3. Hanging the Fan

REMEMBER
Follow the steps below to hang your fan properly:
1. Disconnect power at the breaker to the fan location.
Check your outlet box to make sure it has a proper Hot, Neutral,
and Ground. If not, you will need to consult with a licensed
electrician to install a new cUL/UL outlet box (Fig. 3).
2. Remove 1 of 2 screws from the bottom of mounting bracket
and save for use in the Finishing the Installation section. Loosen
the other screw (Fig. 3).
3. Pass the 120-volt supply wires through the center hole
in the ceiling mounting bracket as shown in (Fig. 3A).
4. Secure the mounting bracket to the ceiling outlet box with
the screws and washers provided with your fan.
Use A hardware.
5. Lift motor assembly and hang it on the hook of mounting bracket
using one of the screw holes (Fig. 3B).
6. Secure the safety cable to the building structure using spring
washer, flat washer, and wood screw provided (Fig. 3B).
Use B hardware.
NOTE: Safety cable is required for all installations in Canada. Safety
cable is required for ceiling fan and light combinations over 35 lbs. in
both flush and downrod models in the United States.
12 Axis Flush Instructions
to turn off power at the breaker.
F H- W 1 8 0 3 - 5 2
