TRANSLATION OF THE ORIGINAL VERSION
Operating Manual
Foot-hydraulic and battery-hydraulic adjustable Double Scissor Lift Tables
Types HS 300 LARGE | FH und HS 300 LARGE | AH
HS 300 LARGE | FH und HS 300 LARGE | AH
Valid for types:
Reinhold Beck Maschinenbau GmbH
Im Grund 23 | DE -72505 Krauchenwies
Tel.: +49 (0) 7576 / 962 978 - 0 | Fax: +49 (0) 7576 / 962 978 - 90
E-Mail:
info@beck-maschinenbau.de
| Web:
https://www.beck-maschinenbau.de
Advertisement
Table of Contents
Related Manuals for R. Beck Maschinenbau HS 300 LARGE | FH
Summary of Contents for R. Beck Maschinenbau HS 300 LARGE | FH
- Page 1 TRANSLATION OF THE ORIGINAL VERSION Operating Manual Foot-hydraulic and battery-hydraulic adjustable Double Scissor Lift Tables Types HS 300 LARGE | FH und HS 300 LARGE | AH HS 300 LARGE | FH und HS 300 LARGE | AH Valid for types:...
-
Page 2: Table Of Contents
Components and Controls ............................. 17 Model HS 300 LARGE | FH ................................17 Model HS 300 LARGE | AH ................................. 18 Installation and Commissioning ..........................19 Operation ................................19 Switch on Model HS 300 LARGE | AH ............................19 BA_BM_HS-300-LARGE_EN_45-21.docx... - Page 3 Tilting Devices .................................... 36 17.3 Further Options and Accessories ..............................36 17.4 Accessories for Model HS 300 LARGE | AH ..........................36 17.5 Extension Systems for Models without Vacuum ........................37 17.6 Accessories for HS 300 LARGE | VAKUUM ..........................38 17.6.1...
- Page 4 Figure 1: Permissible load with load distribution ........................10 Figure 2: Nameplate ................................. 14 Figure 3: Components and controls of HS 300 LARGE | FH ...................... 17 Figure 4: Components and controls of HS 300 LARGE | AH ..................... 18 Figure 5: Main switch ................................
-
Page 5: Introduction
1 Introduction The information in this operating manual enables safe, proper and economical operation of your lift table. Please observe all the explanations, notes and regulations • to avoid dangers and malfunctions, • to reduce repair costs and downtimes • and to increase reliability and service life of your lift table. -
Page 6: Symbols In Safety Instructions
Symbols in Safety Instructions The lift table is designed and manufactured according to the current state of the art. Nevertheless, residual haz- ards may occur during handling. In this operating manual, possible dangers and residual risks are pointed out at appropriate places. -
Page 7: General
If anything is unclear, please contact the manufacturer. The ergonomic HS 300 LARGE double scissor lift table is the largest model in the HS 300 series. With its 1900 x 740 mm support frame, is suitable for very LARGE table tops. The solid construction made of square profiles and its mobility thanks to four swivel castors make it a universal helper for countless applications in industry and trade, e.g. -
Page 8: Accident Prevention
Accident Prevention To avoid accidents, the following rules must be observed for operation: Prevent unauthorized persons from gaining access to the lift table. Keep unauthorized persons away from the danger areas. Repeatedly inform present other persons about existing residual risks (see section 4.8 "Residual Risks"). Conduct and record regular training &... -
Page 9: Safety
4 Safety Basic Safety Instructions Lift tables can be dangerous if used improperly. Therefore, observe the safety instructions listed in this chapter and the accident prevention regulations of your employer's liability insurance association! The manufacturer accepts no liability for damage and malfunctions resulting from failure to observe these operating instructions. -
Page 10: Consequences In Case Of Disregard
Consequences in Case of Disregard If the lift table is not operated, maintained or repaired in accordance with the safety regulations, not as in- tended, improperly or in an abusive manner, the following will result: Dangers to the health of the operating personnel Dangers to the lift table and objects in its vicinity Impairment of the lift table function In case of improper use of the lift table, any warranty, liability and other claims for damages of the operator... -
Page 11: Hazardous Areas
Hazardous Areas Source Area Cause Risk Prevention Foot pump HS 300 LARGE | FH Slipping off the Injuries to feet Keep foot pedal only: On the foot foot pedal and legs and shoes dry pedal for height Wear work shoes... -
Page 12: Residual Risks
Residual Risks The lift table is built according to the latest state of the art and the recognised safety rules. Nevertheless, the use of the lift table may cause danger to life and limb of the user or third parties or damage to the lift table and other equipment. -
Page 13: Organisational Measures
Work on hydraulic equipment may only be carried out by authorised and trained personnel. Work on the electrical equipment of the lift table model HS 300 LARGE | AH may only be carried out by a qualified electrician or by instructed persons under the direction and supervision of a qualified electrician in accordance with the electrotechnical regulations. -
Page 14: Technical Specifications
Technical Specifications Lift Table Type HS 300 LARGE | FH HS 300 LARGE | AH Article number 191.100.00 191.120.00 Special feature foot-hydraulic height adjustment battery-hydraulic height adjustment Table top none (option) none (option) Support frame dimensions 1900 x 740 mm... -
Page 15: Transport To The Installation Site
• Carefully lift the HS 300 LARGE from the truck. The net weight is approx. 150 kg (FH) resp. approx. 195 kg (AH). The model HS 300 LARGE | FH | VAKUUM weighs approx. 240 kg (net). -
Page 16: Requirements For The Installation Site
• Space requirements: W x H x D = 2010 x 420 x 1010 mm (Model FH with table top) W x H x D = 2010 x 460 x 1010 mm (Model AH with table top) • Load capacity: Concrete of classification B 15 •... -
Page 17: Components And Controls
Components and Controls Model HS 300 LARGE | FH Figure 3: Components and controls of HS 300 LARGE | FH Pos. Description Pos. Description Foot pedal for height adjustment Support frame Swivel castor (4 pieces) Hydraulic cylinder Parking brake (2 pieces) -
Page 18: Model Hs 300 Large | Ah
Model HS 300 LARGE | AH Figure 4: Components and controls of HS 300 LARGE | AH Pos. Description Pos. Description Push-button unit for height adjustment Hydraulic cylinder Swivel castor (4 pieces) Safety catch for maintenance Parking brake (2 pieces) -
Page 19: Installation And Commissioning
Generally wear steel-toed safety shoes and suitable protective work clothing! Switch on Model HS 300 LARGE | AH Before working with the battery-hydraulic lift table "AH", ensure that a) the battery is in a charged state b) the main switch (10) is in the "ON"... -
Page 20: Lifting And Lowering The Platform
Figure 7: Push button unit 9.4.2.1 Accessories for the HS 300 LARGE | AH Battery Unit • An optional push-button unit with a 2 m spiral cable (instead of the standard cable) is available (Art.-No. -
Page 21: Measures After Operation
Measures after Operation 10.1 General Measures Additional electrical components (e.g. machines lying on the lift table) must be switched off after finishing work and also disconnected from the mains by unplugging the power cable. Furthermore, the lift table must be se- cured against unauthorised use. -
Page 22: Configuration With Vacuum Clamping Unit
Configuration with Vacuum Clamping Unit The pre-configured model HS 300 LARGE | VAKUUM (Art.-No. 191.109.00) is equipped with a vacuum clamping device. This allows workpieces to be fixed quickly and securely. The heart of the system is the electric vacuum pump with vacuum tank and automatic switch-off, which is integrated in the bottom frame of the lift table. -
Page 23: Clamping A Workpiece
11.2 Clamping a Workpiece Caution! Danger of crushing hands and fingers between vacuum suction cup and workpiece. Do not reach into this danger area and wear protective gloves if necessary. Danger of cutting and abrasion due to sharp workpiece edges and pointed corners. Be careful with sharp-edged and pointed workpieces and wear protective gloves if necessary. -
Page 24: Unclamp Workpiece
11.2.2.1 Swivelling Universal Clamping Plate In contrast to the universal clamping plate that can be fixed flat on the table, the swivelling version (art. no. 200.406.00) can be tilted by up to 90°. • Simply loosen the clamping wheel (H) by turning it to the left, set the de- sired inclination and tighten the clamping wheel again. -
Page 25: Troubleshooting
Lift table is overloaded Platform cannot be lifted up Hydraulic cylinder, foot pump → Contact customer service or mechanics defective Faults with Model HS 300 LARGE | AH Fault Possible Cause Remedy → Charge battery Battery empty The lift table cannot be →... - Page 26 Models with Vacuum Clamping Unit Fault Possible Cause Remedy Dust / chips / dirt between → Remove contamination workpiece and clamping device Operating vacuum is not achieved or is too weak and → Replace vacuum hoses Vacuum hoses leaking the pump runs without inter- →...
-
Page 27: Maintenance And Repair
(see section 13). • Model HS 300 LARGE | AH: Turn off the main switch before carrying out any mainte- nance or repair work. WARNING! There is an acute risk of electric shock when open- ing the battery box even if the main switch is turned off! •... -
Page 28: Battery Charging Unit
The battery charger "MXS 5.0" integrated in the battery box is a commercially available, microprocessor-con- trolled charger from the manufacturer CTEK. The charging voltage for the lead gel battery installed in the HS 300 LARGE | AH is 14.4 volts. 14.1 CTEK MXS 5.0 - Operation Instructions BA_BM_HS-300-LARGE_EN_45-21.docx... - Page 29 ➔ Select charging mode “14,4 V / 5 A” CAUTION! Charging voltages higher than 14.4 V can damage or destroy the battery! BA_BM_HS-300-LARGE_EN_45-21.docx...
- Page 30 BA_BM_HS-300-LARGE_EN_45-21.docx...
- Page 31 CHARGING PROGRAM BA_BM_HS-300-LARGE_EN_45-21.docx...
- Page 32 BA_BM_HS-300-LARGE_EN_45-21.docx...
- Page 33 BA_BM_HS-300-LARGE_EN_45-21.docx...
-
Page 34: Decommissioning
Decommissioning • Before taking out of service, the platform of the lift table must be lowered completely. • For recommissioning, observe chapter 8 “Installation and commissioning“. • For the final scrapping of the lift table, please refer to chapter 16. Disassembly and Scrapping When dismantling and scrapping the lift table, the current EU regulations or the respective regulations and laws of the country of operation, which are prescribed for proper dismantling and disposal, must be observed. -
Page 35: Options And Accessories
WITH 3 DRAWERS Platform size = 2000 x 1000 x 160 mm | Table top thickness = 27 mm | Internal drawer dimensions 900 x 560 x 100 mm | Weight approx. 74 kg Suitable for HS 300 LARGE with existing metal table top, screwed onto ROLLER TRACK WITH STEEL platform. -
Page 36: Tilting Devices
Weight approx. 30 kg STATIONARY 4 foot plates with threaded bolts, adjustable by ± 15 mm for floor levelling. 200.020.00 VERSION Weight approx. 6 kg 17.4 Accessories for Model HS 300 LARGE | AH Article Description Art.-No. RADIO CONTROL FOR Wireless operation for up/down. -
Page 37: Extension Systems For Models Without Vacuum
17.5 Extension Systems for Models without Vacuum Article Description Art.-No. Platform extension (pull-out per side max. 820 mm), suitable for HS 300 PLATFORM EXTENSION ON LARGE. Can be fixed in 80 mm steps with locking bolts. ONE SIDE, WITHOUT PANEL 200.320.00 Support surface / Side = 810 x 160 mm | Weight approx. -
Page 38: Accessories For Hs 300 Large | Vakuum
17.6 Accessories for HS 300 LARGE | VAKUUM Article Description Art.-No. Suitable for HS 300 LARGE VACUUM, incl. 2 connection coupling sockets. VACUUM PUMP WITH MORE SUCTION POWER 210.450.00 Suction capacity 4,6 m h | Foot switch with 1.5 m fabric hose | 5 m con- nection cable with earthed plug (230 VAC/50Hz) | Weight approx. -
Page 39: Extension Systems For Models With Vacuum
17.6.1 Extension Systems for Models with Vacuum Article Description Art.-No. Platform extension (pull-out per side max. 820 mm), suitable for HS 300 PLATFORM EXTENSION ON LARGE | VACUUM. Can be fixed in 80 mm steps with locking bolts. ONE SIDE, WITHOUT PANEL 200.520.00 Support surface / Side = 770 x 160 mm | Weight approx. -
Page 40: Accessories For Wood Hole Grid Panels
17.7 Accessories for Wood Hole Grid Panels Article Description Art.-No. HORIZONTAL Clamping spigot with trapezoidal internal thread, threaded spindle and CLAMP thrust piece with protective cap. 200.607.22 Threaded spindle 40 mm adjustable | Weight approx. 1 kg VERTICAL RAIL CLAMP For vertical workpiece clamping. -
Page 41: Accessories For Metal Hole Grid Panel (Art.-No. 200.208.00)
Continuation “17.7 Accessories for Wood Grid Hole Panels“ Article Description Art.-No. ANGULAR GEAR TENSIONER Provides secure footing in the matrix plate and enables uniformly strong WITH 2 GRID BOLTS clamping. 200.608.22 Nutzhub = 130 mm | Pressure plate = 100 x 78 mm | Clamping force max. 500 kg | Total length = 260 mm | Weight approx. -
Page 42: Eu - Declaration Of Conformity
Phone: 0049 - 7576 962 978 0 Fax: 0049 - 7576 962 978 90 hereby declares that the manufactured machine Model: Lift Tables HS 300 LARGE | FH and HS 300 LARGE | AH Type designation: Lift Table Serial number(s):...
