- Page 1 PRO Series LCD Monitor PRO MP243P (3PB5) PRO MP273P (3PB4) PRO MP273QP (3PB6) PRO MP273QV (3PB6) User Guide...
-
Page 2: Table Of Contents
Contents Getting Started ......................3 Package Contents ....................3 Installing the Monitor Stand ................... 4 Adjusting the Monitor ..................... 6 Monitor Overview ....................8 Connecting the Monitor to PC ................11 OSD Setup ........................13 OSD Keys ......................13 OSD Menus........................14 Professional ...................... -
Page 3: Getting Started
This chapter provides you with the information on hardware setup procedures. While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity. Package Contents PRO MP243P PRO MP273P Monitor PRO MP273QP PRO MP273QV... -
Page 4: Installing The Monitor Stand
Installing the Monitor Stand PRO MP243P, PRO MP273P, PRO MP273QP 1. Leave the monitor in its protective foam packaging. Align the stand bracket to the monitor groove. 2. Tighten the stand bracket with screws. 3. Connect the base to the stand and tighten the base screw to secure the base. - Page 5 PRO MP273QV 1. Leave the monitor in its protective foam packaging. Align the stand bracket to the monitor. 2. Connect the base to the stand to secure the base. 3. Make sure the stand assembly is properly installed before setting the monitor upright.
-
Page 6: Adjusting The Monitor
Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities. PRO MP243P, PRO MP273P, PRO MP273QP -5° +20° 110mm 30° 30° 90° 90° Getting Started... - Page 7 PRO MP273QV -5° 20° ⚠ Important ∙ Avoid touching the display panel when adjusting the monitor. ∙ Please slightly tilt the monitor backwards before pivoting it. Getting Started...
-
Page 8: Monitor Overview
Monitor Overview PRO MP243P, PRO MP273P, PRO MP273QP PRO MP243P & PRO MP273P PRO MP273QP Getting Started... - Page 9 PRO MP273QV Getting Started...
- Page 10 Lit in orange when the monitor is in Stand-by mode. DisplayPort HDMI™ Connector Supports HDMI™ CEC, 1920x1080@75Hz as specified in HDMI™ 1.4b. (PRO MP243P/ PRO MP273P) Supports HDMI™ CEC, 2560x1440@75Hz as specified in HDMI™ 1.4b. (PRO MP273QP/ PRO MP273QV) HDMI™ Connector Supports 2560x1440@75Hz as specified in HDMI™...
-
Page 11: Connecting The Monitor To Pc
Connecting the Monitor to PC PRO MP243P, PRO MP273P, PRO MP273QP 1. Turn off your computer. 2. Connect the video cable from the monitor to your computer. 3. Assemble the external power supply & power cord. (Figure A) 4. Connect the external power supply to the monitor power jack. (Figure B) 5. - Page 12 PRO MP273QV 1. Turn off your computer. 2. Connect the video cable from the monitor to your computer. 3. Assemble the external power supply & power cord. (Figure A) 4. Connect the external power supply to the monitor power jack. (Figure B) 5.
-
Page 13: Osd Setup
OSD Setup This chapter provides you with essential information on OSD Setup. ⚠ Important All information is subject to change without prior notice. OSD Keys The monitor comes with a set of OSD Keys that help to control the On-Screen Display (OSD) menu. -
Page 14: Osd Menus
OSD Menus PRO MP243P/ PRO MP273P PRO MP273QP / PRO MP273QV ⚠ Important The following settings will be grayed out when HDR signals are received: HDCR ∙ ∙ Brightness OSD Menus... -
Page 15: Professional
Professional 1st Level Menu 2nd/3rd Level Menu Description Mode ∙ Use Up or Down Button to select and preview mode effects. User ∙ Press the E Button to confirm and apply your mode type. sRGB ∙ The default setting “Eco” mode Anti-Blue meets the requirements of TÜV Rheinland’s “Low Blue... - Page 16 1st Level Menu 2nd/3rd Level Menu Description Alarm Clock Location Left Top ∙ After setting the time, press the E Button to activate the timer. Right Top ∙ Users have to manually restore their preset Alarm Clock after any Left Bottom AC power loss and reconnection.
-
Page 17: Image
Image 1st Level Menu 2nd/3rd Level Menu Description Brightness 0-100 ∙ Properly adjust Brightness according to the surrounding lighting. ∙ Brightness will be grayed out when HDCR is enabled. Contrast 0-100 ∙ Properly adjust Contrast to relax your eyes. Sharpness ∙... -
Page 18: Input Source
Input Source 1st Level Menu 2nd Level Menu Description HDMI™ ∙ Select an Input Source from the list. (PRO MP243P/ PRO MP273P) HDMI™ 1 (PRO MP273QP/ PRO MP273QV) HDMI™ 2 (PRO MP273QP/ PRO MP273QV) Auto Scan ∙ Users can use the Navi Key to select Input Source at below status: •... -
Page 19: Navi Key
Navi Key 1st Level Menu 2nd Level Menu Description Enter ∙ All Navi Key items can be adjusted via OSD Menus. Left Brightness Right Mode Alarm Clock Input Source Refresh Rate Info. On Screen Audio Volume OSD Menus... -
Page 20: Setting
Setting 1st Level Menu 2nd Level Menu Description Language 繁體中文 ∙ Users have to press the E Button to confirm and apply the Language setting. English ∙ Language is an independent setting. Users’ own language setting will override Français the factory default. When users set Reset to Yes, Language will not be changed. - Page 21 1st Level Menu 2nd Level Menu Description HDMI™ CEC ∙ HDMI™ CEC (Consumer Electronics Control) supports Sony PlayStation®, Nintendo® Switch™, Xbox Series X|S consoles and various audio-visual devices that are CEC-capable. ∙ If HDMI™ CEC is set to ON: • The monitor will automatically power on when the CEC device is turned on.
-
Page 22: Specifications
Specifications Model PRO MP243P PRO MP273P PRO MP273QP PRO MP273QV Size 23.8 inch 27 inch Curvature Flat Panel Type Resolution 1920 x 1080 2560x1440 Aspect Ratio 16:9 Brightness (nits) 250 (typ.) 350 (typ.) 250 (typ.) Contrast Ratio 1000:1 4000:1 75Hz... - Page 23 Model PRO MP243P PRO MP273P PRO MP273QP PRO MP273QV ∙ Plate Type: 75 x 75 mm ∙ Screw Type: M4 x 10 mm VESA Mounting • Thread Diameter: 4 mm • Thread Pitch: 0.7 mm • Thread Length: 10 mm 541.93 x 200.80 x...
-
Page 24: Preset Display Modes
Preset Display Modes ⚠ Important All information is subject to change without prior notice. PRO MP243P PRO MP273QP PRO MP273P PRO MP273QV Standard Resolution HDMI™/DP HDMI™/DP 640x480 @60Hz @67Hz @72Hz @75Hz Dos-Mode 720x480 @60Hz 720x576 @50Hz SVGA 800x600 @56Hz @60Hz... -
Page 25: Troubleshooting
Troubleshooting The power LED is off. • Press the monitor power button again. • Check if the monitor power cable is properly connected. No image. • Check if the computer graphics card is properly installed. • Check if the computer and monitor are connected to electrical outlets and are turned on. -
Page 26: Safety Instructions
∙ Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. ∙ If this device comes with an adapter, use only the MSI provided AC adapter approved for use with this device. - Page 27 California, USA: The button cell battery may contain perchlorate material and requires special handling when recycled or disposed of in California. For further information please visit: https://dtsc.ca.gov/perchlorate/ Environment ∙ To reduce the possibility of heat-related injuries or of overheating the device, do not place the device on a soft, unsteady surface or obstruct its air ventilators.
-
Page 28: Tüv Rheinland Certification
TÜV Rheinland Certification TÜV Rheinland Low Blue Light Certification Blue light has been shown to cause eye fatigue and discomfort. MSI now offers monitors with TÜV Rheinland Low Blue Light certification to ensure users’ eye comfort and well-being. Please follow the instructions below to reduce the symptoms from extended exposure to the screen and blue light. -
Page 29: Regulatory Notices
1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626) 913-0828 www.msi.com... - Page 30 Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products.
- Page 31 Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners.
