Pullman Holt 45HEPA-D Operation & Care Instructions

45-10 gallon dry hepa filter poly vacuum
Hide thumbs

Advertisement

Quick Links

45-10 Gallon Dry HEPA Filter Poly Vacuum
This vacuum cleaner is a high quality, precision made product. All parts used in
the manufacturing of this vacuum cleaner have passed rigid quality control stan-
dards prior to assembly and an "each unit" final inspection prior to packaging to
assure proper assembly. This vacuum cleaner was protectively packed to pre-
vent possible damage in transit. Should damage occur, please notify the
transporting carrier immediately for loss and/or claim.
TO CONNECT THE HOSE
Simply push the swivel hose cuff into the tank inlet until the lock
feature engages. Press the button to remove the hose assembly.
The wand and/or tools are attached to the opposite (non-swivel)
end of the hose.
DRY OPERATION
The cloth filter located inside the can provides highly efficient sepa-
ration of dust and dirt particles from the incoming air stream.
CAUTION
Never operate the vacuum cleaner unless the HEPA and never
clog filter is in good condition and properly installed.
The use of a disposable paper bag is strongly recommended for
picking up very fine dry materials. The paper bag not only makes
dirt disposal clean and convenient, but also provides an additional
layer of filtration. CLEAN CLOTH FILTER AFTER EACH USE!
DRY FILTER CLEANING
Remove the filter from the vacuum and clean by brushing the
Never-Clog bag to remove direct accumulation from outer surface.
Do not attempt to clean the HEPA filter.
MOTORHEAD
When removing the motorhead, care in handling is essential.
Dropping, banging or other abuse may result in a poor vacuum seal
and loss in suction power.
STORAGE
Store in a dry location indoors. Wrap the cord carefully around the
vacuum head to avoid accidental damage. Clean the tank, filter,
hose and tools prior to storage.
CAUTION
Never lubricate the vacuum cleaner motor. The motor bear-
ings are permanently sealed. Introduction of lubricant into
the motor may cause premature failure.
Operation & Care Instructions
Save For Future Reference
ABOUT THE MACHINE
NEVER USE THIS VACUUM CLEANER TO PICK UP COMBUS11BLE OR
EXPLOSIVE MATERIALS SUCH AS GASOUNE OR KEROSENE, ETC.
HAZARDOUS MATERIAL PICKUP & CLEAN-UP
FOR DRY OPERATION:
With the HEPA Filter Assembly in place, the motor head securely
clamped, and the hose adapter connected to the inlet, plug the
power cable into the proper outlet. Select the appropriate hose,
wand and/or tool and connect to the hose adapter. The vacuum
cleaner is ready for dry use.
DISPOSABLE BAG CHANGING:
Over filling the bag will result in loss of vacuum efficiency. The rec-
ommended bag replacement procedure is as follows:
1. Remove vacuum head and HEPA filter.
2. Tape a 6-mil poly bag over the canister so that the canister is
completely enclosed.
3. Using the poly bag as a glove, disengage the paper bag from the
vacuum inlet stem inside the canister.
4. Invert the canister so that the paper bag tails into the poly bag.
Seal the poly bag and dispose as prescribed by law.
5. Attach a new paper bag to the vacuum inlet securely and fold
the top of the bag down so it does not interfere with the HERA
filter.
6. Replace the HEPA filter and motor head.
7. Thoroughly vacuum the work area to recover any asbestos dust
which may have been dropped.
Dacron "Never Clog"
Filter Bag: H.E.P.A. filter equipped vacuums are sup-plied with a white
"Never Clog" filter bag surrounding the H.E.P.A. filter barrel. The bag
should be changed fre-quently and can be washed in laundry deter-
gent and warm water.
Warning
A used filter is contaminated and must be disposed of in
accordance with local and federal E.P.A. regulations.

Advertisement

loading

  Related Manuals for Pullman Holt 45HEPA-D

  Summary of Contents for Pullman Holt 45HEPA-D

  • Page 1 Operation & Care Instructions 45-10 Gallon Dry HEPA Filter Poly Vacuum This vacuum cleaner is a high quality, precision made product. All parts used in the manufacturing of this vacuum cleaner have passed rigid quality control stan- dards prior to assembly and an “each unit” final inspection prior to packaging to assure proper assembly.
  • Page 2: Grounding Instructions

    17. Be sure that the vacuum is connected to a properly grounded outlet, inspect the ground pin on the power cord prior to each use. 18. Do not use this vacuum to pick up hazardous materials unless the vacuum is equipped with an appropriate HEPA filter. –...
  • Page 3: Replacement Parts List

    Ref. Part No. Description B701878 Handle Vac Head B701879 Dome - Red B701881 On - Off Electrical Switch B701880 Power Head Plug Assembly Plug Shield (Part of Plug Assembly) B701884 Motor Head Chamber - Red B701896 Motor Retainer - Top B701883 Foam Baffle - Silencing B701897...
  • Page 4: Trouble Shooting Guide

    Labor - 1 year In NO circumstance should you return a failed unit to the factory or a service center. If you experience any problems with your vacuum during the warranty period, contact the Pullman-Holt National Service Manager in Tampa, FL at (800)237-7582.
