Page 1: Table Of Contents
Contents Contents ◆ PRECAUTION ◆ USAGE OF DISK ◆ BEFORE YOU BEGIN ◆ COMPATIBLE DVD DISCS ◆ INSTALLATION IN THE CAR ◆ VIEW OF A/V BOX & DVD (HEAD UNIT) ◆ A/V BOX POWER CABLE LINE ◆ USING THE KEY ◆... - Page 2 Contents Contents ◆ DVD MODE ( SET UP DISPLAY & LANGUAGE ) ◆ SUBTITLE ◆ MULTI MODE PLAY ◆ REPEAT MODE ( A / B ) ◆ ZOOM MODE ◆ DVD MODE(REPEATING A SPECIFIC SECTION) ◆ DVD MODE(VCD PBC FUNCTION) ◆...
-
Page 3: Precaution
Precaution BE SURE TO READ THIS PRECAUTION BEFORE USE TO PREVENT ACCIDENTS OF USERS. Upon running or parking, adjust the volume so that you can hear external sound. Upon stop, if starting this product after switching off the ignition, pay attention to an electric discharge. Avoid moisture. - Page 4 Precaution BE SURE TO READ AND UNDERSTAND THE FOLLOWING MATTERS FOR SAFE DRIVING AND TO AVOID PRODUCT DAMAGES. Do not install and fix the DVD or VIDEO screen at a visible position from drivers to avoid accidents. The rear video outlet of this product can be connected to the display unit so that passengers at rear seats can view DVD or VIDEO CD.
-
Page 5: Usage Of Disk
Usage of DISK THE FOLLOWING ARE PRECAUTIONS WHEN USING A DISK. Although playable, a disk in a peculiar form(Heart shape, a shape other than circles, etc.) can not be played. Such disks cause player troubles. This product requires use of 12cm circular disks only. For all disks, check damage, scratch, and warp before use. -
Page 6: Before You Begin
Before you begin This product can be applied to DVD, TV, RADIO, CD, MP3 CD and VCD. Since region codes differ according to countries, products with different region codes can not be used. See the following features: Multi Audio Freely supported in a variety of audio systems recorded. Multi Aspect Convertible in wide screen, letter box and Pan &... -
Page 7: Compatible Dvd Discs
Compatible DVD Discs VIDEO FORMATIC VIDEO CD Dolby Digital AUDIO DISC... -
Page 8: Installation In The Car
Installation In The CAR ※ Cautions : Please separate Battery Units before setting products to prevent from fire and electric shock. DATA CABLE POWER CABLE ANT CABLE CHANGER 5.1CH NAVIGATION LINE OUT (AV3) AUX OUT REAR CAMERA (AV2) AV1 INPUT... -
Page 9: View Of A/V Box & Dvd (Head Unit)
A/V BOX & DVD Instructions (Head Unit) - AV BOX - FRONT VIDEO,AUDIO L,R LINE OUT AV2 & REAR CAMERA INPUT CD CHANGER AV1 INPUT NAVIGATION 5.1CH AUDIO LINE OUT & AV3 INPUT DATA CABLE - AV BOX - REAR (Mono Headsets Available) CENTER AMP POWER CABLE... -
Page 10: A/V Box Power Cable Line
A/V BOX Power Cable Line PIN NO WIRE VIEW 19 17 15 13 11 20 18 16 14 12 COLOR VIOLET VIOLET/BLACK GRAY/BLACK GREEN GRAY GREEN/BLACK WHITE YELLOW BACK UP(+14.4V) WHITE/BLACK YELLOW BACK UP(+14.4V) BLACK/WHITE SIDE BRAKE NO CONNECT ORANGE/WHITE NO CONNECT ORANGE REAR CAMERA... -
Page 11: Using The Key
Using the KEY Monitor OPEN/CLOSE LCD Display (Time / Disply) BAND Change on TV & RADIO Mode. AS/PS : AUTO Search/ PROGRAN Search on TV & RADIO Mode. L/R (Volume Control : 0 ~ 40), Move Cusor on DVD Mode, UP/DW (TV/RADIO Search) Restart POWER ON/OFF... - Page 12 Using the KEY 3D Stereo Surround on DVD Mode. DVD Surround Off->Rock->Pop->Live->Dance->Techno ->Classic->Soft->Off Select play mode on DVD Mode (RANDOM,SINGLE,REPEAT ONE, REPEAT FOLDER, FOLDER,CHAPTER REPEAT,TITLE REPEAT) But it depends on Discs. Stop play on DVD Mode Track Down(Chapter) on DVD Mode Replay and Pause on DVD Mode Track Up(Chapter) on DVD Mode * Ref : The above KEYS operate only on DVD Mode.
-
Page 13: Remote Control
Remote control RADIO TV Power ON/OFF & Change MODE Monitor OPEN/CLOSE Turns On/Off Audio & Change NAVI MODE Memory CH Memory CH DISC DOWN Memory CH Memory CH Memory CH Memory CH Memory CH Memory CH TRACK UP Memory CH Memory CH Memory CH Memory CH... - Page 14 Remote control RADIO TV TA(RDS) EU ONLY PTY(RDS) EU ONLY FRONT LCD DISPLAY BAND BAND AS/PS AS/PS LIST OF CH BEFORE CH SEEK- SEEK- SEEK+ SEEK+ CLOCK ON/OFF MAIN MENU MONITOR VISIBLE ANGLE MONITOR DISTANCE CHANGE EJECT AUDIO ANGLE A ▶ B 3D SOUND ZOOM REPLAY...
-
Page 15: Compatibility Of The Unit
Compatibility Of The Unit Description of the Compatibility of the Product For some DVDs, some operations may not be enabled depending on software characteristics. Also, a method of systematizing the dual operation mode title and chapter while playing with disks enabling menu operation may cause the function of repeated play not to be performed. -
Page 16: Main Key
Main KEY - POWER ON / OFF ♣ Ref : All functions of this unit must be on ACC. - POWER On/Off on Remote Control KEY(Left) and Front Button(Right). - OPEN / CLOSE MONITOR - OPEN / CLOSE Monitor by Remote Control and Front Button. - AUDIO CONTROL - Control sound by Remote Control KEY(Left) and Front Button(Right). -
Page 17: Osd Display Menu - Main Menu
OSD Display Menu (Main Menu) - MAIN MENU SYSTEM PICTURE SCREEN SOUND EXIT SELECT : Press MENU KEY and SEL KEY for the above picture. Push Arrows KEY of Remote Control. ◎ SYSTEM : Setting Time, ON/OFF Buzzer, REAR CAMERA ON/OFF, NAVIGATION ON/OFF. -
Page 18: System Menu (Page
System Menu (Page 1) - SYSTEM MENU(PAGE1) WATCH BUZZER CAMERA NAVI NEXT PAGE RETURN SELECT : ▲ ▼ SYSTEM MENU has 2 pages. Move to SYSTEM MENU from selecting Arrow KEY of MAIN MENU for setting SYSTEM MENU. ◎ WATCH : Press Arrows Key for control of TIME. ◎... - Page 19 System Menu (Page2) -SYSTEM MENU(PAGE 2) LOCK MODIFY RESET BACK PAGE RETURN SELECT : ▲ ▼ ◎ LOCK : Lock Function Be sure to enter Pass word for Lock Function when you turn on. Initial Pass Word is "1234". ◎ MODIFY : Modify Pass Word Of Lock Function. For changing pass word.
-
Page 20: Picture Menu
Picture Menu -PICTURE MENU BRIGHT CONTRAST : 0 COLOR TINT DIMMER RETURN ▶ [ SELECT : ▲ ▼ Press Picture KEY by UP/DW cursor for setting Picture Display. ◎ BRIGHT, CONTRAST, COLOR, TINT, DIMMER : By using UP/DW KEY or L/R KEY. ♣... -
Page 21: Screen Menu
Screen Menu -SCREEN MENU WIDE RETURN SELECT : ▲ ▼ Press SCREEN KEY by UP/DW cursor for setting SCREEN DISPLAY (SCREEN SIZE). ◎ Adjust screen size (WIDE). (FULL ☞ WIDE ☞ NORMAL) ♣ Ref : FULL SCREEN WIDE RATIO - 16:9 SCREEN NORMAL - 4:3 SCREEN SCREEN MENU... -
Page 22: Sound Menu (Page
Sound Menu (Page1) -SOUND MENU(PAGE 1) FADER BALANCE TREBLE BASS NEXT PAGE RETURN ▶ [ SELECT : ▲ ▼ Press SOUND KEY by UP/DW cursor for setting SCREEN DISPLAY (Volume & Sound). ◎ FADER, BALANCE, TREBLE, BASS : BY UP/DW and L/R KEY. ♣... - Page 23 Sound Menu (Page2) -SOUND MENU(PAGE 2) WOOFER CENTER BACK PAGE : 0 NEXT PAGE RETURN SELECT : ▲ ▼ The second page of sound menu as the above will appear when pressing NEXT PAGE in page 1 of sound menu. ◎...
-
Page 24: Radio Mode
Radio Mode FM : 87.50MHz - Pch List - (1) 87.50MHz (2) 90.10MHz (3) 98.10MHz (4) 100.70MHz (5) 107.10MHz (6) 108.00MHz Press Mode KEY of Remote Control & this unit's front button for Radio Mode Change. ♣ Ref : RADIO☞CD CHANGER☞AV1☞AV2☞AV3☞TELEVISION☞DVD DECK (CD changer may not appear on this OSD without setting CD changer. -
Page 25: Tv Mode
TV Mode BAND - TV Mode Press mode key of Remotoe Control & this unit's front button for TV MODE change. - Band Modify : By pressing this unit's front button or Remote Control Button. - Channel Modify : By pressing Remote Control Button DVD(Arrows Button) longer. - Page 26 TV Mode - TV Mode NOW SCANNING ‥‥‥‥ 5 - Save & Search Channel : Save Channel choosen to No 1~6 by pressing AS/PS button or Remote Control. - Seeing by Saved Channel : Seeing saved Channel by pressing Remote Control ( L/R KEY ) or this unit's front button ( UP/DW).
-
Page 27: Dvd Mode
DVD Mode DVD Mode Press Modify KEY of Remote Control & this unit's front button for DVD MODE ( or insert CD for DVD MODE) - Play of DISC Insert a DISC into a CD slot for play of DISC. When you insert a disc, this unit will operate automatically. -
Page 28: Basic Disc Menu Control
Basic Disc Menu Control - Basic PlayBack Control PLAY/PAUSE( ) : Start playback or pause a disc is playing (Press again to restart playback). STOP( ) : Stop playback ) : Press for fast backward search ) : Press for fast forward search PREV( ) : Skip to the previous chapter NEXT(... -
Page 29: Mp3 Disc
MP3 DISC - PLAYING MP3 DISCS 1. Insert the MP3 disc. Disc's label must be facing up. 2. MP3 menu screen is displayed automatically depending on MP3 disc's folder(directory) structure. 3. Using the UP( ▲ ) or DOWN( ▼ ) button to find the desired folder. 4. - Page 30 MP3 DISC 7. If pressing the number of songs through using of Remote Control and a desired song is displayed. 8. Viewing the song being replayed : If pressing the RTN key of the Remocon when the cursor is at another song, the cursor moves to the song being replayed. NOTE! - The file name is only displayed in English.
-
Page 31: Fast Forward / Backward
Fast Forward / Backward Use the function to play the DISC contents in Fast Forward or Fast Reverse. During searching, audio will be muted (except CD-DA ). 1. Press the FR( ) of FF( ) button during disc play. 2. Press the PLAY/PAUSE ( ) button to resume normal playback. -
Page 32: Dvd Mode (Set Up Display & Language)
DVD Mode (Set Up Display & Language) You can display the playback on TV screen as following ; Title,Chapter Number, Playing Time, Disc. 1. Press the DISP button during play. - Disc, Chapter(DVD),Track(CD-DA), Time information appears on screen. 2. To turn off the on-screen display, press the DISP button. Selecting Audio Language It is possible to change the audio soundtrack language to a different language from the one selected at the initial settings. -
Page 33: Subtitle
Subtitle When DVD is recorded with subtitles,you can see the subtitle features to view the subtitle on the screen. 1. Press the SUB/T button during disc play. The subtitle info banner appears. The default is Subtitle off. If no subtitle are recorded, the( ) icon will appear. -
Page 34: Multi Mode Play
Multi Mode Play Multi Mode Play - TITLE, CHAPTER (DVD), TRACK (CD-DA) You can select Play and Repeat mode for desired title, chapter(DVD), track(CD-DA) 1. Press the Multi Mode Button (M/M-) during play. - When press the Multi Mode (M/M) Button, it will be changed as the belows. -
Page 35: Repeat Mode ( A / B )
Repeat (A/B) 1. During playback, press the A/B button at the beginning of the desired section. 2. Press the A/B button again at the end of the section. "AB" will be displayed on the screen then the A/B section is continually repeated. 3. -
Page 36: Zoom Mode
Zoom Mode ZOOMING A PICTURE 1. Press the ZOOM button during playback 2. Each press of the ZOOM button changes the zoom mode in the following 3. If you press the direction button during the ZOOM mode, the ZOOM point will shift. 4. -
Page 37: Section Repeat
DVD Mode ( Repeat A Specific Section ) SECTION REPEAT 1. Press "A/B" button for repeating a specific section users want. 2. Press "A/B button" one more time for replaying section between A and B. 3. Press "A/B" button one more until "AB" disappears when returning to normal play mode. -
Page 38: Dvd Mode(Vcd Pbc Function)
DVD Mode ( VCD PBC Function ) PBC (PLAY BACK CONTROL) function is available only for compatible Discs. Users can control On and Off with PBC button of remote control after inserting a Disc. ♣ Ref : PBC is the same function as SKIP FORWARD function for selecting track. PBC main screen appears by pressing PBC key when watching a VCD. -
Page 39: Dvd (Control Dvd Mode On Operation)
DVD Mode ( DVD Control Mode On Operation ) DVD Control Mode on operation. Press GOTO KEY on operation for the below OSD picture. Users can use ENTER AND REMOTE CONTROL KEY on operation. -
Page 40: Dvd Mode(General Setup)
DVD Mode ( DVD - General Setup ) - DVD Setup menu appears if you press SET UP KEY longer. This function needs to be no disc in the DVD player on operation. All functions of SET UP MENU are possible to select in case of NO DISC. Some functions of SET UP MENU are available to select on playing DVD. -
Page 41: Dvd Mode(Audio Setup)
DVD Mode ( Audio Setup ) - AUDIO SETUP PAGE DOWNMIX : According to Audio system connected in DOWNMIX of speaker setup, users can select LT/RT (TV mono), STEREO(TV stereo), V surround(surround), OFF (5.1CH speaker). FRONT SPEAKER : Large One for Wideband is available to low frequency. Small One is for normal. -
Page 42: Spdif Setup
DVD Mode ( Audio Setup ) - SPDIF SETUP Set up Digital Audio Output 1. SPDIF OUTPUT It can be used when digital amp is connected with this function. 2. When setting up SPDIF OUTPUT by MANUAL, audio output format will be selected according to each audio format. When choosing PCM commonly in DIGITAL/DTS/MPEG/CD/DOLBY, audio stream composed of PCM date outputs at a decoded PCM data. -
Page 43: Dolby Digital Setup
DVD Mode ( Audio Setup ) -DOLBY DIGITAL SETUP -CHANNEL DELAY -EQUALIZER DUAL MONO : This function is for Mono Audio & TV. DYNAMIC : This function is for TV sound , or Stereo System troubles. Please control with Arrows Key after pressing ENTER. - Page 44 DVD Mode ( Audio Setup ) -3D PROCESSING PRO LOGIC Ⅱ : It plays with 5.1CH with upgraded matrix decoder. 1. MODE : Select Project II Mode 2. PANORAMA : It plays panorama sound effectively and broadly. 3. DIMENSING : Control of volume between rear and front speaker. It is for 2 CH.
-
Page 45: Dvd Mode(Video Setup)
DVD Mode ( Video Setup ) -QUALITY CONTRAST : Control by using Arrows Button. GAMMA : Control by using Arrows Button. HUE : Control of Color tone by by Arrows Button. SATURATION : Control by using Arrows Button. LUMA DELAY : Control of image quality by selecting Luma(Y signal) Delay. SHARPNESS : This function is for Screen Sharpness. -
Page 46: Dvd Mode(Dvd Setup - Preference)
DVD Mode ( DVD Setup-Preference ) - TV TYPE Select VIDEO SIGNALS and NTSC or PAL SYSTEM. Mutil for auto select. Select MULTI if users want to change automatically. In case of selecting MULTI the screen may blink for a while. KOREA - NTSC system. - Page 47 DVD Mode ( DVD Setup-Preference ) - SUBTITLE Specific language may set up on playing DVD. (Each language is different according to Disc) - DISC MENU Users can select specific language according to Discs. - PARENTAL This function for protecting childrens from the prohibited movie. Users can select LEVEL out of 8 LEVLES.
-
Page 48: Password Mode
DVD Mode ( DVD Setup-Preference ) - PASSWORD MODE Users can change pass word with choosing ON/OFF.. - PASSWORD Firstly set up pass word change. Enter 4 digits(pass word) users want. (Include existing and new pass word) Select "OK" after entering new pass word. Note! - Do not lose your pass word. -
Page 49: Dvd Mode(Dvd Setup - Exit)
DVD Mode ( DVD Setup-EXIT ) - EXIT If you want to exit from DVD SETUP MENU, please select EXIT and press ENTER. ♣ Ref : DVD DISC REGION CODE Before playing DVD, please check connection between TV & SPEAKERS INPUTS and OUTPUTS correctly. Select external INPUT after pressing TV / OUTPUT button. -
Page 50: Dvd Mode(Random Play)
#### DVD Mode ( Random Play ) Random Play This function is used to play the Title,Chapter and Tracks on the disc in order to desired procedures. 1. Press the PROG button on remote controller.Program menu is displayed on screen. 2. -
Page 51: Osd Menu (A/V, Navi, Camera)
OSD Menu ( A/V, NAVI, CAMERA ) A/V 1 If switching Off CAMERA & NAVI, it displays as the left picture when changing MODE. At this time users can use sounds and pictures of other devices that thery are connected with AV1, AV2, and AV3 A/V 2 AV2 : Users can use on CAMERA MODE ON. -
Page 52: Cd / Dvd Changer Mode (Option)
CD & DVD Changer Mode - If CDC of the AV BOX was mounted on, CDC will play after pressing MODE key. - Changer Display : It displays the count of DISC ( 6 Discs or 12 Discs). - Current DISC : It displays the number of DISC is playing. - Current TRACK : It displays the number of TRACK is playing. - Page 53 CD & DVD Changer Mode - DISC Change : Through the use of the - TRACK Change : Through the use of the changed. - RANDOM Replay : By pressing the replay. But, random replay is done only for DISC that has been replayed. Press Shortly >>...
-
Page 54: Rds Radio(Europe Only)
RDS Radio ( Europe ) TITLE BAR (PS NAME) - Pch List - (1) 87.50MHz (2) 90.10MHz (3) 98.10MHz (4) 100.70MHz (5) 107.10MHz (6) 108.00MHz RDS is available only in Europe, users can control PTY, AF, TA button of Remote Control on Radio Mode. (When using this function, displays for PTY, AF and TA appears on monitor. - Page 55 RDS Radio ( Europe ) RDS Information AF : If this frequency sensitivity is low, AF will be blinking on monitor. When frequency is complete, the blinking stops. - ON RADIO MODE TA indicator will be blinking for searching channels when this unit receives TA signal. And then TA changes when it is completed to find channels.
