- Page 1 Operating manual H i g h - v o lt a g e t e s t a da p t e r V A S 6 5 5 8 / 2 2 12.VW.2210.1589_BA_V01_EN VAS 6558/22...
-
Page 2: Legal Notice
Symbols for warnings, prohibitions, mandatory actions and standards are taken from publicly accessible sources, such as the Internet. CAD product images and product photos are provided by the manufacturer. Images showing the product in use are provided with a reference to the source. 12.VW.2210.1589_BA_V01_EN VAS 6558/22... -
Page 3: Table Of Contents
Important safety instructions Intended use Requirements for the target group Duties of the operator PRODUCT DESCRIPTION Scope of delivery Design Symbols and connections Wiring diagram Technical data OPERATION Startup Cleaning Storage Disposal Maintenance HELP Warranty Customer service 12.VW.2210.1589_BA_V01_EN VAS 6558/22... -
Page 4: Introduction
With experience in both software and hardware development, Stodia GmbH is your dependable partner at every production stage, from prototyping to series production. 12.VW.2210.1589_BA_V01_EN VAS 6558/22... -
Page 5: Safety
This operating manual is only valid for the following product: Item number 22101589 Designation High-voltage test adapter VAS 6558/22 Warning levels This chapter provides information about the warning levels used in this operating manual. DANGER Failure to observe the safety instructions WILL result in death or serious injury! -
Page 6: Intended Use
The operator is responsible for ensuring that all staff working with the test adapter fulfills the requirements for the target group. Furthermore, the operator is responsible for ensuring the following: • The test adapter is always in perfect working order. • The regular inspection intervals for the test adapter are observed and recorded. 12.VW.2210.1589_BA_V01_EN VAS 6558/22... -
Page 7: Product Description
Immediately check the condition of the product and the completeness of the delivery. If anything is missing or defective, please contact the manufacturer immediately. (1) High-voltage measurement adapter (2) USB stick with operating manual Design Product design: (1) Plug (2) Test sockets (see wiring diagram) 12.VW.2210.1589_BA_V01_EN VAS 6558/22... -
Page 8: Symbols And Connections
CAT III Umax = 300V QR code for accessing the product documentation on mobile devices. The product has the following test sockets: Connector Function Negative S socket Positive S socket CC1 socket CC2 socket Negative DC socket 12.VW.2210.1589_BA_V01_EN VAS 6558/22... -
Page 9: Wiring Diagram
EN | Product description Connector Function Positive DC socket PE socket Negative A socket Positive A socket Wiring diagram 12.VW.2210.1589_BA_V01_EN VAS 6558/22... -
Page 10: Technical Data
Elevation above sea Max. 2000 m No limitation. level Humidity Max. 80% up to 31°C, Max. 85% decreasing linearly to 50% at 40°C Pollution rating Condensation Not permitted. Maximum permissible relative humidity: 60% in environments with corrosive gas/air. 12.VW.2210.1589_BA_V01_EN VAS 6558/22... -
Page 11: Operation
Insert the plug into the vehicle’s charging socket. Connect the high-voltage measurement module to the high-voltage measurement adapter according to the guided fault finding. You can now perform measurements in accordance with the guided fault finding. 12.VW.2210.1589_BA_V01_EN VAS 6558/22... -
Page 12: Cleaning
Observe the safety instructions! National and local requirements for regular testing must be observed! Test the product for proper function at intervals of no more than 24 months. Contact the manufacturer to have a professional function test performed. 12.VW.2210.1589_BA_V01_EN VAS 6558/22... -
Page 13: Help
Always include the item number and, if available, the serial number with any product queries. Both numbers are found on the product. Stodia GmbH Im Freitagsmoor 45 38518 Gifhorn, Germany Phone: +49 (0) 5373 – 92197-0 Fax: +49 (0) 5373 – 92197-88 service@stodia.de www.stodia.de 12.VW.2210.1589_BA_V01_EN VAS 6558/22... - Page 14 Volkswagen Aktiengesellschaft K-GVO-LW Group After Sales – Group Service Literature and Systems Repair Shop Equipment PO box 011/4915 38442 Wolfsburg, Germany For internal use only Subject to technical changes Edition 05/2022 12.VW.2210.1589_BA_V01_EN VAS 6558/22...
