Interfaces
NP-F Battery Slot
Volume Knob
Display
UP Arrow Button
DOWN Arrow Button
LEFT Arrow Button
RIGHT Arrow Button
Menu/Confirmation Button
Press and hold the button to enter
the menu interface/Press the button
for confirmation.
0B10 Headset Interface
2-Wire Audio Input & Output Interface
PGM Audio Input Interface
Power Switch
DC Power Interface
1
A Button
OFF: The wired headset user is not in group A. In this case, the user cannot hear or talk
with the other headset users in group A.
ON in orange: The wired headset user is in group A. In this case, the user can hear and talk
with the other headset users in group A.
ANNOUNCE Button
Press and hold the button to mute all remote headsets in the system. In this case, the indicator
turns ON in orange.
USB Interface
B Button
OFF: The wired headset user is not in group B. In this case, the user cannot hear or talk with the
other headset users in group B.
ON in orange: The wired headset user is in group B. In this case, the user can hear and talk with
the other headset users in group B.
RJ45 Interface
RF Antenna Interface
V-Mount/G-Mount
Battery Plate
4-Wire Audio Input &
Output Interface
(RJ45 Socket)
UAC Interface
