  • Page 1 CLP 3521 | 3621 | 3626 instruction Handbook Colour Printer...

  • Page 2: Table Of Contents

    Contents Legal and Safety Information Machine Parts Components at the Front of the Printer ........1-2 Components at the Left of the Printer ........1-2 Internal Components ..............1-3 Components at the Rear of the Printer ........1-3 Operation Panel ................. 1-4 Handling Paper General Guidelines ..............
  • Page 3 General Information ..............7-2 Expansion Memory Modules ............ 7-3 General Description of Options ..........7-5 Computer Interface Interface ..................8-2 USB Interface ................8-2 Network Interface ............... 8-3 Specifications Glossary Index...

  • Page 4: Legal And Safety Information

    Legal and Safety Information CAUTION NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED BY IMPROPER INSTALLATION. Notice on Software SOFTWARE USED WITH THIS PRINTER MUST SUPPORT THE PRINTER'S EMULATION MODE. The printer is factory-set to emulate the PCL. Notice The information in this guide is subject to change without notification. Additional pages may be inserted in future editions.
  • Page 5 License Agreements Typeface Trademark Acknowledgement All resident fonts in this printer are licensed from Monotype Imaging Inc. Helvetica, Palatino and Times are registered trademarks of Linotype-Hell AG. ITC Avant Garde Gothic, ITC Bookman, ITC ZapfChancery and ITC Zapf Dingbats are registered trademarks of International Typeface Corporation.
  • Page 6 Your exclusive remedy and the sole liability of Monotype Imaging in connection with the Software and Typefaces is repair or replacement of defective parts, upon their return to Monotype Imaging. 10 IN NO EVENT WILL MONOTYPE IMAGING BE LIABLE FOR LOST PROFITS, LOST DATA, OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES CAUSED BY ABUSE OR MISAPPLICATION OF THE SOFTWARE AND...

  • Page 7: Original Ssleay License

    Redistributions of any form whatsoever must retain the following acknowledgment: "This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http:// www.openssl.org/)" THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT "AS IS" AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
  • Page 8 If you include any Windows specific code (or a derivative thereof) from the apps directory (application code) you must include an acknowledgement: "This product includes software written by Tim Hudson (tjh@cryptsoft.com)" THIS SOFTWARE IS PROVIDED BY ERIC YOUNG "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.

  • Page 9: Interface Connectors

    Compliance and Conformity This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 10: Safety Information

    This machine contains a transmitter module. We, the manufacturer (UTAX GmbH) hereby declare that this equipment (page printer), model CLP 3521, CLP 3621 and CLP 3626 are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
  • Page 11 because there is a danger of getting burned. Label inside the printer (Laser radiation warning) Cautionary Labels The printer bears any of the following labels. For Europe, Asia...

  • Page 12: Cdrh Regulations

    CDRH Regulations The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2, 1976. These regulations apply to laser products manufactured after August 1, 1976. Compliance is mandatory for products marketed in the United States.
  • Page 13 7779. Disclaimer UTAX GmbH will not be liable to customers or any other person or entity for any loss or damage caused or alleged to be caused directly or indirectly by equipment sold or furnished by us, including but not limited...

  • Page 14: Energy Saving Control Function

    Energy Saving Control Function The device comes equipped with a Low Power Mode where energy consumption is reduced after a certain amount of time elapses since the device was last used, as well as a Sleep Mode where printer functions remain in a waiting state but power consumption is still reduced to a minimum when there is no activity with the device within a set amount of time.

  • Page 15: Installation Precautions

    Installation Precautions Environment CAUTION Avoid placing the printer on or in locations which are unstable or not level. Such locations may cause the printer to fall. This type of situation presents a danger of personal injury or damage to the printer. Avoid locations with humidity or dust and dirt.
  • Page 16 Power Supply/Grounding the Printer WARNING Do not use a power supply with a voltage other than that specified. Avoid multiple connections in the same outlet. These types of situations present a danger of fire or electrical shock. Plug the power cord securely into the outlet. If metallic objects come in contact with the prongs on the plug, it may cause a fire or electric shock.

  • Page 17: Precautions For Use

    Precautions for Use Cautions when Using the Printer • Do not place metallic objects or containers with water (flower vases, flower pots, cups, etc.) on or near the printer. This type of situation presents a danger of fire or electrical shock should they fall inside. •...
  • Page 18 Other Precautions • Do not place heavy objects on the printer or cause other damage to the printer. • Do not open the top/left/rear cover, turn off the main switch, or pull out the power plug during printing. • During printing, some ozone is released, but the amount does not cause any ill effect to one's health.
  • Page 19 About the Operation Guide This Operation Guide has the following chapters: Chapter 1 - Machine Parts This chapter explains the names of parts. Chapter 2 Handling Paper Explains how choose, handle and load paper. Chapter 3 - Printing Operation This chapter explains how to print from your workstation. Chapter 4 - Maintenance This chapter explains how to replace the toner container and how to care for your printer.
  • Page 20 Caution Cautions are statements that CAUTION Do not pull the cassette out suggest mechanical damage as a when holding the front of the machine. result of an action. Warning Used to alert users to the possibility WARNING High voltage is present in the of personal injury.

  • Page 22: Machine Parts

    1 Machine Parts This chapter provides explanations and illustrations for you to determine the parts and their functions. Try to be familiar with the names and functions of these parts for correct use and optimal performance. This chapter contains explanations on the following topics: Components at the Front of the Printer Components at the Left of the Printer Internal Components...
  • Page 23 Components at the Front of the Printer Operation Panel Front Cover Paper Stopper Top Cover (Top Tray) MP (Multi-Purpose) Tray Paper Cassette Power Switch Components at the Left of the Printer 11 12 13 14 Left Cover Waste Toner Box 10 Main Charger Units on the Drum Units 11 Magenta Toner Container (M) 12 Cyan Toner Container (C)

  • Page 24: Internal Components

    Internal Components 15 Paper Transfer Unit 16 Paper Ramp 17 Duplex Unit 18 Envelope Switch Components at the Rear of the Printer 22 23 19 USB Memory Slot 20 Power Cord Connector 21 Option Interface Slot 22 Network Indicators 23 Network Interface Connector 24 USB Interface Connector 25 Rear Cover Machine Parts...

  • Page 25: Operation Panel

    Operation Panel 27 28 33 34 26 Message Display 27 Ready Indicator 28 Data Indicator 29 Attention Indicator 30 Arrow Keys 31 [MENU] Key 32 [OK] Key 33 [GO] Key 34 [Cancel] Key Machine Parts...

  • Page 26: Handling Paper

    2 Handling Paper This chapter contains explanations on the following topics: General Guidelines Selecting the Right Paper Paper Type 2-13 Loading Paper 2-14 Handling Paper...

  • Page 27: Paper Availability

    General Guidelines The machine is designed to print on standard copier paper (the type used in ordinary dry copier machines), but it can also accept a variety of other types of paper within the limits specified below. Note The manufacturer assumes no liability for problems that occur when paper not satisfying these requirements is used.

  • Page 28: Recommended Paper

    Minimum and Maximum Paper Sizes The minimum and maximum paper sizes are as follows. For non standard paper such as transparency, labels, vellum, cardstock, envelope, coated and thick, the MP (Multi-Purpose) tray must be used. Paper Cassette MP Tray Minimum Minimum Paper Size Paper Size...
  • Page 29 Selecting the Right Paper This section describes the guidelines for selecting paper. Condition Avoid using paper that is bent at the edges, curled, dirty, torn, embossed, or contaminated with lint, clay, or paper shreds. Use of paper in these conditions can lead to illegible printing and paper jams, and can shorten the life of the machine.

  • Page 30: Basis Weight

    Smoothness The paper should have a smooth, uncoated surface. Paper with a rough or sandy surface can cause voids in the printed output. Paper that is too smooth can cause multiple feeding and fogging problems. (Fogging is a gray background effect.) Basis Weight Basis weight is the weight of paper expressed in grams per square meter (g/m²).

  • Page 31: Moisture Content

    Moisture Content Moisture content is defined as the percent ratio of moisture to the dry mass of the paper. Moisture can affect the paper’s appearance, feed ability, curl, electrostatic properties, and toner fusing characteristics. The moisture content of the paper varies with the relative humidity in the room.

  • Page 32: Special Paper

    Packaging: Paper should be packed in a sturdy carton to protect it from damage during transport. Quality paper obtained from a reputable supplier is usually correctly packaged. Note You might see the printer emitting steam in the area around the top tray if you use damp paper, but it is safe to continue printing.
  • Page 33 Transparency Transparencies must be able to withstand the heat of fusing during the printing process. The recommended transparency product is 3M CG3700 (Letter, A4). The table below lists the specifications for transparency: Item Specification Tolerance of heat Must tolerate at least 190 °C (374 °F) Thickness 0.100 to 0.110 mm (3.9 to 4.3 mils) Material...
  • Page 34 Labels Labels must be fed from the MP tray. The basic rule for printing on adhesive labels is that the adhesive must never come into contact with any part of the machine. Adhesive paper sticking to the drum or rollers will damage the machine. Label paper has a structure comprising of three layers, as shown in the diagram.
  • Page 35 Postcards Fan the stack of postcards and align the edges before loading them in the MP tray. Make sure the postcards you are going to set are not curled. Feeding curled postcards may cause paper jams. Some postcards have rough Rough edges on the back (those are Edge...

  • Page 36: Thick Paper

    Thick Paper Fan the stack of paper and align the edges before loading them in the MP tray. Some types of paper have rough edges on the back (those are created when the paper is cut). In this case, put the paper on a flat place and rub the edges once or twice with, for example, a ruler to smooth them.
  • Page 37 Paper Type Indicators (Optional paper feeder PF-510) If you are going to load non standard paper in the optional paper feeder PF-510, cut out the blank section of the attached paper type indicator sheet, fold the remaining sheet in half and insert it into the cassette's display folder so that the paper type symbol is displayed.

  • Page 38: Paper Type

    Paper Type The printer is capable of printing under the optimum setting for the type of paper being used. Setting the paper type for the paper source from the printer’s operation panel will cause the printer to automatically select the paper source and print in the mode best suited to that type of paper.

  • Page 39: Loading Paper

    Loading Paper The following explains the procedure for loading paper in the cassette and the MP tray. Loading Paper into the Cassette Fan the media (paper/transparencies), then tap it on a level surface to avoid media jams or skewed printing. Pull the paper cassette all the way out of the printer.
  • Page 40 Pull the release lever of both side guides and slide to the desired Paper Guides paper size. Release Lever Pull the release lever and slide the paper stopper to the desired paper Release Lever size. Paper Stopper When using non-standard size paper, move the paper guides and paper stopper all the way out, insert the paper, then adjust the paper guides and paper stopper to the size of the paper.
  • Page 41 Insert the paper cassette into the slot in the printer. Push it straight in as far as it will go. There is a paper gauge on the right side of the front of the paper cassette to indicate the remaining paper supply. When paper is exhausted, the pointer will go down to the level of (empty).
  • Page 42 Adjust the position of the paper guides on the MP tray. Standard paper sizes are marked on the MP tray. For standard paper sizes, slide the guides to the position marked correspondingly. Align the paper with the paper guides and insert as far as it will go. Note Do not load more paper than will fit under the load limits on the inside of the MP tray.

  • Page 43: Paper Stopper

    Paper stopper Align the paper stopper to the desired paper size. • For A4 or Letter size paper : Align with position • For Legal size paper : Align with position 2-18 Handling Paper...

  • Page 44: Printing Operation

    3 Printing Operation This chapter contains explanations on the following topics: Changing Network Interface Parameters Printing a Network Interface Status Page 3-10 Installing the Printer Driver 3-11 Printing from Application Software 3-17 Printing Operation...
  • Page 45 Changing Network Interface Parameters This printer supports TCP/IP, TCP/IP (IPv6), NetWare, AppleTalk, IPP, SSL Server, IPSec protocols and Security Level. (For details refer to Advanced Operation Guide.) Note After all network related settings have been done, turn the machine OFF and ON again. This is mandatory to make the settings effective! TCP/IP, TCP/IP (IPv6) settings Press [MENU].

  • Page 46: Subnet Mask

    TCP/IP This section describes how to enable the TCP/IP protocol. If TCP/IP is set to Off, use to select On and press [OK]. >TCP/IP > Press . Each time you press , the selection changes. >>DHCP >>IP Address 000.000.000.000 >>Subnet Mask 000.000.000.000 >>Gateway 000.000.000.000...
  • Page 47 TCP/IP (IPv6) This section describes how to enable the TCP/IP (IPv6) protocol. If TCP/IP (IPv6) is set to Off, use to selecto On and press >TCP/IP (IPv6) > [OK]. Press . Each time you press , the selection changes. >>RA(Stateless) >>DHCPv6 Display the item you want to set and press [OK].
  • Page 48 Press . Each time you press , the selection changes. Refer to the explanations below when specifying the settings. If you are using NetWare, AppleTalk, IPP, SSL Server or IPSec to connect to a network, you must enter an administrator ID. By default, the administrator ID is the numeric part of your printer's model name.

  • Page 49: Security Level

    Set the Security Level to High. >Security Level High NetWare This section explains the procedure for enabling NetWare. Enter the administrator ID and password. Then, if NetWare is set to >NetWare > Off, use to select On and press [OK]. Press >>Frame Type Auto...
  • Page 50 AppleTalk This section explains the procedure for enabling AppleTalk. Enter the administrator ID and password. Then, if AppleTalk is set >AppleTalk to Off, use to select On. Press [OK]. A blinking question mark (?) appears. >AppleTalk Press [OK] again. Press [MENU]. The display returns to Ready. This section explains the procedure for enabling IPP.
  • Page 51 SSL Server This section explains the procedure for enabling SSL Server. Enter the administrator ID and password. Then, if SSL Server is set >SSL Server > to Off, use to select On and press [OK]. Press . Each time you press , the selection changes.
  • Page 52 Security Level Security Level is primarily a menu used by service personnel for >Security Level maintenance work. There is no need for customers to use this menu. High Printing Operation...

  • Page 53: Printing A Network Interface Status Page

    Printing a Network Interface Status Page You can print out a status page for the network interface. The network status page shows the network addresses, and other information under various network protocols about the network interface. Adjust/Maintenance Adjust/Maintenance is used to adjust the print quality and to carry out printer maintenance.

  • Page 54: Installing The Printer Driver

    Installing the Printer Driver Ensure the printer is plugged in and connected to the PC before installing the printer driver from the CD-ROM. Installing the Software in Windows If you are connecting this printer to a Windows PC, follow the next steps to install the printer driver.
  • Page 55 Express Mode In Express Mode, the installer automatically detects the printer when it is turned on. Use Express Mode for standard connection methods. In the installation method selection window, select Express Mode. The print system detection window appears and the installer detects the connected printers.
  • Page 56 Custom Mode Use Custom Mode if you want to specify the printer port and select the software to be installed. For example, if you do not want fonts installed on your computer to be replaced, select Custom Mode and deselect the Fonts checkbox in the installation window.
  • Page 57 The printer driver installation program starts up. Choose Select Destination, Installation Type and then install the printer driver as directed by the instructions in the installation software. Note In addition to Easy Install, the Installation Type opti- ons include Custom Install, which allows you to specify the components to be installed.
  • Page 58 Click the IP icon for an IP connection or the AppleTalk icon for an AppleTalk connection and then enter the IP address and printer name. Select the installed printer driver and click Add. Select the options available for the printer and click Continue. Printing Operation 3-15...
  • Page 59 The selected printer is added. This completes the printer setup procedure. 3-16 Printing Operation...

  • Page 60: Printing From Application Software

    Printing from Application Software The steps required to print a document created with an application are explained below. You can select the printing Paper Size and Output Destination. Load the paper required into the paper cassette. From the application File menu, select Print. The Print dialog box displays.

  • Page 61: Status Monitor

    Status Monitor The Status Monitor monitors the printer status and provides an ongoing reporting function. It also allows you to specify and modify settings for printers not included in the KX driver. The Status Monitor is installed automatically during KX driver installation. Accessing the Status Monitor Use either of the methods listed below to launch the Status Monitor.
  • Page 62 3D View This shows the status of the monitored printer as a 3D image. You can choose whether to show or hide the 3D view from the menu displayed when you right-click the Status Monitor icon. If an information notification event occurs, the 3D view and an alert sound are used to notify you.

  • Page 63: Status Monitor Settings

    Status Monitor Settings Use the Preference option to set up the Status Monitor. The Status Monitor has two tabs to configure its settings. Sound Notification Tab The Sound Notification tab contains the following items. IMPORTANT To confirm the settings on Sound Notification tab, the computer requirs the sound capabilities such as sound card and speaker.
  • Page 64 Appearance Tab The Appearance tab is contains the following items. Enlarge window Doubles the size of the Status Monitor window. Always on top Positions the Status Monitor in front of other active windows. Transparency Displays the Status Monitor as a transparent window. Printing Operation 3-21...

  • Page 65: Uninstalling Software (Windows Pc)

    Uninstalling Software (Windows PC) The software can be uninstalled (removed) using the CD-ROM (Product Library) supplied with the printer. IMPORTANT On Macintosh computers, because the printer settings are specified using a PPD (PostScript Printer Description) file, the software cannot be uninstalled using the CD-ROM (Product Library). Exit all active software applications.

  • Page 66: Maintenance

    4 Maintenance This chapter contains explanations on the following topics: General Information Toner Container Replacement Replacing the Waste Toner Box Cleaning the Printer Maintenance...

  • Page 67: Frequency Of Toner Container Replacement

    The life of the toner containers depends on the amount of toner required to accomplish your printing jobs. According to ISO/IEC 19798 and EcoPrint switched off the toner container can print as follows (A4/Letter paper is assumed): CLP 3521 Toner Color Life of the Toner Container (Printable pages) Black...
  • Page 68 Toner Kits For best results, we recommend that you only use genuine UTAX Parts and Supplies. Should any damage be caused by the application of a toner other than the original UTAX toner, then this damage is excluded from the guarantee.

  • Page 69: Replacing The Toner Container

    UTAX toner containers. For optimum performance, it is also recommended to use only the UTAX toner containers which are specifically intended for use in your country or region. If the toner container for another destinations is installed, the printer will stop printing.
  • Page 70 Put the old toner container in the plastic bag (contained in the toner Plastic Bag kit) and discard it later according to the local code or regulations for waste disposal. Take the new toner container out of the toner kit. Shake the new toner container 5 or 6 times as shown in the figure in order to distribute the toner evenly inside the container.

  • Page 71: Replacing The Waste Toner Box

    Replacing the Waste Toner Box Replace the waste toner box when the Check waste toner box message is displayed. A new waste toner box is included with the toner kit. The waste toner box needs to be replaced before the printer will operate.

  • Page 72: Cleaning The Printer

    Open the cap of the new waste toner box. New Waste Toner Box Insert the new waste toner box as shown in the figure. When the box is set correctly, it will snap into place. New Waste Toner Box Make sure that the waste toner box is correctly inserted and close the left cover.

  • Page 73: Cleaning The Printer

    Cleaning the Printer The paper transfer unit should be cleaned each time the toner container and waste toner box are replaced. To maintain optimum print quality, it is also recommended that the inside of the printer be cleaned once a month as well as when the toner container is replaced.
  • Page 74 Wipe away the paper dust on the registration roller and the paper ramp using the cleaning cloth. Paper Transfer Unit Duplex Unit Cleaning Cloth Paper Ramp Transfer Belt (Black) Registration Roller (Metal) Transfer Roller (Black) Note Be careful not to touch the black transfer roller and black transfer belt during cleaning as this may adversely affect print quality.
  • Page 75 4-10 Maintenance...

  • Page 76: Troubleshooting

    5 Troubleshooting This chapter contains explanations on the following topics: General Guidelines Print Quality Problems Error Messages Clearing Paper Jams 5-12 If a problem cannot be corrected, contact your service technician. Troubleshooting...

  • Page 77: General Guidelines

    General Guidelines The table below provides basic solutions for problems you may encounter with the printer. We suggest you consult this table to troubleshoot the problems before calling for service. Symptom Check Items Corrective Action Print quality is not good. Refer to Print Quality Problems on page 5-3.

  • Page 78: Print Quality Problems

    Print Quality Problems The tables and diagrams in the following sections define print quality problems and the corrective action you can conduct to solve the problems. Some solutions may require cleaning or replacing parts of the printer. If the suggested corrective action will not solve the problem, call for service.
  • Page 79 Printed Results Corrective Action Black or white vertical streaks Check the operation panel for toner. If the Toner low C,M,Y,K message is displayed with color description, install a new toner kit for the color. To replace the toner container, refer to Toner Container Replacement on page 4-2.
  • Page 80 Printed Results Corrective Action Grey background Clean the main charger units. For details, refer to LSU/Charger (LSU/Main charger cleaning mode setting) section of the Advanced Operation Guide. Conduct color calibration either by switching the printer off then on or using the printer operation panel.

  • Page 81: Error Messages

    Error Messages The following table lists errors and maintenance messages that you can be dealt with by yourself. If appears, turn off the printer, Call service disconnect the power cord, and contact your service technician. is displayed, turn off the printer Call service Error.Power off.
  • Page 82 Message Corrective Action The top cover of the printer is open. Close the printer top cover. Close top cover This message is displayed when Remove Device was selected while a USB memory was being used. Device busy The previous screen is displayed again 1 or 2 seconds. You attempted to print with a paper size and paper type that cannot be used for duplex Duplex disabled printing.
  • Page 83 No power supply power source and COATED (coated paper) is selected as the paper type setting. Connect it to Cassette a power source via the printer. Displayed when the installed toner is the original UTAX product. Original toner installed Troubleshooting...
  • Page 84 Unknown toner match the printer's. C,M,Y,K Install the specified toner container. Displayed when the installed toner is not the original UTAX product. Install original UTAX Unknown toner toner. installed An error has occurred in the USB memory device. To return the printer to the print-ready USB memory err## status, press [GO].

  • Page 85: Storage Error Codes

    Message Corrective Action • The ID or Password entered for the Job Accounting function is not correct. Check the ID or Password. ID error For more information, refer to Job Accounting (Job Accounting selection/setting) section of the Advanced Operation Guide. •...
  • Page 86 Memory Card and USB Memory Errors Code Meaning The printer does not support the memory card inserted, or the memory card is broken. Insert the correct memory card. For more information, refer to Memory Card (Using the memory card) section of the Advanced Operation Guide.

  • Page 87: Clearing Paper Jams

    MP Tray Paper Cassette Paper Feeder PF-500, PF-510 (Only 2 stacked paper feeders can be used with the CLP 3521) Paper Jam Message Description Reference Page Paper is jammed inside the printer, page 5-13 Paper jam paper cassette or MP tray.

  • Page 88: General Considerations For Clearing Jams

    General Considerations for Clearing Jams Bear in mind the following considerations when attempting jam removal: CAUTION When pulling the paper, pull it gently so as not to tear it. Torn pieces of paper are difficult to remove and may be easily overlooked, deterring the jam recovery. •...
  • Page 89 Paper Jam in Printer Paper is jammed at the paper cassette or inside the printer. Remove the jammed paper using the procedure given below. Press the lever to release the lock. Pull the front cover towards you. If the paper has jammed near the registration roller, as shown in A, remove the paper by pulling it up from the center.
  • Page 90 If the paper has jammed inside the duplex unit, as shown in C, lift the duplex unit and remove the paper by holding it in the middle. Duplex Unit Close the front cover. Paper Jam at Cassette 2 (to 4) Paper is jammed at the paper cassette.
  • Page 91 5-16 Troubleshooting...

  • Page 92: Using The Operation Panel

    6 Using the Operation Panel This chapter contains explanations on the following topics: General Information Understanding the Operation Panel Keys Using the Menu Selection System Setting a Mode Selection Menu 6-10 Report Print 6-11 USB Memory (USB memory selection) 6-17 Job Box 6-19 Counter (Viewing the counter value)

  • Page 93: General Information

    General Information This chapter provides the information you need to configure the Ecosys Color printer. In general you need to use the operation panel only to make default settings. You can make most changes to the printer settings using the printer driver through the application software. Note Changes to printer settings made using a software application override changes made using the operation panel.

  • Page 94: Understanding The Operation Panel

    Understanding the Operation Panel The operation panel on the top of the printer has a 2-line by 16-character liquid crystal display (LCD), eight keys, and three indicators (LED). Messages that appear on the display and functions of indicators and keys are explained in this chapter.
  • Page 95 Status Information Message Meaning The printer is performing self-diagnostics after power-up. Self test The printer is warming up and is not ready. Please wait When the printer is switched on for the first time, this message will take several minutes. This message appears when the printer is preparing to print coated paper (COATED) fed Please wait from the optional paper feeder PF-510.

  • Page 96: Indicators In Message Display

    Indicators in Message Display Ready Ready, Data, and Attention Indicators The following indicators light during normal operation and whenever the printer needs attention. Depending on the status of lighting, each indicator has the following meaning: Indicator Description Flashing. Indicates an error that you can resolve. For details, refer to the Troubleshooting section in the Operation Guide.

  • Page 97: Keys

    Keys The operation panel keys are used to configure the printer operation. Note that certain keys have a secondary function. GO Key Use this key to: • Recover from certain errors. • Recover from Auto Sleep and Low Power mode. Cancel Key This key is used to: •...
  • Page 98 OK Key This key is used to: • Finalize settings of numeric values and other selections. • Set the paper source when Use alternative? is shown in the message display. Using the Operation Panel...

  • Page 99: Using The Menu Selection System

    Using the Menu Selection System Menu Selection System This section explains how to use the menu selection system. [MENU] on the operation panel allows you to use the menu to configure the printer settings to your specific needs. Settings can be made when Ready is indicated on the printer message display.

  • Page 100: Paper Settings

    Selecting a Menu The mode selection menu is hierarchical. Press to display the desired menu. If the selected menu has a sub-menu, > is displayed after the menu. Paper Settings > Press to move to the sub-menu or to go back. Indicates that there is a sub-menu >...

  • Page 101: Setting A Mode Selection Menu

    Setting a Mode Selection Menu This section explains the setting procedures used for each menu item in the mode selection menu. While the printer displays Ready, Please wait, Sleeping and Report Print > Processing, press [MENU]. The mode selection menu is displayed.

  • Page 102: Report Print

    Report Print The printer prints the report. Report Print includes the following items: • Print Menu Map • Print Status Page • Print Fonts List • Print Hard Disk File List • Print RAM Disk File List • Print Mem. Card File List Press [MENU].

  • Page 103: Menu Map

    Menu Map Sample Menu Map Printer CLP 3626 Firmware version 6-12 Using the Operation Panel...

  • Page 104: Status Page

    Print Status Page You can check the printer's current status, including available memory space and option settings by printing a status page. Press while Report Print > is displayed. Press repeatedly until >Print Status Page appears. Press [OK]. A question mark (?) appears. >Print Status Page ? Press [OK] again.
  • Page 105 Firmware Version This item shows the version and release date of the printer firmware. Printer Settings Information This item shows various printer settings for hardware-related items: MP tray paper size and type Paper cassette size and type Sleep time Formfeed timeout time Installed Options This item shows the options installed in the printer: Hard disk...

  • Page 106: File List

    Print Fonts List To help you decide in selecting a font, you can printout lists of the internal fonts or the optional fonts. Press while Report Print > is displayed. Press repeatedly until >Print Fonts List appears. Press [OK]. A question mark (?) appears. >Print Fonts List ? Press [OK] again.
  • Page 107 Print Mem. Card File List This allows you to print a list of the files on a memory card. IMPORTANT This message will be displayed when the memory card installed in the printer. Press while Report Print > is displayed. Press repeatedly until >Print Mem.

  • Page 108: Usb Memory (Usb Memory Selection)

    USB Memory (USB memory selection) This specifies the settings for removing the USB memory and printing USB memory content. IMPORTANT This message is displayed only when the USB host lock is not set. The options available in USB Memory are as follows: •...
  • Page 109 Copies (Number of copies) Sets the number of copies printed of the specified file in USB memory. While Copies in step 5 above is displayed, press Copies to display the number of copies. (E.g.: 10) Press [OK]. Paper Source and a question mark (?) appears. Paper Source ? Cassette 1 Paper Source (Selecting the paper feed source)

  • Page 110: Job Box

    Job Box IMPORTANT To use the Job Box, an optional hard disk must be installed in the printer. The RAM disk may also be used in the Proof-and-Hold and Private Print modes. Job Box is a print function that makes the Job Retention function possible. The settings are specified from the printer driver.
  • Page 111 (Data Name) ID (number of copies) (Input passwords) (Data Name) Copies (number of copies) (Number of copies / deleted) • Job Box Configuration (Job Box Configuration) Press [MENU]. Press repeatedly until Job Box > appears. Job Box > Note that menus shown in the list may vary depending on which optional units installed in the printer.
  • Page 112 Printing Additional Copies using Quick Copy Press while Job Box > is displayed. Press repeatedly until >Quick Copy appears. The name entered in the printer driver (Harold, in this example) also appears. Press [OK]. A blinking question mark (?) appears before the user >Quick Copy name.
  • Page 113 Using Proof-and-Hold When you print multiple copies, this mode first prints one copy so that you can proof it before continuing to print the remaining copies. Since you can proof the printouts before printing the remaining copies, wastage of paper can be reduced.
  • Page 114 Private/Stored (Printing a private print/stored job) In private printing, you can specify that a job is not printed until you release the job from the operation panel. When sending the job from the application software, specify a 4-digit access code in the printer driver. The job is released for printing by entering the access code on the operation panel ensuring confidentiality of the print job.
  • Page 115 Deleting a Private/Stored Job You can individually delete stored jobs by performing the following procedure. Jobs saved using Private Print will be automatically deleted if you turn the power off after printing, but jobs saved using Stored Job will not be deleted automatically. Follow steps 1 through 6 in the above section.

  • Page 116: Counter (Viewing The Counter Value)

    Counter (Viewing the counter value) Displays the number of pages printed. The options available in Counter are as follows: • Printed Pages (Displaying the total printed pages) • Color (Displaying the color printed pages) • Monochrome (Displaying the monochrome printed pages) Press [MENU].

  • Page 117: Paper Settings

    Paper Settings This sets the paper size and type for the MP tray and cassettes from which paper is supplied. The options available in Paper Settings are as follows: • MP Tray Size (Setting MP tray paper size) • MP Tray Type (Setting the MP tray paper type) •...
  • Page 118 Legal Custom Hagaki OufukuHagaki Oficio II Statement Folio Youkei 2 Youkei 4 Press [OK]. Press [MENU]. The display returns to Ready. MP Tray Type (Setting the MP tray paper type) You can use this to set the paper type that can be supplied from the MP tray.
  • Page 119 Cassette (1 to 4) Size (Setting the cassette paper size) To set the standard sizes A5, A4, B5, Letter, and Legal size for the paper cassette, load the paper and turn the paper size dial so that the size of the paper you are going to use appears in the paper size window.
  • Page 120 Envelope C5 ISO B5 Executive Letter Legal Custom Hagaki OufukuHagaki Oficio II Statement Folio Youkei 2 Youkei 4 Note A6 is displayed for Cassette Size or Cassette1 Size. Env. Monarch, Envelope #10, Envelope #9, Envelope #6, Envelope DL, OufukuHagaki, Youkei 2 and Youkei 4 are displayed when one of cassettes 2 to 4 in the optional paper feeder PF-500/PF-510 is installed.
  • Page 121 Entering the Width and Length Enter the paper size for X Dimension and Y Dimension as shown in the figure. X Dimension 105 to 216 mm (4.13 to 8.5 inches) When the unit of measurement is set, press >>X Dimension appears (the paper width setting). Press [OK].
  • Page 122 Cassette (1 to 4) Type (Setting the cassette paper type) By setting a paper type (plain, recycled, etc.) for the paper cassette, you can automatically select the paper in the paper cassette according to the paper type you command on the printer driver. The default setting is plain paper for all paper cassettes.

  • Page 123: Type Adjust

    Type Adjust (Creating custom paper type) The following describes the procedure used to set a user-defined paper type for the printer. Eight custom user settings may be registered. After having been set, any of these may be called up when setting the paper type for a paper source.
  • Page 124 Paper Weight (Setting the paper weight) You can set the paper thickness for your custom paper type to be customized.The default setting is Normal 2. Display the custom paper type (refer to Type Adjust (Creating custom paper type) on page 6-32) and press Press repeatedly until >>Paper Weight appears.

  • Page 125: Print Settings

    Print Settings These settings specify printing parameters such as the print quality used for printing (Normal or Fine), the gloss mode (Low or High), the number of copies, reduced printing and the page orientation. The options available in Print settings are as follows: •...
  • Page 126 Paper Feed Mode (Setting the paper feed source) This mode specifies how the paper should be fed, after the paper feed source and paper type has been chosen. If Auto is selected, the printer searches for a paper feed source that matches the paper size and type, and paper is delivered from that source.
  • Page 127 Duplex (Duplex printing) Using the duplexer, you can automatically print on both sides of the paper. The duplexer is mounted underneath the printer. Duplex printing is available for the following paper types: PLAIN PREPRINTED BOND RECYCLED ROUGH LETTERHEAD COLOR PREPUNCHED HIGH QUALITY Activating the duplexer is done by selecting either short edge or long edge binding mode.
  • Page 128 Press while Print Settings > is displayed. Press repeatedly until >Duplex appears. Press [OK]. A blinking question mark (?) appears. >Duplex ? Off Press to display the desired binding mode. The message display toggles through the following: Off (default) Short edge bind Long edge bind Press [OK].

  • Page 129: Error Report

    Emulation (Setting the emulation) You can change the emulation mode for the current interface. Use the procedure below to select the mode. Press while Print Settings > is displayed. Press repeatedly until >Emulation > appears on the message display. One of the emulation modes appears, indicating the emulation currently in use.
  • Page 130 Color Mode (Selecting color or monochrome printing) You can use the Color Mode menu on the operation panel to select the Monochrome or Color printing mode. By default, the printer is set to print in color mode. Press while Print Settings > is displayed. Press repeatedly until >Color Mode appears.
  • Page 131 EcoPrint Mode (Selecting the EcoPrint mode) By enabling EcoPrint mode, you can minimize the amount of toner used during printing. Because images printed in this mode may be slightly coarser than those printed in standard resolution, you should use EcoPrint for test prints or other situations where high-quality prints are not required.
  • Page 132 Orientation (Print orientation) You can select portrait (upright) or landscape (sideways) page orientation. Portrait Orientation Landscape Orientation Press while >Page Set > is displayed. Press repeatedly until >>Orientation appears. Press [OK]. A blinking question mark (?) appears. >>Orientation ? Portrait Select Portrait or Landscape using Press [OK].

  • Page 133: Network (Network Settings)

    Network (Network settings) This printer supports TCP/IP and TCP/IP (IPv6) protocols. IP is an abbreviation for Internet Protocol. This printer routinely uses the TCP/IP (IPv4) protocol, but provides a separate setting for the next- generation IP, IPv6. TCP/IP (IPv4) uses 32-bit IP addresses, but the rapid growth in the number of Internet users has resulted in a shortage of IP addresses.
  • Page 134 Press [OK]. A blinking question mark (?) appears. >TCP/IP > ? Off Select On or Off using Select On and press [OK]. The display changes to the settings shown below. DHCP (DHCP setting) DHCP (Dynamic Host Configuration Protocol) is the protocol that assigns the information required to establish a network connection when a host attempts to connect to the network (Internet).
  • Page 135 Display the desired IP address and press [OK]. Press [MENU]. The display returns to Ready. Subnet Mask (Subnet mask setting) The subnet mask is a way of augmenting the network address section of an IP address. A subnet mask represents all network address sections as 1 and all host address sections as 0.

  • Page 136: Setting)

    Press to increase or decrease, respectively, the value at the blinking cursor. You can set any value between 000 and 255. Use to move the cursor right and left. Display the desired gateway and press [OK]. Press [MENU]. The display returns to Ready. Bonjour (Bonjour setting) Bonjour, also known as zero-configuration networking, is a service that automatically detects computers, devices and services on an IP network.
  • Page 137 Select On or Off using Select On and press [OK].The display changes to the settings shown below. RA(Stateless) (RA (Stateless) setting) The IPv6 router communicates (transmits) information such as the global address prefix using ICMPv6. This information is the Router Advertisement (RA).

  • Page 138: Device Common (Selecting/Setting The Common Device)

    Device Common (Selecting/Setting the common device) Selects/sets all the functions in this printer. The options available in Device Common are as follows: • MSG Language (Selecting the message language) • Buzzer (Alarm (Buzzer) setting) • RAM Disk Mode (Using the RAM disk) •...
  • Page 139 Buzzer (Alarm (Buzzer) setting) This function uses tones to notify the user of printer operations and the printer status. This setting is useful, for example, when the printer is located some distance from the user. The options available in Buzzer are as follows: •...
  • Page 140 Ready (Preparation completed tone setting) When On is selected in this setting, a tone sounds when print preparation has been completed. The default setting is Off. Press while >Buzzer > is displayed. Press repeatedly until >>Ready appears. Press [OK]. A blinking question mark (?) appears. >>Ready ? Off Select On or Off using...
  • Page 141 RAM Disk Mode (Using the RAM disk) The RAM disk is a memory space shared within the printer memory that can temporarily store print jobs. The stored print job can then be used to print multiple copies of the job reducing the total amount of time required to print the whole job.
  • Page 142 RAM Disk Size (Setting the RAM disk size) Use this procedure to set the amount of memory used for the RAM disk. IMPORTANT The RAM Disk Size menu option only appears when is set to On . RAM Disk Mode Press while >RAM Disk Mode On >...
  • Page 143 Format (Formatting hard disk) A new hard disk must be formatted before it can be used in the printer. Formatting allows data to be written to the hard disk. This menu is displayed only when the optional hard disk is installed on the printer.
  • Page 144 Format (Formatting memory card) A new memory card must be formatted before it can be used in the printer. Formatting allows data to be written to the memory card. IMPORTANT Format is only displayed when a memory card is installed in the printer and protection is disabled. Note Formatting will destroy any existing data on a storage device including a used memory card.
  • Page 145 Duplex (Duplex printing error detection setting) If the error detection setting for duplex printing has been turned On, and you attempt to print onto a paper size and paper type that cannot be used for duplex printing, the Duplex disabled Press GO error message will be displayed and printing will stop.
  • Page 146 Timer (Timer setting) This specifies timer-related settings such as the automatic form-feed timeout and the timeout settings for Auto Sleep. The options available in Timer are as follows: • Form Feed Time Out (Automatic form feed timeout setting) • Sleep Timer (Sleep timer timeout time) •...
  • Page 147 Sleep Timer (Sleep timer timeout time) You can adjust the length of time the printer waits before entering Auto Sleep in the absence of data. The printer reverts to normal operation mode when the printer receives a print job, the operation panel is operated, or one of the exterior covers is opened.
  • Page 148 Auto Error Clear (Auto error clear setting) If an error that still allows you to continue printing occurs, the next received data is automatically printed after a set period of time elapses. For example, if the printer is shared over a network as a network printer and one person causes one of the above errors, after the set period of time elapses, the data sent from the next person is printed.
  • Page 149 Error Clear Timer (Setting the error clear time) If Auto Error Clear is set to On and a non-fatal error (an error that allows printing to continue) occurs, this setting specifies the time until the error is recovered and printing resumes. Press while >Timer >...
  • Page 150 Auto Sleep (Setting the sleep timer) The printer has a sleep timer that is used to conserve power when the printer is not printing, processing, or receiving data. Press while >Timer > is displayed. Press repeatedly until >>Auto Sleep appears. To turn off the sleep timer, press [OK].

  • Page 151: Security

    Security The security functions can be set up to protect printer operation and the print data. The options available in Security are as follows: • ID (Administrator ID input) • Password (Administrator password input) • I/F Block (Interface (external device) block setting) •...

  • Page 152: Usb Interface

    Password (Administrator Password input) To set up the Security functions, you must enter an administrator ID and administrator password. For information on how to set the administrator password, refer to Admin (Administrator settings) on page 6-75. Once you have entered the correct ID in the previous step (ID Password (Administrator ID input)), the message display shows Password (Administrator password input) and a blinking cursor (_).

  • Page 153: Network Interface

    USB Device (USB interface setting) This locks and protects the USB interface. The default setting is Unblock. Press while >I/F Block > is displayed. >>USB Device appears. Press [OK]. A blinking question mark (?) appears. >>USB Device ? Unblock Select Block or Unblock using Press [OK].
  • Page 154 NetWare (NetWare setting) NetWare is a PC-based network operating system specifically for servers. NetWare is a client-server system that operates by installing the NetWare OS on the server and dedicated client modules (NetWare clients) on the client machines (running MS-DOS, OS/2, Windows, etc.). The basic network layer protocol used is NetWare's own IPX (Internetwork Packet eXchange)/SPX (Sequenced Packet eXchange), but the system also supports TCP/IP.
  • Page 155 AppleTalk (AppleTalk setting) AppleTalk is a communications protocol used primarily on Macintosh computers and also refers to the Mac OS network functions. AppleTalk assigns 24-bit network addresses (a 16-bit network section and an 8-bit node address) that are used to identify devices (computers, printers, etc.) on the network.
  • Page 156 SSL Server (SSL Server setting) SSL (Secure Sockets Layer) refers to a protocol used to encrypt information sent and received over a network. SSL can currently be used to encrypt data such as the WWW or FTP files widely used on the Internet so that privacy-related information, credit card numbers, corporate secrets and other confidential information can be sent and received safely.
  • Page 157 3DES (SSL Server 3DES setting) 3DES (Triple Data Encryption Standard) is a high level of encryption in which DES encryption is repeated threefold. The default setting is Off. Press while >SSL Server On > is displayed. >>3DES appears. Press [OK]. A blinking question mark (?) appears. >>3DES ? Off Select On or Off using...
  • Page 158 HTTPS (SSL Server HTTPS setting) HTTPS (HyperText Transfer Protocol Secure) is a protocol that adds SSL data encryption, message authentication and a digital signature function to the HTTP protocol used for data transfer between WWW servers and clients. S-HTTP is a similar protocol, but HTTPS differs in that it uses SSL. The default setting is Off.

  • Page 159: Job Accounting (Job Accounting Selection/Setting)

    Job Accounting (Job Accounting selection/ setting) Job Accounting is a function that allows the number of pages used to be managed by each department to be managed through the use of entered account IDs. Job accounting on this machine offers the following features: •...

  • Page 160: Job Accounting (Job Accounting Selection/Setting)

    Password (Administrator Password input) To set up Job Accounting, you must enter an administrator ID and administrator password. For information on how to set the administrator password, refer to Admin (Administrator settings) on page 6-75. Once you have entered the correct ID in the previous step (ID Password (Administrator ID input)), the message display shows Password (Administrator password input) and a blinking cursor (_).
  • Page 161 Select Account (Department-specific settings) This specifies the functions used for managing individual account IDs. The options available in Select Account are as follows: • Counter (Account-specific counter management [color + monochrome total]) • Color Counter (Account-specific counter management [color]) • Restriction (Print restriction selection [color + monochrome total]) •...
  • Page 162 Restriction (Print restriction selection [color + monochrome total]) Sets restricted functionality for all printing on the currently selected account. You can use the restrictions to prohibit printing by individual departments or to limit the number of pages they can print. Set the account ID and then press repeatedly until >>Restriction appears.
  • Page 163 Maximum Output (Maximum print output setting [color + monochrome total]) Limits the number of pages for all printing on the currently selected account. Set the account ID and then press repeatedly until >>Maximum Output appears. Press [OK]. The message display shows a blinking cursor (_). >>Maximum Output 0000001 Press...
  • Page 164 Add Account (Department registration) This allows you to add a new account for which printing is permitted. IMPORTANT Because account IDs are managed as numeric strings, " 1 " and " 001 " are handled as different accounts. Also, once Job Accounting is enabled, no jobs are printed unless information is attached showing the accounts from which the jobs are being printed.
  • Page 165 Print Job Accounting List (Job Accounting list output) This enables you to print the total number of pages for all accounts as a Job Accounting list. Press while Job Accounting > is displayed. Press repeatedly until >Print Job Accounting List appears.

  • Page 166: Admin (Administrator Settings)

    Admin (Administrator settings) The administrator setting is a function that identifies the user who can use the printer and can be used to manage users. The administrator is authenticated by the entered administrator ID and password and can then use the printer's security functions and Job Accounting functions. The options available in Admin are as follows: •...
  • Page 167 Password (Administrator Password input) You can use this to set the administrator password. The default setting is the numeric part of your printer's model name. If you use CLP 3626, enter "5300". Once you have entered the correct ID in the previous step (ID Password (Administrator ID input)), the message display shows Password (Administrator password input) and a blinking cursor (_).
  • Page 168 Change Password (Administrator Password change) You can use this to change the administrator password. In step 3 in Password (Administrator Password input) above, press >Change Password while the Admin (Change) screen is displayed until >Change **************** Password appears. IMPORTANT The administrator password is not displayed. Press [OK].

  • Page 169: Adjust/Maintenance (Adjust/Maintenance Selection/Setting)

    Adjust/Maintenance (Adjust/Maintenance selection/setting) Adjust/Maintenance is used to adjust the print quality and to carry out printer maintenance. The options available in Adjust/Maintenance are as follows: • Color Calibration • Registration Normal (Color registration [standard]) • Registration Details (Color registration [detailed]) •...
  • Page 170 Registration Normal (Color registration [standard]) When using the printer for the first time after set-up or after having moved it, or if printout of any color (magenta, cyan or yellow) is skewed, use this mode to correct the color registration on the operation panel. The options available in Registration Normal (Color registration (standard)) are as follows: •...
  • Page 171 Sample Color Registration Correction Chart Color Registration Correction Chart MH-L MH-R CH-L CH-R YH-L YH-R When printing ends, the display returns to Ready. 6-80 Using the Operation Panel...
  • Page 172 Adjust Magenta Corrects the registration for magenta (red). Press while Adjust/Maintenance > is displayed. Press repeatedly until >Registration Normal > appears. Press Press repeatedly until >>Adjust Magenta appears. Press [OK]. 0 will be displayed for each value and the cursor (_) will >>Adjust Magenta flash under the left (L) value.
  • Page 173 Adjust Cyan (Cyan correction) and Adjust Yellow (Yellow correction) These options correct the registration for cyan (blue) and yellow. After completing the settings for magenta in step 9 above, press >>Adjust Cyan will be displayed and, once you complete the settings for that color, >>Adjust Yellow will be displayed.
  • Page 174 Press [OK]. Processing appears and a color registration correction chart is printed out. There are horizontal (H) and vertical (V) registration charts for each color (magenta, cyan and yellow) included on the color registration correction chart. When printing ends, the display returns to Ready. Using the Operation Panel 6-83...
  • Page 175 M 12345 3 (Adjust magenta) Makes detailed corrections to the registration for magenta (red). Press while Adjust/Maintenance > is displayed. Press repeatedly until >Registration Details > appears. Press Press repeatedly until >>M 12345 3 appears. Press [OK]. 00000 or 0 will be displayed for each value and the >>M 12345 cursor (_) will flash under the H value.
  • Page 176 C 12345 3 (Cyan correction) and Y 12345 3 (Yellow correction) These options make detailed corrections to the registration for cyan (blue) and yellow. After completing the settings for magenta in step 9 above, press the key. >>C 12345 3 and >>Y 12345 3 are displayed. As with magenta, note down the values for cyan and yellow from the color registration correction chart.
  • Page 177 Service (for maintenance) The options available in Service are as follows: • Print Status Page (Printing the service status page) • Print Network Status Page (Printing the network status page) • Print Test Page • Maintenance (New Maintenance Kit replacement confirmation setting) •...

  • Page 178: Test Page

    Print Test Page The test page is printed to check the effectiveness of printer adjustments. This is primarily used for maintenance by service personnel, but it contains information that may also be useful to you. Press while >Service > is displayed. Press repeatedly until >>Print Test Page appears.
  • Page 179 LSU/Charger (LSU/Main charger cleaning mode setting) This sets the cleaning mode for the LSU/Main charger. When the printing quality declines, cleaning the LSU/Main charger can restore the printing quality. This is primarily used for maintenance by service personnel. Press while >Service > is displayed. Press repeatedly until >>LSU/Charger appears.

  • Page 180: Options

    7 Options This chapter contains explanations on the following topics: General Information Expansion Memory Modules General Description of Options For availability of the options, consult your service technician. Options...

  • Page 181: General Information

    Some options are explained in the following sections. Paper Feeder PF-500/ PF-510 (Only 2 stacked paper feeders can be used with the CLP 3521) USB memory Expansion Memory Memory Card (CF) Hard Disk (DIMM 128/256/512/...

  • Page 182: Expansion Memory Modules

    Expansion Memory Modules The printer's main controller board has a memory slot into which you can plug in optional memory modules (dual in line memory modules). You can increase the printer's memory up to 1280 MB by plugging in the optional memory modules.
  • Page 183 Installing the Memory Modules IMPORTANT Remove any USB memory that is attached to the printer's USB memory slot. Power off the printer and unplug the printer power cord. Unscrew two screws at the back of the main controller board. Pull out the main controller board gently. Main Controller Board Remove the memory module from its package.

  • Page 184: General Description Of Options

    500 sheets of paper. Up to 3 optional feeders can be added to the bottom of the printer (only 2 stacked paper feeders can be used with the CLP 3521), allowing continuous feeding of up to 2,000 sheets of paper (1,250 sheets in the CLP 3521) when combined with the printer's own cassette.

  • Page 185: Hard Disk

    Statement, Folio, Youkei 2, Youkei 4, 16K and Other (92 x 162 mm to 216 x 356 mm) Paper type : Plain, preprinted, labels, bond, recycled, rough, letterhead, color, prepunched, cardstock, envelope, coated, thick, high quality, custom 1 (to 8) IMPORTANT Please make sure that the machine is stable, by placing the paper feeders on a sturdy desk or base.
  • Page 186 USB Memory USB memory is a type of simple, highly portable flash memory that plugs into the USB memory slot. Files stored in USB memory can be printed by plugging the USB memory into the printer and then specifying the desired file names from the operation panel.
  • Page 187 Options...

  • Page 188: Computer Interface

    8 Computer Interface This chapter contains explanations on the following topics: Interface USB Interface Network Interface Computer Interface...

  • Page 189: Usb Interface

    Interface This chapter explains the signals used in the printer's USB, and network interfaces. It also lists pin assignments, signal functions, timings, connector specifications, and voltage levels. • USB Interface • Network Interface USB Interface This printer supports the Hi-Speed USB. USB (Universal Serial Bus) interface specifications and interface signals are as follows.

  • Page 190: Network Interface

    Network Interface Features Automatic IP Address Resolution This feature is compatible with the DHCP/DHCPv6 protocol and allows the printer to automatically receive IP addresses from the DHCP/DHCPv6 server. Management using Web Browsers HTTP pages are incorporated in to the interface, so that a web browser can be used to monitor and change a range of settings.
  • Page 191 Operation Environment 10 to 35 °C (50 to 95 °F), 20-80 % RH (condensation-free) EMI Countermeasures VCCI Class B, FCC Class B (U.S.), CE (Europe) IMPORTANT When IPv6 functions are used, the devices used on the network (routers, PCs, etc) must support IPv6. Computer Interface...

  • Page 192: Specifications

    9 Specifications Note Specifications are subject to change without notice. Description Item CLP 3521 CLP 3621 CLP 3626 Printing Electrophotographic four color (CMYK) printing using tandem (4) drum system Method Printing Cassette A4: 21 ppm, B5, A5, A6: 23 ppm...
  • Page 193 Description Item CLP 3521 CLP 3621 CLP 3626 Paper Sizes Cassette A4, B5, A5, Folio, 8 1/2 × 14"(Legal), 8 1/2 × 11"(Letter), Oficio II, Statement, Executive, ISO B5, A6, Envelope C5, 16K, and Custom Envelope Monarch, Envelope #10, Envelope #9, Envelope #6, Envelope DL, Envelope...
  • Page 194 Description Item CLP 3521 CLP 3621 CLP 3626 Operating During LpA = 53 dB (A) †† Noise Printing During LpA = 36 dB (A) Standby During immeasurably low Sleep Mode Dimensions (W x D x H) 345 × 518 × 455 mm 345 ×...
  • Page 195 Specifications...

  • Page 196: Glossary

    Glossary Additional memory An additional memory (optional) is used for increasing the memory capacity of this machine. For DIMM that can be used in this machine, contact your service technician. AppleTalk AppleTalk offers file sharing and printer sharing and it also enables you to utilize application software that is on another computer on the same AppleTalk network.

  • Page 197: Printer Driver

    IP Address (Internet Protocol Address) The Internet Protocol address is a unique number that represents a specific computer in a network. The format of an IP Address is four numbers separated by dots, e.g. 192.168.110.171. Each number should be a decimal between 0 and 255. KPDL KPDL is Kyocera’s implementation of the PostScript page description language Level3.
  • Page 198 Status page This lists machine conditions, such as the machine’s memory, the total number of prints and paper source settings. You can print the status page from the operation panel. Subnet Mask This is a 32-bit numerical value that defines which bits of the IP address specify the network address and which specify the host address.
  • Page 199 Glossary-4...

  • Page 200: Index

    Index Additional memory ..........Glossary-1 Hard Disk ............6-51, 6-57, 7-6 Administrator ID .......... 6-60, 6-68, 6-75 Change ..............6-76 Administrator Password ......6-61, 6-69, 6-76 Interface Block ...............6-61 Change ..............6-77 IPP (Internet Printing Protocol) ........6-64 Alarm (Buzzer) ............... 6-48 IPSec (IP Security Protocol) ..........6-67 AppleTalk ...............6-64 Automatic Cassette Selection ........6-35...
  • Page 201 Menu Selection System ...........6-8 Thick ..............2-11 Transparency ............2-8 Message Display Indicators ..............6-5 Paper cassette Status information .............6-4 clearing paper jam ..........5-14 diagram ..............1-2 Message display for replacing toner containers ........4-3 Paper Feed Source ............6-34 Online help messages ..........5-13 Paper Feeder ..............
  • Page 202 Timer Auto error clear ............6-57 Auto panel reset ............. 6-58 Auto sleep ............... 6-59 Automatic form feed timeout ........6-55 Error clear time ............6-58 Panel reset ............. 6-58 Sleep ..............6-56 Toner containers diagram ..............1-2 how to replace ............4-4 kits ................
  • Page 203 Index-4...
  • Page 204 We recommend the use of our own brand supplies. We will not be liable for any damage caused by the use of third party supplies in this machine.
  • Page 205 UTAX GmbH, Ohechaussee 235, 22848 Norderstedt, Germany...

This manual is also suitable for:

Clp 3621Clp 3626

Table of Contents
