VOLVO V70 (08-), XC70 (08-) & S80 (07-)

WIRING DIAGRAM

2010
TP 39152201

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo V70

Summary of Contents for Volvo V70

  • Page 1: Wiring Diagram

    VOLVO V70 (08-), XC70 (08-) & S80 (07-) WIRING DIAGRAM 2010 TP 39152201...

  • Page 2: Vehicles With Srs (Airbag)/Sips Bag/Ic (Inflatable Curtain)

    2. Damage or malfunction of the SRS/SIPS bag/IC system. Work involving the SRS/SIPS bag/IC systems or other components in the vehicle that may affect the SRS/SIPS bag/IC systems must always be performed by an authorized Volvo workshop. In case of doubt, consult the SRS and SIPS bag/IC service manual.

  • Page 3: Table Of Contents

    Starting system 5, 6 & 8-Cyl........93 Data communication high speed CAN......45 Starting system 5-Cyl. Diesel........94 Data communication High speed CAN, 4-Cyl....46 Midspeed CAN data communication, LHD ....47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 4 Tow hitch cable harness, 4-pin V70......139 Beam length adjustment, automatic (Dual Xenon) ..98 Tow hitch cable harness, 4-pin S80......140 Running-/ Parking lights, Tail lights V70 ...... 99 Tow hitch cable harness, 7-pin V70......141 Running-/ Parking lights, Tail lights S80 ....100 Tow hitch cable harness, 7-pin S80......
  • Page 5 Central locking, front doors, RHD ......173 Electrically heated rear seat........196 Central locking, rear doors......... 174 Massage seats............197 Central locking, trunk lid V70 ........175 Central locking, trunk lid S80 ........176 Group 87 Climate control system Central locking, fuel filler flap........177 Signal receiver, central locking ........

  • Page 6: Explanations

    = Japan RD, R = Red = Korea VT, VO = Violet = Norway WH, W = White = Netherlands YE, Y = Yellow = Sweden = United States of America = Western Europe TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 7: How To Use The Wiring Diagrams 1:2

    G. Component location Audio The end of the manual contains a section that Service/diagnostics describes component appearance and location in Contact reel numerical order. Meter Ignition component/shunt Optics Ground connection Branching point Connector TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 8: How To Use Wiring Diagrams 2:2

    = DIN cable, coaxial cable, etc. = Data communication = CAN communication = MOST communication = MOST communication = Connection with distribution box = Further connection to... = Connector between cable harnesses = Connector connected in component TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 9: Electrical Distribution 1:2

    15/32 RD-GY 11A/4 15/32 RD-BN 11A/5 15/32 11A/6 4/46B:16 5&6CYL 4/46B:43 DW10 2/193 RD-GY 4/46B:54 8CYL VT-GN 4/56C1:48 11B/14 11B/13 11B/11 11B/9 11B/15 11B/12 11B/10 11B/24 11B/8 11B/25 11B/26 31/3 C1:1 C1:1 73/3076 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 10 11D/A10 RD-GY RD-GN 11D/B11 11D/A11 RD-GY RD-GN 11D/B12 11D/A12 2/75 2/16 RD-GY 2/88 2/82 YE-VT RD-GY RD-VT BU-RD 11D/D1 11D/D2 11D/D3 11D/D4 74/505 11D/D5 11D/D6 11D/D7 11D/D8 11D/D9 11D/D10 11D/D11 11D/D12 BU-RD RD-BN TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 11: Fuses

    Fuses in cargo compartment fuse box 11A/4 2/88 Relay, 15-feed rear 11D/B1-11D/B8 Fuses in cargo compartment fuse box 2/88 11D/B9-11D/B12 Fuses in cargo compartment fuse box 11A/5 11D/D1-11D/D7 Fuses in cargo compartment fuse box 11A/7 9/42 PTC-element continues TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 12: Engine Compartment Distribution Box F9-F24

    9/44 Heated windshield washer nozzle, right 11B/22 6/114 Vacuum pump, 5-Cyl. Turbo 2/133 6/164 Electrical power steering module (EPS) 11B/23 3/111 Light Switch Module (LSM) 11B/24 6/104 High pressure headlight washer motor continues TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 13: Distribution Box In Engine Compartment F25-F31

    16/10 Horn 1 2/17 16/11 Horn 2 2/17 11B/30 2/32 Main relay, engine management system 4/46 Engine Control Module (ECM) 11B/31 4/28 Transmission Control Module (TCM) 4/28 Transmission Control Module (TCM) MPS6 continues TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 14: Distribution Box In Engine Compartment F32-F37

    Engine EGR, 4-Cyl. 1.6L Diesel 7/35 Oil level sensor 8/6-11 Injection valves 8/98 Control valve fuel pressure, Diesel 8/111 Control valve fuel flow, 5-Cyl. Diesel 8/115 Injector 8/116 Injector 7/17 Mass airflow sensor (MAF) continues TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 15: Distribution Box In Engine Compartment F38

    Control motor, turbo, 5-Cyl. Diesel, 1T 7/35 Oil level sensor, 5-Cyl. Diesel Electromagnetic clutch, climate control system, 5-Cyl. Diesel 8/113 Bypass valve, EGR cooling, 5-Cyl. Diesel 8/120 EGR valve, 5-Cyl. Diesel 8/157 Turbocharger control valve, Diesel, 2T continues TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 16: Distribution Box In Engine Compartment F38-F39

    7/82 Rear heated oxygen sensor, 4-Cyl. 7/15 Front heated oxygen sensor, 5-Cyl. Diesel 7/15 Front heated oxygen sensor, 5-Cyl. Turbo. 7/103 Rear heated oxygen sensor, 5-Cyl. Turbo. 8/18 EVAP valve, 5-Cyl. Turbo. continues TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 17: Distribution Box In Engine Compartment F39-F44

    4/109 20/22-25 Glow plug, 4-Cyl. 2/14 11A/43 4/71 Control module, cooling fan, 5-Cyl. Diesel, 6-Cyl., 8-Cyl. 4/71 Control module, cooling fan, 4-Cyl., 5-Cyl. 11A/44 6/164 Electrical power steering module (EPS), 4-Cyl. 1.6L Diesel TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 18: Fuses In The Central Electronic Module (Cem) F1 - F11

    Steering wheel switch right (SWSR) 3/130 3/135 RTI switch 3/130, 3/131 10/1 Lamp housing, front left 10/2 Lamp housing, front right 4/33 Sunroof Module (SRM) 10/48 Right-hand reversing light 10/55 Left-hand reversing light continues TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 19: Central Electronic Module (Cem) F13 - F19

    26/5 DC/AC converter, fuel tank 26/6 Converter/control module, sill moldings, driver’s side 26/7 Converter/control module, sill moldings, passenger side 26/8 Alcolock charging cradle Driver Information Module (DIM) 4/52 Power Seat Module (PSM) continues TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 20: Central Electronic Module (Cem) F20 - F28

    K6-B 6/37 Lock motor, fuel filler cover Climate Control Module (CCM) 16/35 Siren Control Module (SCM) 17/13 Data link connector 3/132 Start Control Module (SCU) Contact brake light 4/93 Keyless Vehicle Module (KVM) TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 21: Passenger Compartment

    Fuses Passenger compartment 11 Fuse in extra fuse holder, passenger compartment Fuse function 19/4 Analog clock TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 22: Rear Electrical Center Fa1-Fa12

    Rear right head restraint solenoid, S80 2/75 11D/A9 17/39 13-pin outlet, tow hitch cable harness FA10 11D/A10 4/52 Power Seat Module (PSM) FA11 11D/A11 4/110 Trailer Module (TRM) FA12 11D/A12 4/116 Power Operated Tailgate Module (POT), V70 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 23: Distribution Box In Cargo Compartment Fb1-Fb12

    3/27 Switch unit, power passenger seat FB10 11D/B10 4/93 Keyless Vehicle Module (KVM) FB11 11D/B11 6/146 Lock motor, rear left brake disc 4/115 FB12 11D/B12 6/147 Lock motor, rear right brake disc 4/115 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 24: Rear Electrical Center Fd1-Fd7

    3/281 Infotainment Control Module (ICM) 4/124 Accessory USB unit (AUU) 11/1 Fuse in extra fuse holder, passenger compartment 16/1 Integrated Audio Module (IAM) 11D/D7 16/60 Phone Module (PHM) 16/147 Bluetooth Phone Module (BPM) TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 25: Battery Pf1-Pf2

    Fuses in the fuse box in the engine compartment 11B/35-11B/41 Fuses in the fuse box in the engine compartment 2/32 11A/42-11A/44 Fuses in the fuse box in the engine compartment 6/25 Starter motor 6/26 Alternator Control Module (ACM) TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 26: Relays

    Relays Relays in engine compartment R2 15/33 Engine compartment cold zone Relay function 2/17 Relay, horn TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 27: Relays In Engine Compartment R8 - R9

    Relays Relays in engine compartment R8 - R9 15/31 Distribution box engine compartment Relay function 2/31 Relay, 15-feed 2/193 Relay, comfort functions TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 28: Relays In Engine Compartment R10 - R13

    Main relay, engine management system 4 Cyl Diesel 2/133 Relay, vacuum pump, 5-Cyl. Turbo 2/142 Relay pre-heater fuel filter, 5-Cyl. Diesel 2/239 Relay, coolant pump, 8-Cyl. 2/35 Relay, starter motor 2/22 Relay, climate control system TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 29: Cargo Compartment

    Relays Cargo compartment Relay in extra holder cargo compartment Relay function 2/141 Refrigeration box relay TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 30: Distribution Box In Cargo Compartment Ra1-Rd1

    Distribution box in cargo compartment RA1-RD1 15/32 Rear electrical center Relay function 2/82 Relay, heated rear window 2/16 Relay, rear window wiper 2/88 Relay, 15-feed rear 2/75 Rear adjustable head restraint relay Mounting TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 31: Central Electronic Module (Cem)

    Reversing lights K5-A Washer motor K5-B Washer motor K6-B Central locking motor, trunk lid Fuel pump Steering Column Lock Module (SCL) K10-A Seat Heating Module (SHM), interior lighting Lock motor, fuel filler cover TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 32: Ground Connections

    Ground connections Overview TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 33 Lighting floor driver’s side, LHD 10/287 Lighting floor passenger side, LHD 16/36 TV receiver, LHD 16/45 Navigation system portable, LHD 16/109 DVD player/control module, LHD 16/181 Rear headphone sockets, LHD 19/4 Analog clock, LHD TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 34: 31/7 - 31/15 Continues

    Switch, driver’s door power window, RHD 3/274 Lock contact, RH front door 3/276 Lock contact, RH rear door 4/52 Power Seat Module (PSM), RHD 6/55 Lock motor, central locking, RH front door continues TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 35 Refrigeration box 10/17 Lamp housing, rear right 10/276 Lighting center armrest rear 1 10/277 Lighting center armrest rear 2 10/280 Lighting cooler compartment left 10/281 Lighting cooler compartment right 17/19 12V outlet, cargo compartment TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 36: 31/65 - 31/83 Continues

    Climate Control Module (CCM) 4/80 Forward Sensing Module (FSM) 4/124 Accessory USB unit (AUU) Driver Information Module (DIM) 7/10 Interior temperature sensor 9/42 PTC-element 10/1 Lamp housing, front left 10/2 Lamp housing, front right continues TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 37 Spark plug with ignition coil, 6-Cyl. Turbo 20/4 Spark plug with ignition coil, 6-Cyl. Turbo 20/16 Capacitor, 6-Cyl. Turbo 20/4 Spark plug with ignition coil, 8-Cyl. 20/6 Spark plug with ignition coil, 8-Cyl. TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 38: 31/93 - 31/Xx10

    Transmission Control Module (TCM) 4/46 Engine Control Module (ECM) 6/73 Coolant pump 6/139 Upper actuating motor, intake manifold 6/140 Lower actuating motor, intake manifold Electromagnetic clutch, climate control system, 4-Cyl. Diesel 9/32 PTC resistor, crankcase ventilation TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 39: 31/Xx14 - 31/Al

    Audio module (AUD) 16/108 Multimedia Module (MMM) 16/145 Remote digital audio receiver (RDAR) 16/162 Digital radio receiver control module (DABM) 31/AL Auxiliary lights 10/65 Auxiliary light, front right 10/69 Auxiliary light, front left TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 40: Control Modules

    Control modules Overview of locations TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 41: Overview Of Designations

    Left rear door module (LDM) 4/31 4/31 Passenger compartment fan control module 3/111 Light Switch Module (LSM) 4/71 4/71 Cooling fan control module 16/108 Multimedia Module (MMM) 17/13 17/13 Data link connector 7/93 Occupant Weight Sensor (OWS) TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 42: Central Electronic Module (Cem) 1:3

    7/199:3 C4:16 RD-BN 4/119:1,4/119.2:1 C2:76 YE-OG 4/83:4, 6/33:4 C3:76 YE-BU 4/102:2 C3:71 C3:42 K6-B C2:71 YE-VT 6/8:1 GY-BN 3/78:4 C2:67 YE-BU 6/37:2 C1:67 16/35:3 C3:73 17/13:16, 4/6C1:1 C3:74 RD-VT 3/132:1 C2:66 RD-WH 3/9:1 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 43 10/17C1:1,10/18C1:1, C1:68 YE-OG 10/6:1 C1:69 BU-RD 10/5:1 K5-A C1:71 6/127:1 K5-B C1:72 VT-GN 6/127:2 C1:65 C3:66 RD-GN 4/9C2:67, 7/93:2 C1:55 GN-WH 4/16C1:8 C2:58 C2:55 BU-RD 7/51:6 C3:68 BU-RD 3/65:1, 9/42C1:1 C4:18 BU-BK 8/48:1 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 44 C4:3 VT-OG 4/33:6 C4:4 GY-BN 4/119:2 C4:6 YE-GY 73/3030 10/19:2, S80 BK-RD C4:7 7/199:2 73/3036 C4:8 GY-RD 7/149:1 BK-GN C4:14 VT-WH 4/33:2 C1:54 C4:20 GY-BK 10/22C1:3 C2:65 BK-GN BK-VT 31/96 31/95 31/7 31/84 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 45: Data Communication High Speed Can

    73/3014 4/28 BU-BK BU-BK 4/115 GN-BK C1:17 GN-BK AUTO BU-BK A:14 C1:16 BU-BK BU-BK 4/46 B:54 BU-BK 5 CYL GN-BK B:41 DIESEL EURO5 4/84 BU-BK 74/518 17/13 C1:15 GN-BK C1:16 BU-BK G036691 GN-BK TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 46: Data Communication High Speed Can, 4-Cyl

    GN-BK GN-BK 74/409 22 23 4 CYL B:37 BU-BK BU-BK 74/504 73/5016 GN-BK BU-BK 4/115 GN-BK C1:17 C1:16 BU-BK BU-BK MPS6 4/84 7/164 4/28B BU-BK 74/518 17/13 C1:15 GN-BK C1:16 BU-BK G036574 GN-BK TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 47: Midspeed Can Data Communication, Lhd

    VT-OG VT-OG VT-OG GY-OG GY-OG C1:2 GY-OG GY-OG GY-OG GY-OG GY-OG 73/4001 73/5084 GY-OG 73/5085 74/9 VT-OG 73/4035 74/30 12 11 73/4034 C1:11 C1:6 16/60 4/52 C1:12 C1:11 4/116 4/86 C2:3 C2:4 G029157 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 48: Midspeed Can Data Communication, Rhd

    VT-OG VT-OG 73/5006 73/5084 73/5010 74/409 73/5085 73/4002 C1:6 VT-OG VT-OG VT-OG VT-OG GY-OG GY-OG C1:2 GY-OG GY-OG 73/4001 74/30 11 12 73/4035 73/4034 16/60 4/52 C1:12 C1:11 4/86 4/116 C2:3 C2:4 G029158 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 49: Data Communication Lin, 1:2

    C3:50 BUS 1 BUS 2 4/102 YE-BU BUS 3 C3:49 GY-BU YE-BU C1:36 7/149 GY-RD C4:8 BUS 2 4/119.2 C2:17 GY-BN BUS 0 C2:40 74/412 C4:4 GY-BN GY-BN 4/119 GY-BN 4/93 C4:14 GY-BN TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 50 6/48 BLIS GN-WH BLIS GN-WH 3/176 27/3 3/126 3/127 27/4 6/95 C2:4 C1:20 BLIS BLIS GN-WH GN-WH GN-WH GN-WH 73/5019 GN-WH GN-WH GN-WH 3/128 3/129 74/507 74/509 74/510 74/508 GN-WH GN-WH GN-WH GN-WH TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 51: Data Communication Most

    74/402 74/404 3/281 16/105 C4:1 C4:2 16/108 C3:1 16/145 RDAR C3:1 C3:2 C3:2 16/79 74/529 C2:1 C2:2 16/162 DABM C3:1 C3:2 16/145 RDAR 16/162 DABM RDAR/DABM C3:2 C3:1 74/529 74/529 16/79 C2:2 C2:1 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 52: Steering Wheel Module (Swm)

    C1:4 3/131 3/135 C1:3 SWSR 3/281 74/401 C1:6 C1:6 C3:5 GN-OG GN-OG C1:2 C3:4 C1:3 73/4016 C1:2 73/4017 C2:1 C2:2 8/30 C2:33 C2:8 C2:34 C2:7 BN-OG C2:36 C2:2 8/61 C2:35 C2:1 OG-BK 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 53: Group 23 Fuel System

    YE-GY 73/3058 20/5 A:16 BU-OG YE-GY 20/6 A:24 GN-VT A:28 BU-BN 6/120 GN-VT C:24 C:32 BU-WH YE-VT C:29 BU-GN YE-VT C:22 A:29 7/24 A:21 SCRN 73/3094 B:47 BK-YE BK-YE 73/3083 31/XX10 BU-BN BU-BN TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 54 4/93 B:20 BK-WH 74/514 C5:14 VT-WH B:37 B:38 74/507 73/5071 73/5072 6/62 3/270 B:32 BN-YE 6/33 B:48 BK-YE BK-YE B:26 BK-YE BK-YE 7/69 B:42 BK-YE B:24 B:36 BU-BN BU-BN 31/XX10 31/84 31/7 31/66 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 55: Engine Management System, 5-Cyl. Turbo 1:2

    GY-BK 73/3004 YE-GY BK-BU 20/5 A:34 BK-RD BU-OG 31/89 7/166 73/3083 A:10 BU-GN GY-YE A:85 A:20 GN-WH 6/120 A:75 BU-GN BU-OG A:14 A:19 73/3089 A:88 GN-VT A:65 BU-RD YE-VT A:74 BU-BN BU-BN 31/2 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 56 B:26 YE-OG YE-OG YE-OG B:21 B:34 BK-WH BK-WH B:35 74/511 74/514 74/507 17 18 73/5072 73/5071 4/83 B:54 6/62 B:41 7/69 BK-YE BK-YE BK-YE 73/3012 6/33 BK-YE BU-BN BU-BN 31/84 31/7 31/66 31/XX10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 57: Engine Management System, 6-Cyl. 1:2

    YE-GY 20/4 YE-GN A:57 BK-OG YE-BU YE-GY 31/88 20/6 YE-GN A:56 BK-RD GN-VT 31/89 7/81 A:24 WH-BN A:23 A:69 BU-GN GY-BU 6/139 A:38 BK-YE GY-BU 73/3094 6/140 A:39 BK-YE GY-BU 73/3039 31/XX10 GY-BU TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 58 BU-WH B:26 B:21 YE-OG YE-OG YE-OG B:34 BK-WH BK-WH B:35 74/511 74/514 74/507 17 18 73/5072 73/5071 4/83 B:54 B:41 6/62 BK-YE BK-YE BK-YE 7/69 73/3012 6/33 BK-YE GY-BU 31/66 31/XX10 31/84 31/7 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 59: Engine Management System 6-Cyl. B6324S2 1:2

    BK-OG YE-BU YE-GY 31/88 20/6 YE-GN C2:1 A:56 BK-RD GN-VT 7/81 31/89 A:24 WH-BN A:23 A:69 BU-GN A:92 BU-BN 73/3095 6/139 A:38 BK-YE GY-BU 6/140 73/3133 A:39 BK-YE GY-BU 73/3039 73/3094 GY-BU 31/XX10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 60 BU-WH YE-OG B:21 YE-OG YE-OG B:34 BK-WH BK-WH B:35 74/511 74/514 74/507 17 18 73/5072 73/5071 4/83 B:54 B:41 6/62 BK-YE BK-YE BK-YE 73/3012 7/69 73/3094 6/33 BK-YE GY-BU 31/XX10 31/66 31/84 31/7 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 61: Engine Management System, 6-Cyl. Turbo 1:2

    A:62 YE-GN YE-GY 20/4 YE-GN A:57 BK-OG YE-BU YE-GY 31/89 20/6 YE-GN A:56 BK-RD GN-VT 7/81 31/88 A:24 BU-BN A:23 A:69 BU-GN 8/28 YE-BU A:95 GY-BU A:90 YE-OG 8/68 73/3039 GY-BU GY-BU GY-BU TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 62 B:26 BU-WH YE-OG YE-OG B:21 YE-OG B:34 BK-WH BK-WH B:35 74/511 74/514 74/507 17 18 73/5072 73/5071 4/83 B:54 B:41 6/62 BK-YE BK-YE BK-YE 7/69 73/3012 6/33 BK-YE GY-BU 31/XX10 31/84 31/7 31/66 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 63: Engine Management System, 8-Cyl. 1:2

    CYL 5 20/8 YE-GN BU-GN A:74 VT-BN 3 Au BU-OG A:11 GN-VT A:67 YE-GY A:24 CYL 8 20/12 YE-GN A:65 BU-RD A:16 YE-GY 31/89 CYL 7 20/13 VT-WH BU-BN 31/100 31/XX10 GY-BU BU-BN TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 64 B:20 BK-WH BK-WH B:29 C5:14 3/284 VT-WH BN-GN 74/511 74/514 74/507 17 18 73/5072 73/5071 6/62 4/83 7/69 B:58 B:45 BK-YE BK-YE BK-YE BK-YE 73/3012 6/33 BK-YE GY-BU BU-BN 31/84 31/7 31/XX10 31/66 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 65: Emission Control, 4-Cyl

    4 CYL Petrol 73/3006 YE-BU 6/99 C:B1 WH-VT C:B2 YE-BU 7/15 B:C1 GN-BN C:C1 BU-BN YE-GN C:C2 B:E1 VT-GN B:M1 YE-BU YE-GN 73/3079 7/82 7/25 A:B2 YE-VT B:D1 WH-OG YE-GN B:E2 GN-BN YE-GN A:B3 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 66: Emission Control, 5-Cyl. Turbo

    B:54 7/15 B:41 A:73 YE-BK YE-BU YE-RD A:91 A:67 YE-GN A:92 VT-BN 7/172 A:68 GN-BK A:16 GN-BN A:36 7/103 GY-VT A:49 A:83 YE-RD YE-BU BU-BK A:90 7/173 A:17 YE-VT A:95 A:37 A:59 GN-VT TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 67: Emission Control, 6-Cyl

    WH-GN A:41 BU-BK 73/3039 GY-BU B:41 GY-BU 8/125 W/O Turbo B:54 A:90 8/126 GY-BU W/O Turbo WH-OG A:91 8/117 GY-BU A:86 7/172 A:11 GN-BN A:34 YE-RD A:12 7/173 YE-VT GN-BN Turbo A:33 GN-VT TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 68: Emission Control, 8-Cyl

    74/86 7/172 VT-BN A:27 A:72 GN-BN GN-BN GN-BN GN-BN 73/3006 7/103 73/3061 GN-BN A:88 A:34 YE-RD YE-RD YE-BU A:40 VT-GN A:22 7/173 GN-BN 7/104 A:89 GY-VT A:32 WH-GN YE-BU A:41 BU-BK A:45 WH-GN TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 69: Engine Management System, 4-Cyl. Diesel Dw10 1:2

    B:39 BU-WH B:18 GN-BU B:17 YE-GN 7/174 WH-BU B:25 B:37 BN-BU GN-OG 74/307 A:31 BK-YE A:32 BK-YE B:47 BK-YE 73/3094 B:48 BK-YE BK-YE C:21 BK-YE 20/22 20/23 20/24 20/25 73/3012 C:46 BK-YE 31/XX10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 70 17 18 C:13 GN-BN C:39 BN-BU C:15 8/120 B:40 BN-WH 6/62 B:16 WH-OG B:28 GY-OG B:11 YE-BU 7/69 B:23 WH-VT 7/54 A:21 YE-VT A:28 BU-WH C:22 BU-BN 73/3039 C:10 BU-BN BU-BN BU-BN 31/84 31/7 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 71: Engine Management System, 4-Cyl. Diesel Dv6B 1:3

    6/99 A:71 4 Au YE-BU A:67 BN-YE A:11 A:18 BU-GN 8/122 A:92 3 Au GN-BU BN-YE 73/3081 A:82 GN-WH A:43 BU-GN 74/307 BK-YE BK-YE 73/3094 BK-YE BK-YE 20/22 20/23 20/24 20/25 73/3012 31/XX10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 72 A:33 BN-BU A:10 GN-BU 8/120 6/34 74/541 74/507 17 18 A:52 BN-WH GN-BU A:81 WH-OG GY-OG A:40 GY-OG A:24 YE-BU A:72 WH-VT GY-OG 6/62 BK-YE 7/69 73/3039 BU-BN BU-BN BU-BN 31/84 31/7 31/66 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 73 BN-GN 7/77 VT-GY A:85 YE-BU A:37 7/154 A:61 A:78 VT-WH A:35 BU-BN 7/25 GY-VT A:42 A:77 YE-VT A:53 GN-BN 7/71 A:15 BU-WH A:87 GN-BU A:89 YE-GN 7/174 GN-OG A:44 A:63 WH-BU A:41 BN-BU TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 74: Engine Management System, 5-Cyl. Diesel Single Turbo 1:3

    73/3131 74/504 4/109 8/98 10 9 7 6 1 Au VT-BK A:42 74/301 74/512 8/111 VT-BK 9/32 9/38 A:95 GN-BU 7/35 1 Ag GY-BU 73/3108 GY-YE A:28 BU-GN A:13 73/3094 GN-BN 31/68 31/XX10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 75 4/93 BK-WH B:21 BK-WH B:46 C5:14 VT-WH 3/284 BN-GN 74/514 74/507 17 18 73/5072 73/5071 B:54 B:41 6/62 BK-YE BK-YE 7/69 6/33 BK-YE 73/3012 GN-BN GN-BN GN-BN BK-YE GN-BN 31/XX10 31/84 31/7 31/66 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 76 A:62 1 Au A:61 BU-RD A:21 7/165 A:32 WH-BN BU-GN A:80 A:45 GN-BN A:85 7/81 GN-BN A:78 A:18 A:82 WH-BN 6/120 1 Au A:24 BU-GN YE-VT A:48 A:58 YE-VT BU-WH A:20 VT-WH A:33 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 77: Engine Management System, 5-Cyl. Diesel Twin Turbo 1:3

    YE-OG 74/504 4/109 8/98 10 9 7 6 1 Au VT-BK A:42 74/301 74/512 8/111 VT-BK 9/32 9/38 A:95 GN-BU 7/35 1 Ag GY-BU 73/3108 GY-YE A:28 BU-GN A:13 73/3094 GN-BN 31/68 31/XX10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 78 4/93 B:21 BK-WH BK-WH B:46 C5:14 VT-WH 3/284 BN-GN 74/514 74/507 17 18 73/5072 73/5071 B:54 B:41 6/62 BK-YE BK-YE 7/69 6/33 BK-YE 73/3012 GN-BN GN-BN GN-BN BK-YE GN-BN 31/XX10 31/84 31/7 31/66 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 79 A:62 1 Au BU-RD A:61 A:21 7/165 A:32 WH-BN A:80 BU-GN A:45 GN-BN A:85 7/81 GN-BN A:78 A:18 A:82 WH-BN 6/120 1 Au BU-GN A:24 YE-VT A:48 A:58 YE-VT BU-WH A:20 VT-WH A:33 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 80: Group 26 Cooling System

    Group 26 Cooling system Cooling fan, 4-Cyl. 15/31 11A/43 11A/44 4/46 7/16 A:19 4 CYL GY-BN 74/301 GY-BN GN-BN GN-BN GY-BN C:27 GY-BN 4/71 B:37 B:15 B:38 BK-BU 31/2 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 81: Cooling Fan, 5-Cyl. Turbo & 6-Cyl

    1 Au A:68 A:13 5 CYL T 7/16 6 CYL 5 CYL .T A:42 A:12 BN-GN 74/301 B:53 B:51 GN-BN GN-BN B:31 GY-BN GY-BN I5 T I6/I6T 4/71 B:54 B:41 BK-BU BK-BU 73/3089 31/2 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 82: Cooling Fan, 4-Cyl. Diesel

    4 CYL. BN-GN A:26 DIESEL 74/301 B:27 B:26 GN-BN GY-BN GN-BN GY-BN B:16 DW10 7/16 DV6B 1 Au A:60 BN-GN A:56 A:25 4/71 A:17 DV6B B:58 DW10 A:11 A:70 (DV6B) BK-BU A:69 (DV6B) 31/2 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 83: Cooling Fan, 5-Cyl. Diesel

    Group 26 Cooling system Cooling fan, 5-Cyl. Diesel 15/31 11A/44 11A/43 4/46 7/16 1 Au A:64 BN-GN DIESEL EURO5 74/301 GN-BN GN-BN B:34 GY-BN GY-BN B:11 4/71 B:54 B:41 BK-BU 31/2 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 84: Cooling Fan, 8-Cyl

    Group 26 Cooling system Cooling fan, 8-Cyl. 15/31 11A/43 11A/44 4/46 7/16 1 Au A:68 A:12 8 CYL 74/301 B:12 GN-BN GN-BN B:19 GY-BN GY-BN 4/71 B:58 B:49 B:45 BK-BU 31/2 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 85: Group 27 Engine Controls

    74/504 4/46 B:38 4/80 C1:8 B:37 31/83 C1:9 C1:7 C1:6 4 CYL. Petrol 74/301 BU-WH B:16 Au Au 7/203 6/120 C1:2 GN-VT C:24 C1:6 C:32 BU-WH YE-VT BU-GN C:29 C:22 YE-VT 31/84 31/7 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 86: Cruise Control 4-Cyl. Diesel

    C1:9 A:25, A:69(DV6B) C1:7 Ag(DV6B) C1:6 74/301 BU-WH C:29, B:47(DV6B) Ag(DV6B) 4CYL. DIESEL 15/31 DW10 DV6B Au Au 7/203 2/32 C1:2 C1:6 B:42 DV6B YE-GY 8/111 YE-GY 73/3149 A:94 GN-BU DV6B 31/84 31/7 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 87: Cruise Control 5-Cyl. & 6-Cyl

    BU-RD 5CYL T C1:2 5CYL T A:74 YE-VT C1:6 5 CYL.T 6 CYL. 6/120 6CYL A:75 YE-VT 6CYL BU-GN A:74 6CYL A:17 BU-OG 6CYL A:67 GN-VT 6CYL A:48 6CYL A:65 BU-RD 31/84 31/7 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 88: Cruise Control 5-Cyl. Diesel

    4/46 B:41 4/80 B:25 C1:8 B:54 31/83 C1:9 C1:7 C1:6 74/301 B:30 BU-WH 5 CYL 15/31 DIESEL Au Au 7/203 2/32 C1:2 C1:6 GN-VT B:27 VT-BK 8/111 VT-BK 73/3051 A:95 GN-BU 31/7 31/84 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 89: Cruise Control 8-Cyl

    B:15 C1:8 B:58 31/83 C1:9 C1:7 C1:6 74/301 BU-WH B:28 8 CYL. Au Au 7/203 6/120 C1:2 YE-VT A:75 C1:6 A:74 BU-GN 3 Au BU-OG A:11 A:67 GN-VT A:24 A:65 BU-RD 31/84 31/7 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 90: Group 32 Alternator And Voltage Regulator

    Group 32 Alternator and voltage regulator Power supply 4-Cyl. 31/3 6/25 C2:1 C1:1 4/46 4 CYL 6/26 C1:1 4/46 4 CYL.D VOLT. REG. B:46 C2:1 DW10 BU-BN 4/46 BU-BN 4 CYL DIESEL A:88 BU-BN DV6B TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 91: Power Supply

    8 CYL A:25 6/26 C1:1 4/46 6 CYL A:92 VOLT. REG. I6/I6T 4/46 C2:1 6 CYL BU-BN BU-BN 73/3095 A:92 BU-BN BU-BN B6324S2 4/46 A:46 BU-BN 5 CYL 4/46 A:36 BU-BN 5 CYL DIESEL TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 92: Group 33 Starting System

    4/102 3/132 74/413 73/4027 C3:35 BU-WH C3:50 C3:74 RD-VT RD-VT C3:49 GY-BU C2:27 GY-BN 73/5055 C3:76 YE-BU 3/271 73/4016 C3:42 C3:71 VT-BN 73/5071 BK-GN 73/4012 BK-BU 73/5072 G029512 31/10 31/3 31/7 31/84 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 93: Starting System 5, 6 & 8-Cyl

    4/102 3/132 74/413 73/4027 C3:35 BU-WH C3:50 C3:74 RD-VT RD-VT C3:49 GY-BU C2:27 GY-BN 73/5055 C3:76 YE-BU 3/271 73/4016 C3:71 C3:42 BK-GN VT-BN 73/4012 73/5071 BK-BU 73/5072 G029264 31/10 31/3 31/7 31/84 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 94: Starting System 5-Cyl. Diesel

    4/102 3/132 74/413 73/4027 C3:35 BU-WH C3:50 C3:74 RD-VT RD-VT C3:49 GY-BU C2:27 GY-BN 73/5055 C3:76 YE-BU 3/271 73/4016 C3:71 C3:42 BK-GN VT-BN 73/4012 73/5071 BK-BU 73/5072 G036568 31/10 31/3 31/7 31/84 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 95: Group 35 Lighting

    C3:51 C5:1 C5:2 74/411 3/111 C1:76 RD-BK C3:52 GN-VT C1:75 C1:49 C1:50 73/4017 C1:74 C1:73 BK-VT BK-OG 10/1 10/2 TURN HIGH TURN HIGH VT-OG GY-BN BU-GN 73/3033 73/3035 YE-RD 73/4016 31/93 31/94 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 96: High And Low Beam (Dual Xenon)

    BU-GN C1:49 C1:50 73/3073 73/4017 C1:74 C1:73 VT-OG 73/3035 73/3033 BK-VT BK-OG 73/3072 BK-VT BK-OG 10/1 10/2 TURN HIGH XENON TURN HIGH XENON HIGH / HIGH / BU-GN YE-RD 73/4016 31/93 31/94 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 97: Beam Length Adjustment, Manual

    Group 35 Lighting Beam length adjustment, manual 15/31 2/31 11B/27 11A/1 11A/2 11B/23 11B/16 74/411 4/56 C5:1 C5:2 C1:45 3/111 C3:52 GN-VT 10/2 10/1 HIGH TURN HIGH TURN VT-GN VT-GN 74/411 73/4017 73/4016 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 98: Beam Length Adjustment, Automatic (Dual Xenon)

    GN-OG C1:14 VT-WH C1:12 GY-BU 7/119 C1:19 YE-GN C1:9 GN-BN Four-C C1:20 BU-RD 7/121 C1:17 YE-GN YE-GN YE-GN C1:8 GN-BN GN-BN GN-BN Four-C C1:18 GN-VT GN-VT GN-VT 74/512 74/504 C1:7 BK-GN 73/3036 31/95 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 99: Running-/ Parking Lights, Tail Lights V70

    73/4016 BK-OG C1:50 C1:40 BK-VT 10/2 10/1 C2:52 C2:50 C2:24 HIGH TURN HIGH TURN GN-OG 74/602 GY-RD WH-OG 10/3 3/35 KVM / 10/18 10/17 73/6001 73/5033 74/602 73/5105 31/48 31/94 31/93 31/83 31/47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 100: Running-/ Parking Lights, Tail Lights S80

    BK-VT 10/2 10/1 C2:52 C2:50 C2:24 HIGH TURN HIGH TURN GN-OG 74/601 GY-RD YE-BK VT-GN 10/3 10/18 10/17 TURN STOP STOP TURN 3/35 73/5038 74/601 BK-OG 73/5105 73/5033 31/47 31/48 31/94 31/93 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 101: Running/ Parking Light, Tail Lights(Dual Xenon) V70

    Group 35 Lighting Running-/ Parking light, Tail lights (Dual Xenon) V70 15/31 11A/1 11A/2 11B/23 C1:2 C1:6 4/56 C5:1 C5:2 74/411 3/111 RD-BK C3:52 GN-VT 73/4017 C1:49 C1:10 73/4016 BK-OG C1:50 C1:40 BK-VT 10/1 10/2 C2:52 C2:50 C2:24 TURN HIGH...

  • Page 102: Running/ Parking Light, Tail Lights (Dual Xenon) S80

    TURN HIGH XENON TURN HIGH XENON HIGH / HIGH / GN-OG 74/601 GY-RD YE-BK VT-GN 10/3 10/18 10/17 TURN STOP STOP TURN 3/35 73/5038 74/601 BK-OG 73/5105 73/5033 31/47 31/48 31/94 31/93 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 103: Fog Lights V70

    11A/2 11B/23 C1:6 RD-BK BU-RD YE-OG 4/56 C5:1 C5:2 C1:69 C1:68 74/411 3/111 RD-BK GN-VT 73/4017 C3:52 73/4016 74/602 73/6004 BN-GN 73/3033 10/18 10/17 73/6001 73/5033 74/602 73/5105 31/48 31/94 31/93 31/47 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 104: Fog Lights S80

    C1:6 RD-BK BU-RD YE-OG 4/56 C5:1 C5:2 C1:69 C1:68 74/411 3/111 RD-BK GN-VT 73/4017 C3:52 73/4016 WH-BU 73/3035 73/3033 BN-GN 10/18 10/17 TURN STOP STOP TURN 73/5105 73/5033 31/93 31/83 31/94 31/47 31/48 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 105: Brake Light V70

    15/31 11A/2 11A/1 4/56 C5:2 C5:1 C2:66 4/93 RD-WH C1:49 C2:54 C5:14 VT-WH VT-WH C1:50 74/602 C2:34 YE-GY 10/19 C2:38 C2:59 BK-OG 73/5089 74/602 73/6002 10/18 10/17 73/6001 73/5033 74/602 73/5105 31/48 31/47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 106: Brake Light S80

    C5:1 C2:66 4/93 RD-WH C1:49 C5:14 C2:54 VT-WH VT-WH C1:50 C4:6 YE-GY 10/19 C2:38 C2:59 73/4014 BK-WH VT-BN 73/5054 VT-BN 10/18 10/17 TURN STOP STOP TURN 74/414 73/5105 73/5033 73/4012 31/10 31/47 31/48 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 107: Reversing Lights V70

    74/301 74/411 BN-VT BN-VT BN-VT BN-VT 11A/1 11A/2 A:14 4/56 C5:1 RD-BK C5:2 RD-BU C3:47 C3:48 C1:26 C2:73 74/301 74/602 3/10 73/6003 10/18 10/17 73/3133 73/6001 74/602 73/5033 73/3094 73/5105 31/XX10 31/48 31/47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 108: Reversing Lights S80

    74/411 BN-VT BN-VT BN-VT BN-VT 11A/1 11A/2 A:14 4/56 C5:1 RD-BK C5:2 RD-BU C3:47 C3:48 C1:26 C2:73 C2:62 74/301 3/10 10/18 10/17 TURN STOP STOP TURN 73/3133 73/5105 73/5033 73/3094 31/XX10 31/47 31/48 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 109: Follow-Me-Home Lighting, Lhd

    11D/A2 74/508 74/507 3/126 3/127 C1:2 C1:2 C2:3 C2:3 C2:12 BK-VT C2:12 BK-VT C2:23 C2:23 C2:15 C2:15 C1:20 C1:20 C1:13 C1:13 6/62 6/63 73/5037 73/5024 10/149 10/148 74/508 74/507 73/5035 73/5023 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 110: Follow-Me-Home Lighting, Rhd

    11D/A1 74/508 74/507 3/127 3/126 C1:2 C1:2 C2:3 C2:3 C2:12 BK-VT BK-VT C2:12 C2:23 C2:23 C2:15 C2:15 C1:20 C1:20 C1:13 C1:13 6/62 6/63 73/5037 73/5024 10/149 10/148 74/508 74/507 73/5035 73/5023 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 111: Interior Lighting, Lhd 1:2

    2 Off BU-RD 3 Ctsy MAP READING BU-RD 74/403 3/117 C1:2 C1:1 10/72 3/272 BK-VT 10/150 16/181 BK-VT 73/5026 BK-WH 73/4014 74/502 BU-WH 73/4020 BU-WH 73/4016 BU-WH BU-WH 73/5035 73/4012 BK-WH BK-WH BK-WH 74/414 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 112 3/82 74/509 6/56 6/55 3/127 C1:2 LOCK UNLOCK C1:4 C2:5 C2:3 C2:21 C2:15 GN-BN 3/83:5 C1:15 C1:13 73/5035 3/129 73/5024 GN-BU BK-GN KEYLESS 73/5025 BK-GN 18 VT-RD 74/508 74/510 BK-GN 73/5023 31/15 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 113: Interior Lighting, Rhd 1:2

    3 Ctsy MAP READING BU-RD 74/403 3/117 C1:2 C1:1 10/72 3/272 BK-VT 10/150 16/181 BK-VT 73/5026 73/4017 BK-WH 73/4014 74/502 BU-WH 73/4020 BU-WH 73/4016 BU-WH BU-WH 73/5023 73/4012 BK-WH BK-WH BK-WH BK-WH 74/414 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 114 74/509 6/56 6/55 3/126 LOCK UNLOCK C1:2 C1:4 C2:5 C2:3 C2:21 C2:15 C2:20 GN-RD GN-RD C1:15 C1:13 73/5035 3/129 73/5037 GN-BU BK-GN KEYLESS 73/5025 BK-GN 18 VT-RD 74/508 74/510 BK-GN 73/5023 31/15 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 115: Active Headlights

    C1:2 C1:14 VT-WH C1:12 YE-GN 7/119 C1:19 YE-GN C1:9 Four-C GN-BN C1:20 BU-RD 74/504 74/512 7/121 C1:17 YE-GN YE-GN YE-GN Four-C C1:8 GN-BN GN-BN GN-BN C1:18 GN-VT GN-VT GN-VT C1:7 BK-GN 73/3036 31/95 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 116: Lighting In Sill Moldings

    Lighting in sill moldings 15/31 11A/1 11A/2 BU-WH 4/56 C5:1 C5:2 BU-WH K10-A 10X/125 73/4019 BU-WH GY-BK 10/126 10/125 C3:67 10X/126 C3:19 BU-WH C3:37 GY-BK GY-BK GY-BK 10/249 10/250 26/6 26/7 10/251 10/252 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 117: Auxiliary Lights

    Group 35 Lighting, Accessories Auxiliary lights 15/31 11A/2 11A/1 11B/28 3/60 4/56 C°/F° C5:1 RD-BK C5:2 RD-BU C1:50 C1:49 C1:7 C1:12 73/ALS3 C1:7 2/64 1(86) 3(30) 5(87) 2(85) 73/ALS1 73/ALS2 10/69 10/65 31/AL TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 118: Lighting In Doors Lhd

    73/5023 KEYLESS 73/5035 73/3030 GY-OG GY-OG 10/284 GY-OG 73/5025 73/5036 BK-VT 3X/19 3X/21 VT-RD VT-RD 3/128 KEYLESS BK-VT 22 11 18 3/129 22 11 18 BK-VT RD-BU RD-BU 74/509 G028988 31/15 31/6 31/96 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 119: Lighting In Doors Rhd

    KEYLESS 73/5035 73/3036 GY-OG GY-OG 10/284 GY-OG 73/5025 73/5036 3X/19 BK-VT 3X/21 VT-RD 3/128 KEYLESS BK-VT 22 11 18 10/285 3/129 22 11 18 BK-VT VT-RD RD-BU RD-BU 74/509 G028989 31/15 31/6 31/95 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 120: Lighting Mug Holder And Floor

    C3:22 BU-RD BU-RD BK-VT 10X/72 C1:49 C1:50 10/72 BU-RD BU-RD C2:65 C1:54 10/161 BK-VT BK-VT 74/1502 BU-RD BU-RD BK-VT BK-VT 10/286 10/287 74/1503 74/502 73/3030 73/3036 19/4:1 19/4:2 73/5035 31/84 31/7 31/96 31/95 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 121: Group 36 Additional Electrical Equipment

    11A/2 3/130 4/56 C5:1 C5:2 K10-A C1:7 C3:51 GN-BK 7/149 C4:17 BU-BK C4:8 GY-RD 73/4014 BK-WH C2:65 C1:36 74/414 1 LHD 4 RHD 3 LHD 2 RHD 73/4012 73/3034 31/XX15 31/10 31/7 31/84 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 122: Direction Indicator And Hazard Warning Flashers Lhd V70

    Group 36 Additional electrical equipment Direction indicator and Hazard warning flashers LHD V70 RD-GN 73/5075 15/31 15/32 3/130 11A/1 11A/2 11A/3 11D/A1 11D/A2 C1:2 C1:6 74/504B RD-GN C1:7 74/508 4/56 C5:1 C5:2 74/507 RD-BK 3/127 3/126 C1:2 C1:2 C2:3 C2:3...

  • Page 123: Direction Indicator And Hazard Warning Flashers Lhd S80

    C3:41 C2:18 C1:1 6/62 6/63 BK-VT 73/5024 10/1 10/2 TURN HIGH TURN HIGH 10/17 10/18 TURN STOP STOP TURN 73/3033 73/4012 74/508 74/507 73/5105 73/5033 73/5023 31/47 31/6 31/93 31/10 31/94 31/15 31/48 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 124: Direction Indicator And Hazard Warning Flashers Rhd V70

    Group 36 Additional electrical equipment Direction indicator and Hazard warning flashers RHD V70 RD-GN 73/5075 15/31 15/32 3/130 11A/1 11A/2 11A/3 11D/A1 11D/A2 C1:2 C1:6 74/504B RD-GN C1:7 74/507 4/56 C5:1 C5:2 74/508 RD-BK 3/127 3/126 C1:2 C1:2 C2:3 C2:3...

  • Page 125: Direction Indicator And Hazard Warning Flashers Rhd S80

    C3:41 C2:18 C1:1 6/63 6/62 BK-GN 73/5024 10/1 10/2 TURN HIGH TURN HIGH 10/17 10/18 TURN STOP STOP TURN 73/4012 73/3033 74/508 74/507 73/5035 73/5105 73/5033 31/47 31/15 31/93 31/94 31/6 31/10 31/48 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 126: Windshield Wiper/Washer

    73/3034 BK-RD BK-RD 4/56 C1:36 C5:2 C5:1 C1:45 74/304 BU-GY BU-GY K5-B K5-A 73/3040 C1:49 C1:50 C1:71 C3:51 C1:72 3/130 73/3037 BK-OG BK-OG 74/304 6/127 18/4 73/3033 WIPER C1:7 GN-BK TURN 31/93 31/XX15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 127: High-Pressure Headlight Washer

    Group 36 Additional electrical equipment High-pressure headlight washer 15/31 11B/27 2/193 1(86) 3(30) 5(87) 2(85) 3/130 11B/24 18/4 4/56 WIPER C1:7 C3:51 GN-BK TURN C1:48 GN-VT C1:47 BU-BK 74/309 73/3035 BK-OG YE-OG 31/94 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 128: Wiper/Washer Rear Window

    Wiper/washer rear window 15/31 3/130 11A/2 11A/1 4/56 18/4 C5:2 C5:1 K10-A WIPER GN-BK C1:7 C3:51 TURN C2:74 C2:44 GY-BN RD-GY 15/32 2/16 RD-GY 6/32 74/602 GY-BU VT-GN BK-OG 73/5105 BK-OG BK-OG 73/6001 31/47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 129: Horn

    Horn 15/31 11A/1 11A/2 11B/29 RD-VT 73/3041 15/33 3/130 3/37 2/17 18/4 C3:2 C3:6 C1:2 C1:10 4/56 C3:13 C5:1 RD-BK C5:2 RD-BU C1:46 16/10 GY-BK BK-VT 16/11 GY-BK BK-VT 73/3035 73/4016 31/83 31/94 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 130: Keyless Vehicle 1:2

    VT-WH C2:27 C3:35 C2:54 VT-WH 74/409 C4:15 GY-BN BU-WH BU-WH 73/5055 73/4027 C3:5 RD-VT GY-BN C5:3 BU-RD C5:18 74/601 3/271 3/35 10/3 C3:4 BK-GN 73/5029 73/5072 73/5071 74/601 73/5105 31/84 31/7 31/47 31/67 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 131 C3:2 BU-BN BU-BN 74/603 16/132 C1:21 GN-OG GN-OG GN-OG C1:22 YE-BK 16/133 C1:18 YE-BK C1:2 BN-VT BN-VT 74/501 16/135 C1:4 GN-RD GN-RD C1:16 YE-OG YE-OG 16/134 C2:14 GY-VT GY-VT C2:17 BU-WH BU-WH 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 132: Anti-Theft Alarm

    C2:9 10/3 73/5105 C2:57 73/4014 BK-OG 7/214 RD-BN YE-RD 6/36 74/507 GN-VT Au GN-VT AJAR 6/55 74/508 74/414 GN-BK GN-BK AJAR 6/57 74/509 AJAR 73/4012 6/56 74/510 AJAR 31/47 31/48 31/10 31/95 31/96 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 133: Parking Assistance

    YE-GY 73/5064 7/133 RR/I C3:3 YE-BK BU-WH C3:5 YE-GN YE-GY 15 2 73/5067 GN-WH C1:8 C3:8 BK-GN GN-WH 73/5033 7/132 LR/I BU-WH C1:14 YE-BK C1:7 GN-WH 7/131 LR/O BU-WH YE-GN GN-WH GN-WH 31/48 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 134: Collision Warning With Brake Servo

    C2:3 C1:6 C1:4 C2:4 C1:7 C1:5 C2:5 9/39 74/412 C1:6 C2:6 C1:1 GY-BK GY-BK C1:S C2:S C1:14 C1:11 74/418 74/411 73/4016 73/4017 7/203 GY-OG W/O FLR GY-OG GY-OG 73/3052 GY-OG 73/3030 31/96 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 135: Tire Pressure Warning (Tpms)

    C5:2 C1:49 4/93 C1:50 C3:5 RD-VT C2:17 GY-BN C4:14 C4:3 C4:4 73/5029 BK-GN C3:4 C2:40 C4:4 C4:16 4/119 RD-BN GY-BN BK-WH 73/4014 RD-BN 7/210 7/211 4/119.2 74/412 GY-BN RD-BN 74/414 7/212 7/213 73/4012 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 136: Alcolock

    Group 36 Additional electrical equipment, Accessories Alcolock 15/31 C1:2 11A/1 11A/2 C1:6 4/56 C5:1 C5:2 7/238 K10-A 26/8 73/4019 C3:67 BU-WH C1:49 C1:50 10X/29 C4:16 C2:40 C2:17 C4:4 17/45 GY-BN 10/29 74/412 4/119.2 GY-BN BK-WH 73/4012 RD-BN 31/10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 137: Group 37 Wiring And Fuses Diagnostics System

    Group 37 Wiring and fuses Diagnostics system 15/31 11A/1 4/56 C5:1 C1:50 C1:49 C3:47 C3:48 C3:73 MIDSPEED 73/4017 BK-WH 73/4012 73/4001 73/4002 73/4037 73/4038 73/4016 31/83 31/10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 138: 12V Outlet

    12V outlet 15/31 11A/3 11A/1 11B/27 2/193 11B/25 74/504B 74/504 73/5075 15/32 4/56 C5:1 C1:48 74/502 11D/A6 BK-VT C3:22 9/25 BK-VT BK-VT 73/5026 73/5027 74/403 10/72 17/19 74/502 73/5023 73/5035 31/48 31/15 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 139: Tow Hitch Cable Harness, 4-Pin V70

    74/602 YE-GY C2:34 73/5075 C2:2 C2:59 15/32 10/19 11D/A11 73/5106 74/602 73/6002 10/18 10/17 4/110 C1:2 C2:3 C2:5 17/37 C3:7 C2:1 C3:3 C2:2 C3:12 C2:4 BK-OG 73/5030 73/6001 74/602 73/5105 31/TRM 31/65 31/47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 140: Tow Hitch Cable Harness, 4-Pin S80

    VT-WH C2:54 73/5075 C2:2 C2:59 15/32 73/5106 73/5054 11D/A11 4/110 C1:2 10/17 C2:5 C2:3 VT-BN STOP TURN 17/37 C3:7 C2:1 C3:3 C2:2 C3:12 BK-OG C2:4 10/18 TURN STOP 73/5033 73/5105 31/TRM 31/47 31/48 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 141: Tow Hitch Cable Harness, 7-Pin V70

    15/32 10/19 74/602 11D/A11 73/5106 73/6002 10/18 10/17 4/110 C1:2 C3:10 C2:3 C3:2 17/38 C2:5 C3:6 C3:8 C2:1 C2:2 C3:1 C3:12 C3:3 BK-OG C2:4 C3:7 73/5030 73/6001 BK-OG 74/602 73/5105 31/65 31/TRM 31/47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 142: Tow Hitch Cable Harness, 7-Pin S80

    15/32 11D/A11 73/5054 73/5106 4/110 C1:2 C3:10 10/17 C2:5 C3:2 17/38 C2:3 VT-BN STOP TURN C3:6 C3:8 C2:1 C2:2 C3:1 C3:12 C3:3 C2:4 BK-OG C3:7 10/18 TURN STOP 73/5033 73/5105 31/TRM 31/48 31/47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 143: Tow Hitch Cable Harness, 13-Pin V70

    11D/A11 73/5106 73/6002 10/18 10/17 4/110 C3:1 C1:2 C3:3 C2:3 C3:7 C2:5 C3:12 C2:1 C3:10 C2:2 C3:6 C3:8 BK-OG C2:4 73/5030 C3:2 73/6001 17/39 BK-OG 74/602 73/5105 RESERVE: INDICATION TRAILER 31/TRM 31/65 31/47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 144: Tow Hitch Cable Harness, 13-Pin S80

    4/110 C3:1 C1:2 10/17 C3:3 C2:5 BU-RD C3:7 C2:3 VT-BN STOP TURN C3:12 C2:1 C3:10 C2:2 C3:6 C3:8 C2:4 BK-OG C3:2 10/18 17/39 TURN STOP 73/5033 73/5105 RESERVE: INDICATION TRAILER 31/TRM 31/48 31/47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 145: Accessory Usb Unit (Auu)

    GY-YE GY-YE GY-YE 73/4016 C1:10 GY-YE 73/4018 74X/401 74/401 GN-OG C1:6 GN-OG GY-OG C1:2 GY-OG VT-OG VT-OG C1:3 GN-WH 4/124 C1:1 C1:2 17/42 YE-BN GN-WH VT-BK C2:2 C2:1 74X/402 74/402 C2:2 C2:1 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 146: Group 38 Instruments

    Group 38 Instruments Seat belt reminder 15/31 11/A2 11/A1 4/56 C5:1 C5:2 3/117 10/22 C4:2 C1:8 C1:4 BK-WH VT-OG 73/4014 C2:23 7/175 74/414 BK-OG 73/5030 BK-GN 73/4012 73/5029 31/65 31/67 31/10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 147: Driver Information Module

    GY-BU C1:25 C1:11 BK-GN 73/3030 7/73 C1:27 GY-VT 31/93 31/96 31/83 BU-WH 4/111 74/511A 73/3036 74/511 18 19 26/5 μ 31/95 11 13 74/511B 74/541 6/33 6/33 6/34 Additive tank FlexiFuel DV6B 31/66 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 148: Analog Clock

    16/1 C1:49 C2:1 C1:50 10X/72 C2:65 C1:54 74/401 74X/401 GN-WH YE-BN GN-WH GN-OG 74/1502 VT-BK GY-OG VT-OG GY-YE GY-YE GY-YE GY-YE 3/281C1:1 3/281C1:10 11/1 74/1503 74/502 73/3030 73/3036 19/4 31/84 31/7 31/96 31/95 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 149: Group 39 Other Audio Premium 1:3

    74/420 C1:1 C5:1 VBUS C1:4 C5:4 C1:2 C5:2 DATA - C1:3 C5:3 DATA + C1:5 C5:5 SHIELD 74/409 C2:2 GN-VT 74/405 C3:1 C3:1S 16/138 16/16 AM/FM2 C1:1 C2:1 C3:1 C3:1S C1:1 31/83 C1:2 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 150 C2:16 C3:22 BU-RD BU-RD WH-OG WH-OG C2:15 C2:17 GN-VT GN-VT C2:1 BU-OG BU-OG C2:13 GY-BN GY-BN C2:2 YE-GN YE-GN C2:3 C2:14 YE-VT YE-VT C2:4 73/5026 74/502 BK-GN BK-VT 73/5023 73/5035 31/INFOT 31/15 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 151 GN-BK GY-BK 16/4.1 16/5 74/510 C1:13 VT-RD VT-RD VT-RD C1:5 YE-RD YE-RD YE-RD 16/137 VT-RD YE-RD 16/6 74/509 C1:12 GN-RD GN-RD GN-RD C1:4 GY-RD GY-RD GY-RD 16/136 GN-RD GY-RD 16/26 74/409 C1:10 C1:2 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 152: Audio 1:2

    C1:10 C3:64 73/4018 C2:1 GY-YE GY-YE C2:8 73/4016 16/123 74/403 C2:10 C2:11 C2:12 16/98 74/412 C2:4 C2:5 74/409 C2:2 GN-VT 74/405 C3:1 C3:1S 16/138 16/16 AM/FM2 C1:1 C2:1 C3:1 C3:1S C1:1 C1:2 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 153 VT-BK C1:7 16/4.2 YE-BK 74/507 C1:6 GN-BK GN-BK GN-BK C1:12 GY-BK GY-BK GY-BK 16/5 74/510 C1:4 VT-RD VT-RD VT-RD C1:10 YE-RD YE-RD YE-RD 16/6 74/509 C1:3 GN-RD GN-RD GN-RD C1:9 GY-RD GY-RD GY-RD TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 154: Cellular Phone 1:2

    C3:64 74/503 74/403 C1:5 GY-YE GY-YE AUDIO PREMIUM GY-YE 16/98 74/412 3/130 16/1 C1:6 C2:5 GY-YE C2:4 C2:1 73/4016 C4:1 C2:8 C1:6 C4:2 74/401 3/281 73/4017 C2:1 C2:2 C1:2 GN-OG C1:6 C1:3 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 155 C3:2 C3:1 GN-VT CLOCK 3/267 74/412 C1:1 BN-GN BN-GN C1:2 GY-VT GY-VT C1:3 BU-GY BU-GY C1:4 YE-VT YE-VT C1:13 C1:14 C1:15 16/47 74/406 C2:1 C3:1 TELE C2:1S C3:1S C5:1 C1:1 C5:1S C1:1S 74/419 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 156: Dab Radio

    C3:1 C3:2 74/531 74/531 C2:1 C2:1 C2:1S C2:1S 73/5086 74/532 C1:2 C2:2 C2:2S 16/16 C4:1 C4:1S 16/1 16/16 C4:1 C3:2 AM/FM2 C4:2 C3:2S 3/281 16/105 C2:1 C2:2 C1:2 C4:1 C1:3 C4:2 C1:6 31/INFOT TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 157: Bluetooth Phone System

    Group 39 Other Bluetooth phone system 15/31 11A/5 74/505 RD-BN 15/32 11D/D7 74/503 74/403 16/147 C2:1 C1:32 C2:2 C1:16 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 158: Bluetooth Handsfree

    1 0/22C1 :5 11D/D6 GY-YE 74/503 74/403 16X/1C2 AUDIO PREMIUM GY-YE GY-YE GY-YE GY-YE 73/4016 C2:8 16/123 74/403 C2:10 C2:12 C2:11 16/98 74/412 C2:4 C2:5 74/409 C2:2 GN-VT GN-VT GN-VT 16/16 C1:1 AM/FM2 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 159: Multimedia & Traffic Information

    C1:6 C3:1 HLDF 74/408 C2:2 C1:2 C2:2 SYNC SYNC C3:2 C1:3 C2:3 C2:3 VREF V-GND C1:4 C2:4 C1:5 C2:5 C1:6 C2:6 C1:S C2:S S-GND C1:11 C5:1 C5:1S C4:1 C4:1S 73/5086 16/16 16/47 31/INFOT TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 160: Rear Seat Entertainment

    73/5026 D:21 BU-RD RD-WH RD-WH 74/502 D:18 RCA RCA RCA D:19 16/81B 74/702 E:13 E:14 RD-WH RD-WH E:15 GY-OG E:16 D:23 VT-OG E:17 E:18 D:24 E:20 D:10 E:19 E:22 E:23 E:24 31/15 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 161: Satellite Radio

    Satellite radio 15/31 11A/5 74/505 RD-BN 15/32 11D/D4 16/145 C1:1 RD-BN RDAR 16/47 C2:1 C2:1 C2:1S C2:1S 73/5086 C1:2 C3:1 C3:2 16/1 C4:1 C4:2 3/281 16/105 C2:1 C2:2 C1:2 C4:1 C1:3 C4:2 C1:6 31/INFOT TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 162: Parking Camera

    C3:1 HLDF 16/108 C1:6 C3:2 C3:1 74/408 C2:2 C1:2 C2:2 SYNC SYNC C3:2 C1:3 C2:3 C2:3 V-GND VREF C1:4 C2:4 73/5030 C1:5 C2:5 C1:6 C2:6 C1:S C2:S S-GND C1:11 73/5086 31/INFOT 31/65 31/47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 163: Navigation System, Portable

    Group 39 Other, Accessories Navigation system, portable 15/31 11A/1 11B/27 2/193 11B/25 74/504 74/502 16/45 4/56 C5:1 C1:48 FUSE 2A 9X/1 NAVI PORTABLE 73/5027 73/5026 74/502 73/5023 73/5035 31/15 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 164: Group 43 Transmission

    11A/1 11A/2 4/46 3/282 B:26 I5D GY-VT 4/56 C5:1 C5:2 3/10 74/301 C1:26 7/123 C1:51 C1:53 WH-VT C1:52 BN-GN C3:43 74/403 73/3133 8/134 WH-BN BK-VT 73/5026 73/3094 74/502 73/5023 73/5035 31/15 31/6 31/XX10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 165: Automatic Transmission Tf-80Sc Awd

    C1:45 C5:1 C5:2 C1:50 C1:49 3/156 8/36 74/301 74/411 74/403 A:16 BU-GY BU-GY BU-GY BU-GY A:13 GN-OG GN-OG GN-RD GN-OG BN-VT BN-VT BN-VT BN-VT 74/502 BK-VT 73/5026 73/3094 73/5023 73/5035 31/XX10 31/15 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 166: Automatic Transmission Mps6

    GN-OG 73/3014 BU-BK BU-BK A:17 BN-VT HISPEED GN-BK GN-BK 73/3015 74/301 A:19 BK-YE 73/3094 3/156 74/411 74/411 74/403 BN-VT BN-VT GN-RD GN-OG BU-GY BU-GY 8/36 74/502 BK-VT 73/5026 73/5023 73/5035 31/15 31/6 31/XX10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 167: Differential Electronic Module (Dem)

    11A/4 4/56 C5:1 RD-BK 74/504B C5:2 RD-BU C3:48 C3:47 73/5040 C2:45 15/32 2/88 11D/B6 GN-RD 4/82 74/511 74/520 C1:1 GN-RD GN-RD BU-BK BU-BK C1:8 GN-BK C1:7 GN-BK C1:4 BK-YE C1:2 BK-YE 74/514 31/65 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 168: Group 55 Parking Brake Electronic Parking Brake

    C3:22 74/504B 73/5040 BU-RD 15/32 3/272 11D/B11 11D/B12 73/4017 74/409 73/4016 4/115 C1:15 C1:13 73/5070 C1:28 BK-OG C1:30 BK-OG 74/514 74/524 Ag Ag Ag Ag 6/146 6/147 2- 1+ 2- 1+ 31/47 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 169: Group 59 Brake System

    C1:43 YE-BK YE-BK C1:42 BU-RD BU-RD C1:19 GN-OG GN-OG C1:18 BU-WH BU-WH C1:22 VT-BN VT-BN C1:29 GN-VT GN-VT 8/46 C1:24 VT-GY C1:23 BU-GY C1:21 WH-GN C1:31 GY-OG C1:17 YE-GN C1:16 C1:47 73/3070 31/XX14 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 170: Group 64 Steering

    4/56 15/31 11A/44 11B/27 11A/2 11A/1 2/31 C5:1 RD-BK C5:2 RD-BU GN-VT C1:45 C1:17 11/B19 11/B22 74/301 6/164 DV6B C1:1 C2:1 C2:2 C2:3 C1:2 4/99 VT-WH 6/71 GN-BU WH-GN BK-OG 73/3033 31/XX5 31/93 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 171: Group 76 Shock Absorbers

    8/22 YE-GN YE-GN YE-GN GN-BU GN-BU GN-BU C1:2 C1:1 YE-BU YE-BU YE-BU 74/511 74/525 3/225 74/503 YE-RD YE-RD C1:24 C1:26 C1:11 GN-BK GN-BK GY-OG C1:29 GY-OG C1:3 YE-BK YE-BK C1:21 VT-OG VT-OG 31/67 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 172: Group 83 Doors And Openings Central Locking, Front Doors, Lhd

    C1:15 C1:13 C1:13 BK-VT BK-VT BK-GN 73/5037 GN-VT GN-BK BK-GN BK-GN C1:9 KEYLESS KEYLESS C1:21 73/5024 C1:21 C1:10 C1:7 C1:9 C1:7 C1:10 BK-GN 73/5023 73/5035 6/55 6/36 GROUND GROUND G029087 GN-BK 31/15 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 173: Central Locking, Front Doors, Rhd

    C1:13 BK-GN BK-GN 73/5019 GN-WH C1:20 BK-VT BK-VT GN-VT GN-WH Au C1:9 KEYLESS KEYLESS GN-BK C1:21 73/5024 C1:21 C1:10 C1:7 C1:9 C1:7 C1:10 73/5023 73/5035 6/55 6/36 GROUND GROUND BK-GN G029088 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 174: Central Locking, Rear Doors

    74/510 GN-WH GN-WH RD-BU RD-BU RD-GN BK-GN BK-GN KEYLESS BK-VT BK-VT KEYLESS 73/5036 BK-VT BK-GN 73/5025 73/5023 73/5035 6/57 3 10 4 6/56 4 10 3 1 GROUND GROUND G029089 VT-RD 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 175: Central Locking, Trunk Lid V70

    C2:5 C2:1 GN-OG GN-OG 6/149 C4:3 C2:1 GN-WH C2:8 GN-BU 74/602 C3:3 GN-OG C5:18 73/5044 GN-BU 3/291 GY-BN GY-BN BU-WH 74/603 BU-BK 3/78 3/35 10/3 10/25 74/602 BU-BK CL-SW BK-OG 31/47 31/10 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 176: Central Locking, Trunk Lid S80

    Central locking, trunk lid S80 15/31 11A/1 11A/2 11B/23 74/411 4/56 C5:1 C5:2 3/111 C3:52 GN-VT 73/4016 K6-B 73/4017 3/173 C3:32 GN-YE BK-WH 73/4012 BK-OG 73/5105 74/601 3/35 10/3 BU-BK 73/5038 31/47 31/10 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 177: Central Locking, Fuel Filler Flap

    Group 83 Doors and openings Central locking, fuel filler flap 15/31 11A/1 11A/2 11B/23 4/56 C5:1 C5:2 74/411 C2:65 BK-GN BK-VT C2:67 C3:52 3/111 6/37 73/4017 73/4016 73/5033 31/48 31/7 31/84 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 178: Signal Receiver, Central Locking

    Group 83 Doors and openings Signal receiver, central locking 15/31 11A/1 11A/2 4/56 C5:1 C5:2 C2:17 C4:16 C4:4 C2:40 74/412 4/119.2 GY-BN BK-WH 73/4012 RD-BN 31/10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 179: Front Door Power Windows, Lhd

    C1:22 C1:11 C1:18 C1:20 C1:2 C1:2 C1:13 BK-GN KEYLESS C1:12 C1:1 C1:6 C1:17 C1:5 C1:16 C1:12 C1:1 C1:6 C1:17 C1:5 C1:16 73/5024 6/60 6/58 74/507 74/508 3/176 GN-WH 73/5023 73/5035 BU-WH BK-VT 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 180: Front Door Power Windows, Rhd

    C1:22 C1:11 C1:18 C2:15 C2:3 C1:13 C1:2 C1:20 C1:13 C2:3 C2:15 C1:12 C1:1 C1:6 C1:17 C1:5 C1:16 C1:12 C1:1 C1:6 C1:17 C1:5 C1:16 74/507 74/508 6/60 6/58 73/5023 73/5035 3/176 GN-WH BK-GN BU-WH 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 181: Rear Door Power Windows

    Group 83 Doors and openings Rear door power windows 15/31 11A/1 11A/3 74/504B 73/5075 15/32 3/19 11D/A3 11D/A4 3/21 RD-BU 74/509 74/510 3/129 3/128 KEYLESS KEYLESS 73/5025 73/5036 6/61 6/59 74/509 74/510 73/5023 73/5035 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 182: Power Sunroof

    C3:75 C4:14 C4:3 F 31 3/117 C3:7 C3:11 C3:6 C3:5 C3:8 C1:5 BU-BK C1:4 BK-WH 73/4014 73/4031 C2:3 YE-OG 10/22 BU-RD C2:2 VT-BN C2:1 BK-BU 4/33 74/414 RD-BN BK-WH BK-WH 73/4012 BK-WH 31/10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 183: Group 84 Exterior Decorative Elements Etc

    3/126 C1:20 C1:2 C1:13 C2:3 C2:15 C1:20 C1:2 C1:13 C2:3 C2:15 74/508 74/507 6/63 6/62 10 1 MEM Y MEM Y MEM X MEM X 73/5035 73/5023 3/176 GN-WH BU-WH BK-VT 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 184: Power Door Mirrors, Rhd

    3/126 C1:13 C1:2 C1:20 C2:15 C2:3 C1:13 C1:2 C1:20 C2:3 C2:15 74/507 74/508 6/62 6/63 10 1 MEM Y MEM Y MEM X MEM X 73/5035 73/5023 3/176 GN-WH BK-GN BU-WH 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 185: Heated Door Mirrors, Lhd

    73/5024 GN-WH KEYLESS BK-GN 73/5019 3/127 3/126 C1:13 C2:3 C2:15 C1:20 C1:20 C1:2 C1:2 C1:13 C2:3 C2:15 C2:23 C2:10 C2:23 C2:10 74/508 74/507 6/62 6/63 73/5035 73/5023 3/176 GN-WH BU-WH BK-VT 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 186: Heated Door Mirrors, Rhd

    BK-VT KEYLESS GN-WH BK-VT 73/5019 73/5024 3/127 3/126 C1:13 C1:2 C1:20 C2:3 C1:13 C1:2 C1:20 C2:3 C2:15 C2:23 C2:10 C2:23 C2:10 74/507 74/508 6/62 6/63 73/5035 73/5023 3/176 GN-WH BK-GN BU-WH 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 187: Blind Spot Information System Lhd

    KEYLESS GN-WH 73/5019 3/126 3/127 C1:13 C2:3 C2:15 C1:20 C1:20 C1:2 C1:2 C1:13 C2:3 C2:15 C2:23 C2:4 C1:3 C2:23 C2:4 C1:3 74/508 74/507 6/62 6/63 73/5035 73/5023 3/176 GN-WH BU-WH BK-VT 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 188: Blind Spot Information System Rhd

    KEYLESS 73/5019 73/5024 3/127 3/126 C1:13 C1:2 C1:20 C2:15 C2:3 C1:13 C1:2 C1:20 C2:3 C2:15 C2:23 C2:4 C1:3 C2:23 C2:4 C1:3 74/507 74/508 6/62 6/63 73/5035 73/5023 3/176 GN-WH BK-GN BU-WH 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 189: Heated Rear Window

    Group 84 Exterior decorative elements, etc. Heated rear window 15/31 11A/1 74/504B 73/5075 15/32 C°/F° 2/82 C1:10 C1:8 4/56 C2:26 YE-RD C1:49 C5:2 C1:50 C5:1 GY-RD GY-RD 74/602 74/602 GY-RD BK-OG 73/6001 16/141 73/5105 31/47 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 190: Group 85 Interior Equipment

    31 S C2:12 WH-BU 6/19 C1:2 C2:4 GY-RD CAN + WH-BK C2:3 73/5 BU-RD CAN - C2:7 C2:11 3/26 6/18 C1:4 WH-BK 73/6 C2:9 C2:13 6/17 WH-BK C1:5 RD-BK C2:10 BK-YE C2:14 BU-BK 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 191: Power Driver's Seat With Memory Function, Rhd

    31 S C2:9 WH-BU 6/19 C2:4 GY-RD WH-BK CAN + 73/5 C1:6 C2:3 BU-RD CAN - C2:14 C2:10 3/26 6/18 WH-BK 73/6 C1:4 C2:12 C2:8 6/17 WH-BK C1:3 RD-BK C2:11 BK-YE C2:7 BU-BK 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 192: Power Passenger Seat, Lhd

    C5:2 3/27 RD-BK 6/65 K10-A WH-BK DOWN 6/66 WH-BK 11D/B9 DOWN 6/20 WH-BK FORWARD BACK OG-BU 6/64 C2:56 WH-BK FORWARD STOP LOGIC BACK 74/31 BU-WH EXT. X RD-WH 73/5044 RD-BK BK-GN 73/5023 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 193: Power Passenger Seat, Rhd

    C5:2 3/27 RD-BK K10-A 6/65 WH-BK DOWN 6/66 WH-BK DOWN 11D/B9 6/20 WH-BK FORWARD BACK OG-BU 6/64 C2:56 WH-BK FORWARD STOP LOGIC BACK 74/31 EXT. X RD-WH BU-WH 73/5044 RD-BK BK-VT 73/5035 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 194: Heated Power Front Seats With Fans

    73/2 BK-BU BK-BU BK-BU BK-BU BU-RD BU-RD 9/18 WH-BU 9/19 WH-BU 7/110 7/111 9/16 9/17 RD-BK RD-BK RD-BK RD-BK 74/31 74/30 BK-BU BK-BU BK-BU BK-BU 73/5023 73/5035 73/5023 73/5035 31/15 31/6 31/15 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 195: Heated Power Front Seats Without Fans

    74/417 2/88 74/409 C2:45 VT-OG WH-GN BN-VT WH-GN BN-VT 74/31 74/30 9/12 9/13 RD-BK RD-BK 9/16 9/17 BK-BU BK-BU 7/110 7/111 9/18 9/19 74/30 74/31 73/5023 73/5035 73/5023 73/5035 31/15 31/15 31/6 31/6 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 196: Electrically Heated Rear Seat

    11D/B5 11D/B7 2/88 C2:45 C3:68 74/403 9/14 3/65 9/15 BU-RD GN-BU GN-BU 9/11 GY-VT GY-VT BK-VT 73/5026 7/112 7/113 GN-BU GN-BU GY-VT GY-VT 9/10 74/502 73/5030 73/5029 73/5035 73/5023 31/65 31/67 31/6 31/15 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 197: Massage Seats

    Group 85 Interior equipment Massage seats 15/31 11A/4 74/504B 73/5040 15/32 4/56 2/88 C2:45 11D/B1 4/131 4/133 6/169 6/170 YE-BK OG-BK 31/TRM TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 198: Group 87 Climate Control System

    Group 87 Climate control system Climate control system PTC-element 15/31 11A/7 11A/1 11A/2 2/31 11B/17 4/56 C5:1 C5:2 C1:65 C1:45 9/42 C2:1 C1:1 BU-RD C3:68 C1:2 C3:39 BU-GN C1:3 C3:1 73/4016 31/83 31/1 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 199: Climate Control System, 4-Cyl. 1:2

    C1:1 C1:7 BN-VT WH-GN C1:12 C°/F° C1:8 VT-BN C1:5 C1:10 73/4028 C1:14 YE-VT YE-RD YE-VT WH-GN C1:13 73/4018 4/31 C1:16 74/401 VT-BK VT-BK C1:2 6/28 7/10 73/4016 C1:4 BU-WH C1:6 GN-BU 31/10 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 200 Climate control system, 4-Cyl. 2:2 4/56 15/31 2/193 11B/26 C1:48 BU-BK VT-GN 74/411 3/112 6/96 74/417 BU-BK 74/401 73/4010 BN-VT BN-VT WH-GN 6/102 73/4012 BK-WH 6/103 6/48 VT-BN 6/95 YE-VT WH-GN 7/159 7/41 31/10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 201: Climate Control System, 5-, 6- & 8-Cyl. 1:2

    73/4028 C1:1 YE-RD C1:7 BN-VT WH-GN C1:12 C°/F° VT-BN 4/31 C1:5 YE-VT C1:14 74/401 VT-BK VT-BK C1:2 YE-VT 6/28 WH-GN C1:13 73/4018 C1:8 C1:16 C1:10 73/4016 7/10 C1:4 BU-WH C1:6 GN-BU 31/83 31/10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 202 Climate control system, 5-, 6- & 8-Cyl. 2:2 15/31 4/56 2/193 11B/26 C1:48 BU-BK VT-GN 74/411 3/112 6/96 74/417 BU-BK 74/401 73/4010 BN-VT BN-VT WH-GN 6/102 73/4012 BK-WH 6/103 6/48 VT-BN 6/95 YE-VT WH-GN 7/159 7/41 31/10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 203: Climate Control System 5-Cyl. Diesel 1:2

    73/4028 C1:1 YE-RD C1:7 BN-VT C1:12 C°/F° WH-GN 4/31 C1:5 BN-VT C1:14 YE-VT 74/401 YE-VT C1:2 VT-BK VT-BK 6/28 C1:13 WH-GN 73/4018 C1:8 C1:16 C1:10 73/4016 7/10 C1:4 BU-WH C1:6 GN-BU 31/10 31/83 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 204 Climate control system 5-Cyl. Diesel 2:2 15/31 4/56 2/193 11B/26 C1:48 BU-BK VT-GN 74/411 3/112 6/96 74/417 BU-BK 74/401 73/4010 BN-VT BN-VT WH-GN 6/102 73/4012 BK-WH 6/103 6/48 VT-BN 6/95 YE-VT WH-GN 7/159 7/41 31/10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 205: Parking Heater, Auxiliary Heater

    VT-OG GY-OG 73/3019 YE-VT 74/9 C1:6 C1:11 C1:3 74/9 C1:7 YE-RD C1:10 WH-VT C1:9 GN-OG 74/504 C1:2 6/73 74/512 9/30 6/35 FUEL COOLANT GLOW PREHEAT TEMP OVERHEAT C1:4 74/9 74/512 73/3034 31/XX15 31/68 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 206: Parking Heater, Remote Start

    FUSE 1A 74/9 C1:6 C1:11 C1:3 74/9 74X/9 C1:7 YE-RD C1:10 WH-VT C1:9 GN-OG 74/504 C1:2 6/73 74/512 9/30 4/106 FUEL COOLANT GLOW PREHEAT TEMP OVERHEAT 6/35 C1:4 74/9 74X/9 74/512 73/3034 31/XX15 31/68 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 207: Refrigeration Box Rear Seat

    Group 87 Climate control system Refrigeration box rear seat 15/31 11A/4 11A/3 74/504B 74/504B 73/5040 73/5075 15/32 4/56 2/88 11D/A6 C2:45 11D/B1 BK-GN 17X/19 74/1500 BK-GN BU-RD 2/141 17/19 74/1501 9/24 31/TRM 31/48 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 208: Group 88 Internal Equipment

    Rear-view mirror with automatic dimming 15/31 11A/2 11A/1 11B/27 2/31 11B/17 4/56 C5:2 C5:1 C1:45 C1:65 C°/F° C4:18 C1:7 BN-VT 74/401 8/48 BU-BK 74/414 BN-VT BN-VT 73/4010 BK-WH BK-WH BK-WH 73/4012 73/4014 31/10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 209: Supplemental Restraint System 1:2

    8/61 C2:36 C2:2 C2:35 C2:1 OG-BK 73/4014 C1:2 73/4016 73/4017 7/179 74/411 7/178 C2:75 C2:50 WH-BU WH-BU WH-GN WH-GN C2:74 C2:49 GY-BN GY-BN YE-RD YE-RD 8/99 74/414 C2:40 C2:39 YE-BK 73/4012 31/83 31/10 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 210 C1:72 YE-BU YE-VT C1:30 C1:73 VT-WH YE-GN C1:29 BU-GY RD-GN RD-GN C1:28 BK-BU C1:27 7/175:2 12 2 6 7 8 2 1 3 74/409 BK-BU BK-GN BK-GN 73/5029 31/67 BK-GN 73/5030 BK-OG 31/65 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 211: Electrically Adjustable Head Restraint

    Group 88 Internal equipment Electrically adjustable head restraint 15/31 3/113 11A/3 11A/2 11A/1 C°/F° C1:10 C1:8 4/56 C5:2 C5:1 C1:49 74/504B C1:50 73/5075 C2:42 RD-GY RD-GY 15/32 2/75 73/5050 8/59 8/60 73/5030 73/5029 31/65 31/67 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 212: Remote Garage Door Opener

    Group 88 Internal equipment Remote garage door opener 15/31 11A/1 11A/2 10/114 LHD 10/115 RHD 4/76 4/56 C5:1 C5:2 K10-A 73/4014 C3:67 BU-WH 73/4019 74/414 74/412 73/4020 BU-WH 73/4012 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 213: Index 1:2

    Emission control 6-Cyl..........79 Memory function driver’s seat ......190 Emission control, 4-Cyl..........65 Midspeed CAN data communication, LHD ....47 Emission control, 5-Cyl. Turbo ........66 Midspeed CAN data communication, RHD ....48 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 214: Table Of Contents

    ..........160 Wiper/washer rear window ........128 Rear-view mirror with automatic dimming ....208 Wiring and fuses, Group 37 ........137 Refrigeration box rear seat ........207 Relays in cargo compartment ........29 TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

  • Page 215: List Of Components 1:6

    Contact, passenger seat belt buckle 4/33 Sunroof control module 3/111 Light Switch Module (LSM) 4/46 Engine Control Module (ECM) 3/112 Climate control system 4/52 Power Seat Module (PSM) 3/113 Rear adjustable head restraint relay TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 216 Additive tank with pump and level sensor 6/169 Left pump back massage 6/35 Fuel pump, auxiliary heater 6/170 Right pump back massage 6/36 Lock motor, central locking, LH front door 6/37 Lock motor, fuel filler cover TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 217 Rear oxygen sensor, bank 2, 8-Cyl. 7/203 Forward-aimed radar (FLR) 7/104 Rear oxygen sensor, bank 2, 6-Cyl. 7/204- 7/104 Rear oxygen sensor, bank 1, 8-Cyl. 7/207 Front parking assistance sensor 7/108 Left-hand rear side impact sensor TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 218 Control valve, fuel volume 9/32 PTC resistor, crankcase ventilation 8/81 Solenoid, variable valve timing, exhaust 9/38 Electrically heated fuel filter 8/82 Solenoid, variable turbo geometry 9/39 Heating element camera 8/84 Switch, vacuum pump 9/42 PTC-element TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 219 Center dashboard speaker 10/127 Lighting, cargo compartment, left-hand side 16/35 Siren Control Module (SCM) 10/128 Lighting, cargo compartment, right-hand side 16/36 TV receiver 10/148 Lighting, left front door mirror 16/45 Portable navigation system TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...
  • Page 220 7-pin outlet, tow hitch cable harness 74X/401 Connector interface, original car 17/39 13-pin outlet, tow hitch cable harness 74X/402 Connector interface, original car 17/42 USB-port 74X/414 Connector interface, original car 17/45 Alcolock outlet TP 39152201 V70(08-), XC70(08-) & S80(07-) 2010...

This manual is also suitable for:

Xc70S802010 v702010 xc702010 s80V70 wiring

Table of Contents

Save PDF
