  • Page 1 CAPTIVA MaXX CG Captiva MaXX Owner’s Handbook...
  • Page 2 Change of name, address or ownership In the event of a Safety Recall, or for various reasons, Holden may need to contact you as the owner of this vehicle. If you have recently changed your address, or name, or purchased this vehicle second-hand, please help us to help you by taking a few minutes to fill in and mail the forms at the beginning of the Service/warranty booklet.

  • Page 3: Table Of Contents

    CHAPTERS Dashboard........1 Locks..........2 Know.your.vehicle......3 Driving.......... 4 Fuel..........5 Emergencies....... .6 Weekly.checks......7 Specifications.......8 Tow.and.Load.......9 Cleaning........10 Index............
  • Page 4 We.thank.you.for.choosing.Holden.and.want. to. assure. you. of. our. continuing. interest. in. your. motoring. pleasure. and. satisfaction. and. compliment.you.on.your.choice. Due. to. different. models. and. options,. you. may find reference in this handbook to some equipment.not.installed.in.your.own.vehicle. Please. note. that. all. information,. illustrations. and specifications in this handbook are based on the latest production information available at.the.time.of.printing..
  • Page 5 Wipers.and.washers. Fuel. Headlamps. Fuel filling. Fog.lamps. Petrol.-.emission.control. Turn.signals. Reducing.fuel.consumption Ignition.switch. Immobiliser. Chapter 6 - Emergencies Hazard.warning. Customer.assistance. Horn. For.New.Zealand.Holden.owners. Climate.control. Flat.tyre. Glovebox. Towing your disabled vehicle. Storage.compartment Engine.overheating. Transmission.shift.lock.failure.mode. Chapter 2 - Locks Flat battery. Keyless.entry. Airbags. Manual.lock.operation. Fuses. Rear.tailgate.lock.
  • Page 6 CONTENTS Chapter 10 - Cleaning Interior.cleaning. Exterior cleaning. Cleaning.products.
  • Page 7 Notes...

  • Page 9: Dashboard

    Turn signals and ignition switch 1-41 Immobiliser and hazard warning 1-42 Horn 1-43 Climate control 1-51 Glovebox 1-52 Storage compartments 3 The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
  • Page 10 Chapter 1 DASHBOARD LAYOUT � � C05H010Q  Brake pedal  Driver air bag  Bonnet release lever  Front passenger air bag  Card holder  Instrument cluster  Coin storage  Driver information display (DID)  Remote control for audio system ...
  • Page 11 Chapter 1 DASHBOARD GAUGES C05H Page Page  Tachometer  Immobiliser warning indicator 1-12  Fuel gauge  Door ajar indicator 1-13  Speedometer  Service vehicle soon warning indicator 1-13  Turn signal indicators 1-11  Engine coolant temperature ...
  • Page 12 Chapter 1 DASHBOARD GAUGES cont. Speedometer The speedometer  indicates the vehicle's speed in kilometres per hour (km/h). C05E010A Odometer and tripmeter The window between the tachometer and speedometer is used for the odometer and tripmeter . The odometer records the distance travelled since the vehicle was built, and the tripmeter records the distance travelled on a particular journey.
  • Page 13 Chapter 1 DASHBOARD GAUGES cont. Fuel gauge The fuel gauge  indicates the level of fuel within the fuel tank when the ignition switch is turned to the ON position. F represents full and E represents empty. The needle in the fuel gauge falls to E when the ignition switch is turned to the OFF position.
  • Page 14 Chapter 1 DASHBOARD DRIVER INFORMATION DISPLAY (DID) The driver information display (DID) displays information for the radio frequency, band, time and outside temperature when the ignition switch is in the ON position. Selecting functions The functions and settings can be accessed via the driver information display (DID).
  • Page 15 Chapter 1 DASHBOARD DRIVER INFORMATION DISPLAY (DID) cont. Outside temperature This mode indicates the temperature outside the vehicle. Note: If the temperature is below -5ºC, no message will be displayed. C05E133A Radio station display This mode displays the band and frequency of the radio station selected.
  • Page 16 Chapter 1 DASHBOARD DRIVER INFORMATION DISPLAY (DID) cont. Language selection The display language can be selected for some functions, select menu item, Language from the settings menu. The available languages are shown opposite. C05E144A Select the desired language Selections are indicated by ► in front of the menu item.
  • Page 17 • stays on continuously while driving, it indicates the air bag system or seat belt pretensioner system may not function correctly, especially in an accident. Contact your Holden Dealer immediately. Low fuel Illuminates when the ignition switch is turned to the ON position and goes out after approximately 4 seconds.
  • Page 18 This lamp should come on when the ignition switch is in the ON position and the engine is not running. If it stays on or comes on while you are driving, there may be a problem with this system, contact your Holden Dealer.
  • Page 19 1-11 Chapter 1 DASHBOARD WARNING LAMPS cont. Winter mode indicator The winter mode indicator illuminates when the winter mode button is pressed, use this mode to drive away smoothly during icy and slippery road conditions. C7E2024A Shift select position indicator (Automatic transmission) Displays the position of the automatic transmission shift select lever.
  • Page 20 4 seconds. This lamp flashes while ESP® C7E2017A is operating and illuminates constantly to indicate there is a malfunction in the system, consult your Holden Dealer. Descent control system (DCS) active and not ready warning lamps When the ignition switch is turned to the ON position, the DCS indicator illuminates for approximately 4 seconds.
  • Page 21 The service vehicle soon lamp will illuminate if a malfunction exists in the non-emission related components C7E2023A or the related sub systems, consult your Holden Dealer. WARNING: If you keep driving your vehicle with the service vehicle soon lamp on, damage may result in the non-emission related components or related sub systems.
  • Page 22 (refer to Chapter 7, Weekly checks). Do not drive the vehicle with the engine oil level indicator lamp illuminated, contact your Holden Dealer. Front passenger seat belt reminder When the ignition switch is turned to the...
  • Page 23 1-1 Chapter 1 DASHBOARD AUDIO SYSTEM Features The audio system includes an AM - FM Radio and MP3 / CD player. Security system Your audio unit includes an electronic security system to prevent theft. This security system allows the audio system to operate only in your vehicle, if the audio system is removed for any reason it will not function in another vehicle.
  • Page 24 1-1 Chapter 1 DASHBOARD AUDIO SYSTEM cont. CD player and radio controls � � �� � ��� � MAIN INFO SOUND AM/FM SETTINGS C05E165B � � � � � Display and functions  Power / volume knob  Body computer (Not applicable for this vehicle) ...
  • Page 25 1-1 Chapter 1 DASHBOARD AUDIO SYSTEM cont. Control buttons Power on power/volume rotary knob  to activate the audio When the power is OFF press the button  to activate the CD player. The radio, CD or MP3 function system, or the will be shown on the display screen.
  • Page 26 1-1 Chapter 1 DASHBOARD AUDIO SYSTEM cont. Speed dependant volume control (SDVC) To compensate for the ambient and rolling noise, the volume of the audio system is adjusted to the speed of the vehicle. The SDVC function can be used to adjust the speed dependant volume setting.
  • Page 27 1-1 Chapter 1 DASHBOARD AUDIO SYSTEM cont. Bass control Bass control is used to adjust the bass (low frequency) sound quality. The bass settings apply to the currently selected audio source and are stored separately for FM/AM radio and the CD player. Select from the menu item, Treble - Bass from the sound menu and the Treble - Bass menu will be displayed.
  • Page 28 1-0 Chapter 1 DASHBOARD AUDIO SYSTEM cont. Balance control Balance control adjusts the volume separation between left-hand and right-hand speakers. Select the menu item Balance - Fader from the sound menu and the Balance - Fader menu will be displayed. Select from the Balance - Fader menu Balance, and the balance slider will be displayed.
  • Page 29 1-1 Chapter 1 DASHBOARD AUDIO SYSTEM cont. Radio -0.5º 22:22 Switch the audio system on by pressing CDin power/volume knob . Press the AM/FM button . 102.4 The tuner menu will be displayed and Station Store the last station selected to will be playing.
  • Page 30 1- Chapter 1 DASHBOARD AUDIO SYSTEM cont. Local/DX function (LOC) The LOC function has two search levels with different sensitivities. Press the LOC  button, the current status LOC ON or LOC OFF will be displayed. Press the LOC  button again to switch on the LOC function. The first search carried out is at the lower sensitivity (LOCAL) to look for the station •...
  • Page 31 1- Chapter 1 DASHBOARD AUDIO SYSTEM cont. Manual storing (option 1) Two options are available for manual station storing: Tune into the desired station, refer 102.4 -0.5º 22:22 to automatic station search in this 102.4 section. 100.4 Press and hold the station button  MHzkHz on which the tuned in station is to be 94.8...
  • Page 32 1- Chapter 1 DASHBOARD AUDIO SYSTEM cont. Selecting a station The desired radio band and mode need to be active, refer to selecting a radio band, in this section. With the radio on and with a station playing select the desired station with the radio station buttons .
  • Page 33 1- Chapter 1 DASHBOARD AUDIO SYSTEM cont. The following information will be displayed: • Audio CD: CD number, album name, track title and artist (depending on CD format) • MP3 or mixed mode CD: CD number, album name, track title and artist •...
  • Page 34 1- Chapter 1 DASHBOARD AUDIO SYSTEM cont. Selecting a CD (option 1) While a track is playing, press the appropriate number key button , the CD player is muted. If a CD has not yet been read "CD reading" appears on the display, the CD compartment selected and the track is displayed.
  • Page 35 1- Chapter 1 DASHBOARD AUDIO SYSTEM cont. CDC extra features CD Extras -0.5º 22:22 The following option fields are available Normal in the "Extras" menu. Random CD Normal: This option is used to disable the functions random CD/magazine, Random Magazine repeat track and scan CD.
  • Page 36 1- Chapter 1 DASHBOARD AUDIO SYSTEM cont. Switch on random magazine (random) After pressing the CDC button , select menu item "Extras". The extras menu will be displayed, select option field "Random Magazine". The CD menu is displayed and the symbol R is displayed.
  • Page 37 1- Chapter 1 DASHBOARD AUDIO SYSTEM cont. Switching on scan CD (option 2) After pressing the CDC button , select menu item "Extras". The extras menu will be displayed, select option field "Scan CD". The CD menu is displayed and the symbol is displayed.
  • Page 38 1-0 Chapter 1 DASHBOARD AUDIO SYSTEM cont. Removing all CD's It is possible to remove all CD's from the player at the same time. button  for a relatively long time. Press and hold the An overlay menu will be displayed with the message, "Eject all CD's". Confirm with "OK"...
  • Page 39 DASHBOARD AUDIO SYSTEM cont. General information Audio system faults In case of faulty operation, consult your GM Holden Dealer. Antenna The AM/FM antenna is mounted on the roof of the vehicle. Radio reception Due to varying reception locations, audio systems have performance limitations that may on occasions create the impression that your radio is malfunctioning.
  • Page 40 1- Chapter 1 DASHBOARD AUDIO SYSTEM cont. Peculiarities of FM mobile reception A mobile FM receiver can not be expected to continuously provide the quality of FM reception you may have experienced on your home receiver. Contrary to popular opinion, FM broadcasts are not static free, and although your new radio has a built-in electronic interference absorption circuit some static will be evident from time to time especially in areas without a direct line of sight to the transmitter.
  • Page 41 1- Chapter 1 DASHBOARD AUDIO SYSTEM cont. Care Of your CD Dirt and liquids on CDs may soil the Handle the CD by its edge and avoid audio systems CD player lens resulting touching the playing surface. in malfunction. Before inserting a CD into the audio system, clean the CD with a cleaning cloth.
  • Page 42 1- Chapter 1 DASHBOARD AUDIO SYSTEM cont. Glossary Of terms Automatic Station Search Station search by tuner. The tuner will search until a station is found. Autostore (AS) The best receivable stations in the FM and AM wave bands can automatically be stored. The stations are stored in a separate AS memory.
  • Page 43 1- Chapter 1 DASHBOARD DIMMER Dimmer – instrument lighting To adjust the instrument lighting brightness, ensure the headlights or park lights are switched on. To dim the instrument illumination, move the wheel to the left, to brighten the instrument illumination, move the wheel to the right.
  • Page 44 1- Chapter 1 DASHBOARD WIPERS AND WASHERS Windshield wipers To operate the windshield wipers, turn the ignition switch to the ACC or ON position and move the windshield wiper / washer lever to one of the following five positions: • MIST: To operate the wipers once in case of light rain or mist, move the windshield wiper lever downward and release it.
  • Page 45 1- Chapter 1 DASHBOARD WIPERS AND WASHERS cont. Rear wiper To switch the rear wiper on, push the wiper lever toward the instrument panel, the wiper will operate with a regular cycle. C05H017P Rear washer To spray washer fluid push the button at the end of the lever until the washer begins.
  • Page 46 1- Chapter 1 DASHBOARD HEADLAMPS and FOG LAMPS Headlamp switch controls The headlamp switch controls the following: • Headlamps off • Tail lamps, Parking lamps, Number plate lamps, Instrument panel lamps are illuminated. • The low beam headlamps and all of the above lamps are illuminated.
  • Page 47 1- Chapter 1 DASHBOARD HEADLAMPS and FOG LAMPS cont Front fog lamps The front fog lamps provide extra illumination to the sides of the road ahead and improve visibility in fog or snow conditions. To switch the front fog lamps on make sure the headlight switch is in the position, then press the button on the...
  • Page 48 1-0 Chapter 1 DASHBOARD TURN SIGNALS AND IGNITION SWITCH Turn signals The turn signal lever is on the right-hand side of the steering column. Push the lever up to signal a left turn and down to signal a right turn. In some turns (such as changing lanes), the steering wheel is not turned far enough to cancel the turn signal.
  • Page 49 To provide additional security, your vehicle is fitted with a vehicle immobiliser. The engine will not start unless the correct key (correctly programmed) is used. Note: Any additional or replacement keys must be purchased from and programmed by a Holden Dealer. Hazard warning Press the switch located below the right centre air vent, to switch the hazard warning flasher on and off.
  • Page 50 1- Chapter 1 DASHBOARD HORN Horn To sound the horn, press the horn symbol on either side of the steering wheel centre pad. The horn will sound regardless of ignition switch position. C05E101A...
  • Page 51 1- Chapter 1 DASHBOARD CLIMATE CONTROL C05H041Q  Side vent  Floor vent   Windscreen demister vent Front door glass demister vent  Centre vent Air outlets The direction of air flowing out of the vents can be changed by moving the airflow deflectors up, down, left or right.
  • Page 52 1- Chapter 1 DASHBOARD CLIMATE CONTROL cont. C05E075B   AUTO mode button Rear window demister button   APS mode button Windscreen demister button   Fan speed selector Air recirculation button   Air conditioning button Air temperature selector ...
  • Page 53 1- Chapter 1 DASHBOARD CLIMATE CONTROL cont. Air outlet selector Different vents are selected when the air outlet selector is set in the following positions: Air flows from the four face level outlets in the instrument panel. The blending mode directs the airflow through both the instrument panel outlets and the floor outlets.
  • Page 54 1- Chapter 1 DASHBOARD CLIMATE CONTROL cont. The fully automatic climate control system controls the interior temperature of your vehicle. It achieves the desired temperature when you select the auto mode. The desired temperature is controlled by an in-car sensor, coolant temperature, sun sensor and the ambient temperature sensor.
  • Page 55 1- Chapter 1 DASHBOARD CLIMATE CONTROL cont. Air conditioning button Press this button to switch the air conditioning on. The engine must be running for the feature to work. Set the fan position to 1, 2, 3, or 4 to begin air circulation. An indicator light illuminates on the button when the air conditioning is in use.
  • Page 56 1- Chapter 1 DASHBOARD CLIMATE CONTROL cont. Recirculation mode Press the recirculation button to recirculate the air in your vehicle. This is useful for keeping dust and odours out or when quick heating or cooling is desired. The indicator light in the button illuminates. Press the button again to switch off the recirculation feature and allow outside air into your vehicle.
  • Page 57 1- Chapter 1 DASHBOARD CLIMATE CONTROL cont. The air purity sensor automatically draws outside air into the passenger compartment or converts to recirculation mode to prevent exhaust gas from the outside contaminating air within the passenger compartment. Press the button to activate the APS mode, the indicator light on the button illuminates.
  • Page 58 1-0 Chapter 1 DASHBOARD CLIMATE CONTROL cont. Operating Tips • To conserve fuel, switch off the air conditioner when it is not required. • Keep the area under the front seat clear of objects to help air circulate through the vehicle.
  • Page 59 1-1 Chapter 1 DASHBOARD GLOVEBOX Glovebox The glovebox is located on the passenger side of the instrument panel. The glovebox can be opened by pulling the handle. Push the lid shut to close the glovebox. C7E2024P Glovebox cooling The glovebox is air conditioned to keep snacks fresh while you are travelling.
  • Page 60 1- Chapter 1 DASHBOARD STORAGE COMPARTMENTS Card holder The card holder is located on the right-hand side of the instrument panel. The card holder can be used by inserting a card into the slot. C7E2028P Coin storage The coin storage is located on the right-hand side of the instrument panel.
  • Page 61 1- Chapter 1 DASHBOARD Notes...
  • Page 62 1- Chapter 1 DASHBOARD...

  • Page 63: Locks

    Locks Page Keys and keyless entry Manual lock operation Rear tailgate lock Child proof lock Bonnet release 3 The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
  • Page 64 In the event of the original keys being lost, any additional or replacement keys must be purchased and programmed by a Holden Dealer, using your key code number.
  • Page 65 Chapter 2 LOCKS KEYS AND KEYLESS ENTRY cont. Keyless entry using remote control The range of the remote control unit should be approximately 6 metres, this may be reduced due to shadowing and reflection of the radio waves. To operate the remote control unit, direct it at the vehicle and press the required button.
  • Page 66 Even if only one transmitter is being replaced, you must rematch all of your transmitters at the same time. Up to four transmitters can be matched to your vehicle. See your Holden Dealer to purchase a new transmitter and to have transmitters matched to your vehicle.
  • Page 67 Chapter 2 LOCKS MANUAL LOCK OPERATION Manual locking system To lock using key: Insert the key in the driver's door lock. Turn the key toward the rear of the vehicle. Allow the key to return to its vertical position for removal.
  • Page 68 Chapter 2 LOCKS MANUAL LOCK OPERATION cont. Door lock buttons To lock: To lock any door from the inside, push down on the door lock button. To unlock: To unlock any door from the inside, pull up on the door lock button. WARNING: C05E117A Before driving, ensure the doors are...
  • Page 69 Chapter 2 LOCKS MANUAL LOCK OPERATION cont. Child proof lock The rear doors on the vehicle can be locked to prevent children from opening them from the inside. To engage the child lock, open the rear door and locate the child proof lock on the doors rear edge.
  • Page 70 Chapter 2 LOCKS...

  • Page 71: Know.your.vehicle

    Interior lamps 3-18 Accessory power outlets 3-19 Sun visors and assist grips 3-20 Storage compartments 3-23 Roof rails 3 The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
  • Page 72 Chapter 3 KNOW YOUR VEHICLE SEAT ADJUSTMENT Manual front seats Seat slide adjustment Lift the lever to unlatch the front seat. Slide the seat as required. Release the lever. Try to move the seat back and forth to check if the catch is fully engaged.
  • Page 73 Chapter 3 KNOW YOUR VEHICLE SEAT ADJUSTMENT cont. Driver’s power seat Seat slide adjustment To move the seat forward or backward, move and hold the switch in the forward or rear position. When the seat reaches the desired position, release the switch. C05H006P Seat height adjustment To adjust the height of the front part of the...
  • Page 74 Chapter 3 KNOW YOUR VEHICLE SEAT ADJUSTMENT cont. Rear seats Seat reclining The rear seats can be partially reclined. To tilt the seatbacks, lift the lever on top of the rear seatback until the seatback is adjusted to the desired position. C05E017A Seat folding The seatbacks can be folded down for...
  • Page 75 Chapter 3 KNOW YOUR VEHICLE HEAD RESTRAINT ADJUSTMENT Adjusting the height To adjust the height of the head restraint, pull up or push down whilst pressing the lock button in. Note: The upper edge of the head restraint should be approximately at eye level, and not at neck level.
  • Page 76 Chapter 3 KNOW YOUR VEHICLE SEAT BELTS Front seat belts To fasten the retractor seat belt, pull the metal tongue across your body and clip it into the buckle. When the metal tongue has locked safely into place you will hear a click. After fastening, settle the seat belt by running your hand under the seat belt starting at the hip, move your hand across to the buckle...
  • Page 77 Chapter 3 KNOW YOUR VEHICLE SEAT BELTS cont. Rear seat belts To put on the seat belt, pull the shoulder portion of the seat belt down until the metal tongue reaches the buckle. Press the metal tongue into the buckle until it clicks into position.
  • Page 78 This is designed to remind you the pretensioner system has been used and therefore needs to be replaced by your Holden Dealer. The seat belts would remain operational, apart from this safety feature.
  • Page 79 Check the seat belts regularly. Replace the seat belts if they become frayed or damaged. The buckle and retractors mechanism operation should also be checked. Your Holden Dealer will regularly do these things as part of the scheduled maintenance plan, refer to the Service Handbook.
  • Page 80 3-0 Chapter 3 KNOW YOUR VEHICLE WHICH TYPE OF CHILD RESTRAINT FOR YOUR CHILD? Children should be restrained at all times and fitted with a child restraint appropriate to their size when travelling in a vehicle. The following outlines guidelines about selecting the appropriate restraint.
  • Page 81 3- Chapter 3 KNOW YOUR VEHICLE CHILD RESTRAINTS J06VF0088 WARNING – EXTREME HAZARD: • Do not use a rearward facing child restraint on a seat protected by an air bag in front of it. The child could be seriously injured if the air bag inflates, as the child’s head would be very close to the inflating air bag. • Never install a child restraint in the front seat of a vehicle fitted with Side Impact Air Bags (SIAB). Remember that it is safer for children to be seated in the rear seats.
  • Page 82 3- Chapter 3 KNOW YOUR VEHICLE CHILD RESTRAINTS cont. Anchor points The tether anchor brackets are installed on the rear of the back seats as shown. Note: The anchor brackets are installed in three positions. C05H001P Attaching the child restraint Tether strap Place the child restraint on the rear seat and attach it to the anchors following...
  • Page 83 3-3 Chapter 3 KNOW YOUR VEHICLE MIRRORS Interior rear view mirror To adjust the rear view mirror, move the mirror right or left, up or down to gain the required angle. The anti-glare lever on the lower edge of the mirror enables the reflector to be used during night driving.
  • Page 84 3- Chapter 3 KNOW YOUR VEHICLE TILT STEERING AND ANTENNA Tilt and telescopic steering The tilt/telescopic steering lever is located on the underside of the steering column. To adjust the height or the reach of the steering wheel, push the lever downward, this unlocks the steering column.
  • Page 85 3- Chapter 3 KNOW YOUR VEHICLE POWER WINDOWS Power windows The main switches for the power windows are located on the driver’s door armrest. The front switches are for the front windows and the rear switches are for the rear windows.
  • Page 86 3- Chapter 3 KNOW YOUR VEHICLE INTERIOR LAMPS Centre interior lamp When either interior lamp buttons are pressed, the left-hand or right-hand lamp will illuminate and stay on until the button is pressed again. The centre and rear interior lamps illuminate when a door or the tailgate is opened.
  • Page 87 3- Chapter 3 KNOW YOUR VEHICLE INTERIOR LAMPS cont. Front door step lamps The front door step lamps illuminate when a door is opened. If the door is left open the lamps will stay illuminated for approximately 10 minutes. When the front door is closed the lamp stays illuminated for approximately 10 seconds, then switches off.
  • Page 88 3- Chapter 3 KNOW YOUR VEHICLE ACCESSORY POWER OUTLETS Front centre console An accessory power outlet is located in the front centre console at the rear of the front cup holders. C05H029Q Rear centre console An accessory power outlet is located on the rear of the centre console below the rear cup holders.
  • Page 89 3- Chapter 3 KNOW YOUR VEHICLE SUN VISORS AND ASSIST GRIPS Sun visors The padded sun visors are used to block out the sun. They can be pivoted up, down and to the side when unhooked, both sun visors have a ticket holder. C7E2031P Assist grip Assist grips are located above the doors...
  • Page 90 3-0 Chapter 3 KNOW YOUR VEHICLE STORAGE COMPARTMENTS Cup holders The cup holders are located in the front and rear of the centre console, the front cup holders are easily accessible. To use the rear cup holder, push the button above the cup holder, it will pop out automatically.
  • Page 91 3- Chapter 3 KNOW YOUR VEHICLE STORAGE COMPARTMENTS cont. Note: Do not allow items in the storage compartment to extend above the top of the storage container, otherwise the storage compartment or the luggage area floor panel may be damaged. C05E099A Floor side trays Floor side trays are located on both sides...
  • Page 92 3- Chapter 3 KNOW YOUR VEHICLE STORAGE COMPARTMENTS cont. Sunglass holder The sunglass holder is located behind the map lamps. To open, push on the rear part of the cover. To close, push upward until it latches. C7E2071A Rear storage compartment The rear storage compartment is located at the rear of the centre console, to open, press the button above the compartment.
  • Page 93 3-3 Chapter 3 KNOW YOUR VEHICLE ROOF RAILS Roof rails The roof rails can be used to carry additional cargo, or bulky items which are better carried outside the vehicle rather than inside. The roof rails are attached to the roof of the vehicle.
  • Page 94 3- Chapter 3 KNOW YOUR VEHICLE...

  • Page 95: Driving

    Descent control system (DCS) 4-16 All wheel drive system (AWD) 4-17 Park brake 4-18 Cruise control 4-20 Add on equipment 3 The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
  • Page 96 Chapter 4 DRIVING SAFETY Before entering the vehicle 1. Check that windows, mirrors and lights are clean. 2. Visually check tyre inflation. Note: It is recommended to check the tyre pressures with a pressure gauge each week. Before driving away 1.
  • Page 97 Chapter 4 DRIVING SAFETY cont. Off road driving The Captiva has not been designed as a full off road vehicle. The requirement to maintain a very high degree of comfort, ride, handling and stability dictates the ground clearance may not be sufficient to allow the vehicle to be driven over very severe four wheel drive tracks.
  • Page 98 10 seconds. If the engine still does not start, release the key and pedal. Wait another 15 seconds and then repeat the entire procedure. If the engine still fails to start, contact your Holden Dealer.
  • Page 99 If the engine is misfiring, reduce the vehicle speed and do not attempt to tow a caravan or trailer, until the misfiring is corrected by the nearest Holden Dealer. Continued driving while the engine is misfiring could result in the catalytic converter and exhaust system overheating, resulting in vehicle damage.
  • Page 100 Chapter 4 DRIVING Dri Ving Pr ECAUTiOn S cont. Brakes Power assisted brakes, which are fitted to your vehicle, utilise vacuum from the engine when it is running. Never let the vehicle run down steep inclines without the engine running. Never coast with the engine switched off. A decrease in driving, cornering and braking traction occurs when water, snow, ice, gravel or other materials are on the road surface.
  • Page 101 If the vehicle is stationary in deep water for an extended period, it should be checked by an authorised Holden Dealer as soon as practicable for water entry to engine, transmission, differentials and wheel bearings.
  • Page 102 Chapter 4 DRIVING AUTOMATiC Tr An SMiSSiOn This system has a five-speed electronically controlled automatic transmission. Its shift indicators are arranged with P (park) at one end, followed in sequence by R (reverse), N (neutral) and then the forward driving ranges.
  • Page 103 Chapter 4 DRIVING AUTOMATiC Tr An SMiSSiOn cont. WARNING: You can select some transmission positions without pressing the button on the selector grip. However, it is recommended that you become familiar with these positions to prevent any accident or damage to your transmission that may occur due to incorrect operation.
  • Page 104 Lamp illuminates. In this situation, the transmission may not shift automatically, or shifting may be much harsher than normal. Have the vehicle serviced as soon as possible by your Holden Dealer. If the malfunction indicator lamp stays on after starting the engine and the transmission does not shift, refer to Chapter 6, Transmission shift lock control system, for more information.
  • Page 105 4- Chapter 4 DRIVING AUTOMATiC Tr An SMiSSiOn cont. Transmission kick down For faster acceleration, press the accelerator pedal all the way down and hold it. The transmission will shift to a lower gear giving more power. When the desired speed is reached, lift off the accelerator and the transmission will shift up.
  • Page 106 ABS. The vehicle’s brake system remains operational but without ABS assistance. You should consult your Holden Dealer as soon as possible. The braking effect is regulated by the ABS every millisecond during braking.
  • Page 107 ESP® function and the ESP® off indicator will extinguish. Note: If the ESP® off does not illuminate when the button is pressed, or it illuminates while driving, it indicates the ESP® system is not functioning. See your Holden Dealer. C05H039P...
  • Page 108 4-4 Chapter 4 DRIVING ELECTr Oni C STABiLiTY Pr Ogr AM (ESP®) cont. Electronic brakeforce distribution (EBD) This system senses the vehicle load (both passengers and luggage) and optimises rear braking force. This system works in combination with the ABS system to prevent excessive braking locking the rear wheels by transferring braking pressure between the front and the rear axles.
  • Page 109 If the amber DCS not ready and warning indicator illuminates it indicates there is a • malfunction in the DCS system. If this condition occurs, see your Holden Dealer. DCS off To deactivate the DCS, press the DCS...
  • Page 110 AWD system is temporarily disabled. If the lamp flashes briefly and then stops, this is normal and does not indicate a system fault. However if the indicator flashes continuously this indicates there is a malfunction in the AWD system. See your Holden Dealer. C7E2106A...
  • Page 111 4- Chapter 4 DRIVING PAr K Br AKE Park brake The park brake acts on the rear wheels and the lever is located between the front seats. To apply the park brake, stop the vehicle, apply the brake pedal and pull the lever firmly upward.
  • Page 112 4- Chapter 4 DRIVING Cr UiSE COn Tr OL Description The cruise control maintains the speed of the vehicle from approximately 40 km/h and upward without having your foot on the accelerator pedal. When the brakes are applied the cruise control disengages. If your vehicle is in cruise control mode when the traction control system begins to limit wheel spin, the cruise control will automatically disengage.
  • Page 113 4- Chapter 4 DRIVING Cr UiSE COn Tr OL cont. Using cruise control on hills When going up a steep hill, you may have to depress the accelerator pedal to maintain your speed. When going downhill, you may have to brake or shift to a lower gear to decrease the vehicles speed.
  • Page 114 Cargo barrier If a cargo barrier is to be fitted, it is critical the Holden approved cargo barrier be used. Other types must not be fitted. The Holden cargo barrier is available from your Holden Dealer and has been compatibility tested with the vehicle’s design, including the Holden...
  • Page 115 4- Chapter 4 DRIVING n otes...
  • Page 116 4- Chapter 4 DRIVING...

  • Page 117: Fuel

    Chapter 5 FUEL Fuel Page Fuel 5-3 Fuel filling 5-4 Petrol – emission control 5-5 Reducing fuel consumption WARNING: The vehicle’s engine has not been designed for conversion to LPG. The performance and safety of the vehicle would be seriously jeopardised if converted to LPG. 3 The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
  • Page 118 – whenever the exhaust system, underbody or rear of the vehicle is damaged. • Take the vehicle to your Holden dealer if you think your vehicle needs inspecting for any of the above reasons. • Do not sit (or leave children or pets) in a parked vehicle for any extended period of time with the engine running.
  • Page 119 Chapter 5 FUEL FUEL FILLING Fuel filler door Stop the engine. • Unlock the doors by pressing the door • lock switch on the driver's door trim pad, then the fuel filler door can be opened by hand. Fuel cap Remove the fuel cap by turning it slowly anticlockwise. C7E3015A WARNING: If you open the cap rapidly while pressure in the tank is high, fuel may spray out from the tank.
  • Page 120 Australian Design Rules, refer to A.D.R. 83/00 (External Noise) and A.D.R. 79/02 (Emission Control for Light Vehicles). It is also illegal to drive a vehicle modified in this way. First drive When the vehicle is driven for the first time, wax and oil on the exhaust system may evaporate, producing smoke-like emissions that should not be inhaled. Allow wax and oil to evaporate while the vehicle is in the open air. Maintenance requirements To ensure continuing compliance with the regulations, you must maintain your vehicle’s emission control system as per your vehicle's service manual, at the frequency shown in the maintenance schedule in the Service/Warranty Booklet. It is recommended the necessary servicing be performed by an authorised Holden Dealer who has the specialised servicing equipment and trained personnel available to ensure the adjustments and services specified are carried out.
  • Page 121 Chapter 5 FUEL REDUCING FUEL CONSUMPTION Engine Maintain the engine in peak mechanical condition by having it serviced regularly in accordance with the maintenance schedule in the Service/Warranty Booklet. This ensures items such as the spark plugs and air cleaner are maintained for minimum fuel usage and peak engine performance. Tyre pressure Keep the tyres at the recommended pressures. Under-inflated tyres create extra rolling resistance and waste fuel, refer to Chapter 7, Weekly checks. Incorrect tyre pressures can also cause uneven and premature tyre wear. Wheel alignment Maintain correct front wheel alignment. Incorrect alignment makes the front wheels drag which wastes fuel and causes uneven and premature tyre wear. Warm ups and idling Avoid long engine warm ups. They are unnecessary and waste fuel. An engine takes approximately five minutes to reach its efficient operating temperature and it does this most effectively when driving. You should also avoid long engine idling. If you have to wait for more than a couple of minutes, switch off the engine to conserve fuel.
  • Page 122 Chapter 5 FUEL...

  • Page 123: Emergencies

    6-22 Fuses 6-27 Bulb replacement Your new vehicle is covered for 3 years by 24 hour Roadside Assistance. 3 The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
  • Page 124 Sales Manager or Service Manager – go to the General Manager or to the Dealer Principal. By now you should have satisfaction. If not, the Holden Customer Assistance office is at your disposal. The Holden Customer Assistance representatives can be telephoned from anywhere within Australia for only the cost of a local call.
  • Page 125 Warranty and Owner Assistance provisions for New Zealand. Applicable details for New Zealand are set out in the Holden Warranty and Owner Assistance Information booklet enclosed in the New Zealand glovebox wallet.
  • Page 126 From the moment delivery is made, our aim is to provide the finest possible ownership experience, from design through manufacturing to servicing and now beyond to the open road, Australia wide. We hope the need never arises, but if it does, we’ll be there to help through Holden Roadside Assistance. How does Holden Roadside Assistance work? Holden Roadside Assistance is provided by GM Holden Ltd.
  • Page 127 Holden’s warranty can be claimed by contacting your local Holden Dealer. What happens if I sell my vehicle? Holden Roadside Assistance stays with the vehicle, so if you sell your vehicle during the 36 month period, it is still eligible for the balance of the Holden Roadside Assistance.
  • Page 128 6-6 Chapter 6 EMERGENCIES HAZARD WARNING Hazard warning Use the hazard warning to warn other drivers any time your vehicle becomes a traffic hazard, day or night. Avoid stopping on the roadway if possible. Switch the hazard warning on or off by pressing the hazard warning switch, which is located under the centre air vent.
  • Page 129 6- Chapter 6 EMERGENCIES FLAT TYRE If using a jack other than the one supplied with the vehicle, refer to Chapter 7, Weekly checks, for lifting positions. WARNING: • Use the jack only for lifting the vehicle when changing wheels. •  Do  not get under a vehicle supported only by a  jack, use vehicle support  stands. •  Do  not  start  or  run  the  engine  while  the  vehicle  is  only  supported  by  the  jack.
  • Page 130 6- Chapter 6 EMERGENCIES FLAT TYRE cont. 3. Remove the wing bolt from the spare wheel by turning it counterclockwise. 4. Remove the spare wheel. C05E048A 5. Remove the wing bolt from the jack by turning it counterclockwise. 6. Remove the jack. 7.
  • Page 131 6- Chapter 6 EMERGENCIES FLAT TYRE cont. 9. Place the jack under the jacking point nearest the wheel your want to change. 10. Attach the wheel wrench to the jack bolt head. 11. Turn the jack handle clockwise to raise the jack.
  • Page 132 6-0 Chapter 6 EMERGENCIES FLAT TYRE cont. 14. Remove any dirt or rust from the wheel nuts and studs, mounting surfaces and spare wheel. 15. Place the spare wheel on the wheel mounting surface. 16. Install the wheel nuts and tighten by hand.
  • Page 133 6- Chapter 6 EMERGENCIES TOWING YOUR DISABLED VEHICLE Emergency towing Proper lifting or towing equipment is necessary when lifting or towing the vehicle to prevent damage. State and local laws must be followed. In an emergency, the vehicle may be towed on all four wheels for short distances only in the following manner: 1.
  • Page 134 6- Chapter 6 EMERGENCIES TOWING YOUR DISABLED VEHICLE cont. Rear towing eye When towing another vehicle, use the rear towing eye. It should be used only in an emergency situation. To use the rear towing eye attachment, use the following procedure: Locate the rear towing eye attachment in the compartment under the rear luggage area floor cover.
  • Page 135 6- Chapter 6 EMERGENCIES ENGINE OVERHEATING WARNING:  •  Immediate action is required if the engine overheats. This can be indicated by  the temperature gauge needle moving to the red zone, by steam escaping from  under the bonnet, a loss of power or a loud knocking or pinging noise. • Continued driving even for a short time could result in a fire or vehicle damage. If the coolant temperature gauge needle should move to the H position and remain there for more than 30 seconds, pull over to the side of the road.
  • Page 136 6- Chapter 6 EMERGENCIES ENGINE OVERHEATING cont. If you see or hear steam coming from the engine, stop and switch the engine off. Do not open the bonnet until the engine has cooled down. If the temperature gauge is high with no sign of steam: 1. Pull over and stop the vehicle as soon as it is safe to do so. 2.
  • Page 137 10 minutes if the temperature gauge does not again show an overheat condition. If overheating occurs again you should have the vehicle attended to, as soon as possible, by a Holden Dealer. The engine may temporarily operate at high temperatures during demanding operating conditions, especially on hot days, including: •...
  • Page 138 5. Shift the gear lever to N (neutral). 6. Remove the key from the slot. 7. Start the engine and shift the transmission into the desired position. 8. Reinstall the cap. 9. Refer to your Holden Dealer as soon as possible.
  • Page 139 6- Chapter 6 EMERGENCIES FLAT BATTERY WARNING: •  Do not push start or tow start your vehicle. If unburnt fuel were to reach the  catalytic converter and ignite, the converter could overheat or be destroyed  by backfire. Therefore, if the battery is flat, you can jump start, but not push start your vehicle. •  To protect your vehicle's electrical system never disconnect the battery when  the engine is running. Never charge the battery while it is still connected to  the vehicle, first disconnect the negative cable, then the positive cable. The polarity of the battery, i.e. the connections for the positive and negative cables, ...
  • Page 140 6- Chapter 6 EMERGENCIES FLAT BATTERY cont. Jump starting 1. The battery in your vehicle has a negative earth and a 12 volt rating. The battery in the other vehicle must also have a negative earth and a 12 volt rating. 2.
  • Page 141 6- Chapter 6 EMERGENCIES AIRBAGS Front airbags The driver's airbag is stored inside the steering wheel. AIRBAG is stamped on the steering wheel and a label is attached under the driver's side sunvisor. WARNING: •  The  h orn  p ad  m ust  n ot  b e  c overed  w ith  adhesive or any other material.
  • Page 142 • Airbags inflate with great force, if you are too close to an inflating airbag it may cause injury. Seat belts help keep you in position for airbag inflation in the event of a collision. The system should also be inspected by a Holden Dealer if: • The steering wheel or dashboard area is scratched, cracked or damaged;...
  • Page 143 6- Chapter 6 EMERGENCIES AIRBAGS cont. Roo/nudge bar If a roo/nudge bar is to be fitted, it is critical the Holden approved roo/nudge bar be used. Refer to Chapter 4, Driving, for further information. Passenger airbag and child restraints WARNING – EXTREME HAZARD: •  Do NOT use a rearward facing child  restraint on a seat protected by an  airbag in front of it.  The child could be seriously injured ...
  • Page 144 If a fuse blows twice in a row a fault is indicated. The cause should be located and rectified by a Holden Dealer. Foot well fuses To open the fuse cover on the left-hand side of the drivers foot well, open the driver's side door, pull the top of the cover outward.
  • Page 145 6- Chapter 6 EMERGENCIES FUSES cont. Driver foot well fuse panel C7E6038A...
  • Page 146 6- Chapter 6 EMERGENCIES FUSES cont. No Allocation AMP's No Allocation AMP's Relay ACC/RAP Front mirror Door Lock Lift glass Airconditioning Front door lock Airconditioning BCM (VB6) Relay run/crank OSRVM HT AP01 Cigar BCM (VB2) AP02 SSPS BCM (VB3) BCM (VB7) Clock Heat/Mat Passenger power...
  • Page 147 6- Chapter 6 EMERGENCIES FUSES cont. Engine compartment Relays Relays are also contained in this fuse box; their location in the fuse box and their function is indicated on the inside of the fuse box cover. 13 14 15 21 22 23 25 26 30 31 32 38 39 40...
  • Page 148 6-6 Chapter 6 EMERGENCIES FUSES cont. No Allocation No Allocation Starter relay Run relay Main relay Anti theft Sun roof Engine 2 Accessory/Ignition Engine 1 Battery Starter Power seat Defog relay Main A/C compressor Front defog relay Engine 3 Park lamp relay Auxiliary fan relay H/light Low RH A/C compressor relay...
  • Page 149 Detailed procedures for headlight aiming are given in the relevant service manual for your vehicle. However, because headlamp aiming is a safety item it is recommended that you have it carried out by your Holden Dealer. Head lamps (55 W) 1. Open the bonnet.
  • Page 150 6- Chapter 6 EMERGENCIES BULB REPLACEMENT cont. Front turn signal lamps (21W) 1. Open the bonnet. 2. Remove the head lamp assembly, refer to Head lamps in this section. 3. Rotate the front turn signal bulb holder counterclockwise and pull it out of the lamp housing.
  • Page 151 6- Chapter 6 EMERGENCIES BULB REPLACEMENT cont. Rear tail lamps 1. Open the tailgate. 2. Remove the two screws and the lamp assembly. 3. Remove the bulb holder by rotating it counterclockwise. 4. Push the bulb inward and rotate it counterclockwise. 5. Insert the replacement bulb into the holder and rotate it clockwise.
  • Page 152 2. Remove the bulb and install the replacement. 3. Refit the lamp assembly. C7E6014P Note: The front fog lamps and the high mount stop lamp are not serviceable, if they fail to illuminate see your Holden Dealer.
  • Page 153 6- Chapter 6 EMERGENCIES Notes...
  • Page 154 6- Chapter 6 EMERGENCIES...

  • Page 155: Weekly.checks

    7- Chapter 7 WEEKLY CHECKS Weekly checks Page Miscellaneous checks Check locations Engine coolant level Engine oil level Engine oil consumption 7-7 Automatic transmission fluid level 7-8 Brake fluid level 7-9 Power steering and washer fluid levels 7-10 Tyres 7-13 Battery 3 The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
  • Page 156 7- Chapter 7 WEEKLY CHECKS MISCELLANEOUS CHECKS As well as taking your vehicle to be serviced (refer to the Servicing Handbook) there are a few simple, weekly checks the owner (or nominee) is recommended to make. These are shown on the following pages. WARNING: • The engine cooling fan can start working unexpectedly, even when the engine is not running. To avoid injury from the fan, ensure the ignition switch is in the LOCK position, so the fan can not start operating. •...
  • Page 157 7- Chapter 7 WEEKLY CHECKS CHECK LOCATIONS 3.2 DOHC HFV6 C7E6   Air cleaner Battery  Engine oil filler cap  Washer fluid reservoir  Power steering fluid reservoir  Brake fluid reservoir  Engine oil level dipstick  Coolant reservoir  Fuse and relay box...
  • Page 158 In emergency situations, plain water may be used temporarily until the correct coolant is obtained as soon as possible from the nearest Holden Dealer. The specified coolant works in three ways: it contains special corrosion inhibitors, it helps the cooling system in hot weather by increasing the boiling point and it protects against freezing down to -30°C, provided the correct concentration is maintained. If you regularly have to top up the cooling system you should contact your Holden Dealer. WARNING: Corrosion inhibitors and antifreeze fluids are poisonous. Use extreme care when handling. If swallowed seek medical attention. If the engine overheats, refer to Chapter 6, Emergencies.
  • Page 159 The oil level should be maintained between the marks, neither going above the upper mark nor under the lower mark. Note: Remember to insert the dipstick firmly after taking the reading. C7E6025C To add engine oil Use the correct oil for your vehicle. Refer to Chapter 8, Specifications. 1. Remove the engine oil cap. 2. Add the required amount of oil. 3. Wait a few minutes for the oil to settle, then check the oil level again. When the oil level is correct, replace the oil cap and dipstick, and clean up any spilt oil. C7E6015B Note: Non-detergent and other low quality oils are specifically not recommended. The use of break-in oil, tune up compounds, friction reducing compounds and other supplemental additives are not recommended. Their use will increase costs, may be detrimental to the operation of your car and may void your New Vehicle Warranty, to the extent that Holden considers the non-recommended fluid to have affected the specifications or quality of your vehicle.
  • Page 160 Probably the most prevalent complaint of oil consumption comes from the driver whose vehicle is frequently driven at below normal operating temperatures. The oil becomes diluted by fuel and moisture which settles in the oil pan and may even raise the oil level creating a false reading on the oil level dipstick. For example, in a vehicle that has accumulated 1,500 km of short distance or intermittent city operation and has consumed a normal amount of oil, the level may not have dropped from the full mark, due to dilution. If this vehicle is driven for some distance at highway speeds on a warm day, the dilution elements evaporate, lowering the oil level and the motorist assumes the oil lost has been consumed in the highway operation. If, after taking into account the above factors, you are still concerned that your engine has excessive oil consumption then you should discuss the situation with a Holden dealer. Remember that an engine’s oil consumption should not be judged until it has run at least 10,000 km.
  • Page 161 7-7 Chapter 7 WEEKLY CHECKS AUTOMATIC TRANSMISSION FLUID LEVEL Automatic transmission fluid level check The fluid level for automatic transmission will be checked for you when your vehicle is taken to your Holden Dealer for servicing, refer to the Servicing Handbook. Note: The automatic transmission fluid level does not require checking by the driver in between these scheduled services.
  • Page 162 • Do not spill brake fluid on the vehicle's exterior surfaces. It can damage the paintwork. If you do, wash it off immediately. The fluid should be kept at the proper level between the MIN and MAX lines on the reservoir. If the brake fluid level is low, the brake system warning light comes on. See "Brake system warning light" in Chapter 1, Dashboard. Brake fluid reservoir Note: If your reservoir requires constant topping up it could indicate that a fault exists. Contact your Holden Dealer immediately. C7E6003P...
  • Page 163 Switch off the ignition. Wipe the cap and the top of the reservoir clean. Remove the cap. Add only enough fluid to bring the level up to the MAX mark. Do not overfill. Replace the cap tightly. Clean up any spilt fluid. Refer to Chapter 8 Specifications, for power steering fluid specifications. If you often need to add fluid, you should see your Holden Dealer. Washer fluid level As washer fluid is regularly used, the level in the washer fluid reservoir should be checked and topped up weekly. For a crystal clear windshield, use the correct amount of Holden Optikleen. Do not use ordinary soap or detergent as these not only froth up but would also damage the wiper rubbers. Ensure the cap is secured. C7E6008A...
  • Page 164 If the pressure is too high, this can result in reduced traction, increased risk of tyre blowout and poor tyre wear. Remember to replace any valve dust caps or extensions, as this stops dirt and moisture from fouling the valves. When checking the tyre air pressure, take a look at the condition of the tyre tread and inspect for stones or abnormal wear. Tyre condition and rim condition Driving over sharp edges can lead to hidden tyre damage and rim damage, which can lead to tyre blowout, drive over edges slowly and at right angles if possible. When parking, ensure the tyres are not pressed against the edge of the curb. Check the tyres regularly for: damage, stones, punctures, cuts, cracks, bulges etc. Check the rims for damage. Consult a Holden Dealer, if in doubt.
  • Page 165 7- Chapter 7 WEEKLY CHECKS TYRES cont. Alignment and balance Improper wheel alignment can cause the tyres to wear faster and to wear unevenly. It can also cause the vehicle to pull to the left or right. Out-of-balance wheels and tyres can cause annoying vibration and uneven tyre wear. If you suspect either of the above problems exist, have a wheel alignment and balance check carried out by your Holden Dealer. Tyre rotation Front and rear tyres perform different jobs and can wear differently depending on the types of roads driven, your driving habits, wheel alignment, balance, tyre pressures, etc. Check the tread depth regularly. If the front tyres have more wear than the rear tyres, have both front wheels rotated with the rear wheels so the tyres with the deeper tread are at the front. Follow the diagram for the correct rotation pattern. If the wheels are rotated it is recommended to check the balance at the same time. J06VF0148...
  • Page 166 WEEKLY CHECKS TYRES cont. Replacement and repair Replacing your factory fitted wheels and tyres with non standard wheels and tyres may affect your new vehicle warranty as well as your insurance policy. Refer tyre placard for tyre size and load rating. Using a different size or type of tyre may affect ride, handling, speedometer, vehicle ground clearance, tyre clearance or snow chain clearance. Take care when using tyres with heavy treads, including tyres made for better grip in the wet. At sustained high speeds, this type of tyre will run at higher temperatures than standard tyres and consequently should only be operated within the limits recommended by the manufacturer. Any doubts about the tyres on your vehicle should be referred to your Holden Dealer. New tyres should be fitted in pairs to the front. If replacing only one tyre, it should be paired on the same axle with the least worn of the other three. The tyres have tread wear indicators (A) which tell you when a tyre has 1.5mm or less of tread left. You should replace your tyres when: • The tyres are worn to the point where the tread indicators appear, or the cord or fabric is showing. The tyres originally fitted to your vehicle have built-in tread indicators which show up when the tyres are worn.
  • Page 167 7- Chapter 7 WEEKLY CHECKS BATTERY Battery maintenance Your vehicle is fitted with a maintenance free battery, which means the fluid level does not need to be checked. To extend the life of your battery, do the following: • Keep the battery mounted securely. • Keep the top of the battery dry and clean.
  • Page 168 7- Chapter 7 WEEKLY CHECKS...

  • Page 169: Specifications

    Chapter 8 SPECIFICATIONS Specifications Page 8-2 Specifications 8-4 Identification labels 3 The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
  • Page 170 Chapter 8 SPECIFICATIONS SPECIFICATIONS Engine Type 3.2 Litre DOHC V6 Piston displacement 3195 cc Compression ratio 10.3 : 1 Bore 89 mm Stroke 85.6 mm Power kW@ rpm Refer to: holden.com.au Torque Nm@ rpm Refer to: holden.com.au Oil specification SAE 5W/30 or SAE 10W/30 API SL/SM ILSAC GF3 / GF4 oil Refill oil capacity (including filter) 7.4 Litres Fuel tank capacity 65 Litres Coolant capacity 10.0 Litres Coolant specification 50% Clean water and 50% Dexcool anti-freeze coolant, conforming to specification number GM 6277M Brake fluid DOT-4 brake fluid Power steering fluid Dexron III...
  • Page 171 Chapter 8 SPECIFICATIONS SPECIFICATIONS cont. Transmission 5 speed automatic Transmission transmission Transmission Esso JWS 3309 or conforming to Holden specification number HN2414 fluid type Drivetrain Rear differential Synthetic Hypoid 75W/90 GL5 Power transfer unit Synthetic Hypoid 75W/90 GL5 Dimensions Overall length 4,637 mm Overall width (excluding mirrors) 1,849 mm Overall height, at kerb weight 1,720 mm Front 1,562 mm Track 1,572 mm Rear Wheel base 2,707 mm...
  • Page 172 – – – – – – Position 10 11 12 13 14 15 16 17 Position Reference Code Description K – Asia Manufacturer L – Korea identifier 3 – Holden C – Captiva Car line D – Captiva MaXX G – AWD (All wheel drive) Manual transmission Transmission D – AWD (All wheel drive) Automatic transmission Body style 26 – All purpose window-4door (Liftgate) Code Displacement Eng option Fuel sys 8 Engine type 3.2L DOHC MPFI HF V6 E – Export...
  • Page 173 Chapter 8 SPECIFICATIONS IDENTIFICATION LABELS cont. Compliance label The compliance label is located in the engine bay at the front of the driver's side suspension tower. Engine number Individual identification numbers are stamped onto the engine block under the centre branch of the exhaust manifold. C7E6018P Fuel label The fuel label is located on the inside of the fuel filler door. C7E3012B Tyre label The tyre placard is found on the lower part of the 'B' pillar on the driver's side. C7E6011P...
  • Page 174 Chapter 8 SPECIFICATIONS...

  • Page 175: Tow.and.load

    9- Chapter 9 TOW and LOAD Tow and Load Page Loading the vehicle Towing Towing precautions 3 The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
  • Page 176 9- Chapter 9 TOW AND LOAD LOADING THE VEHICLE Maximum vehicle payloads Overloading is a safety hazard and could also shorten the life of your vehicle. The typical recommended carrying capacity of the vehicle is shown in the table below. Do not exceed the maximum axle loads shown below in the diagram, including the weight of any options or accessories fitted to the vehicle.
  • Page 177 9- Chapter 9 TOW and LOAD LOADING THE VEHICLE cont. Notes on loading the vehicle Place heavy objects in the rear luggage compartment as far forward as possible • against the rear seat backrests. When stacking objects, place the heavier objects at the bottom.
  • Page 178 Holden will not accept liability for defects occurring in towing equipment not marketed by Holden or for defects in the vehicle arising from the use of such equipment or for loss or injury caused by use of such equipment. The...
  • Page 179 Ensure the weight of the packed trailer is not greater than the towing capacity of the Holden approved tow bar package fitted to the vehicle. C7E6020A...
  • Page 180 9- Chapter 9 TOW AND LOAD TOWING PRECAUTIONS • When heavily loading your vehicle or when towing, your tyres should be inflated to the maximum recommended pressure, refer to Chapter 7, Weekly checks, for tyre placard and information about tyre pressures. Also, refer to Chapter 4, Driving, under 'Loading the vehicle', for driving information with increased loads.
  • Page 181 Running in before towing Holden recommends that you drive your new vehicle for at least 1500 km before towing. If you must tow in the first 1500 km of the vehicle's life, do not exceed 80 km/h. The same applies if the vehicle is equipped with a new or reconditioned engine, transmission or axle.
  • Page 182 9- Chapter 9 TOW AND LOAD...

  • Page 183: Cleaning

    Cleaning Page 10-2 Interior cleaning 10-4 Exterior cleaning 10-8 Cleaning products 3 The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
  • Page 184 10- Chapter 10 CLEANING INTERIOR CLEANING WARNING: Many cleaners are toxic, flammable or may damage the interior. When cleaning the interior, avoid volatile cleaners such as acetone, lacquer thinners, enamel reducers, nail polish removers, or cleaners such as laundry soaps, bleaches or reducing agents.
  • Page 185 Do not bleach or dye seat belts as this may severely weaken them. Interior glass Clean interior glass of the vehicle using a good quality glass cleaner, such as Holden Glass Cleaner, and a clean soft cloth. Take care when cleaning inside the rear window so as not to damage the rear window demister or radio antenna.
  • Page 186 Do not use a sponge or cloth at this point. 2. Fill a bucket with lukewarm water and add no more than two capfuls of gentle detergent, such as Holden Hi Suds Car Wash. Do not use hot water, strong soap or chemical detergents.
  • Page 187 10- Chapter 10 CLEANING EXTERIOR CLEANING cont. WARNING: Take care when moving the vehicle after washing, in case water has affected the brakes. Applying the brakes lightly will indicate whether they have been affected. To dry them quickly, lightly apply the brakes while maintaining a slow forward speed with a clear area ahead, until brake performance returns to normal.
  • Page 188 Under normal circumstances the paint does not need polishing to retain its shine. A weekly wash is sufficient. However, the use of a good quality polymer glaze, such as Holden Quick and Easy Speed Finish, approximately every 3 months will reduce the effects of road bloom by removing natural contaminants which can build up on the paint.
  • Page 189 After the windscreen has been cleaned with a wet sponge, wipe it over with a soft, lint free cloth or chamois. It is recommended that a good quality windscreen washer additive, such as Holden Optikleen, be added to the windscreen washer reservoir.
  • Page 190 10- Chapter 10 CLEANING CLEANING PRODUCTS Part Size Description Usage Number 237 ml Quick and Easy Seals in a deep, lustrous glazed 92145132 Speed Finish finish. Long life protection from oxidation, salt and weather damage. 437 ml Quick and Easy Seals in a deep, lustrous glazed 92145418 Speed Finish...
  • Page 191 10- Chapter 10 CLEANING Notes...
  • Page 192 10-10 Chapter 10 CLEANING...

  • Page 193: Index

    INDEX Cleaning products ......10-8 Cooling system Accessory power outlets....3-18 Coolant level ......7-4 Add on equipment ......4-20 Overheating ......6-11 Airbags ..........6-17 Cruise control ........4-18 Airbag indicator........1-9 Cruise control indicator ....1-13 Air conditioning ......1-43 Cupholders ........3-20 Air pressures (tyres) ......7-10 Customer assistance .......6-2 All wheel drive system (AWD) ..4-16 AWD indicator ........1-13 Antenna .........3-14...
  • Page 194 INDEX cont. Indicators (turn signals) ....1-40 Indicator/warning lamps....1-11 Flashers Infant & child restraints ....3-12 Hazard warning ......1-41 Inflation (tyres) ........7-10 Turn signal ........1-40 Instrument panel .......1-3 Flat battery........6-17 Interior lamps (operation) ....3-16 Flat tyre..........6-7 Bulb replacement ......6-29 Flooded engine .........4-4 Interior cleaning ......10-2 Fluid capacities .........8-2 Fluid levels...
  • Page 195 INDEX cont. Malfunction indicator lamp ....1-10 Radiator ....See “Cooling system” Map lamp ........3-16 Radio ..........1-15 Matching the remote control Rear seats ........3-4 transmitter.........2-4 Rear tailgate lock ......2-5 Mirrors ..........3-13 Rear turn signal ......6-27 Miscellaneous checks.......7-2 Rear vision mirrors ......3-13 Mobile phones ........4-7 Recline..........3-2 Model identifications ......8-4 Reducing fuel consumption ....5-5...
  • Page 196 INDEX cont. Windows .........3-15 Windshield Tachometer ........1-4 Wiper/washer control lever ..1-36 Tailgate release ........2-5 Fluid level ........7-9 Tailgate ajar lamp ......1-13 Tail lamps bulb replacement ...6-29 Temperature warning ......1-13 Tilt steering ........3-14 Towing ..........9-4 Trailer ..........9-6 Disabled vehicle ......6-11 Precautions .........9-6 Transmission Automatic ........4-8...
  • Page 197 Notes...

This manual is also suitable for:

Cg captiva 2007

Table of Contents
