TRANSLATION OF THE ORIGINAL VERSION
Operating Manual
Foot-hydraulic and battery-hydraulic adjustable Scissor Lift Tables
Types HS 2000 | FH and HS 2000 | AH
HS 2000 | FH and HS 2000 | AH
Valid for types:
Reinhold Beck Maschinenbau GmbH
Im Grund 23 | DE -72505 Krauchenwies
Tel.: +49 (0) 7576 / 962 978 - 0 | Fax: +49 (0) 7576 / 962 978 - 90
E-Mail:
info@beck-maschinenbau.de
| Web:
https://www.beck-maschinenbau.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS 2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for R. Beck Maschinenbau HS 2000

  • Page 1 TRANSLATION OF THE ORIGINAL VERSION Operating Manual Foot-hydraulic and battery-hydraulic adjustable Scissor Lift Tables Types HS 2000 | FH and HS 2000 | AH HS 2000 | FH and HS 2000 | AH Valid for types: Reinhold Beck Maschinenbau GmbH Im Grund 23 | DE -72505 Krauchenwies Tel.: +49 (0) 7576 / 962 978 - 0 | Fax: +49 (0) 7576 / 962 978 - 90...
  • Page 2: Table Of Contents

    Lashing on a Transport Vehicle ..............................15 Components and Controls ............................. 16 Model HS 2000 | FH ................................... 16 Model HS 2000 | AH ................................... 17 Installation and Commissioning ..........................18 Operation ................................18 Switch on Model HS 2000 | AH ..............................18 BA_BM_HS-2000_EN_46-21.docx...
  • Page 3 Figure 1: Permissible load with load distribution ........................9 Figure 2: Nameplate ................................. 13 Figure 3: Components and controls of HS 2000 | FH ....................... 16 Figure 4: Components and controls of HS 2000 | AH ....................... 17 Figure 5: Main switch ................................18 Figure 6: Height adjustment pedal ............................
  • Page 4: Introduction

    1 Introduction The information in this operating manual enables safe, proper and economical operation of your lift table. Please observe all the explanations, notes and regulations • to avoid dangers and malfunctions, • to reduce repair costs and downtimes • and to increase reliability and service life of your lift table.
  • Page 5: Symbols In Safety Instructions

    Symbols in Safety Instructions The lift table is designed and manufactured according to the current state of the art. Nevertheless, residual haz- ards may occur during handling. In this operating manual, possible dangers and residual risks are pointed out at appropriate places.
  • Page 6: General

    If anything is unclear, please contact the manufacturer. The ergonomic HS 2000 scissor lift table has a very high load capacity of max. 2000 kg and is therefore particularly suitable for heavy-duty applications. The solid single scissor construction and its mobility thanks to two swivel castors and two fixed castors make it an indispensable assistant for countless applications in industry and trade, e.g.
  • Page 7: Accident Prevention

    Accident Prevention To avoid accidents, the following rules must be observed for operation: Prevent unauthorized persons from gaining access to the lift table. Keep unauthorized persons away from the danger areas. Repeatedly inform present other persons about existing residual risks (see section  4.8 "Residual Risks"). Conduct and record regular training &...
  • Page 8: Safety

    4 Safety Basic Safety Instructions Lift tables can be dangerous if used improperly. Therefore, observe the safety instructions listed in this chapter and the accident prevention regulations of your employer's liability insurance association! The manufacturer accepts no liability for damage and malfunctions resulting from failure to observe these operating instructions.
  • Page 9: Consequences In Case Of Disregard

    Consequences in Case of Disregard If the lift table is not operated, maintained or repaired in accordance with the safety regulations, not as in- tended, improperly or in an abusive manner, the following will result: Dangers to the health of the operating personnel Dangers to the lift table and objects in its vicinity Impairment of the lift table function In case of improper use of the lift table, any warranty, liability and other claims for damages of the operator...
  • Page 10: Hazardous Areas

    Hazardous Areas Source Area Cause Risk Prevention Foot pump HS 2000 | FH only: On the foot pedal Slipping off the Injuries to feet Keep foot pedal for height adjust- foot pedal and legs and shoes dry ment Wear work shoes...
  • Page 11: Residual Risks

    Residual Risks The lift table is built according to the latest state of the art and the recognised safety rules. Nevertheless, the use of the lift table may cause danger to life and limb of the user or third parties or damage to the lift table and other equipment.
  • Page 12: Organisational Measures

    Work on hydraulic equipment may only be carried out by authorised and trained personnel. Work on the electrical equipment of the lift table model HS 2000 | AH may only be carried out by a quali- fied electrician or by instructed persons under the direction and supervision of a qualified electrician in accordance with the electrotechnical regulations.
  • Page 13: Technical Specifications

    Technical Specifications Lift Table Type HS 2000 | FH HS 2000 | AH Article number 196.100.00 196.100.00 + 200.353.00 Special feature - foot-hydraulic height adjustment - battery-hydraulic height adjustment - with push-handle - with push-handle Table top 6 mm thick metal sheet...
  • Page 14: Transport To The Installation Site

    • With the forks set appropriately, drive centrally into the designated places on the freight pallet on the longi- tudinal side of the lift table and lift carefully. • Carefully lift the HS 2000 from the truck. The net weight is approx. 415 kg (FH) resp. approx. 465 kg (AH). Check delivery condition Check for completeness and transport damage.
  • Page 15: Requirements For The Installation Site

    Requirements for the Installation Site The following guidelines apply with regard to space requirements, load-bearing capacity and the condition of the substrate: • Space requirements: W x H x D = 1500 x 500 x 1000 mm (with metal sheet table top) •...
  • Page 16: Components And Controls

    Components and Controls Model HS 2000 | FH Figure 3: Components and controls of HS 2000 | FH Pos. Description Pos. Description Foot pedal for height adjustment Table top Fixed castors (2 pieces) Hydraulic cylinder Swivel castors with brake (2 pieces)
  • Page 17: Model Hs 2000 | Ah

    Model HS 2000 | AH Figure 4: Components and controls of HS 2000 | AH Pos. Description Pos. Description Push-button unit for height adjustment Hydraulic cylinder Fixed castors (2 pieces) Safety catches for maintenance Swivel castors with brake (2 pieces)
  • Page 18: Installation And Commissioning

    Generally wear steel-toed safety shoes and suitable protective work clothing! Switch on Model HS 2000 | AH Before working with the battery-hydraulic lift table "AH", ensure that a) the battery is in a charged state b) the main switch (10) is in the "ON"...
  • Page 19: Lifting And Lowering The Platform

    The height adjustment of the lift table is based on the scissor principle. The hydraulic power is transmitted to the hydraulic cylinder via the foot pump. 9.4.1 HS 2000 | FH Before adjusting the height, first secure the lift table against rolling away with the two parking brakes.
  • Page 20: Measures After Operation

    Measures after Operation 10.1 General Measures Additional electrical components (e.g. machines lying on the lift table) must be switched off after finishing work and also disconnected from the mains by unplugging the power cable. Furthermore, the lift table must be se- cured against unauthorised use.
  • Page 21: Troubleshooting

    Lift table is overloaded Platform cannot be lifted up Hydraulic cylinder, foot pump → Contact customer service or mechanics defective Faults with Model HS 2000 | AH Fault Possible Cause Remedy → Charge battery Battery empty The lift table cannot be →...
  • Page 22: Maintenance And Repair

    (see section 12.1). • Model HS 2000 | AH: Turn off the main switch before carrying out any maintenance or repair work. WARNING! There is an acute risk of electric shock when opening the battery box even if the main switch is turned off! •...
  • Page 23: Battery Charging Unit

    The battery charger "MXS 5.0" integrated in the battery box is a commercially available, microprocessor-con- trolled charger from the manufacturer CTEK.  The charging voltage for the lead gel battery installed in the HS 2000 | AH is 14.4 volts. 13.1 CTEK MXS 5.0 - Operation Instructions BA_BM_HS-2000_EN_46-21.docx...
  • Page 24 ➔ Select charging mode “14,4 V / 5 A”  CAUTION! Charging voltages higher than 14.4 V can damage or destroy the battery! BA_BM_HS-2000_EN_46-21.docx...
  • Page 25 BA_BM_HS-2000_EN_46-21.docx...
  • Page 26 CHARGING PROGRAM BA_BM_HS-2000_EN_46-21.docx...
  • Page 27 BA_BM_HS-2000_EN_46-21.docx...
  • Page 28 BA_BM_HS-2000_EN_46-21.docx...
  • Page 29: Decommissioning

    Decommissioning • Before taking out of service, the platform of the lift table must be lowered completely. • For recommissioning, observe chapter  8 “Installation and commissioning“. • For the final scrapping of the lift table, please refer to chapter  15. Disassembly and Scrapping When dismantling and scrapping the lift table, the current EU regulations or the respective regulations and laws of the country of operation, which are prescribed for proper dismantling and disposal, must be observed.
  • Page 30: Options And Accessories

    16.1 Wood Table Tops Article Description Art.-No. Suitable for HS 2000, attachable to platform, coated with linseed oil. TABLE TOP 196.700.00 BEECH-MULTIPLEX Platform size = 1500 x 1000 x 30 mm | Weight approx. 45 kg 16.2 Steel Table Tops...
  • Page 31: Accessories For Steel Hole Grid Plates With Ø 16 Mm Holes

    16.3 Accessories for Steel Hole Grid Plates with Ø 16 mm Holes Article Description Art.-No. QUICK RELEASE BOLT SHORT, Optimal connecting element with twist lock for the steel hole grid plate WITH TWIST LOCK accessories with ø 16 mm. The extra-large balls protect the chamfer of 200.850.16 the holes and reduce internal friction.
  • Page 32: Accessories For Steel Hole Grid Plates With Ø 28 Mm Holes

    16.4 Accessories for Steel Hole Grid Plates with Ø 28 mm Holes Article Description Art.-No. QUICK RELEASE BOLT SHORT, Optimal connecting element with twist lock for the steel hole grid plate WITH TWIST LOCK accessories with ø 28 mm. The extra-large balls protect the chamfer of the 200.880.28 holes and reduce internal friction.
  • Page 33: Convert Hs 2000 Large | Fh To Ah

    The foot-hydraulic model “FH” can later be converted to the battery-hydraulic “AH” version: Article Description Art.-No. For the conversion of HS 2000 LARGE | FH to the battery-hydraulic version BATTERY HYDRAULIC “AH”. The drive unit is installed in the base frame in a closed sheet metal DRIVE WITH MANUAL box.
  • Page 34: Eu - Declaration Of Conformity

    Phone: 0049 - 7576 962 978 0 Fax: 0049 - 7576 962 978 90 hereby declares that the manufactured machine Model: Lift Tables HS 2000 | FH and HS 2000 | AH Type designation: Lift Table Serial number(s): Year of manufacture:...
