10 CLEANING noTES...
Page 193: Index
InDEx Audio system cont... ABS ..........4-11 Mute ....... 1B-6, 1B-15 Radio operation ......1B-8 Accessories Radio reception ......1B-18 Auxiliary input socket ....1B-14 Active safety systems ...... 4-11 Security code ......1B-5 Anti-lock Brake System (ABS) ... 4-11 Steering wheel controls ...1B-15 Switching on/off......1B-6 Airbags Treble .........1B-7...
Page 194 InDEx cont. Demister, windscreen Capacities (fluid) with climate control ....1A-31 with manual heater ....1A-24 Automatic ........8-2 Dimensions ........8-4 Manual ......... 8-3 Dimmer, instrument lighting ...1A-19 Caravan, towing......... 9-4 Carbon monoxide, warning....5-2 Dipping headlamps ......1A-18 Car key ..........2-2 Dipstick Auto transmission fluid ....
Page 195 InDEx cont. Fuel cont... Engine Fuel cap ........5-4 Cooling system ......7-10 Identification number ....8-6 Fumes warning ......5-2 Overheating ....... 6-11 Gauge ........1A-6 Specifications ......8-2, 8-3 LPG ..........5-4 Starting ........4-6 Octane rating ....... 5-4 Precautions ........
Page 196 InDEx cont. Loading the vehicle..... 4-4, 9-2 Instrumentation ........1A-6 Fuel ..........1A-6 Locks Bonnet lock ........ 2-11 Information displays ....1A-12 Boot lock ........2-10 Speedometer ......1A-6 Child safety locks ......2-7 Tachometer ........1A-6 Door locks ........2-5 Temperature .......1A-6 Ignition switch ....... 2-2, 2-9 Instrument panel ......1A-6 Interior lamps ........
Page 197 InDEx cont. Security alarm........2-8 Park brake ......... 4-5 Serial number ........8-6 Servicing. See Warranty/service booklet. Park brake warning ....1A-8 Parking ..........4-2 Shift lock control system ....6-14 Snow chains ........4-14 Polishing .......... 10-7 Power mirrors ........3-20 Spare wheel........
Page 198 InDEx cont. Warning/reminder indications cont... Trailer towing ........9-4 Transmission Fog lamp indicator ....1A-10 Automatic ........4-8 High beam indicator ....1A-10 Manual ........4-10 Low oil pressure/check oil ..1A-7 Low washer fluid ...... 1A-11 Shift lock control system .... 6-14 Transmission fluid ....7-9, 8-2, 8-3 Malfunction Indicator Lamp (MIL) ......1A-10...
