Profile PCL-333 Kalahari Quick Start Manual

Ceramic heater

Advertisement

Quick Links

CERAMIC HEATER
(with IR remote control)
PCL-333 Kalahari
We thank you for the purchase of this Profile product.
Note: It is important that you read this manual carefully
before using the product. And be sure to save this
manual for possible use later.

Technical information

Mains voltage: 230V (50Hz)
Power:
- In position 1
- In position 2
IP20 (no protection against water)
Overheat protection
Variable, built-in thermostat
Oscillating function
Tilt protection
Auto-off function with timer
Remote control with infrared
With handle for easy moving
Extra ON/OFF switch as protection on the rear of the
base.
Ideal for use in dry spaces to 60 m³

Safety precautions

To ensure safe operation of your heater, the appliance
must be connected in accordance with the indications
in the manual.
The appliance is only suitable for domestic use within
the home.
Do not use the appliance in humid spaces, such as
bathrooms and utility spaces.
When the heater is covered, then this can result in a
fire hazard.
Place the appliance only upright and on a level, dry
base.
The surfaces, and especially the grate, become very
hot during operation. Make sure that small children
cannot touch these surfaces.
No objects may be inserted through the appliance's
grate openings. This can disturb proper operation and
potentially lead to combustion of the object.
Never use the appliance in combination with a time
switch. The automatic operation of heaters can result
in a hazard during your absence.
The mains lead is not allowed to be run across the hot
appliance.
Electrical heaters are designed as additional heating
and are not suitable for main heating during the cold
season.
When the appliance has fallen, first disconnect the
power supply, before returning the appliance to its
upright position and if necessary remove what caused
it to fall.
Never leave your appliance unattended. Also always
pull the plug out of the socket when you leave the
room.
Do not use an extension lead.
Position the heater at a distance of at least 100cm
from obstacles and ensure that the hot air flow of the
appliance is not blown against any easily combustible
objects (such as curtains and/or heat-sensitive
plastics).
1000W
2000W

Connection

The heater is supplied with a socket plug. Never
operate the appliance with a damaged mains lead
and/or plug, or after a malfunctioning of the heater has
occurred or after it has been damaged in any possible
way.
The replacement of a mains lead and/or plug should
only be performed by a qualified expert, who is familiar
with the applicable regulations.
Operation and functions (are identical for both
manual and remote control operation)
Insert the socket plug in the wall socket and press
the switch at the rear side of the appliance.
Display:
A. 1000W + half a sun
lowest position.
B. 2000W + entire sun
highest position.
C. When the oscillating function is activated, the 2
arrows will blink.
D. Christmas tree
negative ion generator is
activated (= the environment air is purified through
the ionisator).
E. Room temperature.
F. Auto-off function with timer.

Push button/key "on-off":

Press the push button/key "on-off" in order to switch
the appliance off or on.
The fan will remain functioning during the switching
off until the heating element has cooled down.

Push button/key "model":

A. Set temperature:
Press the model function 1x until the temperature
blinks on the display.
EN - 1
A
B
D
C
appliance functions in the
appliance functions in the
E
F
