Cooper Lighting NEO-RAY Europa 16-DIP Specifications

DESCRIPTION
"The Europa" embodies the highest attention to architectural design and
detail as well as lighting performance. This luminaire creates a balanced,
visually comfortable environment. Perforated metal side panels facilitate a
soft "glow", a parabolic louver controls the independent downlight
component, and an articulated joiner provides for an elegant continuous
arrangement of luminaries. This truly versatile direct/indirect luminaire is
designed to provide three distinct lighting distributions...Indirect, Direct, and
Direct/Indirect...by the mere separate switching of the single lamp direct
component and the two lamp indirect component.
SPECIFICATION FEATURES
A ... Construction
20-gauge steel housing with
staggered round hole pattern
backed by white acrylic diffuser.
Nominal 3', 4', 6' or 8' illuminated
sections.
End Plates
Die-formed aluminum.
A
4"
[102mm]
S
= Slim Line Ballast only.
ORDERING INFORMATION
Sample Number: S16IP/2T8/ST84/1EB-DU-BP
Series Light Output
16 Europa I Indirect
= =
DI Direct/Indirect
=
Mounting
P Pendant
=
Notes: 1 Available with 7° or earthquake 45° swivel canopy assembly.
2 Not all options available. Please consult your Cooper Lighting Representative for availability.
B ... Shielding
Parabolic, Semi-Specular
Aluminum.
C ... Electrical
120, 277, 347 or Universal Voltage
electronic ballast. Fixtures and
electrical components certified to
UL and CUL standards.
B C
S
3-3/8" [86mm]
12" [305mm]
Number of Lamps Pendant
2 2 Lamps SC Single Cable
= =
3 3 Lamps ST Single Stem
= =
Lamp Type Run Length
T8 T8
= Overall Nominal Run
Length __ ft.
T5 T5
=
T5HO T5HO
=
Specifications and Dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
D ... Finish
Durable, low gloss, white, powder
coated acrylic finish.
Mounting
Pendant: Single stem (standard);
single cable. Canopy: 5" diameter
cover (standard).
D
18"
[457mm]
MIN.
1-1/4"
[32mm]
Voltage 2 Switching Options
1 120V SI Single Switching
=
1 2 277V DU Double Switching
=
3 347V
=
Ballast
EB Electronic Ballast
=
DB Dimming Ballast
=
NEO-RAY
Light Distribution
Perforated Patterns
Perforation
SP Slotted
= =
RP Round
= =
BP None
=
Emergency
EM Emergency Pack
=
07/12/2007 3:06:04 PM
Type
Date
Europa
16-DIP
16-IP
2 & 3T8
2 & 3T5
2 & 3T5HO
SUSPENDED
INDIRECT/DIRECT
Indirect - 66.1%
Direct - 33.9%
Round Hole (Standard)
S - Slotted
Fusing
GLR GLR
=
GMF GMF
=
ADN041832
