ALLURE™ VERTICAL SERIES - NEFVC32H
Specifi cations
Model
BTU
NEFVC32H
5000
* See "Recessed Installation" section for framing dimensions.
Dimensions
13/16"
(20mm)
30 1/2"
(927mm)
BACK VIEW
Minimum Mantel Clearances
!
WARNING
•
When using paint or lacquer to fi nish the mantel, the paint or lacquer must be heat resistant to prevent discolouration.
Product information provided is not complete and is subject to change without notice. Please consult the installation manual for
the most up to date installation information.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 0G8 Canada •
Width
Watts
Actual
Framing
1500
16
1"
14"
(25mm)
(366mm)
Mantel
2"
2"
(5cm)
Wall
Floor
Side View (Wall Mount)
Height
Actual
Framing
*
32
*
5 5/8"
(144mm)
3"
(77mm)
30 1/2"
(927mm)
RIGHT SIDE
VIEW
Mantel
2"
2"
(5cm)
Floor
Side View (recessed into a wall)
1(866)820-8686
Depth
Viewing Area
Actual
Framing
5 5/8
*
15 1/4 x 20
20"
(508mm)
32"
(813mm)
15 1/4" (385mm)
16" (406mm)
FRONT VIEW
0"
0"
0"
W415-1906 / A / 08.08.19
•
www.napoleon.com
