Techly IDATA EXTIP-3834KP6 User Manual page 5

4K@30HZ HDMI
EXTENDER WITH POE
CONNECTIONS
a. Point to point connection: Up to 120 meters transmission
distance over single CAT6
b. LAN Switch Cascade connection: By using LAN switch/ router
to realize unlimited extension.
c. One-to-many connection: By using network router/switch, one
sender to several receivers, realizes extender & splitter function.
Note: Gigabit (1000Mbps) switcher is recommended in LAN
transmission. Fast Ethernet switched (100Mbps) and Gigabit
Ethernet switched (1000Mbps) can not be mixed-use in cascade.
FAQ
Q: TV display "Waiting for connection" on the right corner?
A: Please check if the power supply of TX (Sender) and switcher (if
used) is connected, and make sure connecting cable is firmly.
Q: TV display "Please check the TX input signal"?
A: 1) please check if there is a HDMI signal input of TX.
2) Try to connect the signal source directly to display device to see
if there is signal output from source device or change the signal
source, HDMI wire and try again.
