Summary of Contents for minkaAire SUPRA F563-BS-DW

  • Page 1 SUPRA 44” INSTRUCTION MANUAL WARRANTY CERTIFICATE...
  • Page 2 ©2019 Minka Lighting Inc. Manual design and all elements of manual design are protected by United States Federal and/or State Law including Patents, Trademark, and/or Copyright Laws.
  • Page 3 The Minka-Aire® warranty is for one (1) year from the date of purchase from an authorized Minka-Aire® dealer. This warranty is only valid to the original purchaser or user against all defects in material and workmanship (light bulbs excluded) for one (1) full year. Additionally, Minka-Aire® warrants the motor only for the lifetime of the Minka Aire ceiling fan (excluding wall controls and electrical components), to the original purchaser or user.
  • Page 4 Warranty Service Information To obtain warranty service during the warranty period, the purchaser should return the fan with the sales receipt to the original place of purchase. The authorized Minka-Aire® dealer, at its sole discretion, will either repair or replace the fan after verifying the legitimacy of the warranty claim.
  • Page 5: Table Of Contents

    CONTENTS SAFETY RULES..................ATTACHING THE FAN BLADES............PACKAGE CONTENTS..............ATTACHING THE SWITCH CUP............INSTALLING THE FAN..............OPERATING YOUR FAN................ HANGING THE FAN................ CARE OF YOUR FAN................ELECTRICAL CONNECTIONS............TROUBLESHOOTING................FINISHING THE INSTALLATION..........SPECIFICATIONS..................LISTED E75795 1151 W. Bradford Court, Corona, CA 92882 For Customer Assistance Call: 1-800-307-3267...
  • Page 6: Safety Rules

    SAFETY RULES 1. Before you begin installing the fan, shut power off at the circuit breaker of the fuse box. 2. Be cautious! Read all instructions and safety information before installing your new fan. Review accompanying assembly diagrams. 3. Make sure that all electrical connections comply with local codes, ordinances, or National Electrical Codes. Hire a qualified electrician or consult a do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring.
  • Page 7 NOTE: The important safeguards and instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur. It must be understood that common sense, caution and care are factors which can not be built into this product. These factors must be supplied by the person (s) installing, caring for and operating the unit.
  • Page 8: Package Contents

    PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: A. Mounting hardware: 1. Fan blades (5) #10 x 1.5" Wood screws (2 PCs.) 2. Hanger bracket #8 x 3/4" Machine screws (2 PCs.) 3. Canopy Lock washers (2 PCs.) 4.
  • Page 9: Installing The Fan

    INSTALLING THE FAN Tools Required: Phillips screw driver; slotted screw driver; step-ladder; wire cutters; electrical tape. PARALLEL WOOD BRACE CEILING (MIN. 2" THICK) MOUNTING OPTIONS JOIST OUTLET CROSS BRACE If there isn't an existing mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers.
  • Page 10: Hanging The Fan

    HANGING THE FAN WARNING: All of the parts, hardware and components such as the Step 3. Remove the Hanger Ball from the Downrod Assembly by loosening hanger bracket and hanger ball have been provided for your safety and the Set Screw and removing the Cross Pin. (Fig. 7) the proper installation of your new ceiling fan.
  • Page 11 DOWNROD OUTLET BOX CANOPY DOWNROD CROSS PIN SET SCREWS COUPLING COVER HITCH LOCK HANGER SUPPLY REGISTRATION BALL SET SCREW WIRES SLOT SET SCREWS DOWNROD HANGER BRACKET Fig. 10 Fig. 5 Fig. 6 Fig. 7 Fig. 8 HITCH PIN LOCK PIN Fig.
  • Page 12: Electrical Connections

    ELECTRICAL CONNECTIONS FAN CONTROLLED BY PULL CHAIN, LIGHT KIT CONTROLLED BY PULL CHAIN. REMEMBER to shut the power off at the circuit breaker or fuse box. HOUSE WIRE SUPPLY WHITE (NEUTRAL) GREEN (GROUND) Follow the steps below to connect the fan to your house supply wires. Use the BLACK (HOT) wire nuts supplied with your fan.
  • Page 13 FAN CONTROLLED BY PULL CHAIN, LIGHT KIT CONTROLLED BY WALL SWITCH. FAN CONTROLLED BY WALL CONTROL, LIGHT KIT CONTROLLED BY LIGHT SWITCH. HOUSE WIRE SUPPLY HOUSE WIRE SUPPLY WHITE (NEUTRAL) GREEN (GROUND) WHITE (NEUTRAL) GREEN (GROUND) BLACK (HOT) BLACK (HOT) CEILING CEILING LIGHT SWITCH...
  • Page 14: Finishing The Installation

    FINISHING THE INSTALLATION Step 1. Remove 1 of the 2 screws from the bottom of the hanger bracket and loosen the other one OUTLET BOX half a turn from the screw head. HANGER Step 2. Slide the canopy up towards the hanger bracket and place the key hole on the canopy BRACKET over the screw on the hanger bracket, turn canopy until it locks in place at the narrow section of the key holes.
  • Page 15: Attaching The Fan Blades

    ATTACHING THE FAN BLADES Step 1. Attach the fan blades to the blade holders using the screws and fiber washers provided, tighten screws securely. (Fig. 15) SCREWS FAN MOTOR FAN BLADE Step 2. Remove rubber stops from motor. Rotate FIBER motor so that the screw holes are revealed WASHERS FAN BLADE...
  • Page 16: Attaching The Switch Cup

    ATTACHING THE SWITCH CUP Step 1. Remove the screws from the switch cup plate. While holding the switch cup, firmly snap the wire molexes together. Next, slide switch cup up against plate and rotate it until the screw holes are aligned.
  • Page 17: Operating Your Fan

    OPERATING YOUR FAN Restore power to ceiling fan and test for proper operation. Speed settings for warm or cool weather depend on factors such as the room size. Ceiling height, number of fans, etc. The Reverse switch is located on the switch cup. Slide the switch to the Left for warm weather operation. Slide the switch to the Right for cool weather operation.
  • Page 18 SUMMER OPERATION WINTER OPERATION COUNTERCLOCKWISE DIRECTION CLOCKWISE DIRECTIO FIG. 18 FIG. 19...
  • Page 19: Care Of Your Fan

    CARE OF YOUR FAN Here are some suggestions to help maintain your fan. 4. Use a lint free lightly damp cloth or duster to remove dust from the blades. 1. Because of the fan's natural movement some connections may become 5.
  • Page 20: Troubleshooting

    TROUBLESHOOTING SYMPTOM SYMPTOM SYMPTOM Fan will not start Fan Sounds Noisy Fan Wobble SOLUTION SOLUTION SOLUTION Check fuses or circuit breakers. Allow a 24-hour "break-in" period. Most noises as Check that all blade and blade holder screws sociated with a new fan go away during this time. are secured.
  • Page 21: Specifications

    SPECIFICATIONS These are typical readings. Your actual fan may vary. They Fan Size Speed Volts Amps Watts N.W. G.W. C.F. do not include amps and wattage used by the light(s). 0.241 11.15 44" 9.68 1.25' High 0.642 77.8...
  • Page 22 PERFORMANCE AND ENERGY INFORMATION FAN SPEED AIRFLOW POWER USE AIRFLOW EFFICIENCY (CFM)* (Watts) (CFM/Watt) 1257 11.15 High 5064 77.8 Estimated Ceiling fan airflow is measured in cubic feet per minute (CFM). Airflow 3,360 Yearly Energy Cost Power use is measured in watts. To maximize energy savings: •...
