- Page 2 • Reamer / Hole Punch • Ride Height Gauge • FT Nut Drivers (AE #1666 - 1668, used with #1650 handle) • Wire Cutters • Hobby Knife Associated Electrics, Inc. Customer Service 26021 Commercentre Dr. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501...
- Page 3 :: Hardware - 1:1 Scale View :: Hardware - 1:1 Scale View Button Head (bhcs) Flat Head (fhcs) Ball Bearings 2x4mm (31510) 3x8mm (25201) 3x7x3mm (91475) 2.5x8mm (31521) 3x10mm (25202) 5x10x4mm (91560) 3x5mm (31530) 3x12mm (25203) 3x8mm (31532) 3x14mm (89208) 6x13x5 (91562) 3x10mm (25211) 3x16mm (25204)
- Page 4 This symbol indicates a Racers Tip. until you find the exact size. Each part in the foldout has a number assigned to it for ordering replacement parts. Associated Electrics, Inc. Customer Service 26021 Commercentre Dr. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501...
- Page 5 3/23 :: Quick Start Guide Quick Start Guide Battery Charging Steps and Safety: Remove the battery from the vehicle before charging. Place battery on a fire resistant surface. Avoid any contact with water or other liquids. Be sure to select the correct charging mode for the type of battery you are charging.
- Page 6 :: Quick Start Guide Quick Start Guide - (cont.) - (cont.) Battery Notes and Tip: Connect the battery as shown. Disconnect the battery when not in use! LiPo: LiPo batteries (lithium polymer) are high current rechargeable batteries. LiPo batteries offer extended run time and peak performance over NiMH batteries.
- Page 7 :: Front Top Plate and Steering Build - Step 1 :: Front Top Plate and Steering Build - Step 1 91475 91047 91047 3 x 7 x 3 Heavy-duty Heavy-duty Ball Bearing Ballstud, Ballstud, 91391 Steering Bellcrank 91391 Brace Steering Rack 89202 M3 x 12mm...
- Page 8 :: Front Suspension Build Front Suspension Build - Step 1 - Step 1 91047 Heavy-duty 91048 31530 Ballstud, 91402 Heavy-duty M3 x 5mm Caster Ballstud, BHCS Block Bushing 91417 Steering Block 91560 5 x 10 x 4 91417 Bearing Caster Block 25215 M3 Locknut,...
- Page 9 :: Front Suspension Build Front Suspension Build - - ( ( LT10, DK10 LT10, DK10) - ) - Step 4 Step 4 71035 Front Body Post LT10 DK10 71032 M2.5 x 14mm SHCS :: :: Front Suspension Build Front Suspension Build - ( - (LT10, DK10 LT10, DK10) - Step 5 ) - Step 5...
- Page 10 :: :: Front :: Rear Suspension Front Shock Tower and Bumper Build Rear Suspension Build Shock Tower and Bumper Build - Bag C - Step 3 Build - Step 2 - Step 2 - Bag C - Step 3 91049 Heavy-duty Ballstud, 10mm 25211...
- Page 11 :: :: Gear Diff Gear Diff Build Build - Step 2 - Step 2 91463 Gear Diff 91466 Washer Gear Diff Gear 91463 Gear Diff 9831 Sun Gear 91463 42025 Gear Diff Gear Diff Gear Diff O-Ring O-Ring Outdrive (Small) (Large) 91465 Gear Diff...
- Page 12 :: Gearbox Build - Step 2 Gearbox Build - Step 2 Add a drop of Diff Lube (#6591) to Lube (#6591) to 31532 the teeth of the diff the teeth of the diff gear, idler gears, gear, idler gears, M3 x 8mm M3 x 8mm and top shaft.
- Page 13 :: Gearbox Install - Step 1 The Locknut should The Locknut should be flush with the be flush with the top shaft when top shaft when installed. See page 23 for gear mesh, and slipper clutch setting instructions! :: Gearbox Install - Step 2 Gearbox Install - Step 2 25211 M3 x 10mm...
- Page 14 :: Rear Hub and CVA Build - Step 1 Rear Hub and CVA Build - Step 1 91563 91438 10 x 15 x 4 Bearing 91418 Coupler Rear Hub 91439 CVA Bone 65mm 91562 91562 91048 91438 6 x 13 x 5 6 x 13 x 5 Heavy-duty 71019...
- Page 15 :: Turnbuckles Build - Step 2 91469 91469 91723 Ball Cup Ball Cup Turnbuckles, 3x48mm Front Camber Turnbuckle 23.00mm Racers Tip: Orient the notch Use black grease to the left throughout the (#6588) on the car. It indicates which end threads of the has the left hand threads! turnbuckles for...
- Page 16 :: Shocks Build - Step 2 Shocks Build - Step 2 71051 91491 Shock Body Shock Cap 12 x 27.5mm O-Ring Lightly rub shock oil (front) on the o-ring before 71052 installation! Shock Body 31327 12 x 36mm Shock (rear) Bottom Cap O-Ring 91469...
- Page 17 :: Shocks Build - Step 5 Shocks Build - Step 5 25612 91444 M3 Locknut, 91444 Shock with flange Shock Bushing (black) Bushing Use outside hole in front arm! 25612 89202 M3 Locknut, M3 x 12mm with flange BHCS (black) 25189 Use outside hole in...
- Page 18 :: Electronics Build - Step 3 Electronics Build - Step 3 See page 23 for gear mesh setting instructions! Motor 25225 31532 3 x 3mm M3 x 8mm Set Screw 89218 BHCS 1336 3 x 8mm Pinion Gear, Washer 18T, 48P :: Electronics Build - Step 4 71023 Receiver Box...
- Page 19 :: Electronics Build - Step 6 Electronics Build - Step 6 Receiver 25225 6338 M3 x 3mm Antenna 6727 Set Screw Servo Tape Tube & Cap 25211 71023 M3 x 10mm Receiver BHCS Box Seal 71026 Receiver Box Lid :: Electronics Build - Step 7 Electronics Build - Step 7 Battery 71050...
- Page 20 :: Bumper and Chassis Braces Chassis Braces Build Build - Step 2 91478 M3 x 30mm BHCS 25187 M3 x 14mm BHCS 89204 M3 x 24mm BHCS 71042 71042 71042 Rear Bumper Rear Bumper Rear Bumper Brace Pivot (PRO SC10) (PRO SC10) (PRO SC10) :: Tires and Body Build - Step 1...
- Page 21 :: Tires and Body Build - Step 3 :: Tires and Body Build - Step 3 25215 72116 21173 M3 Locknut Pro2 Small DK10SW Body Clips Body, Orange 31532 M3 x 8mm BHCS 72116 - Pro2 DK10 SW Body, Orange 72119 - Pro2 DK10 SW Body, Clear :: Tuning Tips :: Tuning Tips...
