Functions - Ada COSMO 40 Operating Manual

COSMO 40
Continuous Measurement
Press and hold the button (1) for about 2 seconds to start continuous measuring.
Minimum/ Maximum measurement
This function allows the user to measure the minimum or maximum distance from a fixed measuring point. It is
commonly used to measure room diagonals (maximum values) or horizontal distances (minimum values). Press and hold
down the button (1), until you will hear acoustical signal. Then slowly sweep the laser back and forth and up and down
over the desired target point (e.g. into the corner of a room). Press (1) to stop continuous measurement. The values for
maximum and minimum distances are shown on the display as well as the last measured value in the main line.

FUNCTIONS

Distance measuring
Press button (5): next measurement is added to the previous one. Press button (5): next measurement is
substracted from the previous one.
