June 2021© Jacobsen HR6010 ROPS Installation Manual
Jacobsen HR6010 ROPS
* Shown with optional components *
Jacobsen HR6010 ROPS
This ROPS is designed and built to fit the Jacobsen HR6010.
Designed and Built by:
Tektite Manufacturing Inc:
427 Buffalo Street
P.O. Box 639
Winkler, MB
R6W 4A8
Canada
PH: 204-331-3463
Fax: 204-331-4159
sales@tektite.ca
www.tektite.ca
One year standard product warranty provided by Tektite.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Jacobsen HR6010 ROPS
Summary of Contents for Jacobsen HR6010 ROPS
- Page 1 June 2021© Jacobsen HR6010 ROPS Installation Manual Jacobsen HR6010 ROPS * Shown with optional components * Jacobsen HR6010 ROPS This ROPS is designed and built to fit the Jacobsen HR6010. Designed and Built by: Tektite Manufacturing Inc: 427 Buffalo Street P.O.
- Page 2 DO NOT PROCEED FURTHER UNTIL YOU HAVE READ THE INFORMATION BELOW 1) Always wear personal protective equipment 2) A minimum of two people is necessary to safely install the cab 3) This ROPS cab is heavy. A lift assist device such as an overhead hoist or high lift forklift is required.
- Page 3 June 2021© Jacobsen HR6010 ROPS Installation Manual Tektite Manufacturing Incorporated thanks you for purchasing a Jacobsen HR6010 ROPS! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of protection.
- Page 4 June 2021© Jacobsen HR6010 ROPS Installation Manual Standard Parts List: Description Bolt, Hex, 5/8” x 3”, Gr. 8, YD Nut, Flange, 5/8”, Gr. 8, YD Washer, Heavy, ¼” Flat Isolator (pre-installed) Bolt, Flange, M12 x 35, Gr. 10.9, YD Bolt, Flange, 3/8” x 1 ½”, Gr. 8, YD Nut, Flange, 3/8”, Gr.
- Page 5 June 2021© Jacobsen HR6010 ROPS Installation Manual Installation Instructions: 1. Un-bolt and remove the 2-post ROPS structure from the tractor. Use an over-head hoist to assist, ROPS is VERY heavy. Un-bolt and remove the front bull bar? 2. Take the left rear bracket and position into place where the left side of the 2-post structure was located.
- Page 6 June 2021© Jacobsen HR6010 ROPS Installation Manual 4. Take the left front bracket and position it against the front and left side of the operator foot platform. Use the provided 3/8” x 1 ½” flange bolts and nuts and loosely fasten into place. Re- install the rear bolt in the chassis from the front bar removal.
- Page 7 June 2021© Jacobsen HR6010 ROPS Installation Manual 9. Remove lift straps and lift bolts from ROPS. Optional Steering Console Mounted Turn Signal Lever: 10. Take the turn signal lever and hose clamp included and attach to steering wheel as shown.
- Page 8 June 2021© Jacobsen HR6010 ROPS Installation Manual 13. Take red power and black ground wires that are at the bottom of the right rear tube and route along the mounting bracket and into the engine bay. Connect the black ground wire to the negative post on the battery with 1/4"...
- Page 9 June 2021© Jacobsen HR6010 ROPS Operation Manual Jacobsen HR6010 ROPS * Shown with optional Golf Ball Mesh Package * Jacobsen HR6010 ROPS This ROPS is designed and built to fit the Jacobsen HR6010. Designed and Built by: Tektite Manufacturing Inc: 427 Buffalo Street P.O.
- Page 10 June 2021© Jacobsen HR6010 ROPS Operation Manual Tektite Manufacturing Incorporated thanks you for purchasing a Jacobsen HR6010 ROPS! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of ROPS protection.
- Page 11 June 2021© Jacobsen HR6010 ROPS Operation Manual Tektite Limited Warranty Tektite Manufacturing Inc. (“Tektite”) warrants to the original purchaser (the “Claimant”), that Tektite products will be free from defective materials or workmanship, under normal use and service, for a period of (1) full year from the original invoice date.
-
Page 12: Safety Precautions
June 2021© Jacobsen HR6010 ROPS Operation Manual Safety Precautions Safety First Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use the features that are on this cab/ROPS. - Page 13 June 2021© Jacobsen HR6010 ROPS Operation Manual General Safety 1. Never let an unqualified or untrained driver operate the utility vehicle. 2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be familiar with its use.
- Page 14 June 2021© Jacobsen HR6010 ROPS Operation Manual Safe Operation on Rough Terrain 1. Drive the utility vehicle slowly on hillsides and curves to eliminate the danger of tipping. Avoid slopes which are too steep for safe operation. Avoid sharp uphill turns.
- Page 15 June 2021© Jacobsen HR6010 ROPS Operation Manual 9. Use your turn signals, checking for traffic well in advance of turning. If the utility vehicle is not equipped with turn signals and law requires them, install them prior to operating on or near public roads.
- Page 16 June 2021© Jacobsen HR6010 ROPS Operation Manual Operating Instructions Important The following section locates, identifies and briefly describes the functions of all cab controls. All operators should familiarize themselves with control location and function prior to operating the tractor. Failure to do so may result in unsafe operation of the tractor and possible injury or death to operators and bystanders.
- Page 17 June 2021© Jacobsen HR6010 ROPS Operation Manual 4. Rear Work Light Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work light is on. 5. Beacon Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work lights are on.
- Page 18 June 2021© Jacobsen HR6010 ROPS Operation Manual After your ROPS has been installed: Before starting a utility vehicle equipped with a Tektite ROPS: 1. Clear the operator platform of all tools. Tools left in or around the ROPS and utility vehicle can cause operator interference which could lead to bodily injury and/or damage the machine.
- Page 19 Index Service Part # File Name Description A00-0135 HEAD-LIGHT Head Light A00-0136 RED_TAIL_FLASH Red Turn, Tail Light A00-0143 TURN_LIGHT Turn light, Amber JaHR6010-01 JA6010-ASM-03_ROPS Main 4-Post ROPS Tektite Manufacturing Inc. 24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada Req'd: CNC: Description:...
