Altronix VertiLine Rack Mount Power Supplies provide eight (8) filtered and electronically regulated power outputs
in a space saving 1U EIA 19" rack mount chassis. The units are available with either 12VDC or 24VDC power
outputs. VertiLine Rack Mount Power Supplies are also available in sixteen (16) outputs.
Agency Listing:
• CE European Conformity.
Input:
• 220VAC (working range 190VAC - 256VAC),
50/60Hz.
Output:
VertiLine3DV:
• Eight (8) PTC protected 12VDC outputs rated @ 8A
total current max. (1.0A per device, 2.5A max.).
VertiLine6DV:
• Eight (8) PTC protected 24VDC outputs rated @ 8A
total current max. (1.0A per device, 2.5A max.).
• Filtered and electronically regulated outputs.
Eight (8) Output Rack Mount Configuration Reference Chart:
Altronix
Model Number
VertiLine3DV
VertiLine6DV
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or
moisture. This installation should be made by qualified service personnel and should
conform to the National Electrical Code and all local codes.
- 2 -
Specifica tions:
Total
Output
Output Current
Voltage (Power)
12VDC 8A
24VDC 8A
Overview:
Features:
• Eight (8) power LED indicators.
• Illuminated master power disconnect
circuit breaker with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
• Removable terminal blocks with locking
screw flange.
Mechanical:
• Units can be rack, wall or shelf mounted.
• Modular 1U standard EIA 19" rack mount chassis.
• Enclosure Dimensions (H x W x D approx.):
1.625" x 19.125" x 8.5"
(41.3mm x 486mm x 216mm).
Number of Output
Outputs Protection
8 PTC
8 PTC
220VAC
Current (max. 50/60Hz
per output) Input Current
2.5A
2.5A
VertiLine3DV / VertiLine6DV Installation Guide
0.75A
1.75A
