4.1.3
Control section C
Item Symbol
1
2
Balance AC balance rotary knob (JOB 0)
3
099-00T402-EW501
02.07.2020
Machine control – Operating elements
Description
0
Balance signal light
AC balance (JOBs 1–7), pulse balance
Electrode diameter signal light
Ignition optimisation (TIG)/tungsten balling basic setting (JOB 1-100)
Gas post-flow time
End current signal light
Down-slope time
signal light
Signal light, two colour
Red: Secondary or pulse pause current
Green: Pulse pause time
Signal light, two colour
Red: Main current
/pulse current
Green: Pulse time
Signal light
Up-slope time
(TIG)/hot start time
Signal light
Ignition current
(TIG)/hot start current
Gas pre-flow time signal light
Signal light activArc
signal light
AC frequency (TIG, JOBs 1–7)/pulse frequency (TIG, average value pulsing)/pulse
frequency (MMA)
Description
0
AC frequency rotary knob (JOB 0)
Tungsten electrode diameter rotary knob (JOB 0)
(% of AMP)
(MMA)
(MMA)
> see 5.1.6 chapter
Figure 4-4
Overview of control sections
11
