Page 3 DEAR VOLVO OWNER THANK YOU FOR CHOOSING VOLVO We hope you will enjoy many years of driving pleasure in your Volvo. In order to increase your enjoyment of the car, we recommend that The car has been designed for the safety and comfort of you and your you familiarise yourself with the equipment, instructions and mainte- passengers.
Page 4: Table Of Contents
01 Safety 02 Instruments and controls Important information....... 10 Seatbelts........... 18 Overview, left-hand drive cars....48 Volvo and the environment....... 13 Airbag system........... 21 Overview, right-hand drive cars....50 Airbags............22 Driver's door control panel....... 52 Activating/deactivating the airbag*... 24 Combined instrument panel......
Page 5 Table of contents 03 Climate control 04 Interior 05 Locks and alarm General information on climate control..92 Front seats..........108 Remote control key with key blade..126 Manual climate control, AC....... 94 Interior lighting........111 Active locks..........129 Electronic climate control, ECC*....97 Storage spaces in the passenger com- Keyless drive*..........
Page 6 Table of contents 06 Starting and driving 07 Wheels and tyres 08 Car care General............ 144 General............ 190 Cleaning..........206 Refuelling..........146 Tyre pressure.......... 194 Touching up paintwork......210 Alcoguard*..........150 Warning triangle* and spare wheel * ..195 Rustproofing........... 211 Starting the engine .........
Page 7 Table of contents 09 Maintenance and service 10 Infotainment system 11 Specifications Volvo service........... 214 General............ 244 Type designation........278 Self-maintenance........215 Audio functions........246 Dimensions and weights......280 Bonnet and engine compartment... 216 Radio functions........250 Engine specifications......283 Oils and fluids.........
Page 8 Table of contents 12 Alphabetical Index Alphabetical Index........298...
Page 9 Table of contents...
Page 10: Introduction
Important information Reading the Owner's Manual In the event of uncertainty over what is stand- lighted in the owner's manual by means of the ard or an option/accessory, contact a Volvo text being slightly larger and printed in grey. Introduction dealer.
Page 11 Introduction Important information warning is ignored, may result in serious per- Information Procedure lists sonal injury or fatality. Procedures where action must be taken in a certain sequence are numbered in the owner's Risk of property damage manual. When there is a series of illustrations for step-by-step instructions each step is numbered in the same way as the corres- ponding illustration.
Page 12 We page. therefore recommend that you always contact an authorised Volvo workshop before installing accessories which are connected to or affect Recording data the electrical system.
Page 13: Volvo And The Environment
Introduction Volvo and the environment Volvo Cars' environmental philosophy Environmental care is one of Volvo Car Corpo- Fuel consumption many cases the exhaust emissions are well ration's core values which influence all opera- below the applicable standards. Volvo cars have competitive fuel consumption tions.
Page 14 Textile standard impact - here are a few tips: durability is extended. For more information The interior of a Volvo is designed to be plea- and further advice, see the pages 144 and • sant and comfortable, even for people with Avoid letting the engine idle - switch off the 289.
Page 15 Introduction Volvo and the environment...
Page 16 Seatbelts....................18 Airbag system..................21 Airbags....................22 Activating/deactivating the airbag*............24 Side airbags (SIPS bags)................ 26 Inflatable Curtain (IC)................28 WHIPS..................... 29 When the systems deploy............... 31 Crash mode.................... 32 Child safety..................... 33 Option/accessory, for more information, see Introduction.
Page 17 S A F E T Y...
Page 18: 01 Safety
WARNING The seatbelt locks and cannot be with- drawn: Never modify or repair the seatbelt yourself. Volvo recommends that you contact an • if it is pulled out too quickly authorised Volvo workshop. If the seatbelt •...
Page 19 01 Safety Seatbelts Seatbelts and pregnancy such that they can easily maintain control of the Child seats are not covered by the seatbelt vehicle as they drive (which means that they reminder system. must be able to easily operate the foot pedals Rear seat and steering wheel).
Page 20 01 Safety Seatbelts Seatbelt tensioner The front seatbelts and the two for the outer rear seats are equipped with seatbelt tension- ers. A mechanism in the seatbelt tensioner tightens the seatbelt in the event of a suffi- ciently violent collision. The seatbelt then pro- vides more effective restraint for occupants.
Page 21: Airbag System
The symbol indi- cates a fault in the seatbelt tensioner sys- The warning symbol in the combined instru- tem, SIPS, SRS or the IC system. Volvo rec- ment panel illuminates when the remote con- ommends that you contact an authorised trol key is turned to key position I, II or III.
Page 22: Airbags
01 Safety Airbags Airbag system WARNING NOTE Volvo recommends that you contact an The sensors react differently depending on authorised Volvo workshop for repair. the course of the collision and whether or Defective work in the airbag system could not the seatbelts on the driver's side and cause malfunction and result in serious per- passenger side are used.
Page 23 01 Safety Airbags Airbag on the driver's side WARNING The car has an airbag to supplement the pro- Never place a child in a child seat or on a tection afforded by the seatbelt on the driver's booster cushion in the front seat if the airbag side.
Page 24: Activating/Deactivating The Airbag
Check that the switch is in the required posi- Switch location recommends that you visit an authorised tion. Volvo recommends that the key blade is Volvo workshop as soon as possible The airbag is activated. With the switch in used to change position.
Page 25 01 Safety Activating/deactivating the airbag* A text message and a symbol in the roof panel WARNING NOTE indicate that the airbag for the front passenger Activated airbag (passenger seat): When the remote control key is turned to seat is deactivated (see preceding illustration). key position II or III the warning symbol for Never place a child in a child seat or on a the airbag is displayed on the combined...
Page 26: Side Airbags (Sips Bags)
• Volvo recommends the use only of car seat covers approved by Volvo. Other seat covers may impede the operation of the side airbags.
Page 27 01 Safety Side airbags (SIPS bags) Front passenger seat, left-hand drive. The SIPS bag system consists of side airbags and sensors. A sufficiently violent collision trips the sensors and the side airbags are inflated. The airbag inflates between the occupant and the door panel and thereby cushions the initial impact.
Page 28: Inflatable Curtain (Ic)
This could compromise the intended pro- tection. Volvo recommends that you only ever use Volvo genuine parts that are approved for placement in these areas. WARNING Do not load the car higher than 50 mm under the top edge of the side windows.
Page 29: Whips
Never modify or repair the seat or WHIPS the seat with as little space as possible system yourself. Volvo recommends that The WHIPS system is a supplement to the between the head and the head restraint. seatbelts. Always use a seatbelt. you contact an authorised Volvo workshop.
Page 30 WARNING If a seat has been subjected to extreme forces, such as due to a rear-end collision, the WHIPS system must be checked. Volvo recommends that it is checked by an authorised Volvo workshop. Part of the WHIPS system's protective capacity may have been lost even if the seats appear to be undamaged.
Page 31: When The Systems Deploy
Do not • Always contact a doctor. attempt to start the car since the airbags may deploy. Recovering the car. Volvo rec- ommends that you have it conveyed to an authorised Volvo workshop.
Page 32: Crash Mode
If the car is in crash mode it must not be towed. It must be transported from its loca- Moving the car tion. Volvo recommends that you have it NORMAL MODE is shown after CRASH conveyed to an authorised Volvo workshop.
Page 33: Child Safety
In the event of questions when fitting child beams under the seat. Sharp edges can dam- Volvo recommends that children travel in rear- safety products, contact the manufacturer age the straps. facing child seats until as late an age as pos- for clearer instructions.
Page 34 01 Safety Child safety Label Airbag WARNING WARNING Never place a child in a child seat or on a Booster cushions/child seats with steel booster cushion in the front seat if the airbag braces or some other design that could rest on the seatbelt buckle's opening button is activated must not be used, as they could cause the...
Page 35 Weight Outer rear seat Centre rear seat Front seat Group 0 Volvo infant seat (Volvo Infant Seat) - Volvo infant seat (Volvo Infant Seat) - rear-facing child seat, secured with the rear-facing child seat, secured with the max. 10 kg ISOFIX fixture system.
Page 36 Front seat Group 1 Volvo rear-facing/turnable child seat Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear-fac- (Volvo Convertible Child Seat) - rear-fac- 9 – 18 kg ing child seat, secured with the car's ing child seat, secured with the car's seatbelt and straps.
Page 37 Front seat Group 2 Volvo rear-facing/turnable child seat Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear-fac- (Volvo Convertible Child Seat) - rear-fac- 15-25 kg ing child seat, secured with the car's ing child seat, secured with the car's...
Page 38 Weight Outer rear seat Centre rear seat Front seat Group 2/3 Volvo booster seat with backrest (Volvo Volvo booster seat with backrest (Volvo Volvo booster seat with backrest (Volvo Booster Seat with backrest). Booster Seat with backrest). Booster Seat with backrest).
Page 39 Grasp the cushion with both hands and push it backwards. Push until it locks in place. Volvo’s integrated booster cushion for the outer rear seats is specially designed to pro- For information on activating/deactivating the airbag (SRS), see page 24.
Page 40 Volvo recommends can be blocked from opening from the inside. that you contact an authorised Volvo work- For more information see page 137. shop. Do not make any modifications or additions to the booster cushion yourself.
Page 41 (see the following table). NOTE Volvo recommends that you contact an authorised Volvo dealer for recommenda- tions about which ISOFIX child seats Volvo recommends.
Page 42 01 Safety Child safety Types of ISOFIX child seat Type of child seat Weight Size class Passenger seats for ISOFIX installation of child seats Front seat Outer rear seat Infant seat transverse max. 10 kg Infant seat, rear-facing max. 10 kg (IL) Infant seat, rear-facing max.
Page 43 IL: Suitable for specific ISOFIX child seats. These child seats may be intended for use in a special car model, limited or semi-universal categories. IUF: Suitable for front-facing ISOFIX child seats that are universally approved in this weight class. Volvo recommends rear-facing child seats for this group.
Page 44 Volvo recommends that small children should ment point. sit in rear-facing child seats to as late an age as possible.
Page 45 01 Safety...
Page 46 Overview, left-hand drive cars..............48 Overview, right-hand drive cars.............. 50 Driver's door control panel..............52 Combined instrument panel..............53 Indicator and warning symbols............... 54 Information display.................. 58 Electrical socket..................60 Lighting panel..................62 Left-hand stalk switch................65 Right-hand stalk switch ................. 68 Cruise control*..................
Page 47 I N S T R U M E N T S A N D C O N T R O L S...
Page 48: 02 Instruments And Controls
02 Instruments and controls Overview, left-hand drive cars...
Page 49 02 Instruments and controls Overview, left-hand drive cars Steering wheel adjustment Reading lamp, right-hand side Bonnet release Seatbelt reminder and passenger seat air- bag indicator Control panel Interior rearview mirror Direction indicators, main beam, trip com- Display for climate control and infotain- puter ment system Lighting, fuel filler flap opener...
Page 50: Overview, Right-Hand Drive Cars
02 Instruments and controls Overview, right-hand drive cars...
Page 51 02 Instruments and controls Overview, right-hand drive cars Electrical socket, cigarette lighter Reading lamp, right-hand side Blind Spot Information System, BLIS No function Switch, optional equipment No function Parking brake Sunroof controls Control panel Ignition switch Glovebox Windscreen wipers and washers, head- lamp washers Door handle Cruise control...
Page 52: Driver's Door Control Panel
02 Instruments and controls Driver's door control panel Driver's door control panel Disengaging the rear power windows. Electric child safety lock* Power windows Door mirror, left-hand side Door mirrors, setting Door mirror, right-hand side Option/accessory, for more information, see Introduction.
Page 53: Combined Instrument Panel
02 Instruments and controls Combined instrument panel Speedometer. Tachometer – Indicates engine speed in Button for trip meter – Used to measure thousands of revolutions per minute (rpm). short distances. Short presses on the but- Direction indicators, left. ton switches between the two trip meters Indicator and warning symbols.
Page 54: Indicator And Warning Symbols
02 Instruments and controls Indicator and warning symbols Functionality check, symbols Symbols in the centre of the instrument When the symbol illuminates: panel All indicator and warning symbols illuminate 1. Stop in a safe manner. Do not drive the car when the remote control key is turned to posi- further.
Page 55 ABS fault 3. Drive to a workshop to have the ABS sys- tem checked if the symbol remains lit. Rear fog lamp Volvo recommends that you seek assis- Stability system STC or DSTC tance from an authorised Volvo workshop. No function...
Page 56 If the faulty. symbol illuminates and the oil level is normal Volvo recommends that you contact an author- Parking brake applied ised Volvo workshop. The symbol illuminates when the parking brake is applied.
Page 57 02 Instruments and controls Indicator and warning symbols ± Stop the car in a safe place and check the have the brake system checked. Volvo rec- Low speed level in the brake fluid reservoir, see ommends that you seek assistance from If the car moves at a speed less page 223.
Page 58: Information Display
Specification Message Specification STOP SAFELY Stop the car in a safe TIME FOR REGU- Time for regular manner and turn off service. Volvo rec- LAR SERVICE the engine. Serious ommends that an risk of damage. authorised Volvo workshop carries SERVICE Volvo recommends out the service.
Page 59 163. run the engine at information on idling speed until the If shown repeatedly checking the oil message clears. For then Volvo recom- level, see page 219. more information, mends that an see page 163. authorised Volvo SOOT FILTER...
Page 60: 12 V Electrical Socket
02 Instruments and controls Electrical socket 12 V electrical socket Electrical socket in the rear seat WARNING Always leave the plug in the socket when the socket is not in use. NOTE Optional equipment and accessories - e.g. TV screens, music players and mobile phones - which are connected to one of the passenger compartment's 12V electrical sockets, could be activated by the climate...
Page 61 02 Instruments and controls Electrical socket WARNING Always leave the plug in the socket when the socket is not in use.
Page 62: Lighting Panel
Thumbwheel for headlamp levelling centre position. If necessary, the automatic the height of the beam. dipped beam can be deactivated. Volvo rec- Light switches 1. Turn the remote control key to position II. ommends that this is performed by an author- Thumbwheel for adjusting display and ised Volvo workshop.
Page 63 02 Instruments and controls Lighting panel The lamps are switched off automatically when Fog lamps Fuel filler flap the remote control key is turned to position I or Press button (5) to open the fuel filler flap when NOTE the car is unlocked, see page 134. Regulations for use of fog lamps vary from Instrument lighting country to country.
Page 64 02 Instruments and controls Lighting panel event of a malfunction. The function is only active in twilight or darkness and only when the car is moving. The function can be deactivated/activated with the headlamp control. Headlamp pattern with function deactivated (left) and activated (right) respectively.
Page 65: Left-Hand Stalk Switch
02 Instruments and controls Left-hand stalk switch Stalk switch positions Direction indicators Switching, main and dipped beam The remote control key must be in position II Continuous flash sequence and the headlamp control in end position, see ± Move the stalk switch up or down to page 62, for main beam to be switched on.
Page 66 02 Instruments and controls Left-hand stalk switch Trip computer* car is stationary, " --.- " appears on the display. NOTE During the period for regeneration fuel con- If a warning message interrupts while you sumption may increase, see page 148. are using the trip computer, this message AVERAGE must be acknowledged.
Page 67 02 Instruments and controls Left-hand stalk switch MPH ACTUAL SPEED. Current speed is displayed in mph. Resetting 1. Select --- KM/H AVERAGE SPEED --.- L/100 KM AVERAGE 2. Reset with one press on the RESET but- ton. Press and hold the RESET button for at least five seconds to reset the average speed and average consumption at the same time.
Page 68: Right-Hand Stalk Switch
02 Instruments and controls Right-hand stalk switch Windscreen wipers Single sweep Windscreen/headlamp washer Raise the stalk switch to make a Move the stalk switch toward the steering single sweep. wheel to start the windscreen and headlamp washers. The wipers will make several more sweeps once the stalk switch is released.
Page 69 The function for intermittent wiping for reverse On/Off can be deactivated. Volvo recommends that When activating the rain sensor, the remote you contact an authorised Volvo workshop. control key must be in position I or II and the...
Page 70 02 Instruments and controls Right-hand stalk switch IMPORTANT At an automatic car wash: Deactivate the rain sensor by pressing the button (B) while the remote control key is in position I or II. Otherwise, the windscreen wipers could start swiping and become damaged. Thumbwheel Use the thumbwheel to adjust the frequency of wiper sweeps when intermittent wiping is...
Page 71: Cruise Control
02 Instruments and controls Cruise control* Activating Increasing or decreasing speed NOTE A temporary increase in speed (less than one minute) using the accelerator, such as while overtaking, does not affect the cruise control setting. When you release the accel- erator, the car will return to the programmed speed.
Page 72 02 Instruments and controls Cruise control* Return to the set speed – Press this button to resume the previously set speed. CRUISE appears on the combined instrument panel. Disengaging ± Press CRUISE to disengage the cruise control. CRUISE ON clears on the com- bined instrument panel.
Page 73: Keypad In The Steering Wheel
02 Instruments and controls Keypad in the steering wheel* Button functions in order to enable control of the phone system with the arrow keys. To return to Audio only, press EXIT. With the ENTER button you can select, acti- vate and deactivate options in menus. The but- ton can also be used to access the folder struc- ture and start the playback of audio files if a disc with audio files is inserted in the CD player/...
Page 74: Steering Wheel Adjustment, Hazard Warning Flashers
02 Instruments and controls Steering wheel adjustment, hazard warning flashers Steering wheel adjustment WARNING NOTE Adjust the steering wheel before driving off, Regulations regarding the use of hazard never while driving. Before driving, check warning flashers vary from country to coun- that the steering wheel is fixed in position.
Page 75: Parking Brake
02 Instruments and controls Parking brake Parking brake (handbrake) How to apply the parking brake 1. Fully depress the foot brake pedal. 2. Pull the lever firmly. 3. Release the foot brake pedal and make sure that the car is at a standstill position. 4.
Page 76: Power Windows
02 Instruments and controls Power windows Operation The windows can be opened and closed in two WARNING ways: The power windows are operated using the Make sure that children and other passen- controls in the doors. The ignition key must be gers cannot be trapped in any way when Manual operation in position I or II for the power windows to...
Page 77 02 Instruments and controls Power windows Blocking power windows in the rear Rear power windows NOTE doors If the car has electric child safety locks on the rear doors, the light indicates that these are also activated. The doors then cannot be opened from the inside.
Page 78: Windows, Rearview And Door Mirrors
02 Instruments and controls Windows, rearview and door mirrors Interior rearview mirror Interior rearview mirror with compass* Calibrating the compass The earth is divided into 15 magnetic zones. Bright light from behind could be reflected in The upper right-hand corner of the rearview The compass is set for the geographical area the rearview mirror and dazzle the driver.
Page 79 02 Instruments and controls Windows, rearview and door mirrors 4. Press the button (1) repeatedly until the 1– number for the required magnetic zone ( ) is shown, refer to the map of magnetic zones for the compass. 5. Wait until the display returns to showing the character 6.
Page 80 02 Instruments and controls Windows, rearview and door mirrors Door mirrors Retractable power door mirrors* NOTE The mirrors can be retracted for parking/driving The door mirrors will not be extended auto- in narrow spaces. This can be carried out in matically during unlocking if they were ignition position I and II.
Page 81 02 Instruments and controls Windows, rearview and door mirrors Blind Spot Information System, BLIS* BLIS is an information system that under cer- tain conditions can help to draw the driver's attention to vehicles moving in the same direc- tion in the so-called "blind spot", see page 171.
Page 82: Power Sunroof
02 Instruments and controls Power sunroof* Open positions Ventilation position WARNING Open: If there are children in the car: ± Press the rear edge of the control (5) Switch off the supply to the power sunroof upward. by removing the remote control key if the driver leaves the car.
Page 83 02 Instruments and controls Power sunroof* closed position as long as the button is If you need to interrupt closing: Wind deflector kept depressed. ± Press the lock button again. WARNING WARNING The sunroof's pinch-protection function Make sure that children or other passengers only operates during automatic closing, not are not in danger of becoming trapped in manual closing.
Page 84: Personal Preferences
02 Instruments and controls Personal preferences Possible settings Display Clock, adjustment Personal preferences can be set for some of The hour and minute are each adjusted sepa- MENU the car's functions. This applies to locks, cli- rately. mate control and audio functions. For audio EXIT 1.
Page 85 02 Instruments and controls Personal preferences ± Select On/Off depending on whether or not Doors – auto lock central locking button, as well as the outside you wish the recirculation timer to be door handle button on cars with the keyless When the speed of the car exceeds 7 km/h the active.
Page 86 02 Instruments and controls Personal preferences • 30 seconds • 60 seconds • 90 seconds Information • VIN number… - (Vehicle Identification Number) is the car's unique identity num- ber. • Number of keys… - The number of keys registered for the car is shown.
Page 87: Homelink
02 Instruments and controls HomeLink * General NOTE WARNING HomeLink is designed not to work if the car If HomeLink is used to operate a garage is locked from the outside. door or gate, ensure that nobody is in the vicinity of the door or gate while it is in Save the original remote controls for future motion.
Page 88 02 Instruments and controls HomeLink * The particular distance that is required ess is repeated for approx. 20 seconds Programming individual buttons and indicates that the device has a "roll- between the original remote control and To reprogram an individual button, proceed in ing code".
Page 89 02 Instruments and controls HomeLink * • Constant glow: The indicator lamp illu- 7. Depress the programmed button on minates with a constant glow when the HomeLink , while the "programming but- button is kept depressed, this indicates ton" is still flashing, keep it depressed for that the programming is complete.
Page 90 General information on climate control........... 92 Manual climate control, AC..............94 Electronic climate control, ECC*............. 97 Air distribution..................100 Fuel-driven engine block heater and passenger compartment heater*........... 101 Fuel-driven auxiliary heater* (diesel)............. 104 Option/accessory, for more information, see Introduction.
Page 91 C L I M A T E C O N T R O L...
Page 92: 03 Climate Control
Fault tracing and repair Display The climate control system cools or heats as Volvo recommends that you only entrust fault There is a display above the climate control well as dehumidifies the air in the passenger tracing and repair of the climate control system panel.
Page 93 03 Climate control General information on climate control Air vents in the dashboard ECC* Side windows and sunroof To ensure that the air conditioning works sat- Actual temperature isfactorily, close all side windows and the sun- The temperature you select corresponds to the roof (if fitted).
Page 94: Manual Climate Control, Ac
03 Climate control Manual climate control, AC Control panel Functions 2. Recirculation Recirculation can be used to 1. Fan Recirculation shut out bad air, exhaust Increase or decrease the fan fumes, etc. from the passen- Defroster speed by turning the knob. ger compartment.
Page 95 03 Climate control Manual climate control, AC Timer 4. Air distribution 6. and 7. Heated front seats* The timer function reduces the risk of icing, The airflow can be distributed misting and bad air (if recirculation is selected). to the windows, dashboard See page 84, for activating/deactivating the vents or floor by pressing the function.
Page 96 03 Climate control Manual climate control, AC on the button. Automatic switching off discon- nects the rear window and door mirrors after 12 – 20 minutes depending on outside tem- perature. During cold weather the defrosting* also con- tinues after 20 minutes in order to keep the rear window and door mirrors free of ice and mist.
Page 97: Electronic Climate Control, Ecc
03 Climate control Electronic climate control, ECC* Control panel AUTO Functions 2. Fan Turn the knob to increase or 1. AUTO decrease fan speed. If AUTO The AUTO function automat- is selected then fan speed is Recirculation/Air quality system ically regulates climate con- regulated automatically.
Page 98 03 Climate control Electronic climate control, ECC* • 3. Recirculation The air quality system consists of a multi-filter The defroster functions for the front, side and rear windows can be used to demist and a sensor. The filter separates gases and The function is selected to the windows.
Page 99 03 Climate control Electronic climate control, ECC* A symbol on the display above the climate con- 7 and 8. Heated front seats* on the button. Automatic switching off discon- trol panel and an illuminated light in the relevant nects the rear window and door mirrors after To activate front seat heating: button indicate which function has been 12 –...
Page 100: Air Distribution
03 Climate control Air distribution Air distribution Use: Air distribution Use: Air to windows. Some air to remove ice and Air to the floor and windows. to ensure comfortable flows from the air vents. The misting quickly. Some air flows from the dash- conditions and good air is not recirculated.
Page 101: Fuel-Driven Engine Block Heater And Passenger Compartment Heater
03 Climate control Fuel-driven engine block heater and passenger compartment heater* General information about heaters Refuelling Battery and fuel If the battery has insufficient charge or the fuel The parking heater heats the engine and pas- level is too low, the parking heater is switched senger compartment and can be started off automatically and a message appears on directly or with the timer.
Page 102 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Activating the heater Symbols and display messages Display Specification When one of the timer's settings or HEATER STOP- The heater has been Direct start is activated, the infor- stopped by the car's PED LOW BAT- mation symbol in the combined electronics in order...
Page 103 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Heating of the passenger compartment will After setting TIMER 1 a second start time can NOTE begin as soon as the engine coolant has be programmed with TIMER 2 by scrolling with All timer programming will be cleared if the reached the correct temperature.
Page 104: Fuel-Driven Auxiliary Heater* (Diesel)
03 Climate control Fuel-driven auxiliary heater* (diesel) Auxiliary heater (diesel) In diesel-engined cars the auxiliary heater may be required for achieving the correct tempera- ture in the engine and passenger compartment during cold weather. The heater starts automatically when extra heat is required when the engine is running.
Page 105 03 Climate control...
Page 106 Front seats.................... 108 Interior lighting..................111 Storage spaces in the passenger compartment ........114 Rear seat....................118 Cargo area.................... 120...
Page 107 I N T E R I O R...
Page 108: 04 Interior
04 Interior Front seats Seating position, manual seat The seats can be adjusted for a certain time Lumbar support (driver's and passenger after unlocking the door with the remote con- seat*), turn the wheel. trol key without the key being inserted into the Backrest rake: turn the wheel.
Page 109 04 Interior Front seats Memory function Tipping the front seat backrest* WARNING Risk of crushing. Make sure that children do not play with the controls. Check that there are no objects in front of, behind or under the seat during adjustment. Ensure that none of the rear seat passen- gers is in danger of becoming trapped.
Page 110 04 Interior Front seats Inlaid mats* Volvo supplies inlay mats which are especially produced for your car. WARNING Before setting off check that the inlaid mat in the driver area is firmly affixed and secured in the pins in order to avoid getting caught adjacent to and under the pedals.
Page 111: Interior Lighting
04 Interior Interior lighting Reading lamps and interior lighting Front roof lighting Vanity mirror* The front reading lamps are switched on or off by pressing the relevant button in the roof con- sole. Rear roof lighting Controls in roof console for front reading lamps The lamp is automatically switched on and off and passenger compartment lighting.
Page 112 04 Interior Interior lighting Cargo area lighting Passenger compartment lighting is switched off when: The lighting in the cargo area is switched on and off respectively when the tailgate is • the engine is started opened or closed. • the car is locked with the key or remote control key.
Page 113 04 Interior Interior lighting...
Page 114: Storage Spaces In The Passenger Compartment
04 Interior Storage spaces in the passenger compartment Storage spaces...
Page 115 04 Interior Storage spaces in the passenger compartment Storage pocket on rear of front seats. Glovebox Coat hanger Storage compartment in door panel with cup holder. Ticket clip Storage pocket on front edge of front seat cushions. Glovebox Storage compartment (e.g. for CD discs and cup holder, *) and storage compart- ment behind the centre console.
Page 116 04 Interior Storage spaces in the passenger compartment Storage under the front armrest Cup holder in centre console In the deeper compartment there is space for 10 normal CD cases. The cases must be stored There is a storage space under the armrest. There is space for a double cup holder under vertically on the top edge for all 10 to have There is also a smaller storage space in the...
Page 117 04 Interior Storage spaces in the passenger compartment Storage compartment behind the gear Bottle holder* Ashtray* lever A bottle holder for larger bottles is located on An ashtray is located towards the rear of the the rear of the tunnel console. tunnel console.
Page 118: Rear Seat
04 Interior Rear seat Head restraint, rear Tipping the rear seat backrest IMPORTANT The head restraints could be damaged if IMPORTANT they are not removed for loading. The head restraint in the centre must also be removed There must be no objects on the rear seat for heavy loads.
Page 119 04 Interior Rear seat 2. Lift the rear edge of the seat cushion (1) to fold the seat cushions forward. 3. Pull the lock (2) catch up and forward to release the backrest. A red indicator on the lock catch shows that the backrest is no longer locked in place.
Page 120: Cargo Area
04 Interior Cargo area Safety net* 2. Do the same on the other side. The attach- Safety grille* ments on the net spring shut. Pull the net over towards the left bracket to fit it in place. 3. Check that the attachments on the safety net are securely fastened in the keyed recesses in the roof panel.
Page 121 - an authorised Volvo workshop is recom- mended. 3. Push the button forward so that the 8. The cargo cover is now ready for use.
Page 122 04 Interior Cargo area Using the safety net together with the NOTE cargo cover Pull the cargo cover over the cargo area and When the backrest has been raised, the red hook it into the tracks in the rear pillars in the indicator should no longer be showing.
Page 123 04 Interior Cargo area Electrical socket in cargo area* Bag holder* Fold down the cover to access the electrical The bag holder holds shopping bags in place socket. This socket works regardless of and prevents them from tipping over and spill- whether or not the ignition is on.
Page 124 Remote control key with key blade............126 Active locks................... 129 Keyless drive*..................130 Battery in remote control key..............133 Locking and unlocking ................. 134 Child safety locks.................. 137 Alarm* ....................138 Option/accessory, for more information, see Introduction.
Page 125 L O C K S A N D A L A R M...
Page 126: 05 Locks And Alarm
The car is supplied with two remote control If you lose a remote control key, take the car keys. and the other remote control keys to a Volvo workshop - an authorised Volvo workshop is The remote control keys contain detachable recommended.
Page 127 05 Locks and alarm Remote control key with key blade 30, 60 or 90 seconds. For information on Detachable key blade Removing the key blade setting the delay time, see page 85. To remove the key blade from the remote con- trol key: Tailgate –...
Page 128 05 Locks and alarm Remote control key with key blade Turn the key blade 90 degrees clockwise. NOTE The keyhole is horizontal in the locked When the driver's door is unlocked using the position. key blade and is opened, the alarm is trig- gered.
Page 129: Active Locks
05 Locks and alarm Active locks Active locks for remote control key with key blade. Active locks for remote control key with- out key blade.
Page 130: Keyless Drive
05 Locks and alarm Keyless drive* • Keyless lock and ignition system Remote control key max. 1.5 m from the the READ button has been pressed. Never leave any remote control key in the In order to open a door or the tailgate, a remote control key must be no more than approx.
Page 131 05 Locks and alarm Keyless drive* Locking Unlocking doors with the key blade NOTE On cars with the keyless drive system and automatic transmission the gear selector must be moved to the P position and the ignition dial turned to the 0 position. Other- wise the car cannot be locked or alarmed.
Page 132 05 Locks and alarm Keyless drive* Door handle, right-hand rear NOTE Centre console, under the rear section When the driver's door is unlocked using the key blade and is opened, the alarm is trig- Centre console, under the front section gered.
Page 133: Battery In Remote Control Key
05 Locks and alarm Battery in remote control key Low battery in remote control key 1. Place the remote control key with the key- pad downward and prize up the cover When the battery runs down and full function- using a small screwdriver. ality cannot be guaranteed, the information symbol and display show...
Page 134: Locking And Unlocking
05 Locks and alarm Locking and unlocking Locking/unlocking the car from Rapid closing Locking/unlocking the car from inside outside Press and hold (at least 2 seconds) on the remote control key's lock button to close all For cars with the Keyless system, see windows and sunroof* at the same time.
Page 135 05 Locks and alarm Locking and unlocking • A long press (at least 4 seconds) also Pull one of the door handles twice Temporary deactivation opens all the side windows simultaneously • Press the upper section of the central lock- - for example, to quickly ventilate the pas- ing button and pull the door handle.
Page 136 05 Locks and alarm Locking and unlocking ENTER The next time the remote control key is turned to key position II the system is reset to zero and Navigation the instrument panel display shows the mes- sage Full guard at which the deadlocks func- If someone is going to stay in the car but the tion and the alarm's movement and tilt detec- doors must be locked from the outside, then...
Page 137: Child Safety Locks
05 Locks and alarm Child safety locks Manual select, child lock, rear doors Electrical locking of the rear doors and The lamp in the button illuminates when the lock is active. power windows* NOTE Cars with electric child safety locks do not also have manual child locks.
Page 138: Alarm
– the alarm has been triggered. If there is a fault in the alarm system, a message appears on the display. At which point you should contact a workshop - an authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 139 05 Locks and alarm Alarm* Automatic re-arming of the alarm Remote control key not working Reduced alarm level This function prevents the car being left with To avoid inadvertently triggering of the alarm - alarm disarmed unintentionally. for example when leaving a dog in the car or during a ferry crossing - the movement and tilt If the car is unlocked with the remote control detectors can be temporarily switched off.
Page 140 05 Locks and alarm Alarm* 4. Open one of the doors. A siren should sound and all direction indicators should flash. 5. Deactivate the alarm by unlocking the car with the remote control key. Test of alarm for bonnet 1. Sit in the car and deactivate the movement detector.
Page 141 05 Locks and alarm...
Page 142 General....................144 Refuelling....................146 Alcoguard*.................... 150 Starting the engine ................154 Starting the engine – Flexifuel............... 156 Keyless drive*..................158 Manual gearbox..................159 Automatic gearbox................160 Brake system..................165 DSTC – Stability and traction control system* ........167 Park Assist*................... 169 BLIS* –...
Page 143 S T A R T I N G A N D D R I V I N G...
Page 144: 06 Starting And Driving
06 Starting and driving General • Economical driving Clean the electric contacts of the electric WARNING engine block heater and trailer coupling Driving economically means driving smoothly Never switch off the engine while moving, after driving in water and mud. while thinking ahead and adjusting your driving such as downhill, this deactivates important style and speed to the prevailing conditions.
Page 145 (high volume) one of a greater capacity than the standard • headlamps. model. Check with your nearest Volvo dealer If the battery voltage is low the information dis- regarding the options for your car. LOW BATTERY POWER play shows the text SAVE MODE .
Page 146: Refuelling
06 Starting and driving Refuelling Opening the fuel filler flap 3. Take out the cap. General information on fuel 4. Hang up the cap on the inside of the fuel WARNING filler flap. Always avoid inhaling fuel vapour and get- NOTE ting fuel splashes in the eyes.
Page 147 Mixing different types of fuel or the use of adjusted. These adjustments create optimal nents, and do not replace components with fuel not recommended invalidates Volvo's conditions for efficient combustion of harmful parts that are not specifically designed for use...
Page 148 IMPORTANT specified in the Service and Warranty Booklet damage that is not covered by the Volvo or if you suspect that the car has been filled warranty. The sulphur content must be a maximum of with contaminated fuel.
Page 149 06 Starting and driving Refuelling called "regeneration" is started in order to burn way. The car should then be driven for approx- away the particles and empty the filter. This imately 20 minutes more. requires the engine to have reached normal NOTE operating temperature.
Page 150: Alcoguard
06 Starting and driving Alcoguard* General information on the Alcolock Functions Operation The function of the Alcolock is to prevent the Battery car from being driven by individuals under the Alcolock indicator lamp (4) shows battery sta- influence of alcohol. Before the engine can be tus: started the driver must take a breath test that verifies that he/she is not under the influence...
Page 151 30 minutes within these 30 days then normal engine star- without a new breath test. ting will be blocked - only starting with the An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 152 This setting can be nect the power supply cable from the glovebox changed afterwards at a workshop and wait until indicator lamp (6) is green. An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 153 Test failed - take a INVALID TEST new breath test. ALCOGUARD Blowing too short - blow for longer. BLOW LONGER ALCOGUARD Blowing too hard - blow more gently. BLOW SOFTER An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 154: Starting The Engine
06 Starting and driving Starting the engine ± Before starting the engine Turn the ignition key to the start position NOTE III and just release it - the starter motor ± Apply the parking brake. The idling speed can be noticeably higher then works automatically until the engine than normal for certain engine types during Note that if the car is equipped with an alcolock...
Page 155 06 Starting and driving Starting the engine II – Driving position 2. Hold the steering wheel in this position. Reinsert the key and make a new attempt The remote control key's to start the car. position when driving. The whole electrical system is engaged.
Page 156: Starting The Engine - Flexifuel
III. connections must only be carried out by a 3. When the engine has started, ease the workshop - an authorised Volvo workshop accelerator pedal gradually as the engine is recommended. speed increases.
Page 157 06 Starting and driving Starting the engine – Flexifuel NOTE IMPORTANT Points to remember for carrying reserve After the fuel mixture in the tank has been fuel: changed an adaptation should be made by driving at an even speed for about 15 •...
Page 158: Keyless Drive
06 Starting and driving Keyless drive* General Starting the car Starting with the remote control key ± Depress the clutch pedal (cars with manual gearbox) or brake pedal (cars with auto- matic gearbox). Petrol engine ± Press in and turn the ignition dial to key position III.
Page 159: Manual Gearbox
06 Starting and driving Manual gearbox Gear positions Gear shift indicator - GSI* GSI - Gear Shift Indicator - advises the driver of the opti- mum time to change gear. The indication is given with an arrow for up and down shift- ing respectively in the lower information display of the combined instrument panel, see page 53.
Page 160: Automatic Gearbox
06 Starting and driving Automatic gearbox Geartronic automatic gear positions Geartronic manual gear positions (+/-) NOTE The driver can also change gear manually The brake pedal must be depressed in order using the Geartronic automatic gearbox. The to be able to disengage the gear lever from car engine-brakes when the accelerator pedal the P position.
Page 161 06 Starting and driving Automatic gearbox Kick-down Mechanical gear selector inhibitor Automatic gear selector inhibitor When the accelerator pedal is pressed all the Cars with an automatic gearbox have special way to the floor (beyond the position normally safety systems: regarded as full acceleration) a lower gear is Keylock immediately engaged.
Page 162 06 Starting and driving Automatic gearbox Disengaging the gear selector inhibitor Cold start Automatic gearbox, Powershift * When starting in low temperatures, the gear changes can sometimes feel hard. This is due to the gearbox oil's viscosity at low tempera- tures.
Page 163 06 Starting and driving Automatic gearbox To bear in mind Overheating during slow driving in queues can Text message and action be avoided by driving in stages: Stop the car The transmission's double clutch has overload In some situations the display can show a mes- and wait with your foot on the brake pedal until protection that is activated if it becomes too sage at the same time as a symbol is illumi-...
Page 164 06 Starting and driving Automatic gearbox Symbol Display Driving characteristics Action TRANSM. OVERHEAT BRAKE TO Difficulty in maintaining even speed at con- Gearbox overheated. Keep the car station- stant engine speed. HOLD ary using the foot brake TRANSM. OVERHEAT PARK SAFELY Significant pulling in the car's traction.
Page 165: Brake System
06 Starting and driving Brake system Brake servo Dampness can affect braking Bear in mind that driving with a trailer puts an additional load on the car's brakes. characteristics If the car is rolling or is being towed with the Brake components become wet when the car engine turned off, the brake pedal must be is driven in heavy rain, through pools of water...
Page 166 - an author- 10 km/h the brake light returns from flashing to ised Volvo workshop is recommended. the normal constant glow - while at the same time the hazard warning flashers are activated,...
Page 167: Dstc - Stability And Traction Control System
06 Starting and driving DSTC – Stability and traction control system* General Spin Control The stability system is activated automatically each time the car is started. The function prevents the driving wheels from The stability and traction control system, STC/ spinning against the road surface during accel- DSTC (Dynamic Stability and Traction Control) System operation during skidding and accel-...
Page 168 Constant glow after starting the engine or > If the message remains when the engine while driving means that there is a fault in is restarted, drive to a workshop. An the STC/DSTC system. authorised Volvo workshop is recom- mended. Option/accessory, for more information, see Introduction.
Page 169: Park Assist
Rear parking assistance is deactivated then this is automatically lowered. automatically when towing a trailer if a Volvo The tone becomes constant at a distance of genuine trailer cable is used. about 30 cm. If there are obstacles within this...
Page 170 Front parking assistance is active at speeds attention, contact a workshop - an authorised below 15 km/h. The system is deactivated at Volvo workshop is recommended. higher speeds. When the speed is below 10 km/h the system is reactivated. IMPORTANT...
Page 171: Blis* - Blind Spot Information System
06 Starting and driving BLIS* – Blind Spot Information System General BLIS is an information system that under cer- Blind spots tain conditions can help to draw the driver's attention to vehicles moving in the same direc- tion in the so-called "blind spot". The system is designed to work most effec- tively when driving in dense traffic on multi-lane highways.
Page 172 06 Starting and driving BLIS* – Blind Spot Information System Activating/deactivating ton to clear the text message. For more infor- WARNING mation on messages, see page 58. BLIS does not work in sharp bends. BLIS system message BLIS does not work when the car is revers- ing.
Page 173 BLIS SERVICE must only be performed by a workshop - an REQUIRED authorised Volvo workshop is recom- mended. Here are several examples of situations where the BLIS indicator lamp may illuminate even if Low sun in the camera.
Page 174: Towing And Recovery
06 Starting and driving Towing and recovery Start assistance WARNING IMPORTANT Use a donor battery if the battery is discharged The steering lock remains in the position it Note that the car must always be towed with and the engine does not start. Do not tow the was in when the power was cut off.
Page 175 06 Starting and driving Towing and recovery ± • Move the gear selector to position N and Open the variant with a recess using a NOTE coin or similar inserted in the recess, release the parking brake. On certain cars with fitted towbar the towing turning it outwards.
Page 176: Start Assistance
06 Starting and driving Start assistance Starting with a donor battery 3. If the donor battery is in another car, switch WARNING off the engine in the other car and ensure The battery can generate oxyhydrogen gas, that the cars do not touch one another. which is highly explosive.
Page 177: Driving With A Trailer
• Avoid driving with a trailer on inclines of If the towing bracket is fitted by an authorised more than 12%. Volvo workshop, then the car is delivered with Overheating • For safety reasons, the maximum permit- the necessary equipment for driving with a...
Page 178 06 Starting and driving Driving with a trailer Automatic gearbox hitched trailer. Always use the parking brake. Overheating • Block the wheels with chocks when park- When driving with a trailer in hilly terrain in a hot ing a car with hitched trailer on a hill. climate there may be a risk of overheating.
Page 179: Towing Equipment
If the car is equipped with a detachable towbar, the installation instructions for the loose sec- tion must be followed carefully, see page 181. WARNING If the car is fitted with a Volvo detachable towbar: • Follow the installation instructions care- fully.
Page 180 06 Starting and driving Towing equipment* Specifications Dimensions for mounting points (mm) Fixed towbar standard 1115 Fixed towbar with Nivomat 1111 Detachable towbar standard 1115 Detachable towbar with Nivomat 1111 Side member Ball centre Option/accessory, for more information, see Introduction.
Page 181: Detachable Towbar
06 Starting and driving Detachable towbar* Fitting the towbar 2. Ensure that the mechanism is in the 3. Check that the indicator window (3) shows unlocked position by turning the key clock- red. If the window does not show red, 1.
Page 182 06 Starting and driving Detachable towbar* 5. Check that the indicator window shows green. 4. Insert the towbar until you hear a click. 7. Check that the towbar is secure by pulling it up, down and back. WARNING 6. Turn the key anticlockwise to locked posi- tion.
Page 183 06 Starting and driving Detachable towbar* Removing the towbar 8. Safety cable. 2. Push in the locking wheel and turn it 1. Insert the key and turn it clockwise to the anticlockwise until you hear a click. WARNING unlocked position. Be sure to attach the trailer's safety cable to the correct place.
Page 184 06 Starting and driving Detachable towbar* 3. Turn the locking wheel down fully, until it 4. Push on the protective cover. comes to a stop. Hold it in this position while pulling the towbar rearward and upward. WARNING Secure the towbar safely if it is stored in the car, see page 179.
Page 185: Loading
For more detailed infor- for your car by Volvo. surface of the tailgate. mation on weights, see page 281. Carefully follow the mounting instructions sup- •...
Page 186: Adjusting Headlamp Pattern
On cars equipped with Xenon lamps, head- dazzling oncoming motorists. lamp replacement must be performed at a workshop - an authorised Volvo workshop The correct pattern will also better illuminate is recommended. The lamp must be han- the verge.
Page 187 06 Starting and driving...
Page 188 General....................190 Tyre pressure..................194 Warning triangle* and spare wheel * ............ 195 Changing wheels................... 197 Emergency puncture repair* ..............199 Option/accessory, for more information, see Introduction.
Page 189 W H E E L S A N D T Y R E S...
Page 190: 07 Wheels And Tyres
07 Wheels and tyres General Driving characteristics and tyres Speed ratings New tyres The tyres greatly affect the car's driving cha- The car is approved as a whole, which means racteristics. The type of tyre, dimensions, tyre that dimensions and speed ratings must not pressure and speed rating are important for differ from those specified on the vehicle reg- how the car performs.
Page 191 A suitable dis- cially the studs, a longer service life. tance for the first change is approx. 5000 km and then at 10 000 km intervals. Volvo recom- NOTE mends that you contact an authorised Volvo Tread wear indicators.
Page 192 1. Tighten the wheel nuts of model (1) to 110 washer. Only use wheel rims that are tested and Nm. Tighten the wheel nuts of model (2) to approved by Volvo and which are included in 130 Nm. NOTE the Volvo genuine accessories range.
Page 193 The spare wheel (Temporary spare) is only Volvo recommends that you contact an author- intended for use temporarily and must be ised Volvo workshop for checking if you are replaced by an ordinary wheel as soon as pos- uncertain about tread depth.
Page 194: Tyre Pressure
07 Wheels and tyres Tyre pressure Recommended tyre pressure NOTE Tyre pressure decreases over time, this is a natural phenomenon. Tyre pressure also varies depending on ambient temperature. Even after several kilometres of driving, the tyres warm up and the pressure increases. So air must not be released if the pressure is checked when the tyres are warm.
Page 195: Warning Triangle* And Spare Wheel
Spare wheel* and jack * NOTE triangle*. Place the warning triangle in a suita- Volvo recommends only using the jack* that The car's original jack* ble place with regard to the traffic. belongs to the car model in question, which The original jack must only be used for chang- 1.
Page 196 07 Wheels and tyres Warning triangle* and spare wheel * Putting the spare wheel* and jack* into First aid* the cargo area A case with first aid equipment is located in the 1. Crank the jack (3) to halfway in order that cargo area.
Page 197: Changing Wheels
07 Wheels and tyres Changing wheels Removing wheels NOTE Volvo recommends only using the jack* that belongs to the car model in question, which is indicated on the jack's label. The label also indicates the jack's maximum lift capacity at a specified minimum lifting height.
Page 198 07 Wheels and tyres Changing wheels Fitting the wheel 1. Clean the contact surfaces between wheel and hub. 2. Put on the wheel. Tighten the wheel nuts. 3. Lower the car so that the wheel cannot rotate. 4. Tighten the wheel nuts crosswise. It is important that the wheel nuts are tightened properly.
Page 199: Emergency Puncture Repair
It consists of a compressor used. Volvo recommends that you visit an Decal, maximum permitted speed and a bottle with sealing fluid. The kit works as authorised Volvo workshop for inspection of a temporary repair.
Page 200 07 Wheels and tyres Emergency puncture repair* Sealing fluid bottle WARNING WARNING Pressure gauge The sealing fluid can irritate the skin. In the Do not leave children in the car without case of contact with skin, wash away the supervision when the engine is running. fluid with soap and water.
Page 201 Never leave the engine run- 3. If it is below 1.3 bar then the tyre is insuf- 7. Volvo recommends that you drive to the ning in sealed areas or areas that lack suf- ficiently sealed. The journey should not be nearest authorised Volvo workshop for the ficient ventilation.
Page 202 07 Wheels and tyres Emergency puncture repair* Changing the sealing fluid canister WARNING Replace the bottle before the expiration date Do not leave children in the car without has passed. Treat the old bottle as environ- supervision when the engine is running. mentally hazardous waste.
Page 203 07 Wheels and tyres...
Page 204 Cleaning....................206 Touching up paintwork................. 210 Rustproofing..................211...
Page 205 C A R C A R E...
Page 206: 08 Car Care
08 Car care Cleaning Washing the car Chromed wheels NOTE Wash the car as soon as it becomes dirty. Use Outside lighting such as headlamps, fog IMPORTANT car shampoo. Dirt and road salt can lead to lamps and rear lamps may temporarily have corrosion.
Page 207 Only paint treatment recommended by When using a pressure washer: Make sure rubber. Volvo should be used. Other treatment such that the nozzle of the pressure washer is not as preserving, sealing, protection, lustre When using degreasant on plastic and rub- closer than 30 cm to the bodywork.
Page 208 (or more if the upholstery. necessary). The Volvo Leather Care kit is avail- Vacuuming is important prior to using cleaning able from your Volvo dealer. agents.
Page 209 • Leather needs to breathe. Never cover the Volvo dealer. Make sure the seatbelt is dry leather steering wheel with protective plas- before allowing it to retract. tic.
Page 210: Touching Up Paintwork
08 Car care Touching up paintwork Paintwork Stone chips and scratches If the stone chip has penetrated to the bare metal Paint is an important part of the car's rust- 1. Apply a piece of masking tape over the proofing and should therefore be checked reg- damaged surface.
Page 211: Rustproofing
The car's rustproofing does not normally require treatment for approximately 12 years. After this period, it should be treated at three- year intervals. If the car needs further treat- ment, Volvo recommends that you engage an authorised Volvo workshop for assistance.
Page 212 Volvo service..................214 Self-maintenance.................. 215 Bonnet and engine compartment............216 Oils and fluids..................218 Wiper blades..................224 Battery....................226 Replacing bulbs..................228 Fuses..................... 234...
Page 213 M A I N T E N A N C E A N D S E R V I C E...
Page 214: 09 Maintenance And Service
It was checked again in accord- ance with Volvo Car Corporation regulations before it was handed over to you. To keep your Volvo as safe and reliable as pos- sible, follow the Volvo service programme specified in the Service and Warranty Booklet.
Page 215: Self-Maintenance
NOTE filled. Use washer antifreeze at tempera- High output from the ignition system. The Volvo recommends only using the jack that voltage in the ignition system is highly dan- tures around freezing. belongs to the car model in question. If a gerous.
Page 216: Bonnet And Engine Compartment
09 Maintenance and service Bonnet and engine compartment Opening the bonnet The illustration shows a left-hand drive car. 1. Pull the handle on the far left under the Engine oil dipstick WARNING instrument panel. (In right-hand drive cars Radiator Check that the bonnet locks properly when the handle is on the far right.) You will hear closed.
Page 217 09 Maintenance and service Bonnet and engine compartment Battery Relay and fuse box, engine compartment Air filter Engines with electronic oil level sensor have no dipstick (5-cyl. diesel).
Page 218: Oils And Fluids
Using oil of a higher than specified grade is permitted. If the car is driven in adverse con- ditions, Volvo recommends using an oil of a higher grade than that specified on the decal, see page 285.
Page 219 The choice of oil permitted. If the car is driven in adverse con- has been made very carefully with regard to ditions, Volvo recommends using an oil of a service life, starting characteristics, fuel higher grade than that specified on the decal, consumption and environmental impact.
Page 220 09 Maintenance and service Oils and fluids 5. If the level is close to MIN then 0.5 litres For engines with electronic oil level should be added. If the level is significantly sensor below, then an additional amount is required. 6.
Page 221 09 Maintenance and service Oils and fluids Measuring the oil level Washer fluid, topping up IMPORTANT If the oil level needs to be checked then it Engine oil In the event of the message should be carried out in accordance with the level Fill with 0.5 l oil , only fill with 0.5 litres.
Page 222 • Mix the coolant with approved quality overpressure. tap water. In the event of any doubt about water quality, used ready-mixed coolant in accordance with Volvo rec- NOTE ommendations. The engine must only be run with a well- • When changing coolant/replacing cool- filled cooling system.
Page 223 09 Maintenance and service Oils and fluids Checking and topping up the brake and WARNING clutch fluid If the brake fluid is under the MIN level in the brake fluid reservoir, do not drive further before topping up the brake fluid. The reason for the loss of brake fluid must be investigated.
Page 224: Wiper Blades
09 Maintenance and service Wiper blades Wiper blades Replacing the wiper blades, windscreen 1. Turn up the wiper arm. 2. Press the button located on the wiper blade mounting and pull straight out (1), parallel with the wiper arm. 3. Slide in (2) the new wiper blade until a "click"...
Page 225 09 Maintenance and service Wiper blades > Check that it is firmly installed and fold back the wiper arm.
Page 226: Battery
09 Maintenance and service Battery Battery care Symbols on the battery NOTE The service life and function of the battery is Use protective goggles. The life of the battery is shortened if it influenced by factors such as the number of becomes discharged repeatedly.
Page 227 09 Maintenance and service Battery 4. Disconnect the negative battery lead. Avoid sparks and naked flames. 5. Disconnect the positive battery lead. 6. Undo the front wall of the battery box using a screwdriver. 7. Release the clamp securing the battery. Risk of explosion.
Page 228: Replacing Bulbs
On cars equipped with Xenon lamps, head- from the engine compartment. lamp replacement must be performed at a workshop - an authorised Volvo workshop Removing the lamp housing is recommended. The lamp must be han- 5. Lift out the lamp housing and place it on a 1.
Page 229 09 Maintenance and service Replacing bulbs on or the remote control key inserted into the Main beam, Halogen ignition switch. Dipped beam Fitting a new bulb The illustration shows a halogen bulb. 1. Fit the new bulb. It can only fit in one posi- 1.
Page 230 09 Maintenance and service Replacing bulbs 5. Refit the bulb holder. It can only be refitted 4. Press the bulb holder back on. A "click" is 2. Twist the bulb holder anticlockwise and in one position. heard when the bulb holder is fitted cor- remove it.
Page 231 (A or B). NOTE If an error message remains after the broken bulb has been replaced then we recom- mend that you visit an authorised Volvo workshop. 1. Switch off all lights and turn the remote control key to position 0.
Page 232 09 Maintenance and service Replacing bulbs Location of the bulbs in the rear lamp Brake light (LED) Number plate lighting Position lamp Position/parking lamps Direction indicators Reversing lamp Rear fog lamp (one side) NOTE The rear fog lamp only illuminates in the left rear light cluster on a left-hand drive car and in the right on a right-hand drive.
Page 233 09 Maintenance and service Replacing bulbs Cargo area Vanity mirror lighting* Fitting the mirror glass 1. First, press the three lugs at top edge of mirror glass back into position. 2. Then press the three lower lugs back into position. 1.
Page 234: Fuses
Each fuse box has space for several spare fuses. If the same fuse fails repeatedly then there is a fault in the component. In which case, Volvo recommends that you visit an authorised Volvo workshop for this to be checked.
Page 235 Fuses 1-6 are of the "Midi Fuse" type and must only be replaced by a workshop. On the inside of the cover there are tweezers that facilitate the procedure for the removal and fitting of fuses. An authorised Volvo workshop is recommended.
Page 236 09 Maintenance and service Fuses Cooling fan 50 A ABS valves 20 A Windscreen wipers 30 A Power steering 80 A Engine functions 30 A Supply to passenger com- partment fuse box 40 A Supply to passenger com- Ventilation fan 40 A partment fuse box 60 A...
Page 237 09 Maintenance and service Fuses Engine control module (5-cyl. Injectors (5-cyl. petrol), Turbo Relay coil, relay, climate con- petrol), Transmission control control valve (5-cyl. diesel), trol system, PTC element, oil module (5-cyl.) 10 A Oil level sensor (5-cyl. diesel) trap (5-cyl. petrol), Mass air flow sensor (5-cyl.
Page 238 09 Maintenance and service Fuses Relay/Fuse box in the passenger compartment The fuse box has 50 fuse positions. The fuses completely. The fuse box can be fully are located under the glovebox. The box also unhooked. provides space for several spare fuses. Tools 4.
Page 239 09 Maintenance and service Fuses Phone*, Audio system, Washer, rear window 15 A Parking assistance*, RTI*, Bluetooth* 15 A Xenon* 10 A SRS system 10 A SRS system, Engine con- Control module Keyless* 20 A Reserve – trol module (5-cyl, DRIVe) 10 A Remote control receiver, PTC element, air pre-...
Page 240 09 Maintenance and service Fuses Seat heating (driver's Sunroof*, Overhead con- Power seat, driver 25 A side) 15 A sole for interior lighting, Interior lighting, cargo Seatbelt reminder, rear, Seat heating (passenger area lighting, power Dimming, interior rear- side) 15 A seats, fuel level display view mirror* (2.0F)
Page 241 09 Maintenance and service...
Page 242 General....................244 Audio functions..................246 Radio functions..................250 CD functions ..................255 Menu structure – audio system............. 258 Phone functions*................... 259 Menu structure – phone*............... 266 Bluetooth handsfree*................269 Option/accessory, for more information, see Introduction.
Page 243 I N F O T A I N M E N T S Y S T E M...
Page 244: 10 Infotainment System
10 Infotainment system General • Infotainment system system can be easily operated using the con- EXIT (6) leads back one step in the menu structure. A long press on EXIT will exit the trol panel or the steering wheel keypad*, see menu system.
Page 245 10 Infotainment system General Dolby Surround Pro Logic II Dolby Surround Pro Logic II distributes the two stereo audio channels to left, centre, right and rear speakers. This provides a more real- istic sound quality than that provided by stand- ard two-channel stereo.
Page 246: Audio Functions
10 Infotainment system Audio functions Audio controls ume adjusts automatically depending on vehi- The AUX and USB inputs enable the connec- cle speed, see page 249. tion of an external audio source, e.g. an iPod or MP3 player. Audio source selection If you choose to connect an iPod , MP3 player Repeatedly pressing AM/FM switches or a USB memory stick to the USB connection...
Page 247 10 Infotainment system Audio functions • Select TUNING (4) clockwise or anticlock- NOTE wise. Sometimes the AUX external audio source can The system supports removable media be heard at a different volume to the internal • Use the right or left-hand button (6) of the which is compatible with USB 2.0 and the audio sources, e.g.
Page 248 10 Infotainment system Audio functions ment is possible, see under the heading Surround Equalizer front/rear Activating/deactivating the subwoofer Surround settings govern the spatial The equalizer can be used to adjust different below. perception of the sound. Settings frequency bands separately. •...
Page 249 10 Infotainment system Audio functions are only intended for the user to be able to Automatic volume control adapt the sound reproduction according to The auto volume control function allows the personal taste. audio volume to increase as the speed of the car increases.
Page 250: Radio Functions
10 Infotainment system Radio functions Radio controls Tuning Storing stations Ten station presets can be stored per wave- Automatic tuning length. FM has two memories for presets: 1. Select wavelength using AM/FM (1). . Preset stations are selected 2. Give a brief press on using the preset buttons (2) or the steering wheel keypad.
Page 251 10 Infotainment system Radio functions • Selecting an auto-stored preset Scanning Automatically switches to a stronger trans- mitter if reception in the area is poor. Allowing the radio to remain in Auto mode pro- SCAN (4) automatically searches through a vides access to the autostored presets.
Page 252 10 Infotainment system Radio functions For further programme interruption settings, 3. Scroll to Advanced radio settings… Activating/deactivating News see EON and REG see page 253. The pro- press ENTER. 1. Press MENU and then ENTER. gramme functions are modified via the menu 4.
Page 253 10 Infotainment system Radio functions 2. Press MENU and then ENTER. Display of programme type Automatic frequency update – AF The programme type of the current station can The AF function selects one of the strongest 3. Scroll to and press ENTER. be shown on the display.
Page 254 10 Infotainment system Radio functions Enhanced Other Networks – EON Resetting RDS functions The EON function is especially useful in urban Resets all radio settings to the original factory areas with many regional radio stations. It settings. allows the distance between the car and the 1.
Page 255: Cd Functions
10 Infotainment system CD functions CD function controls automatically. Otherwise, load a disc and Pause change to CD mode by pressing MODE. If the volume is turned down completely, the CD player is stopped. The player is restarted Start playback (CD changer*) when volume is increased.
Page 256 10 Infotainment system CD functions cally when all files in the current folder have Activating/deactivating, random (CD NOTE been played back. changer) It is only possible to scroll between random If a normal music CD is being played: Press left/right on the navigation button if the CD tracks on the current disc.
Page 257 10 Infotainment system CD functions Using low quality CD discs could result in poor or non-existent sound. IMPORTANT Only use standard discs (12 cm in diameter). Do not use CD discs with adhesive disc labels. The heat in the CD player may cause the label to come off, damaging the CD player.
Page 258: Menu Structure - Audio System
10 Infotainment system Menu structure – audio system Overview FM MENU Disc text Audio settings… News Audio settings… USB MENU* CD MENU Playlist PTY… For CD changer* with CD disc Random… selected. Radio text News Random… Advanced radio settings… News Audio settings…...
Page 259: Phone Functions
10 Infotainment system Phone functions* Phone system components. Option/accessory, for more information, see Introduction.
Page 260 (3G only). Combined 3G/GSM cards Volvo recommends that an authorised Missed calls are shown in the display. work. Contact your network operator if a Volvo workshop carries out phone system IDIS be disconnected using menu function 6.5, replacement SIM card is required. servicing.
Page 261 10 Infotainment system Phone functions* Extra SIM card Phone controls Steering wheel keypad Many network operators offer two SIM cards for the same phone number. The extra SIM card can be used in the car. Inserting the SIM card 1. Switch off the phone and open the glove- box.
Page 262 10 Infotainment system Phone functions* On/Off Activating from standby mode Call waiting ± Press PHONE. A two-tone signal during a phone call indicates A handset appears in the display when the that there is another incoming call. Answer? phone system is active or in standby mode shown in the display.
Page 263 If the phone book contains a live caller's con- see menu 6.4.3, on page 266. This function tact information then this is shown in the dis- only applies to the Volvo integrated phone sys- play. Contact information can be stored on the p q r s 7 ß...
Page 264 10 Infotainment system Phone functions* 6. Scroll to SIM card Phone memory 4. Enter the first few letters of the item and 6. Enter the first few letters of the item and press ENTER, or simply press ENTER. press ENTER, or simply press ENTER. press ENTER.
Page 265 10 Infotainment system Phone functions* SMS - Short Message Service IMEI number NOTE To block the phone, you must provide your Press ENTER to dial. Reading SMS network operator with the phone's IMEI num- 1. Press MENU. ber. This is a 15 digit serial number that is pro- NOTE 2.
Page 266: Menu Structure - Phone
10 Infotainment system Menu structure – phone* Phone menu 2.4. Speed dial… 4.6.2. When busy Call register… 2.4.1. Active 4.6.3. Not answered 1.1. Last 10 missed calls 2.4.2. Select numbers 4.6.4. Not reachable 1.2. Last 10 received calls 2.5. Erase SIM 4.6.5.
Page 267 10 Infotainment system Menu structure – phone* 6.2.3. Automatic 1.4.1. All calls 2.4. Speed dial A number stored in the phone book can be 6.3. Edit PIN code 1.4.2. Missed calls stored as a speed dial number. 6.4. Sounds and volume… 1.4.3.
Page 268 10 Infotainment system Menu structure – phone* operator for information on message settings. 4.6.2 When busy 6.1.2. Manual select Normally, these settings should not be altered. 4.6.3. Not answered 6.2. SIM security 3.3.1. SMSC number Select if the PIN code should be on, off or if the 4.6.4.
Page 269: Bluetooth Handsfree
Volvo recommends that you seek assis- Connect mobile phone tance from an authorised Volvo dealer or A mobile phone is connected in different ways visit www.volvocars.com for information on depending on whether or not it has been con- compatible phones.
Page 270 10 Infotainment system Bluetooth handsfree* 4. Choose one of the mobile phones in the the mobile phone can be controlled from the NOTE audio system display. audio system. Some mobile phones require that the 5. Enter the number series shown in the audio changeover from handsfree is confirmed To call system display via the mobile phone key-...
Page 271 10 Infotainment system Bluetooth handsfree* Ring volume More on registering and connecting NOTE Go to Phone Menu… Phone settings… A maximum of five mobile phones can be reg- With certain mobile phones the connection istered. Registration is performed once per Sounds and volume…...
Page 272 List is empty compatible with the voice recognition func- tion. Volvo recommends that you contact an shown when copying is finished. tion is made under Phone Menu… authorised Volvo dealer or visit Bluetooth…...
Page 273 10 Infotainment system Bluetooth handsfree* twice for the second etc. Continue pressing for Bluetooth… Menu structure - Bluetooth more characters, see the table on page 263. handsfree with built-in phone 3.1. Change phone Call register… A short press on EXIT deletes an input char- 3.1.1.
Page 274 10 Infotainment system Bluetooth handsfree* Phone settings… 6.1. Sounds and volume… 6.1.1. Ring volume 6.1.2. Ring signals… 6.1.3. Mute radio 6.2. Synchronise phone book Option/accessory, for more information, see Introduction.
Page 275 10 Infotainment system...
Page 276 Type designation................... 278 Dimensions and weights............... 280 Engine specifications................283 Engine oil....................284 Fluids and lubricants................286 Fuel....................... 289 Wheel and tyres, dimensions and pressure ......... 290 Electrical system................... 292 Type approval..................294 Symbols in the display................295...
Page 277 S P E C I F I C A T I O N S...
Page 278: 11 Specifications
11 Specifications Type designation...
Page 279 NOTE identification and engine numbers can facili- The labels shown in the owner's manual are tate all contact with a Volvo dealer regarding not provided as exact reproductions of the car and when ordering spare parts and those in the car. The purpose is to show accessories.
Page 280: Dimensions And Weights
11 Specifications Dimensions and weights Dimensions Dimensions Dimensions Dimensions Wheelbase 2640 Front track Width 1770 1548 1535 Length 4522 Width including door mirrors 2022 Rear track 1544 Load length, floor, folded seat 1766 with 15" wheel with 16" and 17" wheels 1531 Load length, floor Load width, floor...
Page 281 11 Specifications Dimensions and weights Weights WARNING Kerb weight includes the driver, the fuel tank The car's driving characteristics change 90% full and all fluids. depending on how heavily it is loaded and how the load is distributed. The weight of passengers and accessories, and towball load (when a trailer is hitched, see table) influences the payload and is not included in the kerb weight.
Page 282 11 Specifications Dimensions and weights Towing capacity and towball load Engine Maximum weight, braked trailer (kg) Maximum towball load (kg) 1200 1300 2.0F 1350 1350 others 1500 Engine Maximum weight, unbraked trailer (kg) Maximum towball load (kg) 1.6, 2.0 and 2.0F others...
Page 283: Engine Specifications
11 Specifications Engine specifications Overview Engine Engine Output Output Torque (Nm/ No. of Bore Stroke Swept Com- code (kW/rpm) (hp/rpm) rpm) cylinders (mm) (mm) volume pression (litres) ratio B4164S3 74/6000 100/6000 150/4000 81.4 1,596 11.0:1 2.0F B4204S4 107/6000 145/6000 185/4500 87.5 83.1 1,999...
Page 284: Engine Oil
Choose a fully synthetic engine oil for adverse Volvo Car Corporation disclaims all war- driving conditions. It provides extra protection ranty liability if engine oil of the prescribed for the engine.
Page 285 11 Specifications Engine oil Engine oil grade Engine variant Engine code Recommended oil grade Volume, incl. oil filter (litres) B4164S3 Oil grade: ACEA A5/B5 Viscosity: SAE 5W–30 2.0F B4204S4 B4204S3 D4162T B5254T7 Oil grade: ACEA A5/B5 Viscosity: SAE 0W-30/5W–30 D5204T5 D5204T SAE 0W-30 applies for Europe, SAE 5W-30 applies for other markets For filling engine oil, see page 218.
Page 286: Fluids And Lubricants
Do not mix with any other transmission fluid. If the transmission is topped up with a dif- ferent fluid, contact a workshop nearby for servicing. Volvo recommends that you con- tact an authorised Volvo workshop. Gearbox oil Manual gearbox...
Page 287 Brake system DOT 4+ Power steer- Power steering 1.0 – 1.2 WSS M2C204-A or equivalent product with same specifications. ing fluid Washer fluid 4-cyl. Petrol/Die- Use a washer antifreeze recommended by Volvo, mixed with water for temperatures below freezing. 5-cyl. Petrol/Die-...
Page 288 52 Diesel: see page 148 Diesel: D3 and D4 approx. 60 Water quality must fulfil the standard STD 1285.1. Refrigerant quantity varies depending on engine variant. Volvo recommends that you contact an authorised Volvo workshop for the correct information.
Page 289: Fuel
11 Specifications Fuel Fuel consumption See further information and more advice on pages 14 and 144. There are several causes that can affect fuel consumption negatively. Examples of this are: See page 146 for general information on fuel. • The driver's driving style •...
Page 290: Wheel And Tyres, Dimensions And Pressure
11 Specifications Wheel and tyres, dimensions and pressure Approved tyre pressures Variant Tyre size Speed Load, 1 - 3 persons Max. load Max. load (km/h) Rear Front (kPa) Rear (kPa) Front (kPa) ECO pressure (kPa) 0–160 195/65 R15 160+ 0–160 205/55 R16 DRIVe 160+...
Page 291 11 Specifications Wheel and tyres, dimensions and pressure Variant Tyre size Speed Load, 1 - 3 persons Max. load Max. load (km/h) Rear Front (kPa) Rear (kPa) Front (kPa) ECO pressure (kPa) 205/55 R16 0–160 205/50 R17 160+ 215/45 R18 Temporary Spare Tyre 0–80 In certain countries there is the "bar"...
Page 292: Electrical System
11 Specifications Electrical system General The battery capacity is dependent upon the capacity as the original battery (see the label equipment level in the vehicle. If the starter on the battery). The car has a voltage-regulated AC alternator. battery is replaced, therefore, you must ensure The electrical system is single-pole and uses that you switch to a battery with the same the chassis and engine casing as a conductor.
Page 293 11 Specifications Electrical system Lighting Output (W) Type Front direction indicators, cars with ABL (Active Bending Lights) PY24WSW Rear position/parking and side marker lamps (upper socket) P21/5W Rear position/parking lamps (lower socket) Cargo area lighting, number plate lighting Vanity mirror* Tubular lamp Front position/parking lamps, front side marker lamps Fog lamps...
Page 294: Type Approval
11 Specifications Type approval Remote control key system Certification of the Keyless Drive system Country and Siemens VDO Automotive A.G. hereby certifies region that this equipment type 5WK4 8952, 5WK48956, 5WK48812 conforms to the A, B, CY, CZ, D, DK, essential characteristic requirements and other E, EST, F, FIN, GB, Delphi hereby...
Page 295: Symbols In The Display
11 Specifications Symbols in the display General Symbols in the display Symbol Meaning Page There are a variety of different symbols in the Indicator and warning symbols in the Stability sys- 55, 167, 168 display in the car. The symbols are divided into combined instrument panel tem, STC or warning, indicator and information symbols.
Page 296 11 Specifications Symbols in the display Information symbols in the centre Symbol Meaning Page Symbol Meaning Page console display Low oil pres- 54, 56 Left direction Symbol Meaning Page sure indicators Surround sound (only Premium Sound) Seatbelt 18, 56 Right direction reminder indicators News...
Page 297 11 Specifications Symbols in the display Information symbols in the roof console display Symbol Meaning Page Seatbelt reminder Airbag, passenger 24, 25 seat, activated Airbag, passenger seat, deactivated...
Page 298 12 Alphabetical Index Air quality system, ECC......98 Automatic car washes......206 Air vents............. 93 Automatic gearbox manual gear positions (Geartronic)..160 Alarm............138 electronic climate control..... 99 towing and recovery......174 alarm indicator........138 manual climate control....94, 95 trailer...........
Page 299 12 Alphabetical Index specifications........292 Bulb holder Catalytic converter........147 start assistance........176 removal..........231 recovery..........174 symbols on the battery....... 226 Bulbs CD discs Bioethanol E85........147 changing..........228 storage compartment......116 Blind spot (BLIS)........171 Bulbs, see Lighting......228, 292 CD functions..........
Page 300 12 Alphabetical Index Cleaning Coolant............ 222 Driving automatic car washes......206 cooling system........144 Cooling system........144 car wash..........206 economical......... 144 Crash, see Collision........32 rims............. 206 in water..........144 Cruise control..........71 seatbelts..........209 slippery driving conditions....145 upholstery...........
Page 301 12 Alphabetical Index Electrical system........292 Error messages in BLIS......172 Frequency update, automatic....253 Emergency calls........260 Expectant mothers, seatbelt...... 19 Front seats, heated........95 Emergency equipment External dimensions........ 280 FSC, environmental labelling..... 14 warning triangle........195 Extra mats..........110 Fuel Emergency puncture repair.....
Page 302 12 Alphabetical Index Gear selector inhibitor......161 Geartronic..........160 IDIS – Intelligent Driver Information Sys- Jack............195 General information on fuel..... 146 tem............260 Glovebox..........115 Ignition keys..........155 locking..........128 IMEI number..........265 Gross vehicle weight....... 281 Immobiliser........126, 155 Kerb weight..........
Page 303 12 Alphabetical Index fog lamp..........231 front............ 228 Lambda-sond.......... 147 main beam halogen......229 Main/dipped beam, see Lightning..... 62 number plate lighting......232 Leather upholstery, washing instructions 208 Main beam parking lamps........230 flashing..........65 Lighting position lamps........230 Active Xenon headlamps...... 63 Main beam "flash"........
Page 304 12 Alphabetical Index Meters in the combined instrument panel Passenger compartment heater fuel gauge..........53 fuel-driven........... 101 outside temperature gauge....53 Oil, see also Engine oil..... 219, 284 Personal preferences......... 84 speedometer......... 53 Oil level low..........218 approach light, duration....... 85 tachometer...........
Page 305 12 Alphabetical Index standby, standby mode...... 262 Recommended child seats ....... 33 traffic safety........261 Reduced guard Radio Phone book settings..........85 EON............ 254 handling numbers....... 263 Refrigerant..........92 frequency update........ 253 Phone system.......... 260 Refuelling news........... 252 Pinch protection, sunroof......83 fuel cap..........
Page 306 12 Alphabetical Index Roof load, max. weight ......281 Side airbag SIPS........26 Steering wheel cruise control........71 Rustproofing..........211 SIM card..........260 keypad........71, 73, 261 SIPS bags..........26 steering wheel adjustment....74 SMS............265 Stone chips and scratches...... 210 read.............
Page 307 12 Alphabetical Index removing..........183 specifications........180 Tailgate Unlocking......... 131, 134 Towing eye..........175 driving with open tailgate....145 settings..........85 TP – Traffic information......252 locking/unlocking......126, 134 Upper mounting points, child seat.... 44 Traffic information........252 Tank volume..........286 USB, connection........
Page 308 12 Alphabetical Index Washers Wiper blades..........224 headlamps..........68 cleaning..........224 rear window.......... 69 replacing, rear window....... 224 washer fluid, filling......221 replacing, windscreen......224 windscreen........... 68 Water and dirt-repellent coating....81 Water-repellent surface, cleaning.... 207 Waxing............. 207 Weights kerb weight......... 281 Wheels changing..........
Page 310 Kdakd 8Vg 8dgedgVi^dc IE &'*'. :c\a^h] ! 6I &%)+! Eg^ciZY ^c HlZYZc! <ŽiZWdg\ '%&%! 8deng^\]i © '%%%"'%&% Kdakd 8Vg 8dgedgVi^dc Int.

Volvo V50 2010 Owner's Manual

Quick Links

Related Manuals for Volvo V50 2010

Summary of Contents for Volvo V50 2010

Table of Contents
