TRANSLATION OF THE ORIGINAL VERSION
Operating Manual
Foot-hydraulic and battery-hydraulic adjustable Scissor Lift Tables
Types HS 2000 | FH and HS 2000 | AH
HS 2000 | FH and HS 2000 | AH
Valid for types:
Reinhold Beck Maschinenbau GmbH
Im Grund 23 | DE -72505 Krauchenwies
Tel.: +49 (0) 7576 / 962 978 - 0 | Fax: +49 (0) 7576 / 962 978 - 90
E-Mail:
info@beck-maschinenbau.de
| Web:
https://www.beck-maschinenbau.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS 2000 FH and is the answer not in the manual?

Questions and answers

Summary of Contents for R. Beck Maschinenbau HS 2000 FH

  • Page 1 TRANSLATION OF THE ORIGINAL VERSION Operating Manual Foot-hydraulic and battery-hydraulic adjustable Scissor Lift Tables Types HS 2000 | FH and HS 2000 | AH HS 2000 | FH and HS 2000 | AH Valid for types: Reinhold Beck Maschinenbau GmbH Im Grund 23 | DE -72505 Krauchenwies Tel.: +49 (0) 7576 / 962 978 - 0 | Fax: +49 (0) 7576 / 962 978 - 90 E-Mail:...
  • Page 2: Table Of Contents

    Table of Contents Introduction ................................4 Legal Notice ....................................4 Illustrations ....................................4 Symbols ................................... 4 General Symbols ..................................4 Symbols in Safety Instructions..............................5 General ..................................6 Advantages ....................................6 Applications ....................................6 Target Group and Previous Experience ............................6 Requirements for the Operators ..............................
  • Page 3 Load and Unload the Lift Table..............................18 Moving the Lift Table via Swivel Castors ............................ 18 Lifting and Lowering the Platform .............................. 19 9.4.1 HS 2000 | FH..................................19 9.4.2 HS 2000 | AH ................................... 19 Measures after Operation ............................. 20 10.1 General Measures ..................................
  • Page 4: Introduction

    1 Introduction The information in this operating manual enables safe, proper and economical operation of your lift table. Please observe all the explanations, notes and regulations • to avoid dangers and malfunctions, • to reduce repair costs and downtimes • and to increase reliability and service life of your lift table.
  • Page 5: Symbols In Safety Instructions

    Symbols in Safety Instructions The lift table is designed and manufactured according to the current state of the art. Nevertheless, residual haz- ards may occur during handling. In this operating manual, possible dangers and residual risks are pointed out at appropriate places.
  • Page 6: General

    3 General The operating manual must be read carefully and understood before handling the lift table! If anything is unclear, please contact the manufacturer. The ergonomic HS 2000 scissor lift table has a very high load capacity of max. 2000 kg and is therefore particularly suitable for heavy-duty applications.
  • Page 7: Accident Prevention

    Accident Prevention To avoid accidents, the following rules must be observed for operation: Prevent unauthorized persons from gaining access to the lift table. Keep unauthorized persons away from the danger areas. Repeatedly inform present other persons about existing residual risks (see section  4.8 "Residual Risks"). Conduct and record regular training &...
  • Page 8: Safety

    4 Safety Basic Safety Instructions Lift tables can be dangerous if used improperly. Therefore, observe the safety instructions listed in this chapter and the accident prevention regulations of your employer's liability insurance association! The manufacturer accepts no liability for damage and malfunctions resulting from failure to observe these operating instructions.
  • Page 9: Consequences In Case Of Disregard

    Consequences in Case of Disregard If the lift table is not operated, maintained or repaired in accordance with the safety regulations, not as in- tended, improperly or in an abusive manner, the following will result: Dangers to the health of the operating personnel Dangers to the lift table and objects in its vicinity Impairment of the lift table function In case of improper use of the lift table, any warranty, liability and other claims for damages of the operator...
  • Page 10: Hazardous Areas

    Hazardous Areas Source Area Cause Risk Prevention Foot pump HS 2000 | FH only: On the foot pedal Slipping off the Injuries to feet Keep foot pedal for height adjust- foot pedal and legs and shoes dry ment Wear work shoes with non-slip soles On the foot pedal Stumbling and...
  • Page 11: Residual Risks

    Residual Risks The lift table is built according to the latest state of the art and the recognised safety rules. Nevertheless, the use of the lift table may cause danger to life and limb of the user or third parties or damage to the lift table and other equipment.
  • Page 12: Organisational Measures

    4.10 Organisational Measures Always keep this operating manual within easy reach and at the place of use of the lift table. In addition to the operating manual, observe and instruct on generally applicable legal and other binding regulations for accident prevention and environmental protection. Supplement the operating manual with further instructions, including supervisory and reporting duties, to take account of special operational features (e.g.
  • Page 13: Technical Specifications

    Technical Specifications Lift Table Type HS 2000 | FH HS 2000 | AH Article number 194.100.00 194.100.00 + 200.351.00 Special feature - foot-hydraulic height adjustment - battery-hydraulic height adjustment - with push-handle - with push-handle Table top 6 mm thick metal sheet 6 mm thick metal sheet 1500 x 1000 mm 1500 x 1000 mm...
  • Page 14: Transport To The Installation Site

    Transport to the Installation Site Only trained personnel may be used for the following work: • Transport the lift table • Unloading the lift table • Check delivery condition of the lift table Unloading the Lift Table There is an increased risk of accidents when unloading and transporting the lift table! The lift table can fall or tip over due to its weight! Use only suitable and technically perfect lifting gear and suspension systems with an adequate lifting capacity of 1000 kg.
  • Page 15: Requirements For The Installation Site

    Requirements for the Installation Site The following guidelines apply with regard to space requirements, load-bearing capacity and the condition of the substrate: • Space requirements: W x H x D = 1500 x 500 x 1000 mm (with metal sheet table top) •...
  • Page 16: Components And Controls

    Components and Controls Model HS 2000 | FH Figure 3: Components and controls of HS 2000 | FH Pos. Description Pos. Description Foot pedal for height adjustment Table top Fixed castors (2 pieces) Hydraulic cylinder Swivel castors with brake (2 pieces) Safety catches for maintenance Lifting scissor Hydraulic pump with tank...
  • Page 17: Model Hs 2000 | Ah

    Model HS 2000 | AH Figure 4: Components and controls of HS 2000 | AH Pos. Description Pos. Description Push-button unit for height adjustment Hydraulic cylinder Fixed castors (2 pieces) Safety catches for maintenance Swivel castors with brake (2 pieces) Battery box Lifting scissor Battery charging unit...
  • Page 18: Installation And Commissioning

    Installation and Commissioning The lift table must be set up in a stable position so that there are no crushing or shearing points between the lift table and/or the load and objects in the vicinity. Therefore, ensure sufficient space around the lift table. It must be possible to carry out the intended work on the lift table or the load without obstruction.
  • Page 19: Lifting And Lowering The Platform

    Lifting and Lowering the Platform Before the lift table platform is lifted, the lift table must be fixed in place by the two lockable brakes on the two front swivel castors. Tip: If you want to use your lift table for a longer time at the same height position (without adjustment), you can additionally fix it mechanically with the safety catch (see section ...
  • Page 20: Measures After Operation

    Measures after Operation 10.1 General Measures Additional electrical components (e.g. machines lying on the lift table) must be switched off after finishing work and also disconnected from the mains by unplugging the power cable. Furthermore, the lift table must be se- cured against unauthorised use.
  • Page 21: Troubleshooting

    Troubleshooting Repair and maintenance work may only be carried out by competent, trained and instructed personnel. Repair work on mechanical and hydraulic components may only be carried out by authorised and trained personnel. Proceed systematically when searching for the cause of a malfunction. If you are unable to find the fault or to remedy the malfunction, contact our customer service department (phone: 0049 7576 / 962 978 - 0).
  • Page 22: Maintenance And Repair

    Maintenance and Repair Maintenance and repair work may only be carried out by competent, trained and instructed personnel. If neces- sary, further operating instructions and/or additional documents must be observed. After maintenance or repair work on the lift table, always carry out a function test. •...
  • Page 23: Battery Charging Unit

    Battery Charging Unit The battery charger "MXS 5.0" integrated in the battery box is a commercially available, microprocessor-con- trolled charger from the manufacturer CTEK.  The charging voltage for the lead gel battery installed in the HS 2000 | AH is 14.4 volts. 13.1 CTEK MXS 5.0 - Operation Instructions BA_BM_HS-2000_EN_46-21.docx...
  • Page 24 ➔ Select charging mode “14,4 V / 5 A”  CAUTION! Charging voltages higher than 14.4 V can damage or destroy the battery! BA_BM_HS-2000_EN_46-21.docx...
  • Page 25 BA_BM_HS-2000_EN_46-21.docx...
  • Page 26 CHARGING PROGRAM BA_BM_HS-2000_EN_46-21.docx...
  • Page 27 BA_BM_HS-2000_EN_46-21.docx...
  • Page 28 BA_BM_HS-2000_EN_46-21.docx...
  • Page 29: Decommissioning

    Decommissioning • Before taking out of service, the platform of the lift table must be lowered completely. • For recommissioning, observe chapter  8 “Installation and commissioning“. • For the final scrapping of the lift table, please refer to chapter  15. Disassembly and Scrapping When dismantling and scrapping the lift table, the current EU regulations or the respective regulations and laws of the country of operation, which are prescribed for proper dismantling and disposal, must be observed.
  • Page 30: Options And Accessories

    Options and Accessories In the following tables you will find available options and accessories that you can use to upgrade your lift table. Please also visit our online shop  https://www.hokubema.com. Only use the original accessories and spare parts specified by the manufacturer. The use of other accessories or spare parts may cause injury to persons and damage to the lift table.
  • Page 31: Accessories For Steel Hole Grid Plates With Ø 16 Mm Holes

    16.3 Accessories for Steel Hole Grid Plates with Ø 16 mm Holes Article Description Art.-No. QUICK RELEASE BOLT SHORT, Optimal connecting element with twist lock for the steel hole grid plate WITH TWIST LOCK accessories with ø 16 mm. The extra-large balls protect the chamfer of 200.850.16 the holes and reduce internal friction.
  • Page 32: Accessories For Steel Hole Grid Plates With Ø 28 Mm Holes

    16.4 Accessories for Steel Hole Grid Plates with Ø 28 mm Holes Article Description Art.-No. QUICK RELEASE BOLT SHORT, Optimal connecting element with twist lock for the steel hole grid plate WITH TWIST LOCK accessories with ø 28 mm. The extra-large balls protect the chamfer of the 200.880.28 holes and reduce internal friction.
  • Page 33: Convert Hs 2000 Large | Fh To Ah

    16.5 Convert HS 2000 LARGE | FH to AH The foot-hydraulic model “FH” can later be converted to the battery-hydraulic “AH” version: Article Description Art.-No. For the conversion of HS 2000 LARGE | FH to the battery-hydraulic version BATTERY HYDRAULIC “AH”.
  • Page 34: Eu - Declaration Of Conformity

    EU - Declaration of Conformity in accordance with the EU Machinery Directive 2006/42/EC Annex II A The manufacturer, Fa. Reinhold Beck Maschinenbau GmbH Im Grund 23 DE-72505 Krauchenwies (Germany) Phone: 0049 - 7576 962 978 0 Fax: 0049 - 7576 962 978 90 hereby declares that the manufactured machine Model: Lift Tables HS 2000 | FH and HS 2000 | AH...
