iSR6200 Enterprise-class Connectivity, Routing and Services
Interface Specification
Interfaces per router blade. The iSR6200 can
support one or two installed blades.
Gigabit Ethernet
• Two ports: copper 1000 BaseT, RJ45
• Full duplex, auto negotiating 100/1000 Mbps
Fibre Channel
• Two optical ports, full duplex
• Auto negotiation : 8/4/2 Gbps
• N_ports, NL_ports, F_ports, FL_ports
• Class 2, 3 connectionless
Management Ports
• Ethernet 10/100 BaseT with RJ45
• RS-232 serial port with RJ45
Expansion Configurations
One expansion card per router blade adds ports to
the system
• 2 x 1Gb Ethernet module
• 2 x 10Gb Ethernet module
• 2 x 10Gb Fibre Channel over Ethernet (FCoE)*
• 2 x 20Gb Infiniband DDR*
Performance Features
Maximum Data Rates
• iSCSI: 2.6-Gbps aggregate (1.3 Gb per blade)
• FC: 12.8-Gbps aggregate (6.4Gb per blade)
Input/output Operations per Second (IOPS)
• 200K IOPS aggregate (100K per blade)
VLAN Support
• Up to 4 VLANs per 10GbE port
ISCSI Host Support
• 2,048 iSCSI Hosts (1,024 per router blade)
WAN Device Support
• 252 WWNNs (63 per FC port)
• Simultaneous target and initiator mode for FC
ports
Supported SFP Types
• Shortwave (optical)
• Longwave (optical)
Interoperability
• Compatible with FC-SW-2 complaint switches
• Management interoperability with leading SAN
management applications
*Future product release
Corporate Headquarters
Europe Headquarters
© 2008 QLogic Corporation. Specifications are subject to change without notice. All rights reserved worldwide. QLogic and the QLogic logo are registered trademarks and SmartWrite and TrueFlex are trademarks of QLogic Corporation. All other brand and product
names are trademarks or registered trademarks of their respective owners. Information supplied by QLogic Corporation is believed to be accurate and reliable. QLogic Corporation assumes no responsibility for any errors in this brochure. QLogic Corporation reserves
the right, without notice, to make changes in product design or specifications.
iSCSI Initiator Support
• Microsoft: Windows 2000/2003/2008
• Solaris: SPARC 2.6, 8, 9, 10: X86
• Linux: Red Hat AS 3, 4, 5; SuSE Enterprise Server
8, 9, 10
• VMware: ESX Server v3.0.x, v3.5x
• AIX: AIXL 5
• HP-UX: versions 9, 10
• QLogic: 4010, 4050, 4052, 4060, 4062
• Apple: OS-X (via ATTO driver)
Device Management
Management Methods
• Wizard-based configuration tools
• Command line interface (CLI)
• SNMP and SMI-S*
Access Methods
• Dedicated out-of-band Ethernet 10/100BaseT,
RJ45
Diagnostics
• Power-on self-test (POST) of all functions except
media modules
User Interface
• LED front panel indicators, CLI, and browser
utilities
Mechanical
Enclosure Type
• 1U, full rack width
Dimensions
• Width: 431.8mm (17.00")
• Height: 43.7mm (1.72")
• Depth: 631.4mm (24.9")
Power Supply
• 235W maximum (2 blades & 2 Exp cards)
• 106W typical (1 Blade, 2 power modules)
• 100 VAC to 240 VAC; 50 Hz to 60 Hz
• 1.9A at 100–125 VAC; 1.02A at 200-240VAC
• Dual, redundant, hot-swap power supplies
Cooling
• Six redundant fans with back-to-front airflow
High Availability
• Hot-swap router blades and power supplies
• Router blade persistence: all zoning and
addressing maintained in non-volatile memory.
• Fan modules powered by both power supplies.
QLogic Corporation 26650 Aliso Viejo Parkway
QLogic (UK) LTD. Quatro House Lyon Way, Frimley
SN0058070-00 A
D A T A S H E E T
Data Migration
Host/Application Status
• Online or offline migration
Transport Protocols
• Any-to-any protocol for: Fibre Channel, ISCSI,
FCoE, and InfiniBand
Storage Topology
• Local
• Remote (license upgrade)
Performance
• Up to 10TB per hour (5TB/hr per blade)
Protocols
• SmartWrite II for WAN accelleration
• iSCSI to FCP
• FCIP
• CHAP security and authentication
• IPv6 and IPv4
Environmental/Safety
Operating
• Temperature: +5C to +40C (41F to 104F)
• Humidity: 5% to 90% non-condensing
• Altitude: 0 to +10,000 ft
• Vibration: IEC 68-2, 5-500Hz, random, 0.21G
rms, 10 minutes
• Shock: IEC 68-2, 4g, 11ms, 20 repetitions
Non-operating
• Temperature: -40C to +70C (-40F to158F)
• Humidity: 5% to 93% non-condensing
• Altitude: 0 to +50,000 ft
• Vibration: IEC 68-2, 5-500Hz, random, 2.09G
rms, 10 minutes
• Shock: IEC 68-3, 30g, 292 ips, 3 repetitions, 3
axis
Agencies
• Safety Standards: UL 60950 (USA), CSA 2.2 No.
60950 (Canada), EN 60950 (EC), CB Scheme-IEC
60950, FCC Class A, Industry Canada IECS-003
Class-A, CISPR22:1997 (3rd Edition, Class –A
International), VVCI Approval to V.3 (Japan), ACA
Ctick Approval to AS/NZS 3548 (Australia / New
Zealand), RPL Certification (Korea), Class 1 Laser
Product per DHHS 21CFR(J) and IEC 680825
• Environmental: RoHS, WEEE
• Harmonics: EN 61000-3-2
• Immunity: EN 55024:1998, EN55022:1998
Aliso Viejo, CA 92656 949.389.6000
Camberley Surrey, GU16 7ER UK
