- Page 1 NI-9211...
- Page 2 Re-Verification ......................... 6 Accuracy Under Calibration Conditions .................. 6 Where to Go for Support ......................7 Software Calibrating the NI 9211 requires the installation of NI-DAQmx 9.2 or later on the calibration system. You can download NI-DAQmx from . NI-DAQmx supports ni.com/downloads ™...
- Page 3 Documentation Consult the following documents for information about the NI 9211, NI-DAQmx, and your application software. All documents are available on and help files install with the ni.com software. NI cDAQ-9174/9178 Quick Start NI-DAQmx installation and hardware setup NI 9211 Operating Instructions and Specifications...
- Page 4 Attach the other end of the wire to the system safety ground. Install the module in slot 8 of the NI cDAQ-9178 chassis. Leave slots 1 through 7 of the NI cDAQ-9178 chassis empty. Connect the NI cDAQ-9178 chassis to your host computer.
- Page 5 Accuracy Verification Complete the following procedure to determine the As-Found status of the NI 9211. Set the calibrator to Standby mode (STBY). Connect the NI 9211 to the calibrator as shown in Figure 1. Figure 1. Accuracy Verification Connections TC0+ TC0–...
- Page 6 The following performance adjustment procedure describes the sequence of operation required to adjust the NI 9211. Accuracy Adjustment Complete the following procedure to adjust the accuracy performance of the NI 9211. Set the calibrator to Standby mode (STBY). Connect the NI 9211 to the calibrator as shown in Figure 1.
- Page 7 EEPROM Update When an adjustment procedure is completed, the NI 9211 internal calibration memory (EEPROM) is immediately updated. If you do not want to perform an adjustment, you can update the calibration date and onboard calibration temperature without making any adjustments by initializing an external calibration, setting the C Series calibration temperature, and closing the external calibration.
- Page 8 Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for more information on National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the...
