Getting Started

EN

Unpacking the system:

You should have the following:
• one main unit
(with 2 main speakers, 2 surround speakers);
• one remote control;
• one AM loop antenna;
• one user's guide;
• one safety leaflet.
• Owner and registration Card

Back View

~
1. FM Pigtail Antenna
2. AM Loop Antenna Connector
3. Surround Speaker Jacks
4. Main Speaker Jacks
2
4:20 PM
Page 6
Speaker Wire Connection
Push Speaker terminal tab
down to insert wire.
NOTE: Make sure the insulation is completely removed from the

Installation

To ensure sufficient ventilation, keep the spacings
shown below free from other surfaces:
1
2
_
_
3
+
+
R
L
_
_
4
+
+
R
L
Release tab to lock wire in
the terminal.
ends of the speaker wires at all connection points.
4 inches
DIGITAL AUDIO SYSTEM RS2600
4 inches
S I M U L T A N E O U S P L A Y A N D L O A D S Y S T E M
STANDBY
OPEN/CLOSE
POWER
DIMMER/
DEMO
TIMER
CLOCK
PROG./SET
B
ass
B
oost
ROCK/CLASSIC
POP/JAZZ
CD DISPLAY
TUNE/PRESET
SOURCE
DISC SKIP
PHONES
UP
CUSTOM
/FLAT
DOWN
REPEAT
BAND
AUTO PROG.
D I R E C T D I S C A C C E S S
1
2
3
4
5
DECK-1
DECK-2
REC/PLAYBACK
PLAYBACK
Front View
4 inches
2
inches
Side View
4 inches
