Bush Hog HDRG84 Operator's Manual

Heavy duty road grader

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Published 09/20

This Operator's Manual is an integral part of the safe operation of this machine and must

be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety

and Operation Instructions contained in this manual before operating the equipment. C01-

Cover

BUSH HOG

2501 Griffin Ave.

Selma, AL 36703

334-874-2700

www.bushhog.com

OPERATOR'S MANUAL

HDRG84

HDRG96

HEAVY DUTY

ROAD GRADER

Part No. 50076169

$0.00

Table of Contents

Need help?

Do you have a question about the HDRG84 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bush Hog HDRG84

Page 1 HDRG84 HDRG96 HEAVY DUTY ROAD GRADER Published 09/20 Part No. 50076169 OPERATOR’S MANUAL This Operator's Manual is an integral part of the safe operation of this machine and must be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment.
Page 2 BEFORE YOU START! Read the safety messages on the implement and shown in your manual. Observe the rules of safety and common sense! For future reference, record your Bush Hog product model number and serial number. Dealer Telephone Model Number...
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY SECTION ......................1-1 General Safety Instructions and Practices ......................1-2 Decal Location ..............................1-9 FEDERAL LAWS AND REGULATIONS ......................1-11 INTRODUCTION SECTION ....................2-1 ASSEMBLY SECTION ......................3-1 OPERATION SECTION ....................... 4-1 Standard Equipment and Specifications ......................4-3 OPERATOR REQUIREMENTS .........................
Page 5: Safety Section
SAFETY SECTION Safety Section 1-1...
Page 6: General Safety Instructions And Practices
SAFETY General Safety Instructions and Practices A careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to the owner/operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions.
Page 7 SAFETY Never operate the Tractor or Implement until you have read and completely understand this Manual, the Tractor Operator’s Manual, and each of the Safety Messages found in the Manual or on the Tractor and Implement. Learn how to stop the tractor engine suddenly in an emergency.
Page 8 SAFETY Never allow children to operate, ride on, or come close to the Tractor or Implement. Usually, 16-17 year-old children who are mature and responsible can operate the implement with adult supervision, if they have read and understand the Operator’s Manuals, been trained in proper operation of the tractor and Implement, and are physically large enough to reach and operate the controls easily.
Page 9 SAFETY PROLONGED EXPOSURE LOUD NOISE CAUSE PERMANENT HEARING LOSS! Tractors with or without an Implement attached can often be noisy enough to cause permanent hearing loss. We recommend that you always wear hearing protection if the noise in the Operator’s position exceeds 80db. Noise over 85db over an extended period of time will cause severe hearing loss.
Page 10 SAFETY Periodically inspect all moving parts for wear and replace when necessary with authorized service parts. Look for loose fasteners, worn or broken parts, and leaky or loose fittings. Make sure all pins have cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order.
Page 11 SAFETY Operate the Tractor and/or Implement controls only while properly seated in the Tractor seat with the seat belt securely fastened around you. Inadvertent movement of the Tractor or Implement may cause serious injury or death. (SG-29) Be particularly careful when transporting the Implement with the Tractor. Turn curves or go up hills only at a low speed and using a gradual steering angle.
Page 12 These parts are made and tested to Bush Hog specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit” parts may reduce equipment performance, void warranties, and present a safety hazard. Use genuine Bush Hog parts for economy and safety.
Page 13: Decal Location
SAFETY Decal Location NOTE: Bush Hog supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Bush Hog cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 15: Federal Laws And Regulations
SAFETY FEDERAL LAWS AND REGULATIONS This section is intended to explain in broad terms the concept and effect of federal laws and regulations concerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such.
Page 17: Introduction Section
INTRODUCTION SECTION Introduction Section 2-1...
Page 18 INTRODUCTION This Grader Blade is designed with care and built with quality materials by skilled workers. Proper assembly, maintenance, and operating practices, as described in this manual, will help the owner/operator get years of satisfactory service from the machine. The purpose of this manual is to familiarize and instruct. The Assembly Section instructs the owner/operator in the correct assembly of the Blade using standard and optional equipment.
Page 19 INTRODUCTION NOTE: All references made in this manual to right, left, front, rear, top or bottom are as viewed facing the direction of forward travel with implement properly attached to tractor. These Grader Blades fit a wide range of tractors. The Heavy-Duty, CAT I three-point hitch, 4"...
Page 20 NOTE: Warranties are honored only if completed “Owner Registration and Warranty” forms are received by Bush Hog within thirty days of delivery of the implement. 3. Record the Model and Serial Numbers on Warranty Page at the front of the Operator’s Manual. Keep this as part of the permanent maintenance file for the Implement.
Page 21 2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 3. If parts not made or supplied by Bush Hog have been used in connection with the unit, if, in the sole judgement of Bush Hog such use affects its performance, stability or reliability.
Page 23: Assembly Section
ASSEMBLY SECTION Assembly Section 3-1...
Page 24 The HDRG Series Road Graders are shipped completely assembled from the factory. Upon receipt of the unit make a thorough inspection of the machine to insure it is complete and in good working order. Contact Bush Hog Service Department to report any shipping damage, defective or missing parts.
Page 25: Operation Section
OPERATION SECTION Operation Section 4-1...
Page 26 OPERATION ROAD GRADER OPERATION INSTRUCTIONS Your Road Grader should now be assembled and inspected for any evidence of defective or damaged parts before use. Any evidence of damage should be reported to your dealer immediately. After the Three-Point Hitch is attached, carefully remove safety blocks from under the implement (if used). This section of the Operator’s Manual is designed to familiarize, instruct, and educate safe and proper blade use to the operator.
Page 27: Standard Equipment And Specifications
OPERATION Standard Equipment and Specifications HDRG84 HDRG96 Working Width 84” 96” Box Depth 54-7/16” 54-7/16” Overall Depth 54-7/16” 54-7/16” Overall Height 33-5/8” 33-5/8” Overall Width 90” 102” Side Sheet Thickness 3/16” 3/16” Shank Penetration 5/8” -2-1/2” 5/8” -2-1/2” Shank Size 3/4”x2-1/2”...
Page 28: Operator Requirements
OPERATION 2. OPERATOR REQUIREMENTS Safe operation of the unit is the responsibility of a qualified operator. A qualified operator has read and understands the implement and tractor Operator’s Manuals and is experienced in implement and tractor operation and all associated safety practices. In addition to the safety messages contained in this manual, safety signs are affixed to the implement and tractor.
Page 29: Tractor Requirements
OPERATION 3. TRACTOR REQUIREMENTS Operating the grader with a tractor that does not meet the following requirements may cause tractor or grader damage and be a potential danger to the operator and passersby. Tractor Requirements and Capabilities • Certified approved Roll-Over Protective Structure (ROPS) or ROPS cab and seat belt. •...
Page 30: Tractor 3-Point Hitch - Rg Models
3.3 Tractor 3-Point Hitch - RG Models The tractor 3-point hitch must be rated to lift at least 750 lbs. for the HDRG84 and 828 lbs. for the HDRG96 Series Blades. The HDRG Series can attach to tractors with a CAT I or II hitch.
Page 31: Boarding The Tractor
OPERATION 4.1 Boarding the Tractor Use both hands and equipped handrails and steps for support when boarding the tractor. Never use control levers for support when mounting the tractor. Seat yourself in the operator’s seat and secure the seat belt around you.
Page 32: Starting The Tractor
OPERATION 5. STARTING THE TRACTOR The operator must have a complete understanding of the placement, function, and operational use of all tractor controls before starting the tractor. Review the tractor operator’s manual and consult an authorized dealer for tractor operation instructions if needed. Essential Tractor Controls: •...
Page 33 OPERATION Connecting the Road Grader 1. Shorten or remove the tractor drawbar to avoid interference when raising and lowering the road grader. 2. Board the tractor and start the engine. Position the tractor to the road grader with the 3-point lift arms positioned between the respective set of road grader A-frame lift lugs.
Page 34: Pre-Operation Inspection And Service
OPERATION 7. PRE-OPERATION INSPECTION AND SERVICE Before each use, a pre-operation inspection and service of the implement and tractor must be performed. This includes routine maintenance and scheduled lubrication, inspecting that all safety devices are equipped and functional, and performing needed repairs. DO NOT operate the unit if the pre-operation inspection reveals any condition affecting safe operation.
Page 35: Blade Pre-Operation Inspection/Service
OPERATION 7.2 Blade Pre-Operation Inspection/Service Before each use, a complete inspection and service is required to ensure the blade is in good and safe working condition. Damaged and/or broken parts should be repaired and/or replaced immediately. To ensure the blade is ready for operation, conduct the following.
Page 36 OPERATION Tractor PRE-OPERATION Inspection Tractor ID#:________________________Make:________________________ Date:______________________________Shift:________________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the implement is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 37 OPERATION Blade & Box Blade PRE-OPERATION Inspection Blade ID#:_______________________Make:__________________________ Date: ___________________________Shift:___________________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the blade is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 38: Driving The Tractor And Implement
OPERATION 8. DRIVING THE TRACTOR AND IMPLEMENT Safe tractor transport requires the operator possess a thorough knowledge of the model being operated and precautions to take while driving with an attached implement. Ensure the tractor has the capacity to handle the weight of the implement and the tractor operating controls are set for safe transport.
Page 39: Starting The Tractor
OPERATION 8.1 Starting the Tractor The procedure to start the tractor is model specific. Refer to the tractor operator’s manual for starting procedures for your particular tractor. Consult an authorized dealer if the starting procedure is unclear. Ensure the 3-point control lever is in the lowered position and the PTO is disengaged before starting the tractor.
Page 40: Operating The Tractor And Implement
OPERATION turning with a towed implement, the overall working length of the unit is increased. Allow additional clearance for the units when turning. To avoid overturns, drive the tractor with care and at safe speeds, especially when operating over rough ground, crossing ditches or slopes, and turning corners.
Page 41: Shutting Down The Implement
OPERATION 10. Shutting Down the Implement To shut down the implement, first bring the tractor to a complete stop. Park the tractor on a level surface, place the transmission in park or neutral and apply the parking brake, lower the attached implement to the ground, shut down the engine, remove the key, before exiting the tractor.
Page 42: Transporting The Tractor And Implement
OPERATION Never allow children to play on or around Tractor or Implement. Children can slip or fall off the Equipment and be injured or killed. Inadvertent contact with controls can cause the Implement to shift or fall crushing themselves or others. (SG-25) 13.
Page 43 OPERATION Transport only at speeds where you can maintain control of the equipment. Serious accidents and injuries can result from operating this equipment at high speeds. Understand the Tractor and Implement and how it handles before transporting on streets and highways. Make sure the Tractor steering and brakes are in good condition and operate properly.
Page 44: Transporting On Public Roadways
OPERATION Before transporting the tractor on a public roadway or boarding a trailer for transport, the tractor brake pedals should be locked together. Locking the pedals ensures that both wheels brake simultaneously while stopping, especially when making an emergency stop. Use extreme caution and avoid hard applications of the tractor brakes when towing heavy loads at road speeds.
Page 45 OPERATION The SMV (Slow-Moving Vehicle) emblem is universal symbol used to alert drivers of the presence of equipment traveling on roadways at a slow speed. SMV signs are a triangular bright orange with reflective red trim for both easy day and night visibility.
Page 46: Hauling The Tractor And Implement
OPERATION 14.2 Hauling the Tractor and Implement Before transporting a loaded tractor and implement, measure the height and width dimensions and gross weight of the complete loaded unit. Ensure that the load will be in compliance with the legal limits set for the areas that will be traveled through.
Page 47: Troubleshooting Guide
OPERATION 15. TROUBLESHOOTING GUIDE Problem Possible Cause Remedy Grader will not penetrate soil Excessive Speed Reduce Speed Cutting edge dull Replace Cutting edge Grader set to straight Increase Top Link length RG MODELS ONLY Soil too hard Use scarifiers to loosen soil A-Frame bent Hitting hidden objects in the backfill Use slow speed when in unknown...
Page 49: Maintenance Section
MAINTENANCE SECTION Maintenance Section 5-1...
Page 50: Replacing Scarifier Points
MAINTENANCE Replacing Scarifier Points Make certain that you wear gloves and safety glasses. Chips can fly off hammer or punch and cause eye damage, loss of eyesight, or other injury. Place Scarifier assembly in vise securely. Using a hammer and drift or punch, drive the worn point off. Hammer the new point on securely.
Page 53 TO THE OWNER/OPERATOR/DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this Manual. The Table of Contents clearly identifies each section where you can easily find the information you need. The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes these minimum safety...
Page 54 HDRG84 / HDRG96 Road Grader HDRG Series Road Grader-SOM-09/20 P/N 50076169 Printed U.S.A...
