- Page 1 C C A A L L A A I I S S U.S. PATENTS D526,714; D527,094; D530,415; D532,896; D536,777...
- Page 2 This product is protected by United States Federal and/or State Law, including Patent, Trademark and/or Copyright laws. Manual design is protected by United States Federal and/or State Law, including Patent, Trademark and/or Copyright laws.
- Page 3 Minka-Aire warrants to the original owner that this fan will be free from defects in material and workmanship for one ® year from the date of purchase, excluding the motor. Minka-Aire warrants to the original owner that the motor in this fan ®...
- Page 4 This warranty shall not apply to fans which have been damaged in any way, including improper installation, damage as a result of the removal of the fan from the origial installation, or damage in shipping. This warranty shall not apply to fans which have been subjected to use for which the fan was not designed.
-
Page 5: Table Of Contents
CONTENTS SAFETY FIRST INSTALLING THE LIGHT KIT & GLASS SHADE PACKAGE CONTENTS OPERATING THE REMOTE CONTROL/WALL CONTROL HANGING THE FAN CARE OF YOUR FAN ELECTRICAL CONNECTIONS TROUBLESHOOTING ATTACHING THE BLADES SPECIFICATIONS 1151W. Bradford Court, Corona CA 92882 For Customer Assistance Call: 1-800-307-3267... -
Page 6: Safety First
SAFETY FIRST 1. Before you begin installing the fan, shut power off at the circuit breaker of the fuse box. 2. Be cautious! Read all instructions and safety information before installing your new fan. Review accompanying assembly diagrams. 3. Make sure that all electrical connections comply with local codes, ordinances, or National Electrical Codes. Hire a qualified electrician or consult a do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring. - Page 7 NOTE:The important safeguards and instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur. It must be understood that common sense, caution and care are factors which can not be built into this product. These factors must be supplied by the person (s) installing, caring for and operating the unit.
-
Page 8: Package Contents
PACKAGE CONTENTS 1. Mounting bracket mounting screws and Spring washers (2 pcs) 2.Fan motor assembly A23, 12v battery) Star washers (2 pcs) 3. Fan housing 12. Receiver pre-installed in Flat washers (2 pcs) 4. Glass fan motor. C. Blade Holder Hardware: 5. -
Page 9: Hanging The Fan
HANGING THE FAN Tools Required: Phillips screw driver; slotted screw driver; step- ladder; wire cutters; electrical tape. WARNING: All of the parts, hardware and components have been MOUNTING BRACKET OUTLET provided for your safety and the proper installation of your new ceiling fan. - Page 10 SCREW Fig.3...
-
Page 11: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: To avoid possible electrical shock be sure electricity is Step 1. Connect the black (hot) wire from the ceiling to the black and turned off at the min fuse or breaker box before wiring. the black wires from the fan. Connect the white (Neutral) wire from the ceiling to the white wire from the fan. - Page 12 Fig.4...
- Page 13 MOUNTING BRACKET MOTOR HOUSING BLACK(HOT) GREEN(GROUND) WHITE(NEUTRAL) SCREW BLACK(MOTOR) GROUND- WHITE (NEUTRAL) (CONNECT TO GROUND WIRE ON HANGER BRACKET IF NO HOUSE GROUND WIRE EXISTS.) Fig.5 Fig.6...
-
Page 14: Attaching The Blades
ATTACHING THE BLADES Step 1. Attach the fan blade to the medallion & the blade bracket using the screws provided. Tighten screws securely. PLUG SCREW Repeat for remaining blades. (Fig. 7) Step 2. Align holes in blade bracket and motor and secure BLADE HOLDER with proper screws. -
Page 15: Installing The Light Kit & Glass Shade
INSTALLING THE LIGHT KIT & GLASS SHADE Use light bulb in accordance with the fan's specifications. DO NOT nipple. (Fig. 10). EXCEED THE MAXIMUM WATTAGE RATING. Step 5. Install the glass shade and secure with the the cap & the Step 1. -
Page 17: Operating The Remote Control/Wall Control
OPERATING THE REMOTE CONTROL/WALL CONTROL Remote Control fans only: Install the A23, 12v battery (included) . To prevent damage to transmitter remove the battery if not used for long periods of time. Restore Power to Ceiling Fan c o n t r o l t h e b r i g h t n e s s s e t t i n g s o f t h e brightness as the last time it was turned off. -
Page 18: Care Of Your Fan
CARE OF YOUR FAN Here are some suggestions to help you maintain your fan. additional protection and enhanced beauty. Cover small scratches with a light application of shoe polish. 1. Because of the fan's natural movement, some connections may become loose. Check the support connections, brackets, and blade 5. -
Page 19: Troubleshooting
TROUBLESHOOTING SYMPTOM SYMPTOM SYMPTOM SYMPTOM Lights shut off and will not Fan will not start Fan Wobble Fan will not start come back on. SOLUTION SOLUTION SOLUTION SOLUTION 1. Allow a 24-hour "break in" 1.NOTE: All blade sets are grouped by 1.Check to make sure the wall switch is turned on. - Page 20 SYMPTOM Frequency interference SOLUTION 1.Turn the power off to your ceiling fan. 2.lease use a small size tool to change the frequency setting on the control system. 3.Return power to the unit Note: After the AC power is on,do not press any other button on the transmitter before pressing the “Stop”...
-
Page 21: Specifications
SPECIFICATIONS Fan Size Speed Volts Watts N.W. G.W. 12.8 2150 52" 0.483 34.1 3500 13.15 15.20 2.75' High 79.8 6050 These are typical readings. Your actual fan may vary. They do not include Amps and Wattage used by the light kit. For any additional information about your Minka-Aire Ceiling Fan,please write to:... - Page 22 English Verison...
