Document 6434005-02, Ver. 2, Rel. 0, August 2002

Unpacking Instructions

Floor Space .....................................................................................................4
Floor Clearance ..............................................................................................5
Floor Strength and Inclination.....................................................................5
Power and Grounding ..................................................................................5
Environmental Conditions...........................................................................6
Providing Necessary Tools and Equipment..............................................6
Taking ESD Precautions ...............................................................................6
Receiving the Library....................................................................................8
Unboxing the Library ...................................................................................8
Positioning the Library ...............................................................................14
Unpacking the Library................................................................................18
Storing the Shipping Materials..................................................................23
Leveling the Library....................................................................................24
Quantum ATL P4000
3
4
6
7
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P4000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Quantum P4000

Summary of Contents for Quantum P4000

  • Page 1: Table Of Contents

    Taking ESD Precautions ...6 Unpacking the Library Receiving the Library...8 Unboxing the Library ...8 Positioning the Library ...14 Unpacking the Library...18 Storing the Shipping Materials...23 Leveling the Library...24 Document 6434005-02, Ver. 2, Rel. 0, August 2002 Quantum ATL P4000 Unpacking Instructions...
  • Page 2 Quantum ATL 4000 Library Unpacking Instructions Document 6434005-02, Ver. 2, Rel. 0 August 2002 6207947-04fN 13...

  • Page 3: Introduction

    This document explains how to unpack the ATL P4000. Once the library is unpacked and moved to the desired installation location, set up the library using the instructions in the ATL P4000 and ATL P7000 User’s Guide (PN 6434003). Figure 1 ATL P4000 Library...

  • Page 4: Selecting An Installation Location

    • Floor space • Floor clearance • Floor strength and inclination • Power and grounding • Environmental conditions These requirements are also described in the ATL P4000 and ATL P7000 User’s Guide (PN 6434003). Figure 2 Floor Space Figure 2 Floor Space Requirements shows the minimum floor space required by the ATL P4000.

  • Page 5: Floor Strength And Inclination

    Figure 4 Wall Outlet The dedicated wall outlet and a 20 amp circuit breaker must provide power to the ATL P4000 library only. Outside North America, replace the supplied power cord with a harmonized 3 x 1.5 mm that is approved by the country where used, and install the appropriate wall outlet.

  • Page 6: Environmental Conditions

    To avoid damaging these parts while performing installation procedures, always observe the following precautions: For additional library specifications (including Note: environmental requirements during shipping and storage), see appendix A in the ATL P4000 and ATL P7000 User’s Guide (PN 6434003). Preparing for the Installation...

  • Page 7: Unpacking The Library

    Unpacking the Library This section explains how to unpack the library and move it to its final installation location. The ATL P4000 is shipped in packing materials designed to protect it from damage during transit. By following these instructions, you help ensure that the library will continue to be safeguarded after it arrives at the installation site.
  • Page 8 13.5 lbs. It is strongly advised to use at least two people to move and install the library. Choose the unloading side. The ATL P4000 may be unloaded from either the right or left side of the pallet. Verify the minimum floor space requirements.
  • Page 9 Space Requirements— Uncrating Site 3 ft (91 cm) 9 ft (2.74 m) for ramp extensions Quantum ATL 4000 Library Unpacking Instructions 3 ft (91 cm) 3 ft ( 91 cm) Cut the two steel bands that secure the library and packing...
  • Page 10 Quantum ATL 4000 Library Unpacking Instructions Document 6434005-02, Ver. 2, Rel. 0 August 2002 Figure 6 Removing the Steel Bands Figure 7 Removing the Box Top Cover Lift the cardboard box top cover straight up and off of the pallet...
  • Page 11 Figure 8 Removing the Cardboard Box Quantum ATL 4000 Library Unpacking Instructions Pull the eight cardboard box retaining clips to their open position. Unwrap the cardboard box from the library (see Remove the accessory kit from the rear compartment of the crate.
  • Page 12 Quantum ATL 4000 Library Unpacking Instructions Document 6434005-02, Ver. 2, Rel. 0 August 2002 Figure 9 Removing the Foam Cap Figure 10 Removing the Wooden Bar On the right side of the library, lift the wooden bar out of its...
  • Page 13 Figure 11 Removing the Stop Blocks Quantum ATL 4000 Library Unpacking Instructions On the right side of the library, unscrew the bolts that secure the hold-down brackets. Each hold-down bracket is secured with two bolts . Remove each hold-down bracket from under the library (see figure 11), using the supplied wrench.
  • Page 14 Quantum ATL 4000 Library Unpacking Instructions Document 6434005-02, Ver. 2, Rel. 0 August 2002 Figure 12 Removing the Ramp Extensions To position the library: Positioning the Library Place the ramp extensions aside until the library is ready to be positioned.
  • Page 15 Figure 13 Removing the Shipping Bag Quantum ATL 4000 Library Unpacking Instructions Inspect the library for any damage that may have occurred during shipment. The ramp may be set up on either the right side or the Note: left side of the pallet. The following illustrations show the ramp set-up procedure when the right side of the library is used.
  • Page 16 Quantum ATL 4000 Library Unpacking Instructions Document 6434005-02, Ver. 2, Rel. 0 August 2002 Figure 14 Preparing the Ramp Figure 15 Raising the Leveling Feet Verify that the library’s four leveling feet are raised. If not, raise each foot as needed as by turning the leveling foot until it is 1/2...
  • Page 17 Figure 16 Moving the Wooden Bar Quantum ATL 4000 Library Unpacking Instructions Move the wooden bar: Remove the wooden bar from the ramp-side of the pallet. Turn the bar over and place it under the ramp extensions for support (see figure 16).
  • Page 18 Quantum ATL 4000 Library Unpacking Instructions Document 6434005-02, Ver. 2, Rel. 0 August 2002 Figure 17 Rolling the Library Down the Ramp To unpack the library: Unpacking the Library Using the power cable from the accessory kits, connect the library to a grounded power source.
  • Page 19 Load Port Shipping Plate Figure 19 Locating the Vertical Carriage Assembly Quantum ATL 4000 Library Unpacking Instructions Remove the shipping plate that protects the load port: Unscrew and remove the bolts and washers securing the plate to the load port (see figure Remove the shipping plate from the load port.
  • Page 20 Quantum ATL 4000 Library Unpacking Instructions Document 6434005-02, Ver. 2, Rel. 0 August 2002 Figure 20 Removing the Horizontal Carriage Restraint Gripper assembly Extension axis assembly Remove the horizontal carriage restraint (see Remove the two screws that secure the horizontal carriage restraint to the horizontal carriage.
  • Page 21 Gripper Restraint Sprint post Gripper restraint Follower guide Quantum ATL 4000 Library Unpacking Instructions Gripper restraint Slide the gripper assembly away from the vertical axis until the gripper assembly is fully extended and the gripper restraint disengages from the follower guide (see...
  • Page 22 Quantum ATL 4000 Library Unpacking Instructions Document 6434005-02, Ver. 2, Rel. 0 August 2002 Figure 23 Removing the Gripper Restraint Gripper assembly (fully extended) Remove the gripper restraint by gently pulling it back toward the vertical axis. Slide the gripper assembly toward the vertical axis.

  • Page 23: Storing The Shipping Materials

    To store the shipping and packaging materials for future use: Storing the Shipping Materials Quantum ATL 4000 Library Unpacking Instructions Use the screws removed in steps 6, 8, and restraints to the inside of the library (see The profile of each shipping restraint is clearly outlined Note: on the storage label.

  • Page 24: Leveling The Library

    Quantum ATL 4000 Library Unpacking Instructions Document 6434005-02, Ver. 2, Rel. 0 August 2002 Figure 25 Storing the Shipping Restraints To level the library: Leveling the Library Slide the two ramp extensions into their shipping position on top of the pallet.
  • Page 25 Quantum ATL 4000 Library Unpacking Instructions Determine which side of the library is low. Adjust the leveling foot on the low side of the library by rotating the leveling foot with the open-end wrench. Repeat step 4 until the front is level.
  • Page 26 Quantum ATL 4000 Library Unpacking Instructions Document 6434005-02, Ver. 2, Rel. 0 August 2002 Unpacking the Library...
