Summary of Contents for EcoFlow DELTA Pro 3
- Page 1 User Manual V0.4 EcoFlow DELTA Pro 3 ＊ This document is a beta version intended for prototype tests only and is NOT for public distribution. ＊ Images are for demonstration only. EcoFlow App...
-
Page 2: Table Of Contents
10 Getting Started 10 Power On/Off 11 Power Your Appliances 14 Charge Your Power Station 17 Product Management 17 Download EcoFlow App 17 Bind EcoFlow Device 18 Expand Battery Capacity 18 X-Boost: Power the High-Wattage Appliances 19 UPS: Backup for Essential Devices... -
Page 3: Safety Instructions
If used for general medical equipment, please this product, it is deemed that you understand, approve and accept all the terms and content in this document. EcoFlow be sure to monitor the power status to ensure that the power is not liable for any loss caused by the user's failure to use does not run out. -
Page 5: What's In The Box
What's in the Box • If any item is damaged or missing, please reach out to EcoFlow Customer Service for assistance. EcoFlow DELTA Pro 3 AC Charging Cable Product Documents • Reveal/Hide Electric Outlets: Slide the protective cover to reveal or hide electic outlets. -
Page 6: Overview
Overview APPEARANCE • Images displayed in this manual are for demonstration only. Product appearance may vary by region and version. ① ⑦ ② ④ ③ ⑤ ⑧ ⑨ ⑥ ⑩ ① ⑥ Main Power Button AC Output Socket (LV, NEMA 5-20R)×4 ②... - Page 7 ⑪ ⑪ 12V DC Output Control ⑫ ⑫ DC5521 Port (12V) ⑬ ⑬ REMOTE Port ⑭ ⑭ Anderson Port (12V) ⑱ ⑰ ⑮ ⑯ ⑳ ⑲ ⑮ ⑱ AC Input Socket Solar Input (LV) / DC Input ⑯ ⑲ Charge Speed Switch AC Power IN/OUT Port ⑰...
-
Page 8: Buttons And Switch
• The product has built-in buzzers. Product operation will result in a buzzing sound as a reminder. To disable it, switch it off in the EcoFlow app. • There will be two AC output control buttons that control the output of different voltage sockets. -
Page 9: Led Indicators
AC Output Breathing press the button to re-enable it. If the White problem recurs, upgrade the firmware version via the EcoFlow app and try again. The corresponding AC output sockets Solid White are enabled. The corresponding DC output ports are disabled. -
Page 10: Display Screen
Customized will be charged at a customized speed set in the EcoFlow Charging Speed app. The charge limit or discharge limit is set in the EcoFlow app. Charging/ Discharging The discharge limit is reached. The AC output and 12V DC... -
Page 11: Troubleshooting
Display current battery level. Remaining charging/ Display the remaining charging or discharging time. discharging time EcoFlow smart extra battery is connected via the Extra Extra Battery Battery port. Smart EcoFlow smart generator is connected via the Extra Generator Battery port. -
Page 12: Getting Started
The alarm will temperature Blinking disappear once the product temperature returns to normal warning operating levels. An error has occurred. Check the EcoFlow in-app instructions for troubleshooting. Battery error Blinking An error has occurred. Check the EcoFlow in-app instructions for troubleshooting. -
Page 13: Power Your Appliances
POWER YOUR APPLIANCES VIA USB PORTS Connect your device to the USB port directly. VIA AC OUTPUT SOCKETS 1. Press the AC output control button once to enable the power supply. 2. Connect your device to the AC output socket. ❶... - Page 14 ❷ ❶ ❷ ❶ Tips: 1. To ensure optimal power output, the AC output Button (HV) and AC output Button (LV) can not be used simultaneously. When one is enabled, the other is automatically disabled. 1 2 |...
- Page 15 2. In the event of abnormal AC output, try the following steeps: a. Press the button to re-enable the AC power output. b. If the problem recurs, upgrade the firmware version via the EcoFlow app and try again. c. If the problem persists, please contact technical support.
-
Page 16: Charge Your Power Station
CHARGE YOUR POWER STATION FROM WALL OUTLET Connect the product's AC input socket to a wall outlet using the AC charging cable provided. FROM SOLAR Connect the product's solar input port to solar panels. Tip: To ensure efficient charging, connect the solar panel correctly to the corresponding high-voltage or low-voltage input of the power station. - Page 17 Solar n Solar n Solar 1 Solar 1...
- Page 18 Method 2: via the Extra Battery port （ EcoFlow generator only ） a. Install the DELTA Pro to Smart Generator Adapter into the product's extra battery port. b. Connect the product to an EcoFlow generator‘s XT150 port via the extra battery connection cable. Applicable for third-party and EcoFlow generators...
-
Page 19: Product Management
EcoFlow devices stay up-to-date and function optimally at all times. BIND ECOFLOW DEVICE 1. Visit the EcoFlow app and log into your EcoFlow account. If you don't have an account, create one first. 2. Tap the Add Device button or in the top right corner to search for new EcoFlow devices. -
Page 20: Expand Battery Capacity
How do I use this feature? X-Boost is disabled by default. To use it, toggle it on in the EcoFlow app. What kind of devices does X-Boost support? X-Boost is more suitable for heating devices, such as an electric blanket, a water heater, or a heat pump. -
Page 21: Ups: Backup For Essential Devices
UPS: Backup for Essential Devices A UPS (Uninterrupted Power Supply) is a device or system that provides continual power supply as a backup when the grid electricity fails. You can use the power station as a UPS to support essential household appliances. The power station supports standby UPS (10 ms) to reconnect the appliances. -
Page 22: Storage And Maintenance
Storage and Maintenance STORAGE • Storage Temperature: 20°C-30°C (68°F-86°F) • Do not store it in places where the temperature exceeds 113°F (45°C) or falls below 14°F (–10°C). • Store the product in a tidy, dry, and well-ventilated place. • Keep the product away from water, intense heat, and sharp objects. •... - Page 24 © 2024 EcoFlow Inc. All rights reserved.
