Ada COSMO 40 Operating Manual page 14

1 COSMO 40
maximum distance is fixed. The result of the measurement is displayed in the second line. Previous measure-
ment is displayed in the first line. The result of the function is displayed in the main display area.
Indirect measurement – determing a distance using 3 measurements
This function is used when it's necessary to measure diagonals of rectangular areas, and also for calculation
of the length of frameworks, inclined distances and so on.
Press button (2) 4 times. The symbol "triangle" is displayed. The distance to be measured is blinking in the
symbol triangle. Press button (1) to take distance measuring (side of the triangle) . The result of the function
is displayed in the second line. This measurement can be taken in the mode of continious measurement. Press
and hold button (1) for 2 sec. After second pression of the button (1) maximum value is fixed. The second
distance to be measured is blinking in the symbol triangle. It's very important to have right angle between
laser beam and the length you need to measure. That's why you should work in continious mode. Press and
hold button (1) for 2 sec. After second pressure of the button (1) maximum distance is fixed. The result of the
function is displayed in the main display area. Previous measurement is displayed in the first line.
