Hollyland Solidcom C1 Pro User Manual page 15

Operation Guide
Cascaded Connection
Multiple hubs can be cascaded to expand the number of headsets. The hub
supports two cascade methods — cascade via 4-wire analog signals and cas-
cade via IP digital signals. Generally, it is recommended to cascade two hubs
using 4-wire analog signals, and cascade three or more than three hubs using
IP digital signals.
It is recommended to use a CAT5e cable for cascade and use the 568B stan-
dard for the RJ45 interface.
Standard Network Cable
Two-System Cascaded Connection via the 4-Wire Interface
Use a standard network cable to connect two hubs via the 4-wire interface.
The length of the network cable is up to 300 meters.
Specifications
CAT5e
CAT6e
Network cable of 300 meters
16
Max Length
300 meters
