Kenmore FeatherLite DU1275 Use & Care Manual page 9

5. Insert one end of the flexible hose into
the main body as shown until you hear a
'click'. Then run the flexible hose over the
hose storage. Insert the other end of the
hose into the lower hose connection as
shown until you hear a 'click'.
II
I
6. Store the extension wand under the hose
storage as shown. Make sure the smaller
end of the extension wand is upward.
Push and snap into place.
ASSEMBLY INSTRUCTIONS
Hose
Storage
III
Lower
Hose
Connection
- 9 -
7. Insert the combination tool onto the
accessory storage post located on
the back of the main body. The Pet
®
HandiMate is stored in the attachment
holder on the wand.
II
I
8. Make sure the upper cord hook is in
the proper position as shown. Wrap the
power cord loosely around the upper
and lower cord hooks.
NOTE:
Make sure to wrap the power
cord around the upper cord hook first, and
then around the lower cord hook to avoid
damaging the power cord.
Upper
Cord
Hook
