Operating Manual
Foot-hydraulic and battery-hydraulic adjustable Scissor Lift Tables
Types HS 300 MIDI | FH and HS 300 MIDI | AH
HS 300 MIDI | FH and HS 300 MIDI | AH
Valid for types:
Reinhold Beck Maschinenbau GmbH
Im Grund 23 | DE -72505 Krauchenwies
Tel.: +49 (0) 7576 / 962 978 - 0 | Fax: +49 (0) 7576 / 962 978 - 90
E-Mail:
info@beck-maschinenbau.de
| Web:
https://www.beck-maschinenbau.de
Advertisement
Table of Contents
Related Manuals for R. Beck Maschinenbau HS 300 MIDI
Summary of Contents for R. Beck Maschinenbau HS 300 MIDI
- Page 1 TRANSLATION OF THE ORIGINAL VERSION Operating Manual Foot-hydraulic and battery-hydraulic adjustable Scissor Lift Tables Types HS 300 MIDI | FH and HS 300 MIDI | AH HS 300 MIDI | FH and HS 300 MIDI | AH Valid for types:...
-
Page 2: Table Of Contents
Lashing on a Transport Vehicle ..............................15 Components and Controls ............................. 16 Model HS 300 MIDI | FH ................................16 Model HS 300 MIDI | AH ................................17 Installation and Commissioning ..........................18 Operation ................................18 Switch on Model HS 300 MIDI | AH............................18 BA_BM_HS-300-MIDI_EN_44-21.docx... - Page 3 Figure 1: Permissible load with load distribution ........................9 Figure 2: Nameplate ................................. 13 Figure 3: Components and controls of HS 300 MIDI | FH ......................16 Figure 4: Components and controls of HS 300 MIDI | AH ......................17 Figure 5: Main switch ................................
-
Page 4: Introduction
1 Introduction The information in this operating manual enables safe, proper and economical operation of your lift table. Please observe all the explanations, notes and regulations • to avoid dangers and malfunctions, • to reduce repair costs and downtimes • and to increase reliability and service life of your lift table. -
Page 5: Symbols In Safety Instructions
Symbols in Safety Instructions The lift table is designed and manufactured according to the current state of the art. Nevertheless, residual haz- ards may occur during handling. In this operating manual, possible dangers and residual risks are pointed out at appropriate places. -
Page 6: General
If anything is unclear, please contact the manufacturer. In contrast to the standard model, the ergonomic scissor lift table HS 300 MIDI is equipped with a larger support frame for even larger table tops. The solid construction of square profiles and its mobility thanks to four swivel castors make it an indispensable assistant for countless applications in industry and trade, e.g. -
Page 7: Accident Prevention
Accident Prevention To avoid accidents, the following rules must be observed for operation: Prevent unauthorized persons from gaining access to the lift table. Keep unauthorized persons away from the danger areas. Repeatedly inform present other persons about existing residual risks (see section 4.8 "Residual Risks"). Conduct and record regular training &... -
Page 8: Safety
4 Safety Basic Safety Instructions Lift tables can be dangerous if used improperly. Therefore, observe the safety instructions listed in this chapter and the accident prevention regulations of your employer's liability insurance association! The manufacturer accepts no liability for damage and malfunctions resulting from failure to observe these operating instructions. -
Page 9: Consequences In Case Of Disregard
Consequences in Case of Disregard If the lift table is not operated, maintained or repaired in accordance with the safety regulations, not as in- tended, improperly or in an abusive manner, the following will result: Dangers to the health of the operating personnel Dangers to the lift table and objects in its vicinity Impairment of the lift table function In case of improper use of the lift table, any warranty, liability and other claims for damages of the operator... -
Page 10: Hazardous Areas
Hazardous Areas Source Area Cause Risk Prevention Foot pump HS 300 MIDI | FH Slipping off the Injuries to feet Keep foot bar only: foot bar and legs and shoes dry On the foot bar Wear work shoes for height adjust-... -
Page 11: Residual Risks
Residual Risks The lift table is built according to the latest state of the art and the recognised safety rules. Nevertheless, the use of the lift table may cause danger to life and limb of the user or third parties or damage to the lift table and other equipment. -
Page 12: Organisational Measures
Work on hydraulic equipment may only be carried out by authorised and trained personnel. Work on the electrical equipment of the lift table model HS 300 MIDI | AH may only be carried out by a qualified electrician or by instructed persons under the direction and supervision of a qualified electrician in accordance with the electrotechnical regulations. -
Page 13: Technical Specifications
Technical Specifications Lift Table Type HS 300 MIDI | FH HS 300 MIDI | AH Article number 190.200.00 190.210.00 Special feature foot-hydraulic height adjustment battery-hydraulic height adjustment Table top none (option) none (option) Support frame dimensions 1200 x 740 mm... -
Page 14: Transport To The Installation Site
• With the forks set appropriately, drive centrally into the designated places on the freight pallet on the longi- tudinal side of the lift table and lift carefully. • Carefully lift the HS 300 MIDI from the truck. The net weight is approx. 85 kg (FH) resp. approx. 110 kg (AH). Check delivery condition Check for completeness and transport damage. -
Page 15: Requirements For The Installation Site
Requirements for the Installation Site The following guidelines apply with regard to space requirements, load-bearing capacity and the condition of the substrate: • Space requirements: W x H x D = 1250 x 470 x 770 mm (without table top and other accessories) •... -
Page 16: Components And Controls
Components and Controls Model HS 300 MIDI | FH Figure 3: Components and controls of HS 300 MIDI | FH Pos. Description Pos. Description Foot bar for height adjustment Support frame Swivel castor (4 pieces) Hydraulic cylinder Parking brake (2 pieces) -
Page 17: Model Hs 300 Midi | Ah
Model HS 300 MIDI | AH Figure 4: Components and controls of HS 300 MIDI | AH Pos. Description Pos. Description Push-button unit for height adjustment Hydraulic cylinder Swivel castor (4 pieces) Safety catch for maintenance Parking brake (2 pieces) -
Page 18: Installation And Commissioning
Generally wear steel-toed safety shoes and suitable protective work clothing! Switch on Model HS 300 MIDI | AH Before working with the battery-hydraulic lift table "AH", ensure that a) the battery is in a charged state b) the main switch (10) is in the "ON"... -
Page 19: Lifting And Lowering The Platform
Figure 7: Push button unit 9.4.2.1 Accessories for the HS 300 MIDI | AH battery unit As an alternative to the wired push button unit, a radio control for the battery hydraulics is available, which enables completely wireless operation of the height adjustment (Art.-No. 190.151.00). -
Page 20: Measures After Operation
Measures after Operation 10.1 General Measures Additional electrical components (e.g. machines lying on the lift table) must be switched off after finishing work and also disconnected from the mains by unplugging the power cable. Furthermore, the lift table must be se- cured against unauthorised use. -
Page 21: Troubleshooting
Lift table is overloaded Platform cannot be lifted up Hydraulic cylinder, foot pump → Contact customer service or mechanics defective Faults with Model HS 300 MIDI | AH Fault Possible Cause Remedy → Charge battery Battery empty The lift table cannot be →... -
Page 22: Maintenance And Repair
(see section 12.1). • Model HS 300 MIDI | AH: Turn off the main switch before carrying out any mainte- nance or repair work. WARNING! There is an acute risk of electric shock when open- ing the battery box even if the main switch is turned off! •... -
Page 23: Battery Charging Unit
The battery charger "MXS 5.0" integrated in the battery box is a commercially available, microprocessor-con- trolled charger from the manufacturer CTEK. The charging voltage for the lead gel battery installed in the HS 300 MIDI | AH is 14.4 volts. 13.1 CTEK MXS 5.0 - Operation Instructions BA_BM_HS-300-MIDI_EN_44-21.docx... - Page 24 ➔ Select charging mode “14,4 V / 5 A” CAUTION! Charging voltages higher than 14.4 V can damage or destroy the battery! BA_BM_HS-300-MIDI_EN_44-21.docx...
- Page 25 BA_BM_HS-300-MIDI_EN_44-21.docx...
- Page 26 CHARGING PROGRAM BA_BM_HS-300-MIDI_EN_44-21.docx...
- Page 27 BA_BM_HS-300-MIDI_EN_44-21.docx...
- Page 28 BA_BM_HS-300-MIDI_EN_44-21.docx...
-
Page 29: Decommissioning
Decommissioning • Before taking out of service, the platform of the lift table must be lowered completely. • For recommissioning, observe chapter 8 “Installation and commissioning“. • For the final scrapping of the lift table, please refer to chapter 15. Disassembly and Scrapping When dismantling and scrapping the lift table, the current EU regulations or the respective regulations and laws of the country of operation, which are prescribed for proper dismantling and disposal, must be observed. -
Page 30: Options And Accessories
Options and Accessories In the following tables you will find available options and accessories that you can use to upgrade your lift table. Please also visit our online shop https://www.hokubema.com. Only use the original accessories and spare parts specified by the manufacturer. The use of other accessories or spare parts may cause injury to persons and damage to the lift table. -
Page 31: Other Accessories
190.300.00 moved from the rack by one person and fed to the processing machine (e.g. sliding table saw, etc.). For plates up to 120 kg | Weight approx. 48 kg 16.3 Option for Model HS 300 MIDI | AH Article Description Art.-No. - Page 32 Continuation “16.4 Accessories for Wood Grid Hole Panels” Article Description Art.-No. VERTICAL RAIL CLAMP The lever handle with latching mechanism offers dosed, fast and 22 x 8.5 mm, vibration-proof tensioning during vertical workpiece clamping. VARIABLE PROJECTION, 200.713.22 Projection = 100 mm | Clamping height max. 200 mm | LEVER HANDLE WITH Swivelling by 360°...
-
Page 33: Accessories For Metal Grid Hole Panel (Art.-No. 200.115.00)
16.5 Accessories for Metal Hole Grid Panel (Art.-No. 200.115.00) Can only be used for 4 mm thick metal hole grid plates with Ø 28 mm! Article Description Art.-No. Ideal connecting element with twist lock for the metal hole grid table top ADJUSTABLE QUICK-CLAMP- accessories with ø... - Page 34 Continuation “16.5 Metal Grid Hole Panel (Art.-No. 200.115.00)“ Article Description Art.-No. STOP & CLAMPING Lockable with quick-release bolt. With nitrided surface. ANGLE 75L 200.818.28 Length = 75 mm | Width = 50 mm | Height = 75 mm | Material thickness = 25 mm STOP &...
-
Page 35: Accessories For 16B-System Steel Hole Grid Plate (Art.-Nr. 200.400.16)
16.6 Accessories for 16B-System Steel Hole Grid Plate (Art.-Nr. 200.400.16) Article Description Art.-No. Optimal connecting element for clamping 2 components with twist lock, QUICK-ACTION for hole grid plate accessories with ø 28 mm holes. The extra-large balls CLAMPING BOLT, SHORT protect the chamfer of the holes and reduce internal friction. -
Page 36: Eu - Declaration Of Conformity
Phone: 0049 - 7576 962 978 0 Fax: 0049 - 7576 962 978 90 hereby declares that the manufactured machine Model: Lift Tables HS 300 MIDI | FH and HS 300 MIDI | AH Type designation: Lift Table Serial number(s):...
