S
4"
[102mm]
3-3/8" [86mm]
12" [305mm]
Construction: Extruded aluminum housing, 20-
gauge steel side shields with staggered round hole
pattern backed by white acrylic diffuser. Nominal 3',
4', 6' or 8' illuminated sections.
End Plates: Die-formed aluminum.
Shielding: Parabolic, Semi-Specular Aluminum.
Electrical: 120, 277, 347 or Universal Voltage
electronic ballast. Fixtures and electrical
components certified to UL and CUL standards.
Finish: Durable, low gloss, white, powder coated
acrylic finish.
Mounting: Pendant: Single stem (standard); single
cable. Canopy: 5" diameter cover (standard).
S
= Slim Line Ballast only.
R O W C O N F I G U R AT I O N
3FT. Row
26" [660mm]
5-5/16"
[151mm]
36-5/8" [938mm]
6FT. Row
5-5/16"
62" [1575mm]
[151mm]
72-5/8" [1845]
20FT. Row
5-5/16"
92" [2337mm]
[151mm]
96-5/8" [2454]
NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
ORDERING INFORMATION:
Sample number: 16-DIP-3T5-SC35-2EB-DU-RP
Series
18"
[457mm]
16=Europa
MIN.
Light Output
1-1/4"
DIP=Direct-Indirect Pendant
[32mm]
IP=Indirect Pendant (2 lamps only)
Number of Lamps
3=3 Lamps
Lamp Type
T8
Pendant Type
ST=Single Stem
Run Length
Overall Nominal Run Length__ft. (Any combination of 8', 6', 4' and 3'
sections)
Voltage
1
1=120V
Ballast
EB=Electronic Ballast (Standard)
[Only slim line ballast (small case)]
Switching
SI=Single Switching
Perforation
RP=Round BP=None
Emergency
EM=Emergency Pack (Consult Factory)
Fusing
GLR
1 Due to various constraints, some options may not be combined with others.
2 Available with 7° or earthquake 45° swivel canopy assembly.
4FT. Row
38" [965mm]
48-5/8" [1235mm]
8FT. Row
98" [2849mm]
1 3/8"[35mm]
20' - 5 1/2" [6209mm]
(per cross section) (not included)
T5
T5HO
2
SC=Single Cable
2=277V
3=347V
U=Universal
DB=Dimming Ballast
DU=Dual Switching
SP=Slotted
GMF
5FT. Row
5-5/16" [151mm]
50" [1270mm]
60-5/8" [1540mm]
5-5/16" [151mm]
88-3/8" [2245mm]
96-5/8" [2454]
44" [1118mm]
96-5/8" [2454]
48-5/8" [1235mm]
NEO-RAY
I N D I R E C T- D I R E C T
• Indirect - direct light
distribution.
• T5 and T8 lamping options.
• Three distinct light
distributions - direct, indirect
and direct-indirect (specify
dual switching).
• Die formed steel perforated
housings.
• Dual aircraft cable hangers
for superior leveling.
• Nominal 3', 4', 5', 6' or 8'
long illuminated sections.
• Articulated joiners between
sections.
• Optional slotted perforated
pattern.
• Precision die cast end caps.
5-5/16" [151mm]
COOPER LIGHTING
™
EUROPA
16-DIP
16-IP
725
