Page 2
H58.0.01.6C-02 Operating Manual GMH 1170 Page 2 of 7 CONTENTS GENERAL NOTE ..............................2 SAFETY ................................2 ..............................2 NTENDED ..........................3 AFETY SIGNS AND SYMBOLS ............................. 3 AFETY GUIDELINES PRODUCT SPECIFICATION ..........................3 ..............................3 COPE OF SUPPLY ........................ 3 PERATION AND MAINTENANCE ADVICE NOTES TO FUNCTIONS OF DEVICE .........................
Page 3
H58.0.01.6C-02 Operating Manual GMH 1170 Page 3 of 7 2.2 Safety signs and symbols Warnings are labelled in this document with the followings signs: Caution! This symbol warns of imminent danger, death, serious injuries and significant damage to property at non-observance.
Page 4
H58.0.01.6C-02 Operating Manual GMH 1170 Page 4 of 7 Notes to Functions of Device 4.1 In General: Measuring Temperature With Thermocouples Temperature differences between the instrument and the probe connector may produce measuring errors. Therefore wait after connecting or touching the connector until the temperatures have adjusted. (can take up to 15 mins.
Page 5
H58.0.01.6C-02 Operating Manual GMH 1170 Page 5 of 7 Configuration Of The Instrument: To configure the instrument proceed like follows: Switch off the instrument. Press the ‘Mode‘ key while switching on the instrument, keep ‘Mode‘ key pressed until ‘PoF‘ appears (about 3 seconds).
Page 6
H58.0.01.6C-02 Operating Manual GMH 1170 Page 6 of 7 Pop-up clip Handling: • Pull at label “open” in order to swing open the pop-up clip. • Pull at label “open” again to swing open the pop-up clip further. Pop-up clip at position 90°...
Page 7
H58.0.01.6C-02 Operating Manual GMH 1170 Page 7 of 7 Specification Measuring range: -65,0 ..+199,9°C, resolution 0,1°C resp. -85,0 ... +199,9°F, resolution 0,1°F -65 .. +1150°C, resolution 1°C resp. -85 ... +1999°F, resolution 1°F Precision: (±1 Digit) -65,0°C ..+199,9°C: ±0,05% of meas. value ±0,2% full scale -65°C ...
