Regalo 1348DS Owner's Manual

Double door super wide
Hide thumbs

Advertisement

Quick Links

Download this manual
• READ ALL INSTRUCTIONS BEFORE ASSEMBLY AND USE OF GATE.
• KEEP INSTRUCTIONS FOR FUTURE USE.
www.regalo-baby.com
Regalo International, LLC.
3200 Corporate Center Drive, Suite 100 / Burnsville, MN 55306, USA
866.272.5274 (U.S. only) or 952.435.1080
Made in China
Double Door Super Wide
OWNER'S MANUAL MODEL:
Safety Gate
1348, 1348DS

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1348DS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Regalo 1348DS

Summary of Contents for Regalo 1348DS

  • Page 1 Double Door Super Wide Safety Gate 1348, 1348DS OWNER’S MANUAL MODEL: • READ ALL INSTRUCTIONS BEFORE ASSEMBLY AND USE OF GATE. • KEEP INSTRUCTIONS FOR FUTURE USE. www.regalo-baby.com Regalo International, LLC. 3200 Corporate Center Drive, Suite 100 / Burnsville, MN 55306, USA 866.272.5274 (U.S.

  • Page 3: Before Using Product

    Before Using Product Read and follow all instructions carefully to ensure that your gate and extensions are properly installed. Improper installation could result in the gate becoming unstable or dislodged from the doorway. Always make sure the extension is securely attached to the gate before using.
  • Page 4 WARNING • To prevent serious injury or death, securely install gate or enclosure and use according to manufacturer’s instructions. • Children have died or been seriously injured when gates are not securely installed. ALWAYS install and use gate as directed using all required parts.

  • Page 5: Before Assembly

    Before Assembly PLEASE CHECK TO MAKE SURE Y OU HAVE THE FOLLOWING PARTS: Primary Door Panel (1) Secondary Door Panel (1) Gate Frame (6 Panels) Plastic Mounting Brackets (4 – Attached to Gate Frame) U-frame Support (1) 1" Wall Mounting Screws (8) (requires a Phillips/cross-head screwdriver) Frame Assembly Screws (4) Hex Key English...
  • Page 6 Assembling Your Gate STEP 1 Connect the double doors by pushing the door frames together until the bases meet. STEP 2 Place the U-frame support on top of the connected door base an align screw holes. STEP 3 Use the hex key to fix the U-frame support to the door frame bases using the frame assembly screws.
  • Page 7 Option A: Installing Your Gate Between Two Walls STEP 1 Unfold the gate frame by turning the locking knobs counter clockwise at each pivoting joint. Loosen the knobs enough to allow the gate to swing open freely without fully removing the knobs. LOCKING KNOB STEP 2 Arrange the gate panels to your desired configuration to fit your opening...
  • Page 8 STEP 4 Tighten all the locking knobs to secure your gate in place. NOTE: to maximum width openings 192 inches wide . 52.5 INCHE S English Englis h...
  • Page 9 Option B: Converting Your Gate to a Play Yard STEP 1 Unfold the gate frame by turning the locking knobs counter clockwise at each pivoting joint. Loosen the knobs enough to allow the gate to swing open freely without fully removing the knobs. STEP 2 Release the vertical metal pivot bars at each end of the play yard by removing the following parts from the assembly:...
  • Page 10 STEP 3 Position the play yard into your desired configuration (e.g. square), then join the free ends of the play yard together at the plastic joints. STEP 4 Insert one of the previously removed metal pivot bars through the opening created by joining the upper plastic joints.
  • Page 11 STEP 5 Reassemble the upper locking joint by adding one of the previously removed toothed disks and locking knobs. STEP 6 Tighten each of the locking knobs by turning them clockwise, fixing the play yard into the configuration you have chosen.
  • Page 12 Operating the Single Door STEP 1 Simultaneously slide the lock and lift up the metal lift latch to unlock the door. The primary door will swing open in one direction only. SLIDE LOCK METAL LIFT LATCH STEP 2 To lock the gate, close the door completely and push the metal lift latch back into place.
  • Page 13 Operating the Double Doors STEP 1 After you have opened the primary door, rotate the locking hinge on the secondary door. Lift the door up and swing open. The secondary door will open in either direction. LOCKING HINGE ROTATING LOCKING HINGE STEP 2 To close the secondary door, lift up on the door and place onto door frame base.

  • Page 14: Care And Maintenance

    Regalo International, LLC, will replace or repair it at Regalo’s option. PROOF OF PURCHASE REQUIRED.

  • Page 15: Replacement Parts

    Replacement Parts Bottom Hinge - Male Door Frame Toothed Hinge White = #13002 White = #13009 Wall Mount Bottom Top Hinge Cap - Female White = #13011 White = #13014 1” Wall Mount Screws Locking Knob #10001 White = #13005 27”...
  • Page 16 Regalo International, LLC. 3200 Corporate Center Drive, Suite 100 Burnsville, MN 55306, USA 866.272.5274 (U.S. only) or 952.435.1080 20180430ET...
