  • Page 2 This symbol indicates a special note or instruction in the manual. :: Additional Your new Pro4 SC10 comes assembled. The following items are needed for completion. • (4) AA batteries Tools included: • 1.5mm, 2.0mm, 2.5mm Wrenches :: Other Helpful Items •...
  • Page 3 :: Hardware - 1:1 Scale View Button Head (bhcs) Flat Head (fhcs) Ball Bearings 2.5x5mm (31519) 2.5x8mm (31448) 5x8x2.5mm (8680) 2.5x6mm (31520) 2.5x10mm (31350) 5x11x4mm (25618) 3x4mm (91158) 3x6mm (31541) 3x6mm (31531) 3x12mm (25203) Aluminum (8556) 10x15x4mm (91563) 3x8mm (31532) Titanium (91594) 3x10mm (25211) 3x14mm (89208)

  • Page 4: Battery Installation

    :: Quick Start Guide Battery Charging and Safety: Before charging your battery for the first time, please read the document Important Safety Instructions and Warnings found in the documents bad included with your vehicle. Charging 1. To prepare the battery for charging, remove the battery from the vehicle and place it on a fire-proof surface [image 1] free from moisture and the potential for contact with water or any other liquids.
  • Page 5 1/23 :: Quick Start Guide - (cont.) Battery Notes and Tip: Connect the battery as shown. Disconnect the battery when not in use! LiPo: LiPo batteries (lithium polymer) are high current rechargeable batteries. LiPo batteries offer extended run time and peak performance over NiMH batteries. They require a peak detection charger designed specifically for LiPo batteries.
  • Page 6 :: Step 1 25810 25810 25810 Sun Gear Sun Gear Sun Gear Shim Shim 25810 25810 25810 Sun Gear 25810 Diff Diff 25810 Input Pin O-Ring O-Ring Input Pin 25810 25810 Diff Output Diff Output Shaft Shaft 25808 25807 Ring Gear, Diff Case (Front/Rear) Build 2 (1 front, 1 rear)
  • Page 7 :: Step 4 25812 Center Diff Cross Pin 89208 3x14mm FHCS 25812 PLanetary Gear Shim 25811 25812 25812 Center Diff Center Diff Gasket Input Shaft Planetary Spline Center Diff Fluid: Gear 100k cst #5459 31448 2.5x8mm FHCS :: Step 5 25831 E-Clip, 2.5mm...
  • Page 8 :: Step 7 25805 Servo Saver Tube 25805 2.5mm Upper Servo Saver Arm 25825 Spring Cup 25825 25805 Spring Lower Servo Collar Saver Arm 25805 25805 25832 Servo Saver Servo Saver Shock Spring Collar Spring Spring :: Step 8 25805 25805 41079 2.6mm...
  • Page 9 :: Step 10 25806 Gearbox 25802 Arm Mount Insert 25804 Front Arm 25803 25211 Inner 89202 3x10mm Hinge Pin 3x12mm BHCS 25802 BHCS 25819 Arm Mount Caster Block Hat Bushing :: Step 11 6332 Body Clip 25817 Body Post 25211 3x10mm BHCS 25817...
  • Page 10 :: Step 13 25821 Slider Drive Shaft, Female 25820 2x9.8mm 91563 10x15x4mm Bearing 25820 25618 12mm Hex 5x11x4mm Bearing :: Step 14 25835 Anti-Roll Bar Eyelet 25803 Outer Hinge 81258 3x12mm Set Screw 25215 M3 Locknut :: Step 15 25225 3x3mm Set Screw 25835...
  • Page 11 :: Step 16 25828 Pivot Ball, Long 25189 3x22mm BHCS 25824 25824 Turnbuckle Ball Cup 89203 Steering Turnbuckle 3x16mm 15.50mm BHCS 25215 M3 Locknut Build x2 (right and left side) :: Step 17 25828 Pivot Ball, 25187 Long 3x14mm BHCS 25824 25824 Turnbuckle...
  • Page 12 :: Step 19 25852 Chassis 25211 25211 Guard 3x10mm 3x10mm BHCS BHCS :: Step 20 89207 4x12mm BHCS 25856 Drive Shaft 31520 25852 2.5x6mm Drive Shaft BHCS Cover :: Step 21 25806 89202 25809 Gearbox, 3x12mm Input Rear BHCS Pinion 25843 25806 12x18x4mm...
  • Page 13 :: Step 22 25802 25802 Arm Mount Arm Mount 25211 Insert 3x10mm BHCS 25802 Arm Mount 25804 Insert Rear Arm 25802 Arm Mount 25803 89203 Inner Hinge 3x16mm BHCS :: Step 23 25817 25816 Body Post Rear Shock Tower 25817 25211 Body Mount 3x10mm...
  • Page 14 :: Step 25 25835 Anti-Roll Bar Eyelet 81258 25215 3x12mm M3 Locknut Set Screw 25803 Outer Hinge :: Step 26 25225 3x3mm Set Screw 25835 Anti-Roll 25835 Bar, Rear Anti-Roll 91158 Bar Pivot 3x4mm Ball BHCS :: Step 27 25828 Pivot Ball, Long 25189...
  • Page 15 :: Step 28 89207 4x12mm BHCS 25801 Skid Plate 81262 31520 4x10mm 2.5x6 FHCS BHCS 25203 89206 3x12mm 4x10mm FHCS BHCS :: Step 29 25825 25827 Shock Pivot Ball, 25827 Spacer Small Pivot Ball, 25188 Small 3x20mm BHCS 25188 3x20mm BHCS 25211 3x10mm...
  • Page 16 :: Step 31 25854 25854 Mud Flap Rear Bumper Plate Brace 25854 25855 Rear Lower Rear LED Bumper *Optional 31520 2.5x6mm 25854 BHCS Rear Bumper 31532 3x8mm BHCS 25211 25854 3x10mm BHCS Flaps :: Step 32 25211 3x10mm BHCS 25187 3x14mm BHCS 89209...
  • Page 17 :: Step 34 Motor Motor 25815 25815 Motor Motor Mount Plate Mount Plate 25225 25225 3x3mm 3x3mm Set Screw Set Screw 25861 31532 31532 15T-32P 3x8mm 3x8mm Pinion FHCS :: Step 35 25815 Motor Mount Tension Spring 25188 3x20mm BHCS Set The Gear Mesh: To set the gear mesh, rock the spur gear back and forth without making the pinion gear move.
  • Page 18 :: Step 37 25827 Pivot Ball, Short 25824 25824 4x12mm Ball Cup Set Screw 31532 M3x8mm Servo Link Turnbuckle 25805 BHCS Servo Arm, 0.80mm 89202 M3x12mm BHCS :: Step 38 25225 Receiver M3x3mm Set Screw 6338 Antenna Tube, 12” 6727 Servo Tape Battery :: Step 39...
  • Page 19 :: Step 40 91738 M4 Black Nut Serrated Aluminum Install 4 :: Step 41 31532 6332 3x8mm Body Clip BHCS 25862 91477 SC Body, Nuts, M3, Yellow / Black Black...
  • Page 20 :: Tuning Tips Tips for Beginners: Before making any changes to the standard setup, make sure you can get around the track without crashing. Changes to your vehicle will not be beneficial if you can’t stay on the track. Your goal is consistent laps. Once you can get around the track consistently, start tuning your vehicle.
  • Page 21 MT10 FT Steel CVA Kit, front 1597 FT Tire Adhesive, medium 25848 MT10 FT Steel CVA Kit, rear 6588 Black Grease - 4cc 25855 Pro4 SC10 LED Light Kit 6591 S.Diff Lube - 4cc 6636 Silicone Grease - 4cc 6727 Servo Tape :: Shock Fluid...
