Assembly (Option#2) (continued)
5
Installing support bars
□ Except for the holes that are over the stud, drill in
the exisiting holes on the wall using ø5/16" (8mm)
drill bit and insert the wall anchors (F) into the holes
using a rubber mallet until the wall anchors are
flush with the wall.
F
ø5/16"
8mm
6
Installing support bars
□ Replace and secure the support bars (E) with
screws (G).
12
HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
E
G
