CONNECTOR CONVERSION BOX
GT16H-CNB-42S
User's Manual
Manual Number JY997D40401E
Date April 2015
This manual describes the part names, dimensions, mounting, and specifications
of the product. Before use, read this manual and manuals of relevant products
fully to acquire proficiency in handling and operating the product. Make sure to
learn all the product information, safety information, and precautions.
And, store this manual in a safe place so that you can take it out and read it
whenever necessary. Always forward it to the end user.
Registration
Ethernet is a registered trademark of Xerox Corporation in the United States.
MODBUS is a trademark of Schneider Electric SA. The company name and the
product name to be described in this manual are the registered trademarks or
trademarks of each company.
Effective April 2015
Specifications are subject to change without notice.

2010 MITSUBISHI ELECTRIC CORPORATION
Safety Precaution
(Read these precautions before using.)
Before using this product, please read this manual and the relevant manuals
introduced in this manual carefully and pay full attention to safety to handle the
product correctly.
The precautions given in this manual are concerned with this product.
In this manual, the safety precautions are ranked as and
Indicates that incorrect handling may cause hazardous
conditions, resulting in death or severe injury.
Indicates that incorrect handling may cause hazardous
conditions, resulting in medium or slight personal injury or
physical damage.
Depending on circumstances, procedures indicated by
linked to serious results.
In any case, it is important to follow the directions for usage.
DESIGN PRECAUTIONS
 Some failures of the GOT or cable may keep the outputs on or off.
An external monitoring circuit should be provided to check for output signals
which may lead to a serious accident.
Not doing so can cause an accident due to false output or malfunction.
 If a communication fault (including cable disconnection) occurs during
monitoring on the GOT, communication between the GOT and PLC CPU is
suspended and the GOT becomes inoperative.
A system where the GOT is used should be configured to perform any
significant operation to the system by using the switches of a device other
than the GOT on the assumption that a GOT communication fault will occur.
Not doing so can cause an accident due to false output or malfunction.
 Do not use the GOT as the warning device that may cause a serious
accident. An independent and redundant hardware or mechanical interlock is
required to configure the device that displays and outputs serious warning.
Failure to observe this instruction may result in an accident due to incorrect
output or malfunction.
 Incorrect operation of the touch switch(s) may lead to a serious accident if the
GOT backlight is gone out. When the GOT backlight goes out, the POWER
LED flickers (green/orange) and the display section turns black and causes
the monitor screen to appear blank, while the input of the touch switch(s)
remains active. This may confuse an operator in thinking that the GOT is in
"screensaver" mode, who then tries to release the GOT from this mode by
touching the display section, which may cause a touch switch to operate.
Note that the following occurs on the GOT when the backlight goes out.
- The POWER LED flickers (green/orange) and the monitor screen appears
blank.
Side
B
DESIGN PRECAUTIONS
 Do not bundle the control and communication cables with main-circuit, power or
other wiring. Run the above cables separately from such wiring and keep them a
minimum of 100mm (3.94in.) apart.Not doing so noise can cause a malfunction.
MOUNTING PRECAUTIONS
 Make sure to turn off the Connector Conversion Box's power before attaching or
detaching it to/from the GOT.
Failure to do so may cause unit failure or malfunctions.
MOUNTING PRECAUTIONS
 Use the Connector Conversion Box within the generic environment specifications
described in this manual. If the product is used in such conditions, electric shock,
fire, malfunctions, deterioration or damage may occur.
WIRING PRECAUTIONS
 Be sure to shut off all phases of the external power supply used by the system
before wiring. Failure to do so may result in an electric shock, product damage or
malfunctions.
 Please make sure to ground FG terminal of the Connector Conversion Box power
supply section by applying 100 or less which is used exclusively for the GOT. Not
doing so may cause an electric shock or malfunction.
 Correctly wire the Connector Conversion Box power supply section after
confirming the rated voltage and terminal arrangement of the GOT. Not doing so
can cause a fire or failure.
 Exercise care to avoid foreign matter such as chips and wire offcuts entering the
GOT. Not doing so can cause a fire, failure or malfunction.
WIRING PRECAUTIONS
 Plug the communication cable into the connector of the connected unit and
tighten the mounting and terminal screws in the specified torque range.
Undertightening can cause a short circuit or malfunction. Overtightening can
.
cause a short circuit or malfunction due to the damage of the screws or unit.
TEST OPERATION
PRECAUTIONS
 Before performing the test operations of the user creation monitor screen (such as
turning ON or OFF bit device, changing the word device current value, changing
the settings or current values of the timer or counter, and changing the buffer
memory current value), read through the manual carefully and make yourself
may also be
familiar with the operation method. During test operation, never change the data
of the devices which are used to perform significant operation for the system.
False output or malfunction can cause an accident.
STARTUP/MAINTENANCE
PRECAUTIONS
 When power is on, do not touch the terminals.
Doing so can cause an electric shock or malfunction.
 Before starting cleaning or terminal screw retightening, always switch off the
power externally in all phases. Not switching the power off in all phases can cause
a unit failure or malfunction. Undertightening can cause a short circuit or
malfunction. Overtightening can cause a short circuit or malfunction due to the
damage of the screws or unit.
STARTUP/MAINTENANCE
PRECAUTIONS
 Do not disassemble or modify the unit.
Doing so can cause a failure, malfunction, injury or fire.
 Do not touch the conductive and electronic parts of the unit directly.
Doing so can cause a unit malfunction or failure.
 The cables connected to the unit must be run in ducts or clamped.
Not doing so can cause the unit or cable to be damaged due to the dangling,
motion or accidental pulling of the cables or can cause a malfunction due to a
cable connection fault.
 When unplugging the cable connected to the unit, do not hold and pull the cable
portion. Doing so can cause the unit or cable to be damaged or can cause a
malfunction due to a cable connection fault.
DISPOSAL PRECAUTIONS
 When disposing of the product, handle it as industrial waste.
TRANSPORTATION
PRECAUTIONS
 The Connector Conversion Box is a precision instrument. During transportation,
avoid impacts larger than those specified in this manual. Failure to do so may
cause failures in the unit. After transportation, verify the operations of the unit.
Certification of UL, cUL standards
UL, cUL Standards are recognized in use by the following combination.
 GT1665HS-VTBD (Hardware version F or later)
 GT16H-CNB-42S
 External cable (GT16H-C30-42P, GT16H-C60-42P, GT16H-C100-42P)
General notes on power supply
This equipment must be supplied by a UL Listed or Recognized 24 V dc rated
power supply and UL Listed or Recognized fuse rated not higher than 4A, or a UL
Listed Class 2 power supply.
Compliance with EC directive (CE Marking)
This note does not guarantee that an entire mechanical module produced in
accordance with the contents of this note will comply with the following standards.
Compliance to EMC directive for the entire mechanical module should be checked by
the user/manufacturer. For more details please contact the local Mitsubishi Electric
sales site.
Attention
 This product is designed for use in industrial applications.
 Authorized Representative in the European Community:
Mitsubishi Electric Europe B.V.
Gothaer Str. 8, 40880 Ratingen, Germany
Requirement for Compliance with EMC directive
The following products have shown compliance through direct testing (to the
identified standards) and design analysis (forming a technical construction file) to the
European Directive for Electromagnetic Compatibility (2004/108/EC) when used as
directed by the appropriate documentation.
Type: Programmable Controller (Open Type Equipment)
Standard Remark
Compliance with all relevant aspects of the
EMI
standard. (Radiated Emissions)
EN61131-2 : 2007
P r o g r a m m a b l e
Compliance with all relevant aspects of the
controllers- Equipment,
standard. (ESD, RF electromagnetic field, EFTB,
EMS
requirement and tests
Surge, RF conducted disturbances and Power
frequency magnetic field)
For more details please contact the local Mitsubishi Electric sales site.
Notes for compliance to EMC regulation
1) General notes on the control panel
Make sure to combine the GT16 Handy GOT with the Connector Conversion
Box to comply with the EMC directive. The Connector Conversion Box is an
open type device (device installed to another device) and must be installed in a
conductive control panel.
2) General notes on the use of communication cables
 External cable (GT16H-C30-42P, GT16H-C60-42P, GT16H-C100-42P)
 Direct connection cable
Existing Cables User Made Cables
The cable need to be independently tested by the user to
GT01-C30R4-8P demonstrate EMC compatibility when they are used with
GT11H-C30R2-6P the GOT, the PLC of MELSEC-Q series, MELSEC-L series,
MELSEC-QnA, MELSEC-A series and MELSEC-FX series.
 Ethernet connection cable (Shielded twisted pair cable (STP))
 PLC (manufactured by other company), microcomputer, temperature
controller, inverter, servo amplifier, CNC, MODBUS(R)/RTU or MODBUS(R)/
TCP connection
Produce the cable (RS-232 cable, RS-422 / 485 cable) for connecting the GOT
to a controller with reference to the following manual.
 GOT1000 Series Connection Manual for GT Works3 and a controller used
3) General notes on Power supply
The Connector Conversion Box requires an
additional ferrite filter to be attached to the
24V DC power supply cables. The filter
should be attached in a similar manner as
shown in the figure opposite, i.e. the power
Up to 75mm
c a b l e s a r e w r a p p e d a r o u n d t h e f i l t e r.
(2.95inch)
However, as with all EMC situations the more
correctly applied precautions the better the
systems Electro-magnetic Compatibility. The
ferrite recommended is a TDK ZCAT3035-
1330 or similar. The ferrite should be placed
as near to the 24V DC terminals of the
Connector Conversion Box as possible (which
should be within 75mm of the GOT terminal).
Associated Manuals
The following manuals are relevant to this product. When these loose manuals are
required, please consult with our local distributor.
Manual Number
Manual name Contents
(Model Code)
G T 1 6 H a n d y
G O T U s e r ' s Describes the Handy GOT hardware-
JY997D41201
Manual relevant content such as part names,
(Hardware/Utility, external dimensions, mounting, power JY997D41202
Connection) s u p p l y w i r i n g , s p e c i f i c a t i o n s , a n d
1/2, 2/2 introduction to option devices
(sold separately)
For details of a PLC to be connected, refer to the PLC user's manual respectively.
Bundled Items
Bundled item
GT16H-CNB-42S Connector conversion box
Packing for panel installation
Flange for GT10-9PT5S
Screws for flange installation (M3×8)
CONNECTOR CONVERSION BOX GT16H-CNB-42S User's
Manual (This manual)
1. Features
The Connector Conversion Box relays the GOT's external 42-pin connector to the
power supply/switch and the PLC's connector and terminal block, while enabling
users to operate the Handy GOT outside the enclosure.
Handy GOT
Control panel or
operation panel
GT16H-CNB-42S
Connector Conversion Box PLC
External cable
GT16H-C -42P
(Option)
2. Specifications
General Specifications
Other specifications are the same as the GT16 Handy GOT main unit.
Item Specifications
Operating
ambient 0 to 55C
temperature
Storage
ambient -20 to 70C
temperature
Half-
Frequency Acceleration
amplitude
 When
Vibration
5 to 9Hz -- 1.75mm
installing
resistance
DIN rail
2
9 to 150Hz 4.9m/s --
Must be free of lamp black, corrosive gas, flammable gas, or
Operating
excessive amount of electroconductive dust particles and must be no
atmosphere
direct sunlight. (Same as for saving)
(09R821)
Quantity
1
1
1
2
1
Sweep
Count
10 times
each in X, Y
and Z
directions
