Getting Started

Unpacking the system:

EN
You should have the following:
• one main unit (with 2 main speakers);
• one remote control;
• one FM antenna;
• one AM loop antenna;
• one user's guide;
• one safety leaflet.
• Owner and registration Card

Back View

1
AC
120V/60Hz
1. FM Antenna Jack
2. AM Loop antenna connector.
3. Main Speaker Jacks

Using the FM and AM Antennas

Before you use your audio system, you'll want to
make sure both the FM and AM antennas are posi-
tioned properly. Connect the FM antenna to the FM
connector on the back of the unit. Uncoil it, making
sure it is fully extended. (you may even want to tape
it to the wall behind the unit if possible. The higher
the better.)
You'll also need to connect the AM antenna loop to
the back of the unit if you listen to AM stations.
Rotate the AM loop antenna for better reception.
2
2
R
L
_
GND
FM
ANTENNA
AM LOOP

Connecting the Speakers

Each speaker has a black (negative) and a red
(positive) jack. When connecting the speakers, match
the red wires to the red jacks and the black wires to
the black jacks.
Antenna and Speaker Wire Connection
Push terminal tab down to
insert wire.
NOTE: Make sure the insulation is completely removed from the
ends of the Antenna and speaker wires at all connection
points.
3

Installation

To ensure sufficient ventilation, keep the spacings
shown below free from other surfaces:
Front View
4 inches
Side View
2 inches
Release tab to lock wire in
the terminal.
4 inches
4 inches
VOLUME
DEMO/DIMMER
ON/
SOURCE
TUNE/PRESET
STANDBY
EQ
X-BASS
CLOCK
TIMER
SLEEP
SHUFFLE
REPEAT
INTRO
CD INFO
PROG/SET
ST/MONO
RECORD
BAND
1
2
3
4
5
DISC
DISC
DISC
DISC
DISC
CD-R / RW COMPATIBLE
5
DISC CHANGER
4 inches
