Bush Hog MBX60 Operator's Manual

Bush Hog MBX60 Operator's Manual

Box blade
Hide thumbs Also See for MBX60:
Table of Contents

Advertisement

Quick Links

Download this manual
Published 09/20
This Operator's Manual is an integral part of the safe operation of this machine and must
be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety
and Operation Instructions contained in this manual before operating the equipment. C01-
Cover
®
BUSH HOG
2501 Griffin Ave.
Selma, AL 36703
334-874-2700
www.bushhog.com
OPERATOR'S MANUAL
© 2020 Alamo Group Inc.
MBX60/72/84/96
BOX BLADE
Part No. 50027355
$0.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MBX60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bush Hog MBX60

Summary of Contents for Bush Hog MBX60

  • Page 1 MBX60/72/84/96 BOX BLADE Published 09/20 Part No. 50027355 OPERATOR’S MANUAL This Operator's Manual is an integral part of the safe operation of this machine and must be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment.
  • Page 2 BEFORE YOU START! Read the safety messages on the implement and shown in your manual. Observe the rules of safety and common sense! For future reference, record your Bush Hog product model number and serial number. Dealer Telephone Model Number...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SAFETY SECTION ......................1-1 General Safety Instructions and Practices ......................1-2 PARTS INFORMATION ............................. 1-8 Decal Location ..............................1-9 Decal Description ............................. 1-10 FEDERAL LAWS AND REGULATIONS ......................1-11 INTRODUCTION SECTION ....................2-1 OPERATION SECTION ....................... 4-1 Standard Equipment and Specifications ......................

  • Page 5: Safety Section

    SAFETY SECTION Safety Section 1-1...

  • Page 6: General Safety Instructions And Practices

    Safety Messages. Always use good common sense to avoid hazards. (SG-2) Si no lee ingles, pida ayuda a alguien que si lo lea para que le traduzca las medidas de seguridad. (SG-3) MBX60/72/84/96 09/20 Safety Section 1-2 © 2020 Alamo Group Inc.
  • Page 7 Operate the Tractor controls from the tractor seat only. (SG-9) Never allow children or other persons to ride on the Tractor or Implement. Falling off can result in serious injury or death. (SG-10) MBX60/72/84/96 09/20 Safety Section 1-3 © 2020 Alamo Group Inc.
  • Page 8 NOTE: Hearing loss from loud noise [from tractors, chain saws, radios, and other such sources close to the ear] is cumulative over a lifetime without hope of natural recovery. (SG-I7) MBX60/72/84/96 09/20 Safety Section 1-4 © 2020 Alamo Group Inc.
  • Page 9 Make sure all pins have cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order. (SG-21) MBX60/72/84/96 09/20 Safety Section 1-5 © 2020 Alamo Group Inc.
  • Page 10 Do not transport unless 3-Point lift lever is fully raised and in the latched transport position. Dropping implement in transport can cause serious damage to the tractor and/or Implement and possibly cause the operator or others to be injured or killed. (S3PT-02) MBX60/72/84/96 09/20 Safety Section 1-6 © 2020 Alamo Group Inc.
  • Page 11 Lower Stand and pin in place, or put a secure support under the A-Frame. Lower Blade carefully to the ground. Do not put hands or feet under lifted components. (SBL-4) Cancer and Reproductive Harm www.P65Warnings.ca.gov MBX60/72/84/96 09/20 Safety Section 1-7 © 2020 Alamo Group Inc.

  • Page 12: Parts Information

    These parts are made and tested to Bush Hog specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit” parts may reduce equipment performance, void warranties, and present a safety hazard. Use genuine Bush Hog parts for economy and safety.

  • Page 13: Decal Location

    SAFETY Decal Location NOTE: Bush Hog supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Bush Hog cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).

  • Page 14: Decal Description

    SAFETY Decal Description MBX60/72/84/96 09/20 Safety Section 1-10 © 2020 Alamo Group Inc.

  • Page 15: Federal Laws And Regulations

    Some regulations specify that no one under the age of 16 may operate power machinery. It is your responsibility to know what these regulations are in your own area or situation. (Refer to U.S. Dept. of Labor, Employment Standard Administration, Wage & Home Division, Child Labor Bulletin #102.) MBX60/72/84/96 09/20 Safety Section 1-11 © 2020 Alamo Group Inc.

  • Page 17: Introduction Section

    INTRODUCTION SECTION Introduction Section 2-1...
  • Page 18 Indicates an imminently hazardous situation that, if not avoided, MAY result in MINOR INJURY. Identifies special instructions or procedures that, if not strictly observed, could result in damage to, or destruction of the machine, attachments or the environment. MBX60/72/84/96 09/20 Introduction Section 2-2 © 2020 Alamo Group Inc.
  • Page 19 Bush Hog’s MBX Series Medium Duty Box Blades are the ideal choice for use around the farm or by landscape contractors on the job site. These box blades are rated for use on 2WD tractors up to 65 PTO horsepower and 4WD tractors up to 55 PTO horsepower with a Cat.
  • Page 20 NOTE: Warranties are honored only if completed “Owner Registration and Warranty” forms are received by Bush Hog within thirty days of delivery of the implement. 3. Record the Model and Serial Numbers on Warranty Page at the front of the Operator’s Manual. Keep this as part of the permanent maintenance file for the Implement.
  • Page 21 2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 3. If parts not made or supplied by Bush Hog have been used in connection with the unit, if, in the sole judgement of Bush Hog such use affects its performance, stability or reliability.

  • Page 23: Operation Section

    OPERATION SECTION Operation Section 3-1...
  • Page 24 READ, UNDERSTAND, and FOLLOW the following Safety Messages. Death or serious injury may occur unless care is taken to follow the warnings and instructions stated in the Safety Messages. Always use good common sense to avoid hazards. (SG-2) MBX60/72/84/96 09/20 Operation Section 3-2 © 2020 Alamo Group Inc.

  • Page 25: Standard Equipment And Specifications

    1/2”x6” 1/2”x6” Number of Cutting Edges Weight (Approximate) 580 lbs. 640 lbs. 710 lbs. 790lbs. Warranty 1 Year 1 Year 1 Year 1 Year SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE MBX60/72/84/96 09/20 Operation Section 3-3 © 2020 Alamo Group Inc.

  • Page 26: Operator Requirements

    Serious injury or death to the operator or others could result if the operator is under the influence of drugs or alcohol. (SG-27) MBX60/72/84/96 09/20 Operation Section 3-4 © 2020 Alamo Group Inc.

  • Page 27: Tractor Requirements

    (4WD). Operating these implements with a tractor that does not have adequate power may damage the tractor engine. Exceeding the recommended horsepower may cause blade damage by overpowering the unit in heavy operating conditions. MBX60/72/84/96 09/20 Operation Section 3-5 © 2020 Alamo Group Inc.

  • Page 28: Tractor 3-Point Hitch

    Never allow passengers to ride on the tractor or attached equipment. Riders can easily fall off and be seriously injured or killed from falling off and being ran over. It is the operator’s responsibility to forbid all extra riders at all times. OPS-U- 0008 MBX60/72/84/96 09/20 Operation Section 3-6 © 2020 Alamo Group Inc.

  • Page 29: Dismounting The Tractor

    Place the tractor shift lever into a low range or parking gear to prevent the tractor from rolling. Never dismount a Tractor that is moving or while the engine is running. Operate the Tractor controls from the tractor seat only. (SG-9) MBX60/72/84/96 09/20 Operation Section 3-7 © 2020 Alamo Group Inc.

  • Page 30: Starting The Tractor

    Always shut the Tractor completely down, place the transmission in park, and set the parking brake before you or anyone else attempts to connect or disconnect the Implement and Tractor hitches. (S3PT-15) MBX60/72/84/96 09/20 Operation Section 3-8 © 2020 Alamo Group Inc.

  • Page 31: Connecting The Blade

    IMPORTANT: Scan this QR Code with your smart phone to link to the PAMI Safe Implement Hitching Manual for more information on correctly connecting agricultural tractors to implements. Or type in your internet browser the following web address: www.algqr.com/hme Ops-0008-MISC MBX60/72/84/96 09/20 Operation Section 3-9 © 2020 Alamo Group Inc.

  • Page 32: Pre-Operation Inspection And Service

    Engine coolant level and condition • Power brake fluid level • Power steering fluid level • Fuel condition and level • Sufficient lubrication at all lube points • Air filter condition OPS-U-0030 MBX60/72/84/96 09/20 Operation Section 3-10 © 2020 Alamo Group Inc.

  • Page 33: Blade Pre-Operation Inspection/Service

    Ensure the manual canister is secured to the equipment with the operator’s manual inside. • Ensure all safety signs are in place and legible. Replace missing, damaged, and illegible decals. OPS-U- 0011 MBX60/72/84/96 09/20 Operation Section 3-11 © 2020 Alamo Group Inc.
  • Page 34 The engine coolant fluid level is full The radiator is free of debris The air filter is in good condition Operator’s Signature:___________________________________________________ DO NOT OPERATE an UNSAFE TRACTOR or IMPLEMENT MBX60/72/84/96 09/20 Operation Section 3-12 © 2020 Alamo Group Inc.
  • Page 35 The skid shoes are in good condition. The scarifier shanks are properly retained. (If applicable) The scarifier points are in good condition. (If applicable) Operator’s Signature:_____________________________________________________ DO NOT OPERATE an UNSAFE TRACTOR or IMPLEMENT MBX60/72/84/96 09/20 Operation Section 3-13 © 2020 Alamo Group Inc.

  • Page 36: Driving The Tractor And Implement

    When operating in traffic always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. (SG-19) MBX60/72/84/96 09/20 Operation Section 3-14 © 2020 Alamo Group Inc.

  • Page 37: Starting The Tractor

    When operating in traffic, always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. MBX60/72/84/96 09/20 Operation Section 3-15 © 2020 Alamo Group Inc.

  • Page 38: Driving The Tractor And Implement

    Care should be taken during use of the box blade to prevent hanging the scarifier points or the blades on immovable objects. Care should also be taken to prevent the use of the implement under conditions beyond its designed capacity. MBX60/72/84/96 09/20 Operation Section 3-16 © 2020 Alamo Group Inc.

  • Page 39: Shutting Down The Implement

    3-point hitch top link to remove tension on the top link hitch pin. When the pin is loose and easy to rotate, remove the pin from the blade. Next remove both lower hitch pins. MBX60/72/84/96 09/20 Operation Section 3-17...

  • Page 40: Blade And Storage

    Such an impact could cause the Implement and Tractor to pivot violently resulting in loss of steering control, serious injury, or even death. Never allow the Implement to contact obstacles. (S3PT-12) MBX60/72/84/96 09/20 Operation Section 3-18 © 2020 Alamo Group Inc.
  • Page 41 (SG-19) Never allow children or other persons to ride on the Tractor or Implement. Falling off can result in serious injury or death. (SG-10) MBX60/72/84/96 09/20 Operation Section 3-19 © 2020 Alamo Group Inc.

  • Page 42: Transporting On Public Roadways

    Make certain that the “Slow Moving Vehicle” (SMV) sign is installed in such a way as to be clearly visible and legible. When transporting the Equipment use the Tractor flashing warning lights and follow all local traffic regulations. (SG-6) MBX60/72/84/96 09/20 Operation Section 3-20 © 2020 Alamo Group Inc.
  • Page 43 Reduce speed before turning or applying the brakes. Ensure that both brake pedals are locked together when operating on public roads. OPS-U- 0023 MBX60/72/84/96 09/20 Operation Section 3-21 © 2020 Alamo Group Inc.

  • Page 44: Hauling The Tractor And Implement

    If during transport a hard braking, sharp turning, or swerving action was performed, stop at the next safe location to inspect the security of the load. OPS-U- 0026 MBX60/72/84/96 09/20 Operation Section 3-22 © 2020 Alamo Group Inc.

  • Page 45: Troubleshooting Guide

    Use slow speed when in unknown position soil conditions Moldboard digging in too much Blade pitch excessive Adjust Top Link Unable to hold level ground Tractor Draft Control lifting Blade Adjust Draft Control MBX60/72/84/96 09/20 Operation Section 3-23 © 2020 Alamo Group Inc.

  • Page 47: Maintenance Section

    MAINTENANCE SECTION Maintenance Section 5-1...

  • Page 48: Replacing Scarifier Points

    NOTE: These values apply to fasteners as received from supplier, dry or when lubricated with normal engine oil. They do not apply if special graphited or molydisulphide greases or other extreme pressure lubricants are used. This applies to both UNF fine and UNC coarse threads. MBX60/72/84/96 09/20 Maintenance Section 5-2 © 2020 Alamo Group Inc.
  • Page 49 MAINTENANCE MBX60/72/84/96 09/20 Maintenance Section 5-3 © 2020 Alamo Group Inc.
  • Page 51 TO THE OWNER/OPERATOR/DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this Manual. The Table of Contents clearly identifies each section where you can easily find the information you need. The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes these minimum safety...
  • Page 52 MBX60/72/84/96 Box Blade MBX60/72-84/96-SOM-09/20 P/N 50027355 Printed U.S.A...

This manual is also suitable for:

Mbx72Mbx84Mbx96
