Graco Mark IV HD Operation, Parts

Electric airless sprayers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operation, Parts
695 / 795 / 1095 / 1595 / Mark IV HD/ Mark V
HD/ Mark VII HD/ Mark X HD Electric Airless
Sprayers
For professional use only. Not approved for use in explosive atmospheres or
hazardous locations. For portable airless spraying of architectural paints and
coatings.
Models: 695 / 795 / 1095 / 1595 / Mark IV HD/ Mark V HD/ Mark VII HD/ Mark X HD
3300 psi (228 bar, 22.8 MPa) Maximum Working Pressure
See page 4 for additional model information.
Important Safety Instructions
Read all warnings and instructions in this manual and in Related Manuals listed on
page 2 before using the equipment. Be familiar with the controls and the proper usage
of the equipment. Save all instructions.
Use only genuine Graco replacement parts.
The use of non-Graco replacement parts may void warranty.
3A6342F
EN

Advertisement

Table of Contents
loading

Related Manuals for Graco Mark IV HD

Summary of Contents for Graco Mark IV HD

  • Page 1 For portable airless spraying of architectural paints and coatings. Models: 695 / 795 / 1095 / 1595 / Mark IV HD/ Mark V HD/ Mark VII HD/ Mark X HD 3300 psi (228 bar, 22.8 MPa) Maximum Working Pressure See page 4 for additional model information.

  • Page 2: Before You Spray

    Important! Read carefully and practice good safety habits. Related Manuals 3A6285 Contractor PC Spray Gun 311254 Flex Plus Spray Gun 309495 Heavy-Duty InLine Spray Gun 308491 Heavy-Duty Texture Spray Gun Manuals can also be found at www.graco.com 3A6584 Displacement Pump ProConnect™ Displacement 3A6583 Pump 3A6342F...

  • Page 3: Table Of Contents

    695/795/Mark IV HD ProContractor Parts ........58...

  • Page 4: Models

    Models Models 695 Models Standard ProContractor Hi-Boy Standard Lo-Boy Voltage Model Ultra Max II 695 17E572 17E574 17E577 Ultimate MX II 695 826222 826223 826224 NEMA 5-15 230 CEE 7/7 Ultra Max II 695 17E632 17E635 230 Europe Multi Ultra Max II 695 17E633 17E636 110 UK...
  • Page 5 Models 1095 Models Standard ProContractor Hi-Boy IronMan Voltage Model Ultra Max II 1095 17E583 17E585 17E586 Ultimate MX II 1095 826227 826228 826229 NEMA 5-15 230 CEE 7/7 Ultra Max II 1095 17E646 17E647 17E650 230 Europe Multi Ultra Max II 1095 17E648 230 ANZ/KR Ultra Max II 1095...
  • Page 6 Models Mark HD Models Standard Hi-Boy ProContractor IronMan Voltage Model Mark IV HD 17E603 17E604 NEMA 5-15 Mark V HD 17E628 NEMA 5-20 Mark V HD 17E605 17E606 17E607 NEMA 5-15 Mark X HD 17E608 17E609 NEMA L6-30 Mark IV HD...

  • Page 7: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings.
  • Page 8 Hose assembly, Spray Gun, and objects in and around the spray area shall be properly grounded to protect against static discharge and sparks. Use Graco conductive or grounded high-pressure airless paint sprayer hoses.
  • Page 9 Check hoses and parts for signs of damage. Replace any damaged hoses or parts. • This system is capable of producing 3000 psi (207 bar, 20.7 MPa). Use Graco replacement parts or accessories that are rated a minimum of 3000 psi (207 bar, 20.7 MPa).
  • Page 10 Warnings MOVING PARTS HAZARD Moving parts can pinch, cut, or amputate fingers and other body parts. • Keep clear of moving parts. • Do not operate equipment with protective guards or covers removed. • Equipment can start without warning. Before checking, moving, or servicing equipment, follow the Pressure Relief Procedure and disconnect all power sources.

  • Page 11: Know Your Sprayer

    Know Your Sprayer Know Your Sprayer 695 / 795 / 1095 / 1595 / Mark IV HD/ Mark V HD/ Mark VII HD/ Mark X HD Standard Models: Suction Tube ON/OFF Switch Inlet Strainer Pressure Control Knob Drain Tube Prime / Spray Valve...
  • Page 12 Know Your Sprayer 695 / 795 / 1095 / 1595 Mark IV HD/ Mark V HD/ Mark VII HD/ Mark X HD ProContractor Models: Suction Tube LED Display (not included on all units) Inlet Strainer ON/OFF Switch Drain Tube Pressure Control Knob...
  • Page 13 Know Your Sprayer 1095 / 1595 / Mark V HD IronMan Models: Inlet Strainer LED Display (not included on all units) Drain Tube ON/OFF Switch M Hose Pressure Control Knob Whip Hose (not included on all models) Prime / Spray Valve Pressure Gauge (not included on all units) Spray Gun Amp Switch (not equipped on all units)

  • Page 14: Know Your Controls

    Know Your Controls Know Your Controls The ON/OFF power switch controls the power to your sprayer. The Pressure Control Knob increases or decreases the pressure. It also has a setting for Prime/Slow and FastFlush™. PRIME/SPRAY The Prime/Spray Valve directs the fluid to either the Drain Tube or the Hose and Spray Gun.

  • Page 15: Setup

    Assemble Your Sprayer When unpacking sprayer for the first time or after long term storage perform setup Fill throat packing nut with Graco TSL™ procedure. to prevent premature packing wear. Do All sprayers except ProContractor: this each time you spray.

  • Page 16: Quikreel

    Setup QuikReel™ Pull reel handle down and out. Turn clockwise to reel in Hose. (ProContractor models only) Moving parts can pinch, cut or amputate fingers and other body parts. To avoid injury from moving parts, be sure to keep your head clear of QuikReel while winding up Hose.

  • Page 17: Grounding

    Setup Grounding Extension Cords Use an extension cord with an undamaged ground contact. If an extension cord is necessary, use a 3-wire, 12 AWG (2.5 mm minimum. The equipment must be grounded to NOTE: Smaller gauge or longer extension reduce the risk of static sparking and cords may reduce sprayer performance.

  • Page 18: Start Up

    Start Up Start Up Pressure Relief Procedure Follow the Pressure Relief Procedure whenever you see this symbol. Put Drain Tube into a waste pail and This equipment stays pressurized until turn Prime/Spray Valve down to PRIME pressure is manually relieved. To help position to relieve pressure.

  • Page 19: 10/16 Amp Switch

    Start Up 15/20 Amp Switch If you suspect the spray tip or Hose is clogged or that pressure has not been (120V 1595 and Mark V units) fully relieved: VERY SLOWLY loosen the tip guard retaining nut or the Hose end coupling to relieve pressure gradually.

  • Page 20: Strain The Paint

    Start Up Make certain Prime/Spray Valve is 10. Turn the ON/OFF switch to OFF down in the PRIME position. position. Strain the Paint Make certain the Pressure Control Disposable paint strainer bags are used to Knob is set to OFF (all the way remove coarse particles and debris from counterclockwise).

  • Page 21: Fill Pump (Prime Pump)

    Start Up Fill Pump (Prime Pump) Fill Spray Gun and Hose The Prime/Spray Valve directs the fluid to Remove Spray Tip Guard. either the Drain Tube or the Hose and Spray Gun. It is used to prime the sprayer, which means to evacuate the air out of the pump, Hose, and Spray Gun.

  • Page 22: Refilling Paint Pail

    Start Up Continue to trigger Spray Gun into Install Spray Tip Guard. Rotate Spray waste pail until only paint comes out of Tip back to SPRAY position and ensure the Spray Gun. the Spray Tip Guard is tight. Release trigger. Engage Trigger Lock. Spray High-pressure spray is able to inject toxins into the body and cause serious bodily...

  • Page 23: Spraying

    Spraying Spraying Spray Pattern Quality A good spray pattern is evenly distributed as it hits the surface. • Spray should be atomized (evenly distributed, no gaps at edges). • Increase Pressure Control Knob if needed until spray is even and without Start gaps at edges.
  • Page 24 Spraying Spray Techniques Triggering Spray Gun Pull trigger after starting stroke. Release Use a piece of scrap cardboard to practice trigger before end of stroke. Spray Gun must these basic spraying techniques before you be moving when trigger is pulled and begin spraying the surface.
  • Page 25 Spraying Clear Spray Tip Clog Engage Trigger Lock. Rotate Spray Tip back to SPRAY position. Disengage Trigger Lock and continue spraying. SPRAY In the event that particles or debris clog the Spray Tip, the Spray Tip can be reversed to quickly and easily clear particles without disassembling the sprayer.

  • Page 26: Cleanup

    Cleanup Cleanup Place Suction Tube in appropriate flushing fluid. Place Drain Tube in waste pail. Perform Pressure Relief Procedure, page 18. Remove Spray Tip Guard and Spray Tip. For additional information, see separate Spray Gun manual. To flush Drain Tube and pump turn Prime/Spray Valve down to PRIME position.
  • Page 27 Cleanup Clean Hose and Spray Gun 12. Remove Suction Tube from flushing fluid so that air can enter the pump and push Hold Spray Gun against a grounded flushing fluid out of the Hose and Spray metal waste pail. Point Spray Gun into Gun.
  • Page 28 Cleanup 15. Turn Pressure Control Knob to OFF and NOTE: If flushing with water, flush again with turn ON/OFF switch to OFF position. mineral spirits or Pump Armor™ to leave a Disconnect power to sprayer. protective coating to prevent freezing or corrosion for longterm storage.

  • Page 29: Watchdog

    HIGH sensitivity when detecting if the sprayer has run out of paint. By default, WatchDog sensitivity is set to MEDIUM. WatchDog sensitivity can be adjusted using the Graco BlueLink app or by using the LED Display, as described above. 3A6342F...

  • Page 30: Bluelink™ App

    BlueLink™ App BlueLink™ App Download the Graco BlueLink app from the Turn the ON/OFF switch to the OFF Apple App Store, Google Play, or other position. Turn the Pressure Control available application stores to connect to the Knob all the way counterclockwise to the ®...
  • Page 31 BlueLink™ App Replacing BlueLink Battery In order to keep your sprayer synced, your Remove black battery cover with a unit has a small battery built-in. If you receive philips screwdriver. the following message, the battery will need to be replaced. Slide battery out of the holder, to the left.

  • Page 32: Led Display

    LED Display LED Display (not included on all models) Operation Main Menu Change Display Units Short press DISPLAY button to move to Press and hold the DISPLAY button for next display. Press and hold to change 5 seconds to change pressure units units or reset data.
  • Page 33 LED Display Job Gallons Turn power switch on while holding DISPLAY button down. Short press DISPLAY button to move to Job Gallons (or liters x 10). SERIAL NUMBER scrolls past on the display. 2. Press and hold the DISPLAY button to reset to zero. Short press DISPLAY button to move to MOTOR HOURS.
  • Page 34 LED Display Press and hold DISPLAY button 11. Short press DISPLAY button to move to clear code. NO CODE STORED will to Pressure Control Knob Calibration. be displayed after clearing the code KNOB displays. If you wish to calibrate the Pressure Control Knob, follow the procedure below.

  • Page 35: Maintenance

    100 gallons of additional operation before a repacking is required. Packing nut can be tightened without 0-ring removal. Maintenance can be scheduled and tracked via the Graco BlueLink app. See Maintenance, page 35, for more information. Recycling and Disposal at End of Life Dismantle and recycle: At the end of the product’s useful life,...

  • Page 36: Troubleshooting

    Troubleshooting Troubleshooting Mechanical/Fluid Flow Perform Pressure Relief Procedure, Solutions listed at the beginning of each page 18, before checking or repairing. problem are the most common. Problem Cause Solution There is a blockage in the VERY SLOWLY loosen the Hose connection to the Spray Gun and pump Hose or Spray Gun.
  • Page 37 Troubleshooting Problem Cause Solution Pump throat packings are Tighten packing nut/wet cup. If leakage Pump output is low worn. continues, replace packings; see pump (continued) manual. Also check piston valve seat for hardened paint or nicks and replace if necessary. Tighten packing nut/wet-cup. Intake valve ball is packed Clean intake valve;...
  • Page 38 Troubleshooting Electrical Turn pressure control knob clockwise 1/2 turn. Observe BlueLink status light to diag- nose and resolve error codes in the fol- lowing Troubleshooting chart. Keep clear of electrical and moving parts during troubleshooting procedures. To avoid electrical shock hazards when covers are removed for troubleshooting, wait 5 minutes after unplugging power cord for stored electricity to dissipate.
  • Page 39 Troubleshooting Problem Cause Solution • Multiple electrical See flow chart, page 46. Sprayer does not run at all issues. • Display is blank • BlueLink status light never lights up Multiple electrical See flow chart, page 48. Sprayer will not shut off issues.
  • Page 40 Troubleshooting Problem Cause Solution • Control board Set sprayer to OFF and disconnect power Sprayer does not run at all detected voltage to sprayer. • Display shows CODE 4 surges. Locate a good voltage supply to prevent damage to electronics. •...
  • Page 41 Troubleshooting Problem Cause Solution Green Blue Red Black STEP 1: Green Blue Red Black STEP 2: Green Blue Red Black STEP 3: 3A6342F...
  • Page 42 Troubleshooting Problem Cause Solution • Control is Perform Field Short Test: Test at Sprayer does not run at all commanding large 4-pin motor field connector. • Display shows CODE 05 motor to run but There should not be continuity from pin motor shaft does 4, the ground wire, and any of the not rotate.
  • Page 43 Troubleshooting Problem Cause Solution • Motor overheated NOTE: Motor must be cooled down for the Sprayer does not run at all test. • Display shows CODE 06 Keep sprayer in cooler location with good ventilation. Make sure motor air intake is not blocked. Remove motor cover.
  • Page 44 Troubleshooting Problem Cause Solution • Incoming voltage Set sprayer to OFF and disconnect Sprayer does not run at all too low for sprayer power to sprayer. • Display shows CODE 08 operation Remove other equipment that uses the same circuit. Locate a good voltage supply to avoid damage to electronics.
  • Page 45 • Display shows CODE 17 Locate a good voltage supply to avoid damage to electronics. • BlueLink status light blinks 17 times repeatedly • Battery depleted See Replacing BlueLink Battery, page 31. Error appears in Graco Bluelink App 3A6342F...
  • Page 46 Troubleshooting Electrical cont... Sprayer does not run at all, display is blank, or BlueLink status light never lights up. (See following page for steps) Remove control box cover. Turn sprayer ON. Observe control board status light on control board See step 1. Do (see below).
  • Page 47 Troubleshooting STEP 1: Plug power cord in and turn switch ON. Connect probes to on/off switch. Turn meter to AC Volts. STEP 2: Check motor thermal switch. Unplug yellow wires above motor. Meter should read according to Resistance Table on page 42. NOTE: Motor should be cool during reading.
  • Page 48 Troubleshooting Electrical cont... Sprayer Will Not Shut Off Perform Pressure Relief Procedure, 2. Follow the troubleshooting page 18. Leave prime valve open, turn procedure below. power switch OFF, and unplug sprayer from power outlet. Plumb pressure gauge into paint Hose, plug sprayer in, and turn power switch ON.
  • Page 49 Notes Notes 3A6342F...

  • Page 50: 695/795 Lo-Boy Standard Parts

    695/795 Lo-Boy Standard Parts 695/795 Lo-Boy Standard Parts Ref. Torque 40-45 in-lb (4.5 - 5.0 N•m) 9-11 in-lb (1.0 - 1.2 N•m) 200-230 in-lb (22.6 - 25.9 N•m) 190-210 in-lb (21.4 - 23.7 N•m) 22-28 in-lb (2.4 - 3.1 N•m) 25-30 ft-lb (33.8 - 40.6 N•m) 70-80 ft-lb (94.9 - 108.4 N•m) 130-150 in-lb (14.6 - 16.9 N•m)
  • Page 51 695/795 Lo-Boy Standard Parts 695/795 Lo-Boy Standard Parts List Ref. Part Description Qty. Ref. Part Description Qty. 241920 DEFLECTOR, threaded 15C753 SCREW, mach, torx, hex 287289 GEAR, combination; 15E891 CLIP, retaining includes 28, 30 156306 WASHER, flat 287283 HOUSING, drive 119420 WHEEL, pneumatic includes 6, 36, 90a...

  • Page 52: 695/795/Mark Iv Hd Hi-Boy Standard Parts

    695/795/Mark IV HD Hi-Boy Standard Parts 695/795/Mark IV HD Hi-Boy Standard Parts Ref. Torque 40-45 in-lb (4.5 - 5.0 N•m) 9-11 in-lb (1.0 - 1.2 N•m) 200-230 in-lb (22.6 - 25.9 N•m) 190-210 in-lb (21.4 - 23.7 N•m) 22-28 in-lb (2.4 - 3.1 N•m) 25-30 ft-lb (33.8 - 40.6 N•m)
  • Page 53 695/795/Mark IV HD Hi-Boy Standard Parts 695/795/Mark IV HD Hi-Boy Standard Parts List Ref. Part Description Qty. Ref. Part Description Qty. 257185 695/Mark IV HD 230V 15C753 SCREW, mach, torx, hex 257186 795/Mark IV HD 120V 15E891 CLIP, retaining 241008 ROD, connecting;...

  • Page 54: 1095/1595/Mark V Hd/Mark Vii Hd Hi-Boy Standard Parts

    1095/1595/Mark V HD/Mark VII HD Hi-Boy 1095/1595/Mark V HD/Mark VII HD Hi-Boy Standard Parts Ref. Torque 40-45 in-lb (4.5 - 5.0 N•m) 9-11 in-lb (1.0 - 1.2 N•m) 200-230 in-lb (22.6 - 25.9 N•m) 190-210 in-lb (21.4 - 23.7 N•m) 22-28 in-lb (2.4 - 3.1 N•m) 25-30 ft-lb (33.8 - 40.6 N•m) 70-80 ft-lb (94.9 - 108.4 N•m)
  • Page 55 1095/1595/Mark V HD/Mark VII HD Hi-Boy 1095/1595/Mark V HD Hi-Boy Standard Parts List Ref. Part Description Qty. Ref. Part Description Qty. 257187 1095/Mark V 230V/Mark V 15C753 SCREW, mach, torx, hex Japan 15E891 CLIP, retaining 257188 1595/Mark V 120V/UK 156306 WASHER, flat Mark V/Mark VII 119509...

  • Page 56: Mark X Hd Standard Parts

    Mark X HD Standard Parts Mark X HD Standard Parts Ref. Torque 40-45 in-lb (4.5 - 5.0 N•m) 55-60 in-lb (6.2 - 6.7 N•m) 200-230 in-lb (22.6 - 25.9 N•m) 190-210 in-lb (21.4 - 23.7 N•m) 22-28 in-lb (2.4 - 3.1 N•m) 25-30 ft-lb (33.8 - 40.6 N•m) 70-80 ft-lb (94.9 - 108.4 N•m) 130-150 in-lb (14.6 - 16.9 N•m)
  • Page 57 Mark X HD Standard Parts Mark X HD Standard Parts List Ref. Part Description Qty. Ref. Part Description Qty. 24V028 HOUSING, bearing; 15C753 SCREW, mach, torx, hex includes 12, 14, 24, 31, 15E891 CLIP, retaining 55, 77, 108, 117 156306 WASHER, flat 258909 MOTOR, electric;...

  • Page 58: 695/795/Mark Iv Hd Procontractor Parts

    695/795/Mark IV HD ProContractor Parts 695/795/Mark IV HD ProContractor Parts Ref. Torque 40-45 in-lb (4.5 - 5.0 N•m) 9-11 in-lb (1.0 - 1.2 N•m) 200-230 in-lb (22.6 - 25.9 N•m) 190-210 in-lb (21.4 - 23.7 N•m) 120-130 in-lb (13.5 - 14.6 N•m) 25-30 ft-lb (33.8 - 40.6 N•m)
  • Page 59 695/795/Mark IV HD ProContractor Parts 695/795/Mark IV HD ProContractor Parts List Ref. Part Description Qty. Ref. Part Description Qty. 17E739 795 Ultimate 16C975 PLATE, pivot 248214 TUBE, intake; includes 15C753 SCREW, mach, hex wash hd 16X203 CLIP, drain line 105510 WASHER, lock, spring 24V087 HOUSING, bearing;...

  • Page 60: 1095/1595/Mark V Hd/Mark Vii Hd Procontractor Parts

    1095/1595/Mark V HD/Mark VII HD 1095/1595/Mark V HD/Mark VII HD ProContractor Parts Ref. Torque 40-45 in-lb (4.5 - 5.0 N•m) 9-11 in-lb (1.0 - 1.2 N•m) 200-230 in-lb (22.6 - 25.9 N•m) 190-210 in-lb (21.4 - 23.7 N•m) 120-130 in-lb (13.5 - 14.6 N•m) 25-30 ft-lb (33.8 - 40.6 N•m) 38-42 ft-lb (51.5 - 56.9 N•m) See page 68.
  • Page 61 1095/1595/Mark V HD/Mark VII HD 1095/1595/Mark V HD/Mark VII HD ProContractor Parts List Ref. Part Description Qty. Ref. Part Description Qty. 17E743 1595 Ultimate 16C975 PLATE, pivot 17E750 Mark VII 15C753 SCREW, mach, hex wash hd 248215 TUBE, intake; includes 109 105510 WASHER, lock 16X203 CLIP, drain line...

  • Page 62: Mark X Hd Procontractor Parts

    Mark X HD ProContractor Parts Mark X HD ProContractor Parts Ref. Torque 40-45 in-lb (4.5 - 5.0 N•m) 55-60 in-lb (6.2 - 6.7 N•m) 200-230 in-lb (22.6 - 25.9 N•m) 190-210 in-lb (21.4 - 23.7 N•m) 120-130 in-lb (13.5 - 14.6 N•m) 25-30 ft-lb (33.8 - 40.6 N•m) 38-42 ft-lb (51.5 - 56.9 N•m) 130-150 in-lb (14.6 - 16.9 N•m)
  • Page 63 Mark X HD ProContractor Parts Mark X HD ProContractor Parts List Ref. Part Description Qty. Ref. Part Description Qty. 17E751 LABEL, front 16C975 PLATE, pivot 16X363 LABEL, right side 15C753 SCREW, mach, hex wash 16X203 CLIP, drain line 24V089 HOUSING, bearing; 105510 WASHER, lock, spring includes 7, 12, 14, 15, 31, 15E891 CLIP, retaining...

  • Page 64: 1095/1595/Mark V Hd /Mark Vii Hd Ironman Parts

    1095/1595/Mark V HD /Mark VII HD IronMan 1095/1595/Mark V HD /Mark VII HD IronMan Parts Ref. Torque 40-45 in-lb (4.5 - 5.0 N•m) 9-11 in-lb (1.0 - 1.2 N•m) 200-230 in-lb (22.6 - 25.9 N•m) 190-210 in-lb (21.4 - 23.7 N•m) 90-110 in-lb (10.1 - 12.4 N•m) 25-30 ft-lb (33.8 - 40.6 N•m) 65-85 in-lb (7.3 - 9.6 N•m)
  • Page 65 1095/1595/Mark V HD /Mark VII HD IronMan 1095/1595/Mark V HD/Mark VII HD IronMan Ref. Part Description Qty. Ref. Part Description Qty. 17E748 Mark V 15C753 SCREW, mach, torx, hex 17E750 Mark VII 105510 WASHER, lock, spring 248215 TUBE, intake; includes 109 15E891 CLIP, retaining 16X203 CLIP, drain line 156306 WASHER, flat...

  • Page 66: Mark X Hd Ironman Parts

    Mark X HD IronMan Parts Mark X HD IronMan Parts Ref. Torque 40-45 in-lb (4.5 - 5.0 N•m) 55-60 in-lb (6.2 - 6.7 N•m) 200-230 in-lb (22.6 - 25.9 N•m) 190-210 in-lb (21.4 - 23.7 N•m) 22-28 in-lb (2.4 - 3.1 N•m) 25-30 ft-lb (33.8 - 40.6 N•m) 130-150 in-lb (14.6 - 16.9 N•m) 90-110 in-lb (10.1 - 12.4 N•m)
  • Page 67 Mark X HD IronMan Parts Mark X HD IronMan Parts List Ref. Part Description Qty. Ref. Part Description Qty. 258909 MOTOR, electric; includes 15C753 SCREW, mach, torx, hex 125, 126, 127 105510 WASHER, lock, spring 24V086 ROD, connecting 15E891 CLIP, retaining 241920 DEFLECTOR, threaded 156306 WASHER, flat 288035 GEAR, combination;...

  • Page 68: Procontractor Quikreel

    ProContractor QuikReel ProContractor QuikReel Ref. Torque 130-150 in-lb (14.6 - 16.9 N•m) 25-35 ft-lb (33.8 - 47.4 N•m) 120-130 in-lb (13.5 - 14.6 N•m) 38-42 ft-lb (51.5 - 56.9 N•m) QuikReel Parts List Ref. Part Description Qty. Ref. Part Description Qty.

  • Page 69: Spray Gun And Hose

    Spray Gun and Hose Spray Gun and Hose 695-1595 Models Mark IV-Mark VII Models Mark X Models Spray Gun and Hose Parts List Ref. Part Description Qty. Ref. Part Description Qty. 246468 Mark IV HOSE, coupled 245820 Mark X 240794 Ultra, 1/4” x 50’ HOSE, whip 826079 Ultimate, 1/4”...

  • Page 70: Filter

    Filter Filter Ref. Torque 90-110 in-lb (10.1 - 12.4 N•m) 35-45 ft-lb (47.4 - 61.0 N•m) 190-210 in-lb (21.4 - 23.7 N•m) 100-120 in-lb (11.2 - 13.5 N•m) 38-42 ft-lb (51.5 - 56.9 N•m) 15-25 in-lb (1.6 - 2.8 N•m) 365-385 in-lb (41.2 - 43.5 N•m) 3A6342F...
  • Page 71 Filter Filter Parts List Ref. Part Description Qty. Ref. Part Description Qty. 244071 30 mesh 117285 PACKING, o-ring 244067 60 mesh, original equipment 16U013 SCREW, cap, socket head 244068 100 mesh 111457 PACKING, o-ring 244069 200 mesh 15C972 PIN, grooved 114 104813 PLUG, pipe, 3/8 TUBE, formed 118 125926 FITTING, elbow...

  • Page 72: Control

    Control Control Ref. Torque Ref. Torque 10-15 in-lb (1.1 - 1.7 N•m) 30-35 in-lb (3.3 - 3.9 N•m) 40-45 in-lb (4.5 - 5.0 N•m) 15-20 in-lb (1.7 - 2.2 N•m) 200-230 in-lb (22.6 - 25.9 N•m) 2-3 in-lb (0.2 - 0.4 N•m) 3A6342F...
  • Page 73 Control Control Box Parts List Ref. Part Description Qty. Ref. Part Description Qty. 75e 244285 Japan 117791 SCREW, cap, flange head India 114391 SCREW, grounding 17N232 695/796/1095/Mark IV/Mark V 115522 SCREW, mach, pnh 256219 POTENTIOMETER, (ProContractor/IronMan assembly series) 16Y496 DISPLAY 116752 SWITCH, rocker, ON/OFF COVER, control 15D527 SWITCH, rocker, Mark X...

  • Page 74: Wiring Diagrams

    Wiring Diagrams Wiring Diagrams 695-1595/Mark IV HD-V HD 120V Models 3A6342F...
  • Page 75 Wiring Diagrams 695-1095/Mark IV HD-VII HD 110V/230V Models 3A6342F...
  • Page 76 Wiring Diagrams Mark X HD (North America) 3A6342F...
  • Page 77 Wiring Diagrams Mark X HD (International) 3A6342F...

  • Page 78: Technical Specifications

    Technical Specifications Technical Specifications 695 Sprayers U.S. Metric Sprayer Maximum Delivery 0.95 gpm 3.6 lpm Maximum Tip Size 0.031 0.031 Fluid Outlet npsm 1/4 in. 1/4 in. Cycles 226 per gallon 60 per liter Generator Minimum 5000 W 5000 W 120V, A, Hz 15, 50/60 230V, A, Hz...
  • Page 79 Technical Specifications 795 Sprayers U.S. Metric Sprayer Maximum Delivery 1.1 gpm 4.2 lpm Maximum Tip Size 0.033 0.033 Fluid Outlet npsm 1/4 in. 1/4 in. Cycles 195 per gallon 52 per liter Generator Minimum 5000 W 5000 W 120V, A, Hz 15, 50/60 230V, A, Hz 10, 50/60...
  • Page 80 Technical Specifications 1095 Sprayers U.S. Metric Sprayer Maximum Delivery 1.2 gpm 4.5 lpm Maximum Tip Size 0.035 0.035 Fluid Outlet npsm 1/4 in. 1/4 in. Cycles 123 per gallon 33 per liter Generator Minimum 5000 W 5000 W 120V, A, Hz 15, 50/60 230V, A, Hz 10, 50/60...
  • Page 81 Technical Specifications 1595 Sprayers U.S. Metric Sprayer Maximum Delivery 1.35 gpm 5.1 lpm Maximum Tip Size 0.039 0.039 Fluid Outlet npsm 1/4 in. 1/4 in. Cycles 110 per gallon 29 per liter Generator Minimum 5000 W 5000 W 120V, A, Hz 20, 50/60 Dimensions Weight:...
  • Page 82 Technical Specifications Mark IV HD Sprayers U.S. Metric Sprayer Maximum Delivery 1.1 gpm 4.2 lpm Maximum Tip Size North American 0.033 0.033 Models International Models 0.031 0.031 Fluid Outlet npsm 3/8 in. 3/8 in. Cycles 195 per gallon 52 per liter...
  • Page 83 Technical Specifications Mark V HD Sprayers U.S. Metric Sprayer Maximum Delivery 1.35 gpm 5.1 lpm Maximum Tip Size North American and UK 0.039 0.039 Models International Models 0.035 0.035 Fluid Outlet npsm 3/8 in. 3/8 in. Cycles 110 per gallon 29 per liter Generator Minimum 5000 W...
  • Page 84 Technical Specifications Mark VII HD Sprayers U.S. Metric Sprayer Maximum Delivery 1.58 gpm 6.0 lpm Maximum Tip Size 0.041 in. 0.041 in. Fluid Outlet npsm 1/2 in. 1/2 in. Cycles 97 per gallon 26 per liter Generator Minimum 5000 W 5000 W 230V, A, Hz 16, 50/60...
  • Page 85 Technical Specifications Mark X HD Sprayers U.S. Metric Sprayer Maximum Delivery 2.1 gpm 8.0 lpm Maximum Tip Size 0.045 in. 0.045 in. Fluid Outlet npsm 1/2 in. 1/2 in. Cycles 70 per gallon 19 per liter Generator Minimum 5000 W 5000 W 230V, A, Hz 16, 50/60...

  • Page 86: Compliance

    Compliance Compliance Radio Frequency Approvals Transmitter Frequency (all models): 2.4GHz NOTE: FCC/IC Notice (all models) Transmitter Power (all models): +8dBm Contains FCC ID: QOQBGM13P Contains IC: 5123A-BGM13P The enclosed device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s).

  • Page 87: Graco Standard Warranty

    Graco’s written recommendations. This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts.

  • Page 88: Graco Information

    Original instructions. This manual contains English. MM 3A6342 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA Copyright 2018, Graco Inc. All Graco manufacturing locations are registered to ISO 9001. www.graco.com...
