3. 1. 1. 2

Manual Jam

1. Pull up the Engine Unit Open Levers (1) to open the Engine Unit.
1
NOTE
Do not open the Engine Unit when the Scanner Unit is opened.
If the Scanner Unit is opened, it will hit the bottom of User Interface.
2. Remove the mis-fed paper pulling frontward.
3. Close Engine Unit.
NOTE
(1) Be sure to close the Engine Unit firmly until it is locked at the correct position.
(2) The mis-fed paper can be replaced with a new one, or be inserted at the opposite edge to
the feeder. An extreme crease may cause a paper jam.
3-5 Chapter 3 Error Correction
