Summary of Contents for Zotac ZBOX
- Page 2 ZOTAC. Products and corporate names mentioned in this manual may not be registered trademarks or copyrights of their respective companies, and are used for identification purposes only.
-
Page 3: Table Of Contents
Setting up your system ----------------------------------------------------------------------- 4 Care during use -------------------------------------------------------------------------------- 4 Welcome --------------------------------------------------------------------------------------------- 5 Package contents ------------------------------------------------------------------------------ 5 Getting to know your ZOTAC ZBOX -------------------------------------------------------- 6 Front view ---------------------------------------------------------------------------------------- 6 Rear view----------------------------------------------------------------------------------------- 7 Customizing ZOTAC ZBOX -------------------------------------------------------------------- 8 Installing a memory module ----------------------------------------------------------------- 8... -
Page 4: Product Specifications
ZOTAC ZBOX Product Specifications q Chipset v Intel ® NM70 q Product Dimensions v 188mm x 188mm x 44mm q Onboard CPU v Intel ® 1007U (dual core, 1.5GHz) q Onboard graphics v Intel ® HD Graphics Family v HDMI & DVI-I output... -
Page 5: Safety Information
ZOTAC ZBOX Safety information Your ZOTAC ZBOX is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system Read and follow all instructions in the documentation before you operate your system. -
Page 6: Welcome
ZOTAC ZBOX Welcome Congratulations on your purchase of the ZOTAC ZBOX mini-PC. The following illustration displays the package contents of your new ZOTAC ZBOX. Please contact your retailer If any of the below items are damaged or missed. Package contents •... -
Page 7: Getting To Know Your Zotac Zbox
ZOTAC ZBOX Getting to know your ZOTAC ZBOX Front view Refer to the diagram above to identify the components on this side of the system 1. Headphone/Audio Out jack The stereo headphone jack (3.5mm) is used to connect the system’s audio out signal to amplified speakers or headphones. -
Page 8: Rear View
ZOTAC ZBOX Rear view Refer to the diagram above to identify the components on this side of the system. 1. eSATA port The external SATA port is compatible with e.SATA devices such as external hard drives and Blu-ray drives. 2. USB 3.0 ports The USB 3.0 port supports the SuperSpeed USB 3.0 devices and is backwards... -
Page 9: Customizing Zotac Zbox
ZOTAC ZBOX Customizing the ZOTAC ZBOX Before installing hardware, please follow the instructions below to remove the cover of your ZOTAC ZBOX. 1. Unscrew. 2. Gently remove the cover as the image below. Installing a memory module 1. Locate the SO-DIMM memory slots and insert a SO-DIMM memory module into the slot at a 45 degree angle. -
Page 10: Removing The Memory Module
2. Gently press down on the memory module until it locks into place by the arms of the memory slot. Note: This ZOTAC ZBOX accomodates two DDR3 SO-DIMM memory modules. You must install at least one module in one of the two slots. -
Page 11: Installing A Hard Disk
ZOTAC ZBOX Installing a hard disk 1. Locate the hard disk bracket and remove the thumb screw. 2. Lift up on the plastic flap. 3. Insert a 2.5-inch SATA hard disk into the bracket at a 45 degree angle and gently slide into the connector. -
Page 12: Setting Up Your Zotac Zbox
Connect the supplied AC adapter to the DC IN jack on the system rear panel and then press the power switch on the front panel to turn on the system. Note: When your ZOTAC ZBOX is not in use, unplug the power adapter or switch off the AC outlet to conserve power. -
Page 13: Positioning Your Zotac Zbox
ZOTAC ZBOX Positioning your ZOTAC ZBOX • Do not position the ZOTAC ZBOX where the ventilation holes are covered. To guarantee proper use, leave 4 inches (10 cm) of spacing in front of the ventilation holes. • ZOTAC ZBOX mini-PC systems provide ample connectivity in a tiny form factor, please choose connectors and cables in appropriate sizes to avoid interference. -
Page 14: Installing Drivers And Software
OS installation source drive connection. Installing system drivers Before you can use the full features of the ZOTAC ZBOX, the system drivers must be installed. The following types of operating systems are supported by the ZOTAC ZBOX driver DVD: •... -
Page 15: Using Your Zotac Zbox
Select the driver you want to install. The driver installer should launch. Follow the onscreen instructions for the selected driver to install. Restart the system. Using your ZOTAC ZBOX Configuring wired connection Using a static IP Right-click the network icon in the notification area and select “Open... -
Page 16: Using A Dynamic Ip (Pppoe Connection)
Note: Contact your internet Service Provider (ISP) if you have problems connecting to the network. Configuring audio output via an HDMI device Follow the steps below to enable audio output via HDMI when connecting the ZOTAC ZBOX to a TV or receiver via HDMI. Access the Sound settings via the system Control Panel. - Page 17 ZOTAC ZBOX 291-MB211-00...
